  1. ランダム行列から
    深層学習へ
    早瀬 友裕
    Cluster Metaverse Lab. Senior Research Scientist
    ACT-X「数理・情報のフロンティア」1期生
    2022/09/12 JST数学関係3領域WS「情報科学と拓く新しい数理科学」

    View Slide

  2. 略歴
    早瀬友裕 博士(数理科学)
    1. 博士課程(東大数理)
    a. 作用素環, 特に自由確率論
    b. CV&ML系のインターン
    2. 富士通人工知能研究所
    a. MLの実践(CV系)
    b. MLの基礎(JST ACT-X 数理と情報領域1期生、「自由確率論による深層学習
    の研究」)
    3. [Now] Cluster Metaverse Lab
    a. MLの実践(VR, 3DCV, CG)
    b. MLの基礎(NNGP)
    2

    View Slide

  3. 概要
    パラメータをランダムにしたニューラルネットを考えると?

    1. 初期化や学習率の調整法

    2. NNGPによるベイズ推定

    3. NTKによる学習曲線予測

    - 勾配降下法によるNNの学習と比較して計算時間を大幅に削減.

    - ランダム行列理論(及びその発展である自由確率論[
    Voiculescu’85])が背景に.

    JST ACT-X「自由確率論による深層学習の研究」
    - R. Karakida & TH, AISTATS2020
    : Fisher情報行列のスペクトル分布と学習率
    - B. Collins & TH, Comm. in Math. Phys. (2022)
    : DNNのヤコビアンの漸近的自由独立性
    Figure: Google AI
    3

    View Slide

  4. Multilayer Perceptron
    4
    4

    View Slide

  5. Deep Neural Network
    A standard formulation of deep learning is as follows:
    1. We are given a deep neural network (DNN).
    They have (one of ) the following conditions:
    1. Parameterized family of transformations, which maps a real vector to a real
    vector.
    2. It is a composition of brief parametrized transformations (e.g. linear
    transformations and non-linear elementwise function)
    2. We are given Object Function : e.g.
    5

    View Slide

  6. Optimization
    Stochastic Gradient Descent:
    We need
    6

    View Slide

  7. Initialization of Parameters
    e.g.
    7

    View Slide

  8. 無限幅極限で出力はガウス分布
    Figure from [Google “Fast and Easy Infinitely Wide Networks with Neural Tangents”]
    8

    View Slide

  9. Neural Network Gaussian Process
    [Lee et al., Deep Neural Networks as Gaussian Processes. ICLR 2018.]
    where
    Estimation:
    9

    View Slide

  10. Kernel Propagation
    通常のDNNのように、各層のカーネル設計の合成で帰納的に最後のカーネルが決まる。
    *特定の活性化関数(ReLU, GeLU, etc)の場合には、この積分は陽に計算できる。
    *以下の計算さえできれば推論できるので、計算量
    O(N^2)
    10

    View Slide

  11. Nural Tangent Kernel
    Informal [Jacot+NeurIPS2018, Lee+NeurIPS2019]: Under the
    wide limit M \to \infty, the learning of the DNN is approximated by
    where
    11
    Learning dynamics of parameters is given by:
    Learning dynamics of DNN is given by:
    where
    ( Neural Tangent Kernel)

    View Slide

  12. NTKは学習過程も予測する
    Figure from [Google “Fast and Easy Infinitely Wide Networks with Neural Tangents”]
    Figure from [Google “Fast and Easy Infinitely Wide Networks with Neural Tangents”]
    12

    View Slide

  13. CNN, ResNetにも対応
    Figure from [Google “Fast and Easy Infinitely Wide Networks with Neural Tangents”]
    13

    View Slide

  14. Attentionにも対応
    Infinite attention: NNGP and NTK for deep attention
    networks [https://arxiv.org/abs/2006.10540]
    14

    View Slide

  15. Spectrum of NTK
    “Spectra of the Conjugate Kernel and Neural Tangent Kernel for linear-width neural networks”
    https://arxiv.org/abs/2005.11879
    They treats the standard formulation: Gaussian Initialization x Multi-samples x
    Small output dimension, and they get:
    15

    View Slide

  16. Current Work
    MLP系統のNNは以前はトイモデルでし
    かなかったが、現在は現実の画像や3
    D
    データについても適用されている。
    e.g. gMLP, NeRF, etc
    理論的に陽に計算しやすく、実用的でも
    あるちょうどよい研究対象!VRでも利用
    が期待される。
    MLP系統のネットワークの理論解析,
    NNGP/NTKによる軽量代理モデルの考
    案。
    16

    View Slide

  17. ACT-X
    自由確率論による深層学習の
    研究
    17

    View Slide

  18. Vanishing/Exploding Gradients
    The optimization of DNN needs its parameter derivations.
    Since the DNN is the composition of the function, the parameter derivations are
    computed by backpropagation.
    The input-output Jacobian given by
    18

    View Slide

  19. Dynamical Isometry
    (Dynamical Isometry) If the eigenvalue distribution of
    is concentrated around 1, then we can prevent the exploding/vanishing gradients.
    [Pennington, Schoenholz, Ganguli, AISTATS2018, Benoit Collins & TH,
    CIMP2022] If we set the initialization of parameters to be Haar orthgonal and
    choose appropriate activation function, then we can make the DNN to achieve the
    dynamical isometry.
    19

    View Slide

  20. Limit Spectral Distributions
    [Pennington, Schoenholz, Ganguli, AISTATS2018]
    20

    View Slide

  21. T. H. & R. Karakida 2020
    “The Spectrum of Fisher Information of Deep Networks Achieving Dynamical Isometry”
    https://arxiv.org/abs/2006.07814
    When the DNN achieves dynamical isometry, the spectrum of the (one-sample x
    high-dim output)”NTK” concentrates around the maximal value, and the maximal
    values is O(L).
    Key recursive equation:
    21

    View Slide

  22. Training under D. Isometry
    Red line (the boarder line of the exploding gradients) :
    This line is expected by our theory !
    22

    View Slide

  23. T. H. & R. Karakida 2020
    “The Spectrum of Fisher Information of Deep Networks Achieving Dynamical Isometry”
    https://arxiv.org/abs/2006.07814
    When the DNN achieves dynamical isometry, the spectrum of the (one-sample x
    high-dim output)”NTK” concentrates around the maximal value, and the maximal
    values is O(L).
    Key recursive equation:
    23

    View Slide

  24. Spectrum of NTK
    The spectrum (eigenvalues) of the NTK has vital role in tuning the learning
    dynamics.
    e.g.
    => The learning dynamics does not converge.
    The condition number determines the convergence speed.
    24

    View Slide

  25. Training under D. Isometry
    Red line (the boarder line of the exploding gradients) :
    This line is expected by our theory !
    25

    View Slide

  26. Summary
    パラメータをランダムにしたニューラルネットを考えると?

    1. 初期化や学習率の調整法

    2. NNGPによるベイズ推定

    3. NTKによる学習曲線予測

    - 勾配降下法によるNNの学習と比較して計算時間を大幅に削減.

    - ランダム行列理論(及びその発展である自由確率論[
    Voiculescu’85])が背景に.

    Future Work: Toy Modelの向こう側へ
    MLP系統のネットワークを足がかりに、理論保証できかつ実データに対応できる境界を攻
    める
    26
