1. ActionBarCompat Chris Banes, Android Developer Programs Engineer
2. ActionBarCompat What is it? A support library which provides a compatible Action Bar to your application, targeting Android v2.1+ Designed to mirror the Action Bar API found in later platforms, as closely as possible
3. ActionBarCompat Add to project Add dependency to build.gradle: Alternatively, add it as a library project See the Support Library Release Notes for more info dependencies { compile "com.android.support:appcompat-v7:18.0.+" ... }
4. Resources
5. ActionBarCompat Styles You need to use one of the following themes: @style/Theme.AppCompat @style/Theme.AppCompat.Light @style/Theme.AppCompat.Light.DarkActionBar
6. ActionBarCompat Styles If you have the following set in the AndroidManifest.xml: ...becomes: <activity ... android:theme="@android:style/Theme.Holo.Light.DarkActionBar" /> <activity ... android:theme="@style/Theme.AppCompat.Light.DarkActionBar" />
7. ActionBarCompat Styles - Customized More tricky... <style name="Theme.Styled" parent="@android:style/Theme.Holo.Light"> <item name="android:actionBarStyle"> @style/Widget.Styled.ActionBar </item> </style> <style name="Widget.Styled.ActionBar" parent="@android:style/Widget.Holo.Light.ActionBar"> <item name="android:background">@drawable/ab_custom_solid_styled</item> <item name="android:backgroundStacked"> @drawable/ab_custom_stacked_solid_styled </item> <item name="android:backgroundSplit"> @drawable/ab_custom_bottom_solid_styled </item> </style>
8. ActionBarCompat Styles - Customized Converting styles rules Use an AppCompat style as the parent Double-set each attribute, once in the android namespace and again the default namespace
9. ActionBarCompat Styles - Customized Becomes: res/values-v14 res/values <style name="Theme.Styled" parent="@style/Theme.AppCompat.Light">
 <!-- Setting values in the android namespace affects API v14+ -->
 <item name="android:actionBarStyle"> @style/Widget.Styled.ActionBar </item>
 </style> <style name="Theme.Styled" parent="@style/Theme.AppCompat.Light"> <!-- Setting values in the default namespace affects API v7-13 -->
 <item name="actionBarStyle"> @style/Widget.Styled.ActionBar </item>
 </style>
10. ActionBarCompat Menu As with the standard Action Bar, items are added via the menu: <menu xmlns:android="http://schemas.android.com/apk/res/android"> <item android:id="@+id/menu_search" android:title="@string/menu_search" android:actionViewClass="android.widget.SearchView" android:showAsAction="always" /> <!-- Your other items... --> </menu>
11. ActionBarCompat Menu As with the standard Action Bar, items are added via the menu: <menu xmlns:android="http://schemas.android.com/apk/res/android" xmlns:yourapp="http://schemas.android.com/apk/res-auto"> <item android:id="@+id/menu_search" android:title="@string/menu_search" yourapp:actionViewClass="android.support.v7.widget.SearchView" yourapp:showAsAction="always" /> <!-- Your other items... --> </menu>
12. Code
13. ActionBarCompat Activity Activities need to extend from: Provides an API which is very similar to that found in Activity: android.support.v7.app.ActionBarActivity getSupportActionBar() startSupportActionMode()
14. ActionBarCompat Activity How to add items to the Action Bar: @Override
 public boolean onCreateOptionsMenu(Menu menu) {
 // Inflate the menu
 getMenuInflater().inflate(R.menu.main_menu, menu);

 // Find the search item
 MenuItem searchItem = menu.findItem(R.id.menu_search);

 // Retrieve the SearchView
 mSearchView = (SearchView) searchItem.getActionView();

 return super.onCreateOptionsMenu(menu);
 }
15. ActionBarCompat Activity How to add items to the Action Bar: @Override
 public boolean onCreateOptionsMenu(Menu menu) {
 // Inflate the menu
 getMenuInflater().inflate(R.menu.main_menu, menu);

 // Find the search item
 MenuItem searchItem = menu.findItem(R.id.menu_search);

 // Retrieve the SearchView
 mSearchView = (SearchView) MenuItemCompat.getActionView(searchItem);

 return super.onCreateOptionsMenu(menu);
 }
16. ActionBarCompat Fragments Use android.support.v4.Fragment as your base class Call setHasOptionsMenu() during onCreate() Override onCreateOptionsMenu() and onPrepareOptionsMenu()
17. ActionBarCompat Split Action Bar Add meta-data element to each Activity element in AndroidManifest.xml <activity android:name=".YourActivity" android:uiOptions="splitActionBarWhenNarrow"> <intent-filter> ... </intent-filter> <meta-data android:name="android.support.UI_OPTIONS" android:value="splitActionBarWhenNarrow" /> </activity> API v14+ API v7+
18. Extras
19. ActionBarCompat SearchView Backport available: android.support.v7.widget.SearchView Be careful with: setSearchableInfo(SearchableInfo) SearchableInfo was added in API v8
20. ActionBarCompat ShareActionProvider Backport available: android.support.v7.widget.ShareActionProvider <menu xmlns:android="http://schemas.android.com/apk/res/android" xmlns:yourapp="http://schemas.android.com/apk/res-auto"> <item android:id="@+id/menu_share" android:title="@string/menu_share" yourapp:actionProviderClass="android.support.v7.widget.ShareActionProvider" yourapp:showAsAction="always" /> </menu>
21. ActionBarCompat ShareActionProvider Backport available: android.support.v7.widget.ShareActionProvider @Override
 public boolean onCreateOptionsMenu(Menu menu) {
 // Inflate the menu
 getMenuInflater().inflate(R.menu.main_menu, menu);

 // Find the share item
 MenuItem shareItem = menu.findItem(R.id.menu_share);

 // Retrieve the SearchView
 mShareAp = (ShareActionProvider) MenuItemCompat.getActionProvider(shareItem);

 return super.onCreateOptionsMenu(menu);
 } // Later when you have created a share intent mShareAp.setShareIntent(shareIntentForContent);
22. ActionBarCompat PopupMenu Backport available: android.support.v7.widget.PopupMenu // Create a PopupMenu, giving it the clicked view for an anchor PopupMenu popup = new PopupMenu(getActivity(), view); // Inflate our menu resource into the PopupMenu's Menu popup.getMenuInflater().inflate(R.menu.popup, popup.getMenu()); // Set a listener so we are notified if a menu item is clicked popup.setOnMenuItemClickListener(new PopupMenu.OnMenuItemClickListener() { @Override public boolean onMenuItemClick(MenuItem menuItem) { ... } }); // Finally show the PopupMenu popup.show();
23. ActionBarCompat ActionBarDrawerToggle Support Automatic support for ActionBarDrawerToggle Need to be using ActionBarActivity // Enable Home button and set to display as up navigation getSupportActionBar().setHomeButtonEnabled(true); getSupportActionBar().setDisplayHomeAsUpEnabled(true); // Create ActionBarDrawerToggle mDrawerToggle = new ActionBarDrawerToggle(this, mDrawerLayout, R.drawable.ic_drawer, R.string.drawer_open, R.string.drawer_close); // Finally set the ActionBarDrawerToggle as the DrawerListener mDrawerLayout.setDrawerListener(mDrawerToggle);
24. ActionBarCompat Progress Bars @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); // Needs to be called before setting the content view supportRequestWindowFeature(Window.FEATURE_INDETERMINATE_PROGRESS); // Now set the content view setContentView(R.layout.activity_main); } // When ready, show the indeterminate progress bar setSupportProgressBarIndeterminateVisibility(true);
25. ActionBarCompat Ancestral Navigation Also known as ‘Up Navigation’
 In your AndroidManifest.xml: In your Activity: // Display home item as up navigation getSupportActionBar().setDisplayHomeAsUpEnabled(true); <activity android:name=".YourActivity" android:parentActivityName=".YourParentActivity"> <meta-data android:name="android.support.PARENT_ACTIVITY" android:value=".YourParentActivity" /> </activity> API v16+ API v7+
26. ActionBarCompat Ancestral Navigation onSupportNavigateUp() getSupportParentActivityIntent() supportShouldUpRecreateTask() onPrepareSupportNavigateUpTaskStack() User clicks Home Parent Activity Started onCreateSupportNavigateUpTaskStack() true supportNavigateUpTo() false Looks at AndroidManifest parent activity Checks if we’re crossing tasks
27. Action Bar Style Generator Now supports ActionBarCompat! http://www.actionbarstylegenerator.com
28. ActionBar-PullToRefresh Now supports ActionBarCompat too! https://github.com/chrisbanes/ActionBar-PullToRefresh ...yes I know it’s a shameless plug
29. ActionBarCompat Find Bugs? http://b.android.com
30. Any questions?
