OAuth 2 for Me and You - 2022 Edition

This session was given at the Adobe ColdFusion Summit 2022 in Las Vegas, Monday October 3rd, 2022.

It covered the OAuth 2 protocol, what it means to be a consumer or provider, and how to navigate the handshake communications between the service. At the end of this session all attendees walked taller, safe in the fact that they understand OAuth 2, how to use it, and what it all means.

Transcript

1. OAUTH 2 FOR ME AND YOU
   Matt Gi
   ff
   ord - Adobe ColdFusion Summit 2022


   View Slide

2. ABOUT ME
   @coldfumonkeh
   app developer / software architect
   writer


   View Slide

3. View Slide

4. View Slide

5. THE SETLIST
   ➤ OAuth?


   ➤ Important De
   fi
   nitions


   ➤ How to be a consumer


   ➤ The Authorization Code Flow


   ➤ Useful Tools


   View Slide

6. THE SCENARIO


   View Slide

7. THE SCENARIO
   I am writing a web-based
   application for lovers of music.


   I want to access data from
   third-party services to enhance
   my application.


   View Slide

8. THE SCENARIO
   I am going to use Spotify to
   build a fun project that can
   generate dynamic playlists for
   the authenticating user.


   View Slide

9. THE SCENARIO
   My application will need to log
   into Spotify on behalf of my
   users to access their account
   information and have write
   access to their playlists.


   View Slide

10. THE SCENARIO


    View Slide

11. WHAT IS OAUTH?


    View Slide

12. WHAT IS OAUTH?


    View Slide

13. A delegation framework to allow
    secure authorization in a simple
    and standard method from web,
    mobile and desktop applications
    WHAT IS OAUTH?


    View Slide

14. A delegation framework to allow
    secure authorization in a simple
    and standard method from web,
    mobile and desktop applications
    WHAT IS OAUTH?


    View Slide

15. View Slide

16. A BRIEF HISTORY


    View Slide

17. A BRIEF HISTORY
    2006 Twitter Chief Architect looked for a better authentication method - no passwords
    2007 OpenID development group (and contributors) came up with the OAuth 1 first draft
    2007 7 updated drafts by the end of the year
    2009 OAuth 2.0 spec was started
    “.. to clear up many of the aspects of OAuth 1 that were difficult or confusing.”
    2012 OAuth 2.0 core spec was published
    There were
    MANY more revisions to the draft


    View Slide

18. View Slide

19. DEFINITIONS


    View Slide

20. ROLES


    View Slide

21. ROLES
    Resource Owner
    (The User)


    View Slide

22. ROLES
    Resource Owner
    (The User)
    The Client
    (The App)


    View Slide

23. ROLES
    The Client
    (The App)
    Resource Owner
    (The User)
    Resource Server


    View Slide

24. ROLES
    The Client
    (The App)
    Resource Owner
    (The User)
    Resource Server
    Authorization Server


    View Slide

25. ROLES
    The Client
    (The App)
    Resource Owner
    (The User)
    Resource Server Authorization Server


    View Slide

26. SCOPE


    View Slide

27. SCOPE


    View Slide

28. SCOPE


    View Slide

29. GRANT TYPES


    View Slide

30. GRANT TYPES


    View Slide

31. TOKENS


    View Slide

32. TOKENS
    ACCESS TOKEN


    View Slide

33. TOKENS
    REFRESH TOKEN


    View Slide

34. BEING A
    CONSUMER


    View Slide

35. REGISTERING YOUR APP


    View Slide

36. REGISTERING YOUR APP


    View Slide

37. REGISTERING YOUR APP


    View Slide

38. REGISTERING YOUR APP


    View Slide

39. REGISTERING YOUR APP


    View Slide

40. REGISTERING YOUR APP


    View Slide

41. REGISTERING YOUR APP


    View Slide

42. REGISTERING YOUR APP


    View Slide

43. REGISTERING YOUR APP


    View Slide

44. THE WORKFLOW


    View Slide

45. My


    Application Spotify
    Authorization


    Server
    Spotify
    Resource


    Server
    THE WORKFLOW
    https://accounts.spotify.com/authorize?
    client_id=0170ed62bfad4dcc90bd5b057787790e&code_challenge=1assIs_OhqosI
    koRWb8MopQ9hqHN9gj8HF4HXd06U2U&code_challenge_method=S256&state=A
    7CC19EA-D207-414D-9C6C6083A5E1237D&redirect_uri=http://
    myapp.local:10539/callback/&scope=playlist-modify-public%20playlist-modify-
    public%20user-read-email%20user-follow-modify&response_type=code


    View Slide

46. My


    Application Spotify
    Authorization


    Server
    Spotify
    Resource


    Server
    User Authorization Request
    THE WORKFLOW


    View Slide

47. My


    Application Spotify
    Authorization


    Server
    Spotify
    Resource


    Server
    User Authorization Request
    THE WORKFLOW
    LINK HREF
    https://accounts.spotify.com/authorize


    View Slide

48. My


    Application Spotify
    Authorization


    Server
    Spotify
    Resource


    Server
    User Authorization Request
    THE WORKFLOW
    https://accounts.spotify.com/authorize?


    client_id=0170ed62bfad4dcc90bd5b057787790e
    LINK HREF


    View Slide

49. My


    Application Spotify
    Authorization


    Server
    Spotify
    Resource


    Server
    User Authorization Request
    https://accounts.spotify.com/authorize?


    client_id=0170ed62bfad4dcc90bd5b057787790e


    &response_type=code
    LINK HREF
    THE WORKFLOW


    View Slide

50. My


    Application Spotify
    Authorization


    Server
    Spotify
    Resource


    Server
    User Authorization Request
    https://accounts.spotify.com/authorize?


    client_id=0170ed62bfad4dcc90bd5b057787790e


    &response_type=code


    &redirect_uri=https://myapp.local:10538/callback
    LINK HREF
    THE WORKFLOW


    View Slide

51. My


    Application Spotify
    Authorization


    Server
    Spotify
    Resource


    Server
    User Authorization Request
    https://accounts.spotify.com/authorize?


    client_id=0170ed62bfad4dcc90bd5b057787790e


    &response_type=code


    &redirect_uri=https://myapp.local:10538/callback


    &scope=playlist-modify-public user-read-email


    LINK HREF
    THE WORKFLOW


    View Slide

52. My


    Application Spotify
    Authorization


    Server
    Spotify
    Resource


    Server
    User Authorization Request
    https://accounts.spotify.com/authorize?


    client_id=0170ed62bfad4dcc90bd5b057787790e


    &response_type=code


    &redirect_uri=https://myapp.local:10538/callback


    &scope=playlist-modify-public user-read-email


    &state=9DC18EB2-3B79-4E05-904BD9E6590267C2
    LINK HREF
    THE WORKFLOW


    View Slide

53. My


    Application
    Spotify
    Do you give permission for
    My Application to


    access your basic profile
    information?
    No
    Yes
    Spotify
    Authorization


    Server
    Spotify
    Resource


    Server
    User Authorization Request
    THE WORKFLOW


    View Slide

54. User Authorization Request
    Authorization Code Grant
    My


    Application Spotify
    Authorization


    Server
    Spotify
    Resource


    Server
    https://myapp.local:10538/callback?code=AUTHORIZATION_CODE
    https://myapp.local:10538/callback?error=XXX
    THE WORKFLOW


    View Slide

55. User Authorization Request
    Authorization Code Grant
    My


    Application Spotify
    Authorization


    Server
    Spotify
    Resource


    Server
    THE WORKFLOW


    View Slide

56. 10 mins
    30-60


    secs
    THE WORKFLOW


    View Slide

57. THE WORKFLOW


    View Slide

58. My


    Application Spotify
    Authorization


    Server
    Spotify
    Resource


    Server
    User Authorization Request
    THE WORKFLOW
    Authorization Code Grant
    Access Token Request


    View Slide

59. My


    Application Spotify
    Authorization


    Server
    Spotify
    Resource


    Server
    User Authorization Request
    REQUESTING AN ACCESS TOKEN
    Authorization Code Grant
    Access Token Request


    View Slide

60. My


    Application Spotify
    Authorization


    Server
    Spotify
    Resource


    Server
    User Authorization Request
    REQUESTING AN ACCESS TOKEN
    Authorization Code Grant
    Access Token Request
    POST https://accounts.spotify.com/token


    View Slide

61. My


    Application Spotify
    Authorization


    Server
    Spotify
    Resource


    Server
    User Authorization Request
    REQUESTING AN ACCESS TOKEN
    Authorization Code Grant
    Access Token Request
    POST
    grant_type=authorization_code
    https://accounts.spotify.com/token


    View Slide

62. My


    Application Spotify
    Authorization


    Server
    Spotify
    Resource


    Server
    User Authorization Request
    REQUESTING AN ACCESS TOKEN
    Authorization Code Grant
    Access Token Request
    POST
    grant_type=authorization_code


    code=33160
    https://accounts.spotify.com/token


    View Slide

63. My


    Application Spotify
    Authorization


    Server
    Spotify
    Resource


    Server
    User Authorization Request
    REQUESTING AN ACCESS TOKEN
    Authorization Code Grant
    Access Token Request
    POST
    grant_type=authorization_code


    code=33160


    redirect_uri=https://myapp.local:10538/callback
    https://accounts.spotify.com/token


    View Slide

64. My


    Application Spotify
    Authorization


    Server
    Spotify
    Resource


    Server
    User Authorization Request
    REQUESTING AN ACCESS TOKEN
    Authorization Code Grant
    Access Token Request
    POST
    grant_type=authorization_code


    code=33160


    redirect_uri=https://myapp.local:10538/callback


    client_id=a3dd5f928fb04a1f8b5f7bdd3dbd3010
    https://accounts.spotify.com/token


    View Slide

65. My


    Application Spotify
    Authorization


    Server
    Spotify
    Resource


    Server
    User Authorization Request
    REQUESTING AN ACCESS TOKEN
    Authorization Code Grant
    Access Token Request
    POST
    grant_type=authorization_code


    code=33160


    redirect_uri=https://myapp.local:10538/callback


    client_id=a3dd5f928fb04a1f8b5f7bdd3dbd3010


    client_secret=e6b218b3a4cb46d8a11578b8a60f55fb
    https://accounts.spotify.com/token


    View Slide

66. My


    Application Spotify
    Authorization


    Server
    Spotify
    Resource


    Server
    User Authorization Request
    RECEIVING THE ACCESS TOKEN
    Authorization Code Grant
    Access Token Request
    Access Token Grant


    View Slide

67. My


    Application Spotify
    Authorization


    Server
    Spotify
    Resource


    Server
    User Authorization Request
    RECEIVING THE ACCESS TOKEN
    Authorization Code Grant
    Access Token Request
    Access Token Grant


    View Slide

68. View Slide

69. User Authorization Request
    Authorization Code Grant
    Access Token Request
    Access Token Grant
    Authenticated API Request
    Protected Resources
    My


    Application Spotify
    Authorization


    Server
    Spotify
    Resource


    Server
    ACCESSING RESOURCES


    View Slide

70. User Authorization Request
    Authorization Code Grant
    Access Token Request
    Access Token Grant
    Authenticated API Request
    Protected Resources
    My


    Application Spotify
    Authorization


    Server
    Spotify
    Resource


    Server
    Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9
    ACCESSING RESOURCES


    View Slide

71. ACCESSING RESOURCES


    View Slide

72. User Authorization Request
    Authorization Code Grant
    Access Token Request
    Access Token Grant
    Authenticated API Request
    Protected Resources
    My


    Application Spotify
    Authorization


    Server
    Spotify
    Resource


    Server
    ACCESSING RESOURCES


    View Slide

73. View Slide

74. REFRESH TOKENS


    View Slide

75. REFRESH TOKENS


    View Slide

76. REFRESHING AN ACCESS TOKEN
    POST https://accounts.spotify.com/token


    View Slide

77. REFRESHING AN ACCESS TOKEN
    POST
    grant_type=refresh_token
    https://accounts.spotify.com/token


    View Slide

78. REFRESHING AN ACCESS TOKEN
    POST
    grant_type=refresh_token


    refresh_token=SflKxwRJSMeKKF2QT4fwpM…
    https://accounts.spotify.com/token


    View Slide

79. REFRESHING AN ACCESS TOKEN
    POST
    grant_type=refresh_token


    refresh_token=SflKxwRJSMeKKF2QT4fwpM…


    client_id=a3dd5f928fb04a1f8b5f7bdd3dbd3010
    https://accounts.spotify.com/token


    View Slide

80. REFRESHING AN ACCESS TOKEN
    POST
    grant_type=refresh_token


    refresh_token=SflKxwRJSMeKKF2QT4fwpM…


    client_id=a3dd5f928fb04a1f8b5f7bdd3dbd3010


    client_secret=e6b218b3a4cb46d8a11578b8a60f55fb
    https://accounts.spotify.com/token


    View Slide

81. REFRESHING AN ACCESS TOKEN


    View Slide

82. REFRESHING AN ACCESS TOKEN


    View Slide

83. USEFUL TOOLS #1


    View Slide

84. USEFUL TOOLS #1


    View Slide

85. USEFUL TOOLS #1


    View Slide

86. USEFUL TOOLS #1


    View Slide

87. USEFUL TOOLS #1


    View Slide

88. USEFUL TOOLS #1


    View Slide

89. USEFUL TOOLS #1


    View Slide

90. CHANGES


    View Slide

91. CHANGES


    View Slide

92. CHANGES


    View Slide

93. CHANGES


    View Slide

94. CHANGES


    View Slide

95. CHANGES


    View Slide

96. CHANGES


    View Slide

97. PKCE
    (Proof Key for Code Exchange)


    View Slide

98. PKCE
    A-Z a-z 0-9 -._~
    1XxTnj2kNC2Szytqp7WDck3jVUD61nu5KwtQQJBIL_HIH6R3
    Code Veri
    fi
    er


    View Slide

99. PKCE
    base64url( sha256( code_veri
    fi
    er ) )
    tZSYs8eBdSGBJpDo3wOPaj729KNWRMnkbG1moPcwB2Q
    Code Challenge


    View Slide

100. My


     Application Spotify
     Authorization


     Server
     Spotify
     Resource


     Server
     User Authorization Request
     PKCE
     https://accounts.spotify.com/authorize?


     client_id=0170ed62bfad4dcc90bd5b057787790e


     &response_type=code


     &redirect_uri=https://myapp.local:10538/callback


     &scope=playlist-modify-public user-read-email


     &state=9DC18EB2-3B79-4E05-904BD9E6590267C2


     View Slide

101. My


     Application Spotify
     Authorization


     Server
     Spotify
     Resource


     Server
     User Authorization Request
     PKCE
     https://accounts.spotify.com/authorize?


     client_id=0170ed62bfad4dcc90bd5b057787790e


     &response_type=code


     &redirect_uri=https://myapp.local:10538/callback


     &scope=playlist-modify-public user-read-email


     &state=9DC18EB2-3B79-4E05-904BD9E6590267C2


     &code_challenge=tZSYs8eBdSGBJpDo3wOPaj729KNWR


     &code_challenge_method=S256


     View Slide

102. My


     Application Spotify
     Authorization


     Server
     Spotify
     Resource


     Server
     User Authorization Request
     PKCE
     code_challenge=tZSYs8eBdSGBJpDo3wOPaj729KNWR


     code_challenge_method=S256


     View Slide

103. My


     Application Spotify
     Authorization


     Server
     Spotify
     Resource


     Server
     User Authorization Request
     PKCE
     POST
     grant_type=authorization_code


     code=10538


     redirect_uri=https://myapp.local:10538/callback


     client_id=a3dd5f928fb04a1f8b5f7bdd3dbd3010


     client_secret=e6b218b3a4cb46d8a11578b8a60f55fb
     https://accounts.spotify.com/token
     code_verifier=1XxTnj2kNC2Szytqp7WDck3jVUD61nu5KwtQQJBIL_HIH6R3


     View Slide

104. My


     Application Spotify
     Authorization


     Server
     Spotify
     Resource


     Server
     User Authorization Request
     PKCE
     base64url( sha256( code_verifier ) ) = code_challenge
     ?


     View Slide

105. USEFUL TOOLS #2


     View Slide

106. USEFUL TOOLS #2


     View Slide

107. USEFUL TOOLS #2


     View Slide

108. USEFUL TOOLS #2 (AND #1)


     View Slide

109. USEFUL TOOLS #2 (AND #1)


     View Slide

110. USEFUL TOOLS #2


     View Slide

111. RUNNING YOUR
     OWN OAUTH2
     SERVER


     View Slide

112. USEFUL TOOLS #3


     View Slide

113. USEFUL TOOLS #3


     View Slide

114. RUNNING YOUR OWN OAUTH SERVER


     View Slide

115. RUNNING YOUR OWN OAUTH SERVER
     gB0NV05ehAs8lkQy


     View Slide

116. RUNNING YOUR OWN OAUTH SERVER
     eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9.eyJpYXQiOjE1MDgxNTgxMTIsImlzcyI6Imh0dHBzOi8vdGV
     zdC5tb25rZWhzZXJ2ZXIuY29tL29hdXRoL3Rva2VuIiwic3ViIjoxMDAwLCJleHAiOjE1MDgxNjE3MTIsI
     nNjb3BlIjoicmVhZC1wcml2YXRlIHdyaXRlIiwiYXVkIjoiQkYyMzQ3M0UtQTZBQS00NzdELUFEREVCM
     0E2REMyNEQyOEUifQ.n4b0VpKAgf0BPVPKxjsep9TtqyoexcnygrSekWu2KV4


     View Slide

117. RUNNING YOUR OWN OAUTH SERVER


     View Slide

118. JWTS FOR
     ACCESS TOKENS


     View Slide

119. HEADER
     PAYLOAD
     SIGNATURE
     JWT
     {


     "alg": "HS256",


     "typ": "JWT"


     }
     eyJhbGciOiJIUzI1NiIsInR5cCI6Ikp
     XVCJ9.


     View Slide

120. HEADER
     PAYLOAD
     SIGNATURE
     JWT
     {


     "alg": "HS256",


     "typ": "JWT"


     }
     {


     "iat": 1508158112,


     "iss": "https://test.monkehserver.com/oauth/token",


     "sub": 1000,


     "exp": 1508161712,


     "scope": "read-private write",


     "aud": "BF23473E-A6AA-477D-ADDEB3A6DC24D28E"


     }
     eyJhbGciOiJIUzI1NiIsInR5cCI6Ikp
     XVCJ9.
     eyJhbGciOiJIUzI1NiIsInR5cCI6Ikp
     XVCJ9.eyJpYXQiOjE1MDgxNTgx
     MTIsImlzcyI6Imh0dHBzOi8vdGVz
     dC5tb25rZWhzZXJ2ZXIuY29tL29
     hdXRoL3Rva2VuIiwic3ViIjoxMDA
     wLCJleHAiOjE1MDgxNjE3MTIsIn
     Njb3BlIjoicmVhZC1wcml2YXRlIH
     dyaXRlIiwiYXVkIjoiQkYyMzQ3M0
     UtQTZBQS00NzdELUFEREVCM0E
     2REMyNEQyOEUifQ.


     View Slide

121. HEADER
     PAYLOAD
     SIGNATURE
     JWT
     {


     "alg": "HS256",


     "typ": "JWT"


     }
     {


     "iat": 1508158112,


     "iss": "https://test.monkehserver.com/oauth/token",


     "sub": 1000,


     "exp": 1508161712,


     "scope": "read-private write",


     "aud": "BF23473E-A6AA-477D-ADDEB3A6DC24D28E"


     }
     HMACSHA256(


     base64UrlEncode(header) + "." +


     base64UrlEncode(payload),


     secret


     )
     eyJhbGciOiJIUzI1NiIsInR5cCI6Ikp
     XVCJ9.eyJpYXQiOjE1MDgxNTgx
     MTIsImlzcyI6Imh0dHBzOi8vdGVz
     dC5tb25rZWhzZXJ2ZXIuY29tL29
     hdXRoL3Rva2VuIiwic3ViIjoxMDA
     wLCJleHAiOjE1MDgxNjE3MTIsIn
     Njb3BlIjoicmVhZC1wcml2YXRlIH
     dyaXRlIiwiYXVkIjoiQkYyMzQ3M0
     UtQTZBQS00NzdELUFEREVCM0E
     2REMyNEQyOEUifQ.
     eyJhbGciOiJIUzI1NiIsInR5cCI6Ikp
     XVCJ9.eyJpYXQiOjE1MDgxNTgx
     MTIsImlzcyI6Imh0dHBzOi8vdGVz
     dC5tb25rZWhzZXJ2ZXIuY29tL29
     hdXRoL3Rva2VuIiwic3ViIjoxMDA
     wLCJleHAiOjE1MDgxNjE3MTIsIn
     Njb3BlIjoicmVhZC1wcml2YXRlIH
     dyaXRlIiwiYXVkIjoiQkYyMzQ3M0
     UtQTZBQS00NzdELUFEREVCM0E
     2REMyNEQyOEUifQ.n4b0VpKAgf
     0BPVPKxjsep9TtqyoexcnygrSek
     Wu2KV4


     View Slide

122. RUNNING YOUR OWN OAUTH SERVER (JWT)


     View Slide

123. RUNNING YOUR OWN OAUTH SERVER (JWT)


     View Slide

124. USEFUL TOOLS #4


     View Slide

125. USEFUL TOOLS #4


     View Slide

126. USEFUL TOOLS #4 - JWT.IO


     View Slide

127. OPENID CONNECT


     View Slide

128. OAUTH 2.1


     View Slide

129. OAUTH 2.1
     ➤ PKCE REQUIRED for ALL OAuth clients using authorisation code
     fl
     ow


     ➤ Redirect URI values MUST use exact-string matching


     ➤ Bearer token usage omits the use of bearer tokens in the query string of URIs


     ➤ Refresh Tokens for public clients must either be sender-constrained or one-time use
     (mobile apps and JavaScript apps)


     View Slide

130. BLOG POSTS INCOMING
     monkehworks.com


     View Slide

131. GITHUB
     github.com/coldfumonkeh


     View Slide

132. OAUTH 2 FOR ME AND YOU
     Matt Gi
     ff
     ord - Adobe ColdFusion Summit 2022
     THANK YOU!


     View Slide
