Auch ohne Netz: Offline-First Architekturen für HTML5 Apps

Christian Weyer | Thinktecture AG Auch ohne Netz Offline-First Architekturen
für HTML5 Apps

Christian Weyer • Co-founder, co-owner and principal consultant at Thinktecture
AG • Focus on – Mobile & web-based application architectures – Interoperability, cross-device – Pragmatic end-to-end solutions • Microsoft MVP for ASP.NET (Architecture) ASP.NET Web API / vNext Advisory Board Member ASPInsider, AzureInsider • Google GDE for AngularJS • http://blogs.thinktecture.com/cweyer [email protected] @christianweyer 2

Talking Points • Offline-First as a Must • Users Matter
• When is “Offline”? • Caching • Data Storage • Synchronization 3

Offline-First • Mobile-First is hip – … but it is
not enough • Few web sites are designed to work offline • Few web apps are designed to work offline • Few mobile apps are designed to work offline • Offline-First == User-First 4

Offline is not an error! 5

Given Facts – Offline is everwhere • Countryside • Flight
• Train • Costs • Roaming • Decide what „offline“ means to you/your apps 6

User Experience • Let people interact with their content •
Aggressive caching is a better user experience • Make error messages informative and consistent • Don’t show contradictory information • Don’t let people start something they can’t finish 11

User Experience • When caching, choose breadth over depth •
Design your empty states well • Never show the raw error message • Remember what your users were doing last • Never purge the cache while offline 12

When is „offline“, anyway? 13

Detect Status: Browser Events • Status properties & events •
May be unreliable with different results on various platforms • Need to write algorithm to ping well-known endpoint 14 window.addEventListener('load', function() { var status = document.getElementById("status"); function updateOnlineStatus(event) { var condition = navigator.onLine ? "online" : "offline"; status.className = condition; status.innerHTML = condition.toUpperCase(); } window.addEventListener('online', updateOnlineStatus); window.addEventListener('offline', updateOnlineStatus); });

Browser Events - Platforms 15

Caching • Static vs. Dynamic caching 16

HTML5 AppCache • Adding static data/files to dedicated browser cache
area – Based on root web page • Manifest describes what to cache • API to detect updates and act accordingly • Can be tough to test and debug • Usage information in browsers – chrome://appcache-internals/ in Chrome – help appcache in Firefox Developer Toolbar 17

AppCache Manifest & API 18 <html manifest="example.appcache"> ... </html> CACHE
MANIFEST # v1 2015-09-14 # This is another comment index.html cache.html style.css image1.png # Use from network if available NETWORK: network.html /api # Fallback content FALLBACK: / fallback.html if (window.applicationCache) { window.applicationCache.addEventListener( 'updateready', function() { if (confirm('An update is available. Reload now?')) { window.location.reload(); } }); }

HTML AppCache - Platforms 19

Service Workers • Browser-based applications need to perform work “outside
the browser” • Rich offline experiences • Periodic background sync • Push notifications • … and more native-like functionality 20

Service Workers • JavaScript Workers • Implement Lifecycle with events
• Browser support to question – Especially on mobile platforms 21

Service Workers - Platforms 22

Data Storage 23

Web Storage • Two types of storage: Session and Local
• Stores key/value pairs – Simple types & JSON • Properties – Storage.length • Methods – Storage.key() – Storage.getItem() – Storage.setItem() – Storage.removeItem() – Storage.clear() 24

Session & Local Storage • sessionStorage and localStorage properties on
window object • Difference – data stored in localStorage has no expiration time – data stored in sessionStorage gets cleared when the browsing session ends 26

Web Storage - Platforms 27

Web SQL 28

Web SQL - Platforms 29

IndexedDB • NoSql database in the browser • Store and
retrieve objects that are indexed with a key – rich query abilities • Changes to the database happen within transactions • Useful for applications that store large amount of data – Also for blobs • API can be challenging to use 30

Dexie.js – IndexedDB Wrapper 31 var db = new Dexie('MyDatabase');
// Define a schema db.version(1) .stores({ friends: 'name, age' }); // Open the database db.open() .catch(function(error){ alert('Uh oh : ' + error); }); // Find some old friends db.friends .where('age') .above(75) .each(function(friend){ console.log(friend.name); }); // or make a new one db.friends .add({ name: 'Camilla', age: 25 });

IndexedDB - Platforms 32

Storage Abstractions • Sometimes you need an abstraction over the
different stores • Mozilla‘s localForage is one of them 33 // In localStorage, we would do: localStorage.setItem('key', JSON.stringify('value')); doSomethingElse(); // With localForage, we use callbacks: localforage.setItem('key', 'value', doSomethingElse); // Or we can use Promises localforage.setItem('key', 'value').then(doSomethingElse);<

Synchronization • „Offline“ heavily depends on use cases • Sometimes
data needs to be synchronized – From server to device – From device to server • Conflicts will happen, for sure – Conflict resolution is king, but tough – Solutions based on functional requirements & logic • Certain architecture types can help – Like CQRS 34

Conflicts “Conflicts are not an error condition, they are the
result of your infrastructure allowing the same dataset to be modified across disconnected systems. The introduction of such conflicts in such a topology is the expected behavior and their programmatic resolution is a core piece of application logic.” 35 https://cloudant.com/blog/introduction-to-document-conflicts-part-two

CQRS Command Query Responsibility Segregation 36

CouchDB & PouchDB • Apache CouchDB – Database that uses
JSON for documents – JavaScript for MapReduce indexes – Regular HTTP for its API • PouchDB – Open-source JavaScript database – Inspired by CouchDB – Designed to run well within the browser • PouchDB can sync with CouchDB – Consider checking the inner workings of the sync protocol 37

Summary • Offline should not be an exception • Prepare
your architecture and your applications for being offline • Think about your users first! • Browsers have simple storages and powerful databases available • Synchronization can be complex and tedious – It all depends on the use cases 38

Resources • Offline: When Your Apps Can’t Connect to the
Internet – https://medium.com/user-experience-design-1/offline-93c2f8396124 • Mobile Apps Offline Support – http://www.infoq.com/articles/mobile-apps-offline-support • Introduction to CQRS – http://www.codeproject.com/Articles/555855/Introduction-to-CQRS • Working with quota on mobile browsers – http://www.html5rocks.com/en/tutorials/offline/quota-research/ • AppCache Nanny – https://github.com/gr2m/appcache-nanny • Gulp-manifest – https://github.com/hillmanov/gulp-manifest 39

Resources • WebStorage API – https://developer.mozilla.org/en-US/docs/Web/API/Web_Storage_API • IndexedDb API –
http://w3c.github.io/IndexedDB/ • Storing images and files in IndexedDB – https://hacks.mozilla.org/2012/02/storing-images-and-files-in-indexeddb/ • Dexie.js – https://github.com/dfahlander/Dexie.js/wiki/Samples • LocalForage – http://mozilla.github.io/localForage/ • Apache CouchDB – http://couchdb.apache.org/ • PouchDB – http://pouchdb.com/ 40

Resources • [email protected] • http://www.thinktecture.com • Thinktecture’s GitHub Repositories –
https://github.com/thinktecture • Christian Weyer’s GitHub Repositories – https://github.com/ChristianWeyer 41
