  1. Practical nginx module development
    ʙC and Luaʙ
    Tatsuhiko [email protected]
    YAPC::Asia TOKYO 2015

    View Slide

  2. @cubicdaiya / Tatsuhiko Kubo
    • Software Engineer @ Mercari, Inc.
    • Infrastructure Engineering
    • Skills
    • C, Go, Lua, nginx, …
    • OSS developer
    • ngx_small_light, ngx_dynamic_upstream,
    nginx-build, slackboard, cachectl, gaurun, …

    View Slide

  3. Activities on Github

    View Slide

  4. Other Activities
    IUUQNP[BJDGNQPTUOHJOY

    View Slide

  5. View Slide

  6. View Slide

  7. Agenda
    • nginx http module development with C
    • nginx API programming
    • Test::Nginx
    • ngx_lua
    • OpenResty

    View Slide

  8. Agenda
    • nginx http module development with C
    • nginx API programming
    • Test::Nginx
    • ngx_lua
    • OpenResty

    View Slide

  9. nginx
    • Open Source Software
    • HTTP server for various purpose
    • Static content delivery
    • Reverse proxy ( HTTP / FastCGI / uWSGI / … )
    • Load balancer
    • Cache
    • TLS Termination / SPDY Gateway
    • etc…
    • Mail proxy ( SMTP / POP3 / IMAP )
    • TCP proxy

    View Slide

  10. nginx’s architecture
    • event-driven
    • non-blocking
    • asynchronous
    • single-threaded ( multi-threaded partially)
    • multi-processes ( master / wokers / …)
    • modular

    View Slide

  11. nginx’s architecture
    • event-driven
    • non-blocking
    • asynchronous
    • single-threaded ( multi-threaded partially)
    • multi-processes ( master / wokers / …)
    • modular

    View Slide

  12. nginx is module-oriented
    • most features are designed as module
    • ngx_http_core_module
    • ngx_http_access_module
    • ngx_http_log_module
    • ngx_http_proxy_module
    • ngx_http_upstream_module
    • etc…

    View Slide

  13. 3rd party module for nginx
    • nginx-user can develop an original module
    • It is not required to modify source code of
    nginx
    • embed original module with ‘./configure’
    $ cd nginx-1.9.x
    $ ./configure —-add-module=${ngx_module_path}

    View Slide

  14. Examples

    View Slide

  15. Example
    • ngx_http_empty_gif_module (Official)
    • return 1x1 GIF
    location /gif {
    empty_gif;
    }
    $ curl -I http://127.0.0.1/gif
    HTTP/1.1 200 OK
    Content-Length: 43
    Content-Type: image/gif
    ...
    $

    View Slide

  16. Example
    • ngx_small_light
    • Dynamic Image Transformation for nginx
    small_light on;
    location ~ small_light[^/]*/(.+)$ {
    set $file $1;
    rewrite ^ /$file;
    }

    View Slide

  17. ngx_small_light
    • Dynamic Image Transformation for nginx
    • https://github.com/cubicdaiya/ngx_small_light
    • Provides various
    • Image Manipulations ( Resize / Crop / Composite / …)
    • Image Processing Libraries (Image Magick / Imlib2 / GD)
    • Image Formats (JPEG / GIF / PNG / WEBP)

    View Slide

  18. Transform image
    ■URI for resize
    /small_light(dw=300,dh=200)/img/image.jpg

    View Slide

  19. Transform image on S3
    proxy from nginx to S3
    small_light on;
    location ~ small_light[^/]*/(.+)$ {
    set $file $1;
    rewrite ^ /$file;
    }
    location /img {
    proxy_pass http://;
    }

    View Slide

  20. Adoption case
    https://github.com/wantedly/nginx-image-server

    View Slide

  21. Adoption case
    https://speakerdeck.com/yano3/dynamic-image-transformation-server-okara-beta

    View Slide

  22. Example
    • ngx_dynamic_upstream
    • Dynamic Upstream for nginx
    location / {
    allow xxx.xxx.xxx.xxx
    deny all;
    dynamic_upstream;
    }

    View Slide

  23. ngx_dynamic_upstream
    • Dynamic Upstream for nginx
    • https://github.com/cubicdaiya/ngx_dynamic_upstream
    • Provides HTTP APIs for manipulating upstream for nginx
    • It is useful for
    • zero-down-time deployment
    • blue green deployment

    View Slide

  24. Zero-down-time deployment on

    View Slide

  25. ɾɾɾ ɾɾɾ
    "1* "[email protected]

    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    HTTPS or SPDY
    OHJOY

    [email protected]@VQTUSFBN
    HTTP
    Mercari frontend
    "1* "[email protected]
    "1* "[email protected]

    ɾɾɾ ɾɾɾ

    View Slide

  26. "1* "[email protected]

    Previous deployment
    "1* "[email protected]

    "1* "[email protected]

    ChatOps with Slack
    yes
    EFQMPZCPU
    rsync
    rsync
    rsync

    View Slide

  27. Pros / Cons
    • Pros
    • Very Very Very simple
    • Cons
    • many 500 error happens at deployment!!!!!

    View Slide

  28. "1* "[email protected]

    Current deployment
    "1* "[email protected]

    ChatOps with Slack
    yes
    EFQMPZCPU
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    "1* "[email protected]

    View Slide

  29. "1* "[email protected]

    Current deployment
    "1* "[email protected]

    ChatOps with Slack
    yes
    EFQMPZCPU
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    "1* "[email protected]

    ※rsync
    ※ rsync ——rsync-path=mercari_app_rsync(↓)
    #!/bin/sh
    mercari_app_ctl down # deactivate server on nginx upstream
    rsync $* # deploy
    mercari_app_ctl up # activate server on nginx upstream

    View Slide

  30. "1* "[email protected]

    Current deployment
    "1* "[email protected]

    ChatOps with Slack
    yes
    EFQMPZCPU
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    "1* "[email protected]

    ※rsync
    ※ rsync ——rsync-path=mercari_app_rsync(↓)
    #!/bin/sh
    mercari_app_ctl down # deactivate server on nginx upstream
    rsync $* # deploy
    mercari_app_ctl up # activate server on nginx upstream

    View Slide

  31. Current deployment
    "1* "[email protected]

    ChatOps with Slack
    yes
    EFQMPZCPU
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    "1* "[email protected]

    ※ rsync ——rsync-path=mercari_app_rsync(↓)
    #!/bin/sh
    mercari_app_ctl down # deactivate server on nginx upstream
    rsync $* # deploy
    mercari_app_ctl up # activate server on nginx upstream
    down
    "1* "[email protected]

    View Slide

  32. "1* "[email protected]

    Current deployment
    "1* "[email protected]

    ChatOps with Slack
    yes
    EFQMPZCPU
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    "1* "[email protected]

    rsync
    ※ rsync ——rsync-path=mercari_app_rsync(↓)
    #!/bin/sh
    mercari_app_ctl down # deactivate server on nginx upstream
    rsync $* # deploy
    mercari_app_ctl up # activate server on nginx upstream

    View Slide

  33. Current deployment
    "1* "[email protected]

    ChatOps with Slack
    yes
    EFQMPZCPU
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    "1* "[email protected]

    ※ rsync ——rsync-path=mercari_app_rsync(↓)
    #!/bin/sh
    mercari_app_ctl down # deactivate server on nginx upstream
    rsync $* # deploy
    mercari_app_ctl up # activate server on nginx upstream
    up
    "1* "[email protected]

    View Slide

  34. "1* "[email protected]

    Current deployment
    "1* "[email protected]

    ChatOps with Slack
    yes
    EFQMPZCPU
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    "1* "[email protected]

    ※rsync
    ※ rsync ——rsync-path=mercari_app_rsync(↓)
    #!/bin/sh
    mercari_app_ctl down # deactivate server on nginx upstream
    rsync $* # deploy
    mercari_app_ctl up # activate server on nginx upstream

    View Slide

  35. Current deployment
    "1* "[email protected]

    ChatOps with Slack
    yes
    EFQMPZCPU
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    ※ rsync ——rsync-path=mercari_app_rsync(↓)
    #!/bin/sh
    mercari_app_ctl down # deactivate server on nginx upstream
    rsync $* # deploy
    mercari_app_ctl up # activate server on nginx upstream
    down
    "1* "[email protected]

    "1* "[email protected]

    View Slide

  36. "1* "[email protected]

    Current deployment
    "1* "[email protected]

    ChatOps with Slack
    yes
    EFQMPZCPU
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    "1* "[email protected]

    rsync
    ※ rsync ——rsync-path=mercari_app_rsync(↓)
    #!/bin/sh
    mercari_app_ctl down # deactivate server on nginx upstream
    rsync $* # deploy
    mercari_app_ctl up # activate server on nginx upstream

    View Slide

  37. Current deployment
    "1* "[email protected]

    ChatOps with Slack
    yes
    EFQMPZCPU
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    ※ rsync ——rsync-path=mercari_app_rsync(↓)
    #!/bin/sh
    mercari_app_ctl down # deactivate server on nginx upstream
    rsync $* # deploy
    mercari_app_ctl up # activate server on nginx upstream
    up
    "1* "[email protected]

    "1* "[email protected]

    View Slide

  38. "1* "[email protected]

    Current deployment
    "1* "[email protected]

    ChatOps with Slack
    yes
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    "1* "[email protected]

    ※rsync
    ※ rsync ——rsync-path=mercari_app_rsync(↓)
    #!/bin/sh
    mercari_app_ctl down # deactivate server on nginx upstream
    rsync $* # deploy
    mercari_app_ctl up # activate server on nginx upstream
    EFQMPZCPU

    View Slide

  39. Current deployment
    ChatOps with Slack
    yes
    EFQMPZCPU
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    ※ rsync ——rsync-path=mercari_app_rsync(↓)
    #!/bin/sh
    mercari_app_ctl down # deactivate server on nginx upstream
    rsync $* # deploy
    mercari_app_ctl up # activate server on nginx upstream
    down
    "1* "[email protected]

    "1* "[email protected]

    "1* "[email protected]

    View Slide

  40. "1* "[email protected]

    Current deployment
    "1* "[email protected]

    ChatOps with Slack
    yes
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    "1* "[email protected]

    rsync
    ※ rsync ——rsync-path=mercari_app_rsync(↓)
    #!/bin/sh
    mercari_app_ctl down # deactivate server on nginx upstream
    rsync $* # deploy
    mercari_app_ctl up # activate server on nginx upstream
    EFQMPZCPU

    View Slide

  41. Current deployment
    ChatOps with Slack
    yes
    EFQMPZCPU
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    OHJOY

    [email protected]@VQTUSFBN
    ※ rsync ——rsync-path=mercari_app_rsync(↓)
    #!/bin/sh
    mercari_app_ctl down # deactivate server on nginx upstream
    rsync $* # deploy
    mercari_app_ctl up # activate server on nginx upstream
    up
    "1* "[email protected]

    "1* "[email protected]

    "1* "[email protected]

    View Slide

  42. Hello, World!

    View Slide

  43. Hello, World!
    • ngx_http_hello_world
    • https://github.com/cubicdaiya/ngx_http_hello_world
    location /hello {
    hello_world;
    }
    $ curl http://127.0.0.1/hello
    Hello, World!
    $

    View Slide

  44. Layout of ngx_http_hello_world
    ngx_http_hello_world
    |———...
    |———config
    |———ngx_http_hello_world_module.c
    └──-...

    View Slide

  45. config
    • module configuration file
    ngx_addon_name=ngx_http_hello_world_module
    HTTP_MODULES="$HTTP_MODULES \
    ngx_http_hello_world_module”
    NGX_ADDON_SRCS="$NGX_ADDON_SRCS \
    $ngx_addon_dir/ngx_http_hello_world_module.c”

    View Slide

  46. Hello, World!
    • ngx_http_hello_world
    • return “Hello, World!”
    location /hello {
    hello_world;
    }
    $ curl http://127.0.0.1/hello
    Hello, World!
    $

    View Slide

  47. Hello, World!
    • ngx_http_hello_world
    • return “Hello, World!”
    location /hello {
    hello_world;
    }
    $ curl http://127.0.0.1/hello
    Hello, World!
    $

    View Slide

  48. Hello, World!
    • ngx_http_hello_world
    • return “Hello, World!”
    location /hello {
    hello_world; # original directive
    }
    $ curl http://127.0.0.1/hello
    Hello, World!
    $

    View Slide

  49. Directive declaration
    struct ngx_command_s {
    ngx_str_t name;
    ngx_uint_t type;
    char *(*set)(ngx_conf_t *cf, ngx_command_t *cmd, void *conf);
    ngx_uint_t conf;
    ngx_uint_t offset;
    void *post;
    };

    View Slide

  50. Directive definition(hello_world)
    static ngx_command_t ngx_http_hello_world_commands[] = {
    {
    ngx_string("hello_world"),
    NGX_HTTP_LOC_CONF|NGX_CONF_NOARGS,
    ngx_http_hello_world,
    0,
    0,
    NULL
    },
    ngx_null_command
    };

    View Slide

  51. Module context
    typedef struct {
    ngx_int_t (*preconfiguration)(ngx_conf_t *cf);
    ngx_int_t (*postconfiguration)(ngx_conf_t *cf);
    void *(*create_main_conf)(ngx_conf_t *cf);
    char *(*init_main_conf)(ngx_conf_t *cf, void *conf);
    void *(*create_srv_conf)(ngx_conf_t *cf);
    char *(*merge_srv_conf)(ngx_conf_t *cf, void *prev, void *conf);
    void *(*create_loc_conf)(ngx_conf_t *cf);
    char *(*merge_loc_conf)(ngx_conf_t *cf, void *prev, void *conf);
    } ngx_http_module_t;

    View Slide

  52. Module context
    static ngx_http_module_t ngx_http_hello_world_module_ctx = {
    NULL, /* preconfiguration */
    NULL, /* postconfiguration */
    NULL, /* create main configuration */
    NULL, /* init main configuration */
    NULL, /* create server configuration */
    NULL, /* merge server configuration */
    NULL, /* create location configuration */
    NULL /* merge location configuration */
    };
    In this case, all is NULL.

    View Slide

  53. Module definition
    ngx_module_t ngx_http_hello_world_module = {
    NGX_MODULE_V1,
    &ngx_http_hello_world_module_ctx, /* module context */
    ngx_http_hello_world_commands, /* module directives */
    NGX_HTTP_MODULE, /* module type */
    NULL, /* init master */
    NULL, /* init module */
    NULL, /* init process */
    NULL, /* init thread */
    NULL, /* exit thread */
    NULL, /* exit process */
    NULL, /* exit master */
    NGX_MODULE_V1_PADDING
    };

    View Slide

  54. Hook original handler
    static char *ngx_http_hello_world(ngx_conf_t *cf, ngx_command_t *cmd, void *conf)
    {
    ngx_http_core_loc_conf_t *clcf;
    clcf = ngx_http_conf_get_module_loc_conf(cf, ngx_http_core_module);
    clcf->handler = ngx_http_hello_world_handler;
    return NGX_CONF_OK;
    }

    View Slide

  55. ngx_http_hello_world_handler()
    #define NGX_HTTP_HELLO_WORLD “Hello, World!”
    static ngx_int_t ngx_http_hello_world_handler(ngx_http_request_t *r)
    {
    ngx_int_t rc;
    ngx_chain_t out;
    ngx_buf_t *b;
    ngx_str_t body = ngx_string(NGX_HTTP_HELLO_WORLD);
    if (r->method != NGX_HTTP_GET && r->method != NGX_HTTP_HEAD) {
    return NGX_HTTP_NOT_ALLOWED;
    }
    if (r->headers_in.if_modified_since) {
    return NGX_HTTP_NOT_MODIFIED;
    }
    b = ngx_pcalloc(r->pool, sizeof(ngx_buf_t));
    if (b == NULL) {
    return NGX_HTTP_INTERNAL_SERVER_ERROR;
    }
    b->pos = body.data;
    b->last = b->pos + body.len;
    b->memory = 1;
    b->last_buf = 1;
    out.buf = b;
    out.next = NULL;
    ngx_str_set(&r->headers_out.content_type, "text/plain");
    r->headers_out.status = NGX_HTTP_OK;
    r->headers_out.content_length_n = body.len;
    rc = ngx_http_send_header(r);
    if (rc == NGX_ERROR || rc > NGX_OK || r->header_only) {
    return rc;
    }

    View Slide

  56. Embed ngx_http_hello_world into nginx
    $ ./confgiure \
    —-add-module=../ngx_http_hello_world
    $ make
    $ sudo make install

    View Slide

  57. Hook details…

    View Slide

  58. Request processing phases in nginx
    TFSWFSSFXSJUF
    QPTUBDDFTT
    MPH
    pOEDPOpH
    SFXSJUF
    QPTUSFXSJUF
    QSFBDDFTT
    USZpMFT
    DPOUFOU
    Request
    BDDFTT
    try_files processing
    access-control
    response body generation
    logging
    rewrite in server
    find location
    rewrite in location

    View Slide

  59. Phase definitions
    typedef enum {
    NGX_HTTP_POST_READ_PHASE = 0,
    NGX_HTTP_SERVER_REWRITE_PHASE,
    NGX_HTTP_FIND_CONFIG_PHASE,
    NGX_HTTP_REWRITE_PHASE,
    NGX_HTTP_POST_REWRITE_PHASE,
    NGX_HTTP_PREACCESS_PHASE,
    NGX_HTTP_ACCESS_PHASE,
    NGX_HTTP_POST_ACCESS_PHASE,
    NGX_HTTP_TRY_FILES_PHASE,
    NGX_HTTP_CONTENT_PHASE,
    NGX_HTTP_LOG_PHASE
    } ngx_http_phases;

    View Slide

  60. Hook handler to specified phases
    ngx_http_handler_pt *h;
    ngx_http_core_main_conf_t *cmcf;
    cmcf = ngx_http_conf_get_module_main_conf(cf, ngx_http_core_module);
    h = ngx_array_push(&cmcf->phases[NGX_HTTP_ACCESS_PHASE].handlers);
    if (h == NULL) {
    return NGX_ERROR;
    }
    *h = ngx_http_xxx_handler;

    View Slide

  61. Agenda
    • nginx http module development with C
    • nginx API programming
    • Test::Nginx
    • ngx_lua
    • OpenResty

    View Slide

  62. Agenda
    • nginx http module development with C
    • nginx API programming
    • Test::Nginx
    • ngx_lua
    • OpenResty

    View Slide

  63. nginx API
    • memory-pool
    • string
    • array
    • hash-table
    • time
    • list
    • regular-expression
    • temporary-file
    • shared-memory
    • etc…

    View Slide

  64. essence of nginx API programming
    • understand nginx architecture
    • event-driven
    • non-blocking
    • asynchronous
    • single-threaded
    • multi-process

    View Slide

  65. essence of nginx API programming
    • memory management strategies
    • memory-pool
    • slab ( for shared-memory)
    • string with length
    • string is not always NULL-terminated

    View Slide

  66. essence of nginx API programming
    • structs for HTTP
    • ngx_http_request_t
    • ngx_http_headers_in
    • ngx_http_headers_out
    • etc… ( See nginx/src/http/ngx_http_request.h )

    View Slide

  67. Move to terminal…

    View Slide

  68. Agenda
    • nginx http module development with C
    • nginx API programming
    • Test::Nginx
    • ngx_lua
    • OpenResty

    View Slide

  69. Agenda
    • nginx http module development with C
    • nginx API programming
    • Test::Nginx
    • ngx_lua
    • OpenResty

    View Slide

  70. Test::Nginx
    https://github.com/openresty/test-nginx

    View Slide

  71. Test::Nginx
    • Testing framework for nginx
    • https://github.com/openresty/test-nginx
    • We are able to test nginx’s behavior with CLI
    • Install from CPAN
    $ cpanm Test::Nginx

    View Slide

  72. test nginx’s behavior with Test::Nginx
    use Test::Nginx::Socket;
    plan tests => repeat_each() * 2 * blocks();
    run_tests();
    __DATA__
    === TEST 1: hello world
    --- config
    location /hello {
    return 200 "Hello, World!\n";
    }
    --- request
    GET /hello
    --- response_body
    Hello, World!
    --- error_code: 200

    View Slide

  73. test nginx’s behavior with Test::Nginx
    use Test::Nginx::Socket;
    plan tests => repeat_each() * 2 * blocks();
    run_tests();
    __DATA__
    === TEST 1: hello world
    --- config
    location /hello {
    return 200 "Hello, World!\n";
    }
    --- request
    GET /hello
    --- response_body
    Hello, World!
    --- error_code: 200
    run tests

    View Slide

  74. test nginx’s behavior with Test::Nginx
    use Test::Nginx::Socket;
    plan tests => repeat_each() * 2 * blocks();
    run_tests();
    __DATA__
    === TEST 1: hello world
    --- config
    location /hello {
    return 200 "Hello, World!\n";
    }
    --- request
    GET /hello
    --- response_body
    Hello, World!
    --- error_code: 200
    run tests
    define behavior
    ɾnginx.conf
    ɾHTTP request
    ɾHTTP response

    View Slide

  75. By the way,
    • C programming is difficult and complicated
    • productivity is not high
    If scripting language is available on nginx,
    productivity would improve dramatically.

    View Slide

  76. Agenda
    • nginx http module development with C
    • nginx API programming
    • Test::Nginx
    • ngx_lua
    • OpenResty

    View Slide

  77. Agenda
    • nginx http module development with C
    • nginx API programming
    • Test::Nginx
    • ngx_lua
    • OpenResty

    View Slide

  78. ngx_lua
    https://github.com/openresty/lua-nginx-moduleʙ

    View Slide

  79. ngx_lua
    • embed Lua/LuaJIT into nginx
    • Lua scripting in nginx.conf
    • Hooking request processing phase with Lua
    • wrap nginx API with Lua
    • non-blocking APIs (e.g. ngx.location.capture())

    View Slide

  80. • set_by_lua / set_by_lua_file
    • rewrite_by_lua / rewrite_by_lua_file
    • access_by_lua / access_by_lua_file
    • content_by_lua / content_by_lua_file
    • log_by_lua / log_by_lua_file
    Hook directives for request processing phases

    View Slide

  81. • set_by_lua / set_by_lua_file
    • rewrite_by_lua / rewrite_by_lua_file
    • access_by_lua / access_by_lua_file
    • content_by_lua / content_by_lua_file
    • log_by_lua / log_by_lua_file
    run Lua script-string
    Hook directives for request processing phases

    View Slide

  82. Hook directives for request processing phases
    • set_by_lua / set_by_lua_file
    • rewrite_by_lua / rewrite_by_lua_file
    • access_by_lua / access_by_lua_file
    • content_by_lua / content_by_lua_file
    • log_by_lua / log_by_lua_file
    run Lua script-file

    View Slide

  83. content_by_lua
    location /hello {
    content_by_lua “ngx.say(‘Hello, World!’)”;
    }
    ■ nginx.conf
    $ curl -s http://127.0.0.1/hello
    Hello, World!
    $
    ■ run

    View Slide

  84. content_by_lua_file
    location /hello {
    content_by_lua_file /etc/nginx/lua/hello.lua;
    }
    ■ nginx.conf
    ■ /etc/nginx/lua/hello.lua
    ngx.say(“Hello, World!”)

    View Slide

  85. set_by_lua $result
    location /yapc {
    set $conference YAPC::Asia;
    set $location Tokyo;
    set $year 2015;
    set_by_lua $result ‘return
    ngx.var.conference .. “ ” ..
    ngx.var.location .. “ ” ..
    ngx.var.year
    ‘;
    content_by_lua ‘ngx.say(ngx.var.result)’;
    }
    ■ nginx.conf
    $ curl -s http://127.0.0.1/hello
    YAPC::Asia Tokyo 2015
    $
    ■ run

    View Slide

  86. Request processing phases in nginx
    TFSWFSSFXSJUF
    QPTUBDDFTT
    MPH
    pOEDPOpH
    SFXSJUF
    QPTUSFXSJUF
    QSFBDDFTT
    USZpMFT
    DPOUFOU
    Request
    BDDFTT
    try_files processing
    access-control
    response body generation
    logging
    rewrite in server
    find location
    rewrite in location
    set_by_lua*

    rewrite_by_lua*
    access_by_lua*
    content_by_lua*
    log_by_lua*

    View Slide

  87. View Slide

  88. ngx_lua APIs
    • ngx.say() / ngx.exit() / ngx.log / …
    • ngx.var.VARIABLE
    • ngx.shared.DICT
    • ngx.header.HEADER
    • etc…

    View Slide

  89. ngx.say()
    ngx.say(“Hello, World!”)
    • output string to response body

    View Slide

  90. ngx.exit()
    ngx.exit(ngx.HTTP_OK)
    • return HTTP status code

    View Slide

  91. HTTP status code in ngx_lua
    • ngx.HTTP_OK (200)
    • ngx.HTTP_CREATED (201)
    • ngx.HTTP_MOVED_PERMANENTLY (301)
    • ngx.HTTP_MOVED_TEMPORARILY (302)
    • ngx.HTTP_NOT_MODIFIED (304)
    • ngx.HTTP_BAD_REQUEST (400)
    • ngx.HTTP_INTERNAL_SERVER_ERROR (500)
    • etc…

    View Slide

  92. ngx.log()
    ngx.exit(ngx.ERR, “some error”)
    • output message to error.log
    • $arg1: log-level, $arg2: message

    View Slide

  93. log-level in ngx_lua
    • ngx.EMERG
    • ngx.ALERT
    • ngx.CRIT
    • ngx.ERR
    • ngx.WARN
    • ngx.NOTICE
    • ngx.INFO
    • ngx.DEBUG

    View Slide

  94. log-level in ngx_lua
    • ngx.EMERG
    • ngx.ALERT
    • ngx.CRIT
    • ngx.ERR
    • ngx.WARN
    • ngx.NOTICE
    • ngx.INFO
    • ngx.DEBUG
    log-level
    High
    Low

    View Slide

  95. ngx.var.VARIABLE
    • read / overwrite nginx variables
    location / {
    set $fn “Tatsuhiko Kubo”;
    set $hn “@cubicdaiya”;
    content_by_lua ‘
    local body = ngx.var.fn .. ngx.var.hn
    ngx.say(body) —- Tatsuhiko [email protected]
    ‘;
    }

    View Slide

  96. ngx.var.VARIABLE
    • creating new variable is not allowed
    location / {
    content_by_lua ‘
    ngx.var.fn = “Tatsuhiko Kubo”
    ngx.var.hn = “@cubicdaiya”
    ‘;
    }
    runtime error: … variable “fn” not found for writing;
    maybe it is a built-in variable that is not changeable
    or …
    ɾ error.log

    View Slide

  97. ngx.shared.DICT
    • dictionary with shared memory
    http {
    lua_shared_dict yapc 1m;
    init_by_lua ‘
    ngx.shared.yapc:set(“presentator”, “@cubicdaiya”)
    ’;

    server {

    location / {
    content_by_lua ‘
    ngx.say(ngx.shared.yapc:get(“presentator”))
    ’;
    }
    }
    }

    View Slide

  98. ngx.header.HEADER
    • response header reference and manipulation
    location / {
    content_by_lua ‘
    local body = “{ \\”presentator\\” : \\”@cubicdaiya\\” }”
    —- assign application/json to Content-Type
    ngx.header.content_type = “application/json”
    ngx.say(body)
    ‘;
    }

    View Slide

  99. Header reference and manipulation
    • ngx.req.get_headers()
    • ngx.req.set_header()
    • ngx.req.clear_header()
    • …
    • ngx.resp.get_headers()
    • ngx.header.HEADER
    • …
    ■ For request-header ■ For response-header

    View Slide

  100. ngx.time()
    • return current timestamp
    local timestamp = ngx.time()

    View Slide

  101. ngx_lua time APIs
    • ngx.time()
    • ngx.today()
    • ngx.now()
    • ngx.update_time()
    • ngx.parse_http_time()
    • ngx.localtime()
    • ngx.utctime()
    • ngx.cookie_time()
    • ngx.http_time()

    View Slide

  102. Use ngx.time() instead of os.time()
    • os.time() always calls gettimeofday()
    • ngx.time() uses timer-cache of nginx
    • avoid system-call’s overhead
    • ngx.time() is more efficient than os.time()

    View Slide

  103. ngx.re.match()
    • Regular Expression matching
    • powered by PCRE
    local matches, err = ngx.re.match(“image/webp”,
    “([^/]+)\/(.+)”)
    -— matches[0] -> image/webp
    -— matches[1] -> image
    -— matches[2] -> webp

    View Slide

  104. ngx.re.* (Regular Expression API)
    • ngx.re.find()
    • ngx.re.match()
    • ngx.re.gmatch()
    • ngx.re.sub()
    • ngx.re.gsub()

    View Slide

  105. • Use PCRE options(e.g. o, j)
    • o -> enable compile-once
    • j -> enable PCRE-JIT
    Optimize ngx.re.*
    local matches, err = ngx.re.match(“image/webp”,
    “([^/]+)\/(.+)”,
    “oj”)

    View Slide

  106. • ngx.re is based PCRE
    • Powerful & Fat
    • Lua builtin-re(regular expression)
    • Simple & Light
    ngx.re.* VS Lua builtin-re
    If ‘re’ is simple, Lua builtin-re is faster.

    View Slide

  107. ngx.location.capture()
    • send non-blocking sub-request to other location
    location /external {
    internal;
    proxy_pass http://external;
    }
    location / {
    content_by_lua ‘
    —— non-blocking behavior
    local res = ngx.location.capture(“/external”)

    ‘;
    }

    View Slide

  108. By the way,
    • ngx_lua is very powerful
    • But setup and deployment is a little painful
    • Lua / LuaJIT instalation
    • Lua packages management

    View Slide

  109. Agenda
    • nginx http module development with C
    • nginx API programming
    • Test::Nginx
    • ngx_lua
    • OpenResty

    View Slide

  110. Agenda
    • nginx http module development with C
    • nginx API programming
    • Test::Nginx
    • ngx_lua
    • OpenResty

    View Slide

  111. OpenResty
    http://openresty.org/

    View Slide

  112. OpenResty
    • Web application framework bundled
    • nginx and 3rd party modules (e.g. ngx_lua)
    • Lua, LuaJIT
    • Resty modules(lua-resty-xxx…)
    • All-in-one superset of nginx

    View Slide

  113. 3rd party modules
    • lua-nginx-module (ngx_lua)
    • echo-nginx-module
    • headers-more-nginx-module
    • etc…

    View Slide

  114. Resty modules
    • lua-resty-core
    • resty-cli
    • lua-resty-mysql / redis / memcached
    • etc…

    View Slide

  115. lua-resty-core
    • pure Lua partial-re-implementation of ngx_lua APIs
    • accelerate ngx_lua APIs with LuaJIT
    • because ngx_lua APIs with C is not JIT compiled
    http {
    # accelerate ngx_lua APIs
    init_by_lua ‘require resty.core’;

    }

    View Slide

  116. lua-resty-cli
    • command-line utility for OpenResty
    • run OpenResty with CLI
    • all APIs are not always enabled
    $ resty -e ‘ngx.say(“Hello, World!”)’
    Hello, World!
    $

    View Slide

  117. lua-resty-mysql / redis / memcached
    • client drivers for mysql / redis / memcached
    • non-blocking behavior
    • Powered by ngx.socket

    View Slide

  118. OpenResty on

    View Slide

  119. PascalʙMercari app-event analysis baseʙ
    0QFO3FTUZ
    0QFO3FTUZ
    0QFO3FTUZ
    (PPHMF#JH2VFSZ
    Developer Data Sientist
    Analyze
    by SQL
    send events
    send events
    send events
    Powered by
    cookpad/puree-(ios|android)
    utilize events
    transfer
    utilize events
    utilize events
    transfer

    View Slide

  120. OpenResty’s role on Pascal
    • High performance event logger
    • receive events as JSON from devices
    • parse JSON
    • utilize events for BigQuery
    • log events into file every event-channel

    View Slide

  121. References
    • The Architecture of Open Source Applications (Volume 2):
    nginx
    • http://www.aosabook.org/en/nginx.html
    • Nginx Internals
    • http://www.slideshare.net/joshzhu/nginx-internals
    • Emiller’s Guide To Nginx Module Development
    • http://www.evanmiller.org/nginx-modules-guide.html

    View Slide

  122. References
    • openresty/lua-nginx-module
    • https://github.com/openresty/lua-nginx-module
    • Using ngx_lua / lua-nginx-module in pixiv
    • http://www.slideshare.net/harukayon/ngx-lua-public
    • ngx_mruby and ngx_lua
    • http://qiita.com/cubicdaiya/items/3913d3dddf6999984c5b

    View Slide

  123. Thanks!

    View Slide
