1. Beyond the basics
   Espresso
   Beyond the basics
   @inyaki_mwc


   View Slide

2. View Slide

3. onView(withId(R.id.button_take_photo))

   .perform(click())

   .check(matches(isDisplayed()));



   View Slide

4. onView(withId(R.id.button_take_photo))

   .perform(click())

   .check(matches(isDisplayed()));



   View Slide

5. Structure


   View Slide

6. public static ViewInteraction onView(final Matcher viewMatcher) {

   return BASE.plus(new ViewInteractionModule(viewMatcher)).viewInteraction();

   }


   View Slide

7. BaseLayerComponent


   View Slide

8. BaseLayerModule
   UiControllerModule
   BaseLayerComponent


   View Slide

9. BaseLayerModule ActivityLifeCycleMonitor
   Context
   Looper
   AsyncTaskPoolMonitor
   Executor
   ActivityRootLister
   EventInjector
   FailureHandler
   UiControllerModule
   Recycler
   BaseLayerComponent
   UiController


   View Slide

10. BaseLayerModule ActivityLifeCycleMonitor
    Context
    Looper
    AsyncTaskPoolMonitor
    Executor
    ActivityRootLister
    EventInjector
    FailureHandler
    UiControllerModule
    Recycler
    BaseLayerComponent
    UiController


    View Slide

11. ActivityLifeCycleMonitor


    View Slide

12. ActivityLifeCycleMonitor
    PRE_ON_CREATE,
    CREATED,
    STARTED,
    RESUMED,
    PAUSED,
    STOPPED,
    RESTARTED,
    DESTROYED


    View Slide

13. ActivityLifeCycleMonitor
    MonitoringInstrumentation


    View Slide

14. ActivityLifeCycleMonitor
    AndroidJUnitRunner
    MonitoringInstrumentation
    ExposedInstrumentationApi
    Instrumentation
    MonitoringInstrumentation


    View Slide

15. ActivityLifeCycleMonitor
    MonitoringInstrumentation
    mLifecycleMonitor.signalLifecycleChange(Stage.DESTROYED, activity);


    View Slide

16. BaseLayerModule ActivityLifeCycleMonitor
    Context
    Looper
    AsyncTaskPoolMonitor
    Executor
    ActivityRootLister
    EventInjector
    FailureHandler
    UiControllerModule
    Recycler
    BaseLayerComponent
    UiController


    View Slide

17. ActivityRootLister


    View Slide

18. ActivityRootLister
    WindowManagerGlobal


    View Slide

19. ActivityRootLister
    WindowManagerGlobal
    mViews
    mParams
    new Root.Builder()
    .withDecorView(views.get(i))
    .withWindowLayoutParams(params.get(i))
    .build());


    View Slide

20. BaseLayerModule ActivityLifeCycleMonitor
    Context
    Looper
    AsyncTaskPoolMonitor
    Executor
    ActivityRootLister
    EventInjector
    FailureHandler
    UiControllerModule
    Recycler
    BaseLayerComponent
    UiController


    View Slide

21. AsyncTaskPoolMonitor


    View Slide

22. @CompatAsyncTask
    @SdkAsyncTask
    AsyncTaskPoolMonitor


    View Slide

23. boolean isIdleNow() {
    if (!pool.getQueue().isEmpty()) {
    return false;
    } else {
    int activeCount = pool.getActiveCount();
    if (0 != activeCount) {
    if (monitor.get() == null) {
    activeCount = activeCount - activeBarrierChecks.get();
    }
    }
    return 0 == activeCount;
    }
    }
    AsyncTaskPoolMonitor


    View Slide

24. private final ThreadPoolExecutor pool;
    AsyncTaskPoolMonitor


    View Slide

25. private final ThreadPoolExecutor pool;
    MODERN_ASYNC_TASK_CLASS_NAME = “android.support.v4.content.ModernAsyncTask”
    MODERN_ASYNC_TASK_FIELD_NAME = "THREAD_POOL_EXECUTOR";
    AsyncTaskPoolMonitor
    ThreadPoolExtractor


    View Slide

26. BaseLayerModule ActivityLifeCycleMonitor
    Context
    Looper
    AsyncTaskPoolMonitor
    Executor
    ActivityRootLister
    EventInjector
    FailureHandler
    UiControllerModule
    Recycler
    BaseLayerComponent
    UiController


    View Slide

27. EventInjector


    View Slide

28. EventInjector
    EventInjectionStrategy


    View Slide

29. EventInjector
    EventInjectionStrategy
    InputManager
    injectInputEventMethod.invoke(instanceInputManagerObject,motionEvent,motionEventMode);


    View Slide

30. BaseLayerModule ActivityLifeCycleMonitor
    Context
    Looper
    AsyncTaskPoolMonitor
    Executor
    ActivityRootLister
    EventInjector
    FailureHandler
    UiControllerModule
    Recycler
    BaseLayerComponent
    UiController


    View Slide

31. UiController


    View Slide

32. UiController
    boolean injectMotionEvent(MotionEvent event) throws InjectEventSecurityException;
    boolean injectKeyEvent(KeyEvent event) throws InjectEventSecurityException;
    boolean injectString(String str) throws InjectEventSecurityException;


    View Slide

33. UiController
    boolean injectMotionEvent(MotionEvent event) throws InjectEventSecurityException;
    boolean injectKeyEvent(KeyEvent event) throws InjectEventSecurityException;
    boolean injectString(String str) throws InjectEventSecurityException;
    EventInjector AsyncTaskMonitor IdlingResourceRegistry


    View Slide

34. UiController
    boolean injectMotionEvent(MotionEvent event) throws InjectEventSecurityException;
    boolean injectKeyEvent(KeyEvent event) throws InjectEventSecurityException;
    boolean injectString(String str) throws InjectEventSecurityException;
    EventInjector AsyncTaskMonitor IdlingResourceRegistry
    boolean allResourcesAreIdle()


    View Slide

35. ViewInteractionComponent


    View Slide

36. ViewInteractionModule Matcher
    ViewFinder
    Matcher
    View
    ViewInteractionComponent


    View Slide

37. ViewInteractionModule Matcher
    ViewFinder
    Matcher
    View
    ViewInteractionComponent
    throw new AmbiguousViewMatcherException
    throw new NoMatchingViewException


    View Slide

38. ViewInteractionModule Matcher
    ViewFinder
    Matcher
    View
    ViewInteractionComponent
    public static ViewInteraction onView(final Matcher viewMatcher) {
    return BASE.plus(new ViewInteractionModule(viewMatcher)).viewInteraction();
    }


    View Slide

39. ViewInteraction


    View Slide

40. ViewInteraction
    public ViewInteraction perform(final ViewAction... viewActions)
    public ViewInteraction check(final ViewAssertion viewAssert)


    View Slide

41. Synchronization


    View Slide

42.

    perform(click());



    MainActivityTest



    View Slide

43.

    perform(click());

    new GeneralClickAction(Tap.SINGLE, VISIBLE_CENTER, Press.FINGER));


    MainActivityTest



    ViewActions



    View Slide

44.

    perform(click());

    new GeneralClickAction(Tap.SINGLE, VISIBLE_CENTER, Press.FINGER));


    MotionEvents.sendDown(uiController, coordinates, precision);



    MainActivityTest



    ViewActions



    Tapper



    View Slide

45.

    perform(click());

    new GeneralClickAction(Tap.SINGLE, VISIBLE_CENTER, Press.FINGER));


    MotionEvents.sendDown(uiController, coordinates, precision);



    uiController.injectMotionEvent(motionEvent);



    MainActivityTest



    ViewActions



    Tapper



    MotionEvents



    View Slide

46. InjectKeyEvent


    View Slide

47. InjectKeyEvent
    loopMainThreadUntilIdle loopUntil
    Asynctask
    Idling


    View Slide

48. InjectKeyEvent
    loopMainThreadUntilIdle loopUntil
    Asynctask
    Idling
    keyEventExecutor
    submit(event)
    loopUntil KeyInject


    View Slide

49. @Override

    public void loopMainThreadUntilIdle() {

    do {

    if (!asyncTaskMonitor.isIdleNow()) {

    asyncTaskMonitor.notifyWhenIdle(…);

    condChecks.add(IdleCondition.ASYNC_TASKS_HAVE_IDLED);

    }



    if (!compatTaskMonitor.isIdleNow()) {

    compatTaskMonitor.notifyWhenIdle(…);

    condChecks.add(IdleCondition.COMPAT_TASKS_HAVE_IDLED);

    }



    if (!idlingResourceRegistry.allResourcesAreIdle()) {

    idlingResourceRegistry.notifyWhenAllResourcesAreIdle(…);

    condChecks.add(IdleCondition.DYNAMIC_TASKS_HAVE_IDLED);

    }



    loopUntil(condChecks);

    } while (!sIdleNow());
    }


    View Slide

50. @Override

    public void loopMainThreadUntilIdle() {

    do {

    if (!asyncTaskMonitor.isIdleNow()) {

    asyncTaskMonitor.notifyWhenIdle(…);

    condChecks.add(IdleCondition.ASYNC_TASKS_HAVE_IDLED);

    }



    if (!compatTaskMonitor.isIdleNow()) {

    compatTaskMonitor.notifyWhenIdle(…);

    condChecks.add(IdleCondition.COMPAT_TASKS_HAVE_IDLED);

    }



    if (!idlingResourceRegistry.allResourcesAreIdle()) {

    idlingResourceRegistry.notifyWhenAllResourcesAreIdle(…);

    condChecks.add(IdleCondition.DYNAMIC_TASKS_HAVE_IDLED);

    }



    loopUntil(condChecks);
    } while (!sIdleNow());
    }


    View Slide

51. View Slide

52. View Slide

53. View Slide

54. View Slide

55. View Slide

56. abstract class WrappingES(delegate: ExecutorService) : ExecutorService {
    val delegate: ExecutorService = checkNotNull(delegate)
    abstract fun wrapTask(callable: Callable): Callable
    fun wrapTask(command: Runnable): Runnable {
    val wrapped = wrapTask(Executors.callable(command, null))
    return Runnable {
    try {
    wrapped.call()
    } catch (e: Exception) {
    throw RuntimeException(e)
    }
    }
    }


    View Slide

57. abstract class WrappingES(delegate: ExecutorService) : ExecutorService {
    val delegate: ExecutorService = checkNotNull(delegate)
    abstract fun wrapTask(callable: Callable): Callable
    fun wrapTask(command: Runnable): Runnable {
    val wrapped = wrapTask(Executors.callable(command, null))
    return Runnable {
    try {
    wrapped.call()
    } catch (e: Exception) {
    throw RuntimeException(e)
    }
    }
    }


    View Slide

58. abstract class WrappingES(delegate: ExecutorService) : ExecutorService {
    val delegate: ExecutorService = checkNotNull(delegate)
    abstract fun wrapTask(callable: Callable): Callable
    fun wrapTask(command: Runnable): Runnable {
    val wrapped = wrapTask(Executors.callable(command, null))
    return Runnable {
    try {
    wrapped.call()
    } catch (e: Exception) {
    throw RuntimeException(e)
    }
    }
    }


    View Slide

59. override fun execute(command: Runnable) {
    delegate.execute(wrapTask(command))
    }
    override fun submit(task: Callable): Future {
    return delegate.submit(wrapTask(checkNotNull(task)))
    }
    override fun submit(task: Runnable): Future<*> {
    return delegate.submit(wrapTask(task))
    }
    override fun submit(task: Runnable, result: T): Future {
    return delegate.submit(wrapTask(task), result)
    }


    View Slide

60. class IdlingResourceExecutorService(delegate: ExecutorService,
    val mIdlingResource: CountingIdlingResource)
    : GuavaWrappingExecutorService(delegate) {
    override fun wrapTask(callable: Callable): Callable {
    return WrappedCallable(callable)
    }
    private inner class WrappedCallable(private val delegate: Callable) : Callable
    {
    @Throws(Exception::class)
    override fun call(): T {
    mIdlingResource.increment()
    val call: T
    try {
    call = delegate.call()
    } finally {
    mIdlingResource.decrement()
    }
    return call
    }
    }
    }


    }


    View Slide

61. class IdlingResourceExecutorService(delegate: ExecutorService,
    val mIdlingResource: CountingIdlingResource)
    : GuavaWrappingExecutorService(delegate) {
    override fun wrapTask(callable: Callable): Callable {
    return WrappedCallable(callable)
    }
    private inner class WrappedCallable(private val delegate: Callable) : Callable {
    @Throws(Exception::class)
    override fun call(): T {
    mIdlingResource.increment()
    val call: T
    try {
    call = delegate.call()
    } finally {
    mIdlingResource.decrement()
    }
    return call
    }
    }
    }


    }


    View Slide

62. class IdlingResourceExecutorService(delegate: ExecutorService,
    val mIdlingResource: CountingIdlingResource)
    : GuavaWrappingExecutorService(delegate) {
    override fun wrapTask(callable: Callable): Callable {
    return WrappedCallable(callable)
    }
    inner class WrappedCallable(val delegate: Callable) : Callable {
    @Throws(Exception::class)
    override fun call(): T {
    mIdlingResource.increment()
    val call: T
    try {
    call = delegate.call()
    } finally {
    mIdlingResource.decrement()
    }
    return call
    }
    }
    }


    }


    View Slide

63. View Slide

64. public class RxSchedulerHook extends RxJavaSchedulersHook {



    private Scheduler customScheduler;

    private CountingIdlingResource idling;

    private static RxSchedulerHook sInstance;

    public RxSchedulerHook(CountingIdlingResource countingIdlingResource) {

    FailedTest watcher = new FailedTest();

    idling = countingIdlingResource;

    customScheduler = new Scheduler() {

    @Override public Scheduler.Worker createWorker() {

    return new CustomWorker();

    }

    };

    }



    View Slide

65. @Override public Subscription schedule(final Action0 action,
    final long delayTime, TimeUnit unit) {

    return super.schedule(new Action0() {

    @Override public void call() {



    action.call();

    }

    }, delayTime, unit);

    }



    @Override public Subscription schedule(final Action0 action) {

    return super.schedule(new Action0() {

    @Override public void call() {

    idling.increment();

    try {

    action.call();

    } finally {

    idling.decrement();

    }

    }

    });

    }


    View Slide

66. RxJavaPlugins.getInstance().registerSchedulersHook(RxSchedulerHook.get());



    View Slide

67. RxIdler


    View Slide

68. RxIdler
    https://github.com/square/RxIdler


    View Slide

69. Rules


    View Slide

70. @Rule
    public ActivityTestRule activityTestRule = new ActivityTestRule<>(Main){

    @Override

    protected void beforeActivityLaunched() {

    super.beforeActivityLaunched();

    }



    @Override

    protected void afterActivityLaunched() {

    super.afterActivityLaunched();

    }



    @Override

    protected void afterActivityFinished() {

    super.afterActivityFinished();

    }

    };


    View Slide

71. @Rule
    public ActivityTestRule activityTestRule = new ActivityTestRule<>(Main){

    @Override

    protected void beforeActivityLaunched() {

    super.beforeActivityLaunched();

    }



    @Override

    protected void afterActivityLaunched() {

    super.afterActivityLaunched();

    }



    @Override

    protected void afterActivityFinished() {

    super.afterActivityFinished();

    }

    };


    View Slide

72. @Rule
    public IntentTestRule activityTestRule = new IntentTestRule<>(Main)


    View Slide

73. @Rule
    public IntentTestRule activityTestRule = new IntentTestRule<>(Main)




    public IntentsTestRule(Class activityClass, boolean initialTouchMode,

    boolean launchActivity) {

    super(activityClass, initialTouchMode, launchActivity);

    }



    @Override

    protected void afterActivityLaunched() {

    Intents.init();

    super.afterActivityLaunched();

    }



    @Override

    protected void afterActivityFinished() {

    super.afterActivityFinished();

    Intents.release();

    }







    View Slide

74. public interface TestRule {

    Statement apply(Statement base, Description description);

    }


    View Slide

75. public interface TestRule {

    Statement apply(Statement base, Description description);

    }
    public class UiThreadTestRule implements TestRule {

    private static final String LOG_TAG = "UiThreadTestRule";



    @Override

    public Statement apply(final Statement base, Description description) {

    return new UiThreadStatement(base, shouldRunOnUiThread(description));

    }



    protected boolean shouldRunOnUiThread(Description description) {

    return description.getAnnotation(UiThreadTest.class) != null;

    }
    }


    View Slide

76. private class ActivityStatement extends Statement {



    private final Statement mBase;



    public ActivityStatement(Statement base) {

    mBase = base;

    }



    @Override

    public void evaluate() throws Throwable {

    try {

    if (mLaunchActivity) {

    act = launchActivity(getActivityIntent());

    }

    mBase.evaluate();

    } finally {

    finishActivity();

    }

    }

    }


    View Slide

77. public class TraceTestRule implements TestRule {



    private Trace trace;



    @Override

    public Statement apply(final Statement base, Description description) {

    return new Statement() {

    @Override

    public void evaluate() throws Throwable {

    try {

    trace.start();

    base.evaluate();

    } finally {

    trace.end();

    }

    }

    };

    }

    }


    View Slide

78. public class TraceTestRule implements TestRule {



    private Trace trace;



    @Override

    public Statement apply(final Statement base, Description description) {

    return new Statement() {

    @Override

    public void evaluate() throws Throwable {

    try {

    trace.start();

    base.evaluate();

    } finally {

    trace.end();

    }

    }

    };

    }

    }
    @Rule

    public TraceTestRule traceTestRule = new TraceTestRule(getTargetContext());



    View Slide

79. public abstract class TestWatcher implements TestRule


    View Slide

80. return new Statement() {

    @Override

    public void evaluate() throws Throwable {

    List errors = new ArrayList();



    startingQuietly(description, errors);

    try {

    base.evaluate();

    succeededQuietly(description, errors);

    } catch (AssumptionViolatedException e) {

    errors.add(e);

    skippedQuietly(e, description, errors);

    } catch (Throwable e) {

    errors.add(e);

    failedQuietly(e, description, errors);

    } finally {

    finishedQuietly(description, errors);

    }



    MultipleFailureException.assertEmpty(errors);

    }

    };
    public abstract class TestWatcher implements TestRule


    View Slide

81. return new Statement() {

    @Override

    public void evaluate() throws Throwable {

    List errors = new ArrayList();



    startingQuietly(description, errors);

    try {

    base.evaluate();

    succeededQuietly(description, errors);

    } catch (AssumptionViolatedException e) {

    errors.add(e);

    skippedQuietly(e, description, errors);

    } catch (Throwable e) {

    errors.add(e);

    failedQuietly(e, description, errors);

    } finally {

    finishedQuietly(description, errors);

    }



    MultipleFailureException.assertEmpty(errors);

    }

    };
    public abstract class TestWatcher implements TestRule


    View Slide

82. public class FailedTest extends TestWatcher {



    public FailedTest() {

    uiAutomation = UiDevice.getInstance();

    }





    @Override

    protected void failed(Throwable e, Description description) {

    super.failed(e, description);

    String fileNameBase = getFileNameWithoutExtension(description);

    saveScreenshot(fileNameBase);

    saveInfo(fileNameBase);

    }



    @Override

    protected void succeeded(Description description) {

    super.succeeded(description);

    }



    @Override

    protected void skipped(AssumptionViolatedException e, Description description) {

    super.skipped(e, description);

    }



    View Slide

83. public class FailedTest extends TestWatcher {



    public FailedTest() {

    uiAutomation = UiDevice.getInstance();

    }





    @Override

    protected void failed(Throwable e, Description description) {

    super.failed(e, description);

    String fileNameBase = getFileNameWithoutExtension(description);

    saveScreenshot(fileNameBase);

    saveInfo(fileNameBase);

    }



    @Override

    protected void succeeded(Description description) {

    super.succeeded(description);

    }



    @Override

    protected void skipped(AssumptionViolatedException e, Description description) {

    super.skipped(e, description);

    }



    View Slide

84. public class FailedTest extends TestWatcher {



    public FailedTest() {

    uiAutomation = UiDevice.getInstance();

    }





    @Override

    protected void failed(Throwable e, Description description) {

    super.failed(e, description);

    String fileNameBase = getFileNameWithoutExtension(description);

    saveScreenshot(fileNameBase);

    saveInfo(fileNameBase);

    }



    @Override

    protected void succeeded(Description description) {

    super.succeeded(description);

    }



    @Override

    protected void skipped(AssumptionViolatedException e, Description description) {

    super.skipped(e, description);

    }



    View Slide

85. public class RuleChain implements TestRule



    View Slide

86. public class RuleChain implements TestRule

    public RuleChain ruleChain = RuleChain.outerRule(new LogRule("outer rule")

    .around(new LogRule("middle around rule")

    .around(new LogRule("inner around rule”))));


    View Slide

87. public class RuleChain implements TestRule

    public RuleChain ruleChain = RuleChain.outerRule(new LogRule("outer rule")

    .around(new LogRule("middle around rule")

    .around(new LogRule("inner around rule”))));
    Starting outer
    Starting middle
    Starting inner
    Finishing inner
    Finishing middle
    Finishing outer


    View Slide

88. public NewActivityTestRule activityRule = new NewActivityTestRule<>(Main.class);





    View Slide

89. public NewActivityTestRule activityRule = new NewActivityTestRule<>(Main.class);





    @Rule

    public RuleChain chain = RuleChain.outerRule(new FailedTest()
    .around(activityRule);



    View Slide

90. public NewActivityTestRule activityRule = new NewActivityTestRule<>(Main.class);





    @Rule

    public RuleChain chain = RuleChain.outerRule(new FailedTest()
    .around(activityRule);



    @Rule

    public RuleChain chain = RuleChain.outerRule(new FailedTest())
    .around(new TraceTestRule())
    .around(activityRule);



    View Slide

91. View Slide

92. What’s next?


    View Slide

93. Android Test Orchestrator


    View Slide

94. Test Apk
    APK
    AndroidJunitRunner
    Android Test Orchestrator


    View Slide

95. Test Apk
    APK
    Orchestrator
    AndroidJunitRunner
    Android Test Orchestrator


    View Slide

96. Test Apk
    APK
    Orchestrator
    AndroidJunitRunner
    Test
    Test
    Test
    Android Test Orchestrator


    View Slide

97. Multiprocess Espresso


    View Slide

98. Espresso
    AndroidJunitRunner
    Multiprocess Espresso


    View Slide

99. Espresso
    AndroidJunitRunner
    Multiprocess Espresso
    Espresso
    AndroidJunitRunner


    View Slide

100. Espresso
     AndroidJunitRunner
     Multiprocess Espresso
     Espresso
     AndroidJunitRunner


     View Slide

101. dependencies {
     androidTestUtil 'com.linkedin.testbutler:test-butler-app:1.3.0@apk'
     }


     View Slide

102. View Slide

103. View Slide

104. @inyaki_mwc
     Thanks


     View Slide
