300以上のマイクロサービスを支えるマルチクラウドアーキテクチャ戦略
前回のDeveloper Conferenceから3年経ったABEMA。
様々な機能追加やサービス規模の拡大に対応するためにクラウドアーキテクチャの改修を行ってきました。
本セッションでは、ABEMAのこれまでの課題とそれらを解決するために取り組んだクラウドアーキテクチャの変遷を紹介します。
https://developer.abema.io/2021/sessions/JRrRCKSqyD/?utm_medium=social&utm_source=slideshare
CyberAgent PRO
December 15, 2021
Transcript
117 slides
-
AbemaTV, Inc. All Rights Reserved Cloud Platform Team 2 About
Mission • 基幹システムの開発・保守 • 次世代アーキテクチャの立案・浸透 • クラウドソリューションの活用戦略 @na_ga @gotyoooo @editnuki -
AbemaTV, Inc. All Rights Reserved Cloud Architecture の変遷 a. ABEMA
b. High Level Architecture アジェンダ 3 Kubernetes on GCP & AWS a. Cloud Edge Proxy b. Service Mesh c. Secret Resource d. Role Based Access Control e. Optimization Node Pool -
AbemaTV, Inc. All Rights Reserved ※ 出典 CyberAgent, inc. 2021
年通期決算発表資料 2018 年比較 • Download 数: 約 2 倍 ABEMA における変化 5 -
AbemaTV, Inc. All Rights Reserved 2018 年比較 • Download 数:
約 2 倍 • Weekly Active Users: 約 2 倍 ABEMA における変化 6 ※ 出典 CyberAgent, inc. 2021 年通期決算発表資料 -
AbemaTV, Inc. All Rights Reserved 2018 年は GKE を中心とした Micro
Service Architecture High Level Architecture の変化 Micro Services Micro Services Micro Services Ingress Micro Services API Gateways Micro Services MongoDB Micro Services BigTable Micro Services Pub/Sub Micro Services Redis Cluster Micro Services Cloud Storage Micro Services BigQuery Micro Services Cloud CDN region: asia-east1 Kubernetes Cluster 共通 SDK 共通 SDK 7 -
AbemaTV, Inc. All Rights Reserved 2018 年は GKE を中心とした Micro
Service Architecture High Level Architecture の変化 Micro Services Micro Services Micro Services Ingress Micro Services API Gateways Micro Services MongoDB Micro Services BigTable Micro Services Pub/Sub Micro Services Redis Cluster Micro Services Cloud Storage Micro Services BigQuery Micro Services Cloud CDN region: asia-east1 Kubernetes Cluster 共通 SDK 共通 SDK GCP 台湾リージョン 8 -
AbemaTV, Inc. All Rights Reserved 2018 年は GKE を中心とした Micro
Service Architecture High Level Architecture の変化 Micro Services Micro Services Micro Services Ingress Micro Services API Gateways Micro Services MongoDB Micro Services BigTable Micro Services Pub/Sub Micro Services Redis Cluster Micro Services Cloud Storage Micro Services BigQuery Micro Services Cloud CDN region: asia-east1 Kubernetes Cluster 共通 SDK 共通 SDK GCP 台湾リージョン サービス間の gRPC通信は共通 SDK によるクライアント LB 実装 9 -
AbemaTV, Inc. All Rights Reserved 開発者の要望 • AWS の Managed
Service と Compute Resource を活用したい • 日本国内のリージョンを活用し、通信遅延を削減したい High Level Architecture の変化 10 -
AbemaTV, Inc. All Rights Reserved 開発者の要望 • AWS の Managed
Service と Compute Resource を活用したい • 日本国内のリージョンを活用し、通信遅延を削減したい High Level Architecture の変化 11 Micro Services Micro Services Micro Services API Gateways Micro Services BigTable Micro Services Trace Micro Services Pub/Sub Micro Services Momerystore Micro Services Cloud Storage Micro Services BigQuery Kubernetes Cluster … etc Micro Services DynamoDB Micro Services SQS Micro Services SNS Micro Services Lambda Micro Services S3 Micro Services Redshift AWS Cloud Kubernetes Cluster … etc Micro Services Micro Services Micro Services API Gateways + 配信システムのリプレス CQRS + Event Sourcing -
AbemaTV, Inc. All Rights Reserved 開発者の要望 • AWS の Managed
Service と Compute Resource を活用したい • 日本国内のリージョンを活用し、通信遅延を削減したい High Level Architecture の変化 12 台湾リージョン 大阪リージョン 東京リージョン -
AbemaTV, Inc. All Rights Reserved 2021 年 High Level Architecture
の変化 Micro Services Micro Services Micro Services Ingress Micro Services API Gateways Micro Services BigTable Micro Services Trace Micro Services Pub/Sub Micro Services Spanner Micro Services Momerystore Micro Services Cloud Storage Micro Services BigQuery Micro Services MongoDB Micro Services Micro Services Micro Services Ingress Micro Services API Gateways Micro Services DynamoDB Micro Services SQS Micro Services SNS Micro Services Aurora Micro Services Lambda Micro Services S3 Micro Services Redshift Micro Services Kinesis Micro Services Cloud CDN region: asia-east1 and asia-northeast1 region: ap-northeast-1 AWS Cloud Micro Services CloudFront Micro Services Edge Proxies Micro Services Edge Proxies Kubernetes Cluster Kubernetes Cluster App Mesh Anthos Service Mesh … etc … etc 13 -
AbemaTV, Inc. All Rights Reserved High Level Architecture の変化 14
2021 年は GCP と AWS を活用したマルチクラウド環境 • 開発者にクラウド各社の差異を意識させない仕組み • 従来の台湾リージョンに加えて 東京リージョンに展開 • マルチクラウド環境を前提とした Monitoring & Alerting 基盤のリプレス • Kubernetes におけるサービス間通信の標準化 • Kubernetes におけるマルチテナントを前提としたセキュリティ設計 • Kubernetes における異なるワークロードの 特性に最適化したノードプール設計 -
AbemaTV, Inc. All Rights Reserved October 2018 The normal capacity
is 3,000 vCPU and 4,000 GiB memory on 100 nodes. The normal workload is 1,000 pods always running on 50 services. Kubernetes Resources in production environment 17 December 2021 The normal capacity is 4,000 vCPU and 5,500 GiB memory on 150+ nodes. ※ The normal workload is 2,500+ pods always running on 300 services. ※ ※ As the peak load increases, the number of nodes and pods is increased by the autoscaler. -
AbemaTV, Inc. All Rights Reserved October 2018 The normal capacity
is 3,000 vCPU and 4,000 GiB memory on 100 nodes. The normal workload is 1,000 pods always running on 50 services. Kubernetes Resources in production environment 18 December 2021 The normal capacity is 4,000 vCPU and 5,500 GiB memory on 150+ nodes. ※ The normal workload is 2,500+ pods always running on 300 services. ※ ※ As the peak load increases, the number of nodes and pods is increased by the autoscaler. サービスの細分化が加速し、異なる特性を持ったワークロードが増加した -
AbemaTV, Inc. All Rights Reserved GKE と EKS を活用した Multi
Kubernetes Cluster 構成 High Level Architecture for Kubernetes Micro Services Micro Services Micro Services API Gateways region: ap-northeast-1 AWS Cloud Micro Services CloudFront Micro Services Ingress Micro Services Edge Proxies Kubernetes Cluster App Mesh Micro Services Micro Services Micro Services API Gateways Micro Services Ingress region: asia-east1 Micro Services Cloud CDN Micro Services Edge Proxies Kubernetes Cluster Anthos Service Mesh Micro Services Micro Services Micro Services API Gateways Micro Services Ingress region: asia-northeast1 Micro Services Cloud CDN Micro Services Edge Proxies Kubernetes Cluster Anthos Service Mesh Plain mTLS 19 -
AbemaTV, Inc. All Rights Reserved High Level Architecture for Kubernetes
GKE と EKS を活用した Multi Kubernetes Cluster 構成 クラウド間のグローバル通信 Cloud Edge Proxy サービス間のインターナル通信 Service Mesh マルチテナントを前提とした Security 異なるワークロードの特性に最適化した Node Pool Plain mTLS 20 -
AbemaTV, Inc. All Rights Reserved Cloud Edge Proxy: 経緯 22
GCP と AWS を活用した Multi Kubernetes Cluster 構成 • システムの多様化によって、異なるクラウドでマイクロサービスが稼働する 背景 -
AbemaTV, Inc. All Rights Reserved Cloud Edge Proxy: 経緯 23
GCP と AWS を活用した Multi Kubernetes Cluster 構成 • システムの多様化によって、異なるクラウドでマイクロサービスが稼働する 異なるクラウドに対して透過的かつ安全に通信したい • EKS 上のサービスも従来の GKE 上のサービスと gRPC 通信を行いたい • グローバル通信となるため認証や暗号化を考慮する必要がある 背景 課題 -
AbemaTV, Inc. All Rights Reserved Cloud Edge Proxy: 経緯 24
GCP と AWS を活用した Multi Kubernetes Cluster 構成 • システムの多様化によって、異なるクラウドでマイクロサービスが稼働する 異なるクラウドに対して透過的かつ安全に通信したい • EKS 上のサービスも従来の GKE 上のサービスと gRPC 通信を行いたい • グローバル通信となるため認証や暗号化を考慮する必要がある 背景 課題 開発者にそれらを意識させず透過的に利用できる基幹システムを提供したい -
AbemaTV, Inc. All Rights Reserved Cloud Edge Proxy: 技術選定 25
VPN Connection • 方式: IPsec • サポート: GCP & AWS • 運用・保守コスト: 低い • ランニングコスト: 高い • Routing 制御: 不可 Envoy Proxy • 方式: Mutual TLS • サポート: コミュニティ • 運用・保守コスト: 高い • ランニングコスト: 低い • Routing 制御: 可能 -
AbemaTV, Inc. All Rights Reserved Cloud Edge Proxy: 技術選定 26
VPN Connection • 方式: IPsec • サポート: GCP & AWS • 運用・保守コスト: 低い • ランニングコスト: 高い • Routing 制御: 不可 Envoy Proxy • 方式: Mutual TLS • サポート: コミュニティ • 運用・保守コスト: 高い • ランニングコスト: 低い • Routing 制御: 可能 -
AbemaTV, Inc. All Rights Reserved Cloud Edge Proxy: 技術選定 27
柔軟な拡張性や Capacity Planning の観点から Envoy Proxy を採用 VPN Connection • 方式: IPsec • サポート: GCP & AWS • 運用・保守コスト: 低い • ランニングコスト: 高い • Routing 制御: 不可 Envoy Proxy • 方式: Mutual TLS • サポート: コミュニティ • 運用・保守コスト: 高い • ランニングコスト: 低い • Routing 制御: 可能 -
AbemaTV, Inc. All Rights Reserved クラウド間のグローバル通信を Mutual TLS によって保護 Cloud
Edge Proxy: 概要 Micro Services Micro Services Micro Services API Gateways region: ap-northeast-1 AWS Cloud Micro Services CloudFront Micro Services Ingress Micro Services Edge Proxies Kubernetes Cluster App Mesh Micro Services Micro Services Micro Services API Gateways Micro Services Ingress region: asia-east1 Micro Services Cloud CDN Micro Services Edge Proxies Kubernetes Cluster Anthos Service Mesh Micro Services Micro Services Micro Services API Gateways Micro Services Ingress region: asia-northeast1 Micro Services Cloud CDN Micro Services Edge Proxies Kubernetes Cluster Anthos Service Mesh Plain mTLS 28 -
AbemaTV, Inc. All Rights Reserved Cloud Edge Proxy: 詳細 29
Kubernetes Cluster 各 Kubernetes Cluster に Envoy Proxy が動作するサービスを配置 Namespace: xxxxx-A Namespace: edge-proxy Namespace: xxxxx-B Kubernetes Cluster Namespace: xxxx-C Namespace: edge-proxy Namespace: xxxx-D AWS Cloud Micro Services grpc-egress Micro Services grpc-ingress Micro Services grpc-ingress Micro Services grpc-egress gRPC Connection gRPC Connection Routing Rules Routing Rules Routing Rules Routing Rules Micro Services service A Micro Services service C Micro Services service B Micro Services service D Plain mTLS L 4 L B L 4 L B -
AbemaTV, Inc. All Rights Reserved Cloud Edge Proxy: 詳細 30
Kubernetes Cluster 各 Kubernetes Cluster に Envoy Proxy が動作するサービスを配置 Namespace: xxxxx-A Namespace: edge-proxy Namespace: xxxxx-B Kubernetes Cluster Namespace: xxxx-C Namespace: edge-proxy Namespace: xxxx-D AWS Cloud Micro Services grpc-egress Micro Services grpc-ingress Micro Services grpc-ingress Micro Services grpc-egress gRPC Connection gRPC Connection Routing Rules Routing Rules Routing Rules Routing Rules Micro Services service A Micro Services service C Micro Services service B Micro Services service D Plain mTLS L 4 L B L 4 L B 内部通信は PLAIN 内部通信は PLAIN -
AbemaTV, Inc. All Rights Reserved Cloud Edge Proxy: 詳細 31
Kubernetes Cluster 各 Kubernetes Cluster に Envoy Proxy が動作するサービスを配置 Namespace: xxxxx-A Namespace: edge-proxy Namespace: xxxxx-B Kubernetes Cluster Namespace: xxxx-C Namespace: edge-proxy Namespace: xxxx-D AWS Cloud Micro Services grpc-egress Micro Services grpc-ingress Micro Services grpc-ingress Micro Services grpc-egress gRPC Connection gRPC Connection Routing Rules Routing Rules Routing Rules Routing Rules Micro Services service A Micro Services service C Micro Services service B Micro Services service D Plain mTLS L 4 L B L 4 L B 外部通信は mTLS 内部通信は PLAIN 内部通信は PLAIN -
AbemaTV, Inc. All Rights Reserved Cloud Edge Proxy: 詳細 32
Kubernetes Cluster 各 Kubernetes Cluster に Envoy Proxy が動作するサービスを配置 Namespace: xxxxx-A Namespace: edge-proxy Namespace: xxxxx-B Kubernetes Cluster Namespace: xxxx-C Namespace: edge-proxy Namespace: xxxx-D AWS Cloud Micro Services grpc-egress Micro Services grpc-ingress Micro Services grpc-ingress Micro Services grpc-egress gRPC Connection gRPC Connection Routing Rules Routing Rules Routing Rules Routing Rules Micro Services service A Micro Services service C Micro Services service B Micro Services service D Plain mTLS L 4 L B L 4 L B Backoff Retry & Circuit Breaker -
AbemaTV, Inc. All Rights Reserved Cloud Edge Proxy: まとめ 33
クラウド間を透過的かつ安全な通信を確立 • 開発者は mTLS を意識する必要がない • Kubernetes Cluster 内の Edge Proxy サービスに従来通りに接続する • Edge Proxy サービスを経由して異なるクラウドのサービスに対して mTLS 通信を行う サービス側に意識させることなく信頼性を向上 • リトライ可能なレスポンスコードに対して、自動的に Backoff Retry を行う • リトライが好ましくないなど、サービス特性に合わせた個別設定を上書きできる • 異常なリクエストを検出した場合は Circuit Breaker によって影響範囲を最小化する -
AbemaTV, Inc. All Rights Reserved 共通 SDK を使用したサービス間通信 • 共通
SDK でサービス間の均等な負荷分散を実装している Service Mesh: 経緯 35 背景 -
AbemaTV, Inc. All Rights Reserved Service Mesh: 経緯 36 共通
SDK を使用したサービス間通信 • 共通 SDK でサービス間の均等な負荷分散を実装している サービスの多様化により共通 SDK の難しさに直面 • 言語毎に一貫性を保った SDK を実装する必要がある • SDK のアップデートを全てのサービスに適用する難しさ 背景 課題 -
AbemaTV, Inc. All Rights Reserved Service Mesh: 経緯 37 共通
SDK を使用したサービス間通信 • 共通 SDK でサービス間の均等な負荷分散を実装している サービスの多様化により共通 SDK の難しさに直面 • 言語毎に一貫性を保った SDK を実装する必要がある • SDK のアップデートを全てのサービスに適用する難しさ 背景 課題 Service Mesh Solution を導入し Networking 処理を移譲したい -
AbemaTV, Inc. All Rights Reserved Service Mesh: 技術選定 38 Istio
• Data Plane: Envoy Proxy • 提供: Self • サポート: コミュニティ • ランニングコスト: 低い • 運用・保守コスト: 激難 ASM & App Mesh • Data Plane: Envoy Proxy • 提供: Managed ※ • サポート: GCP & AWS • ランニングコスト: 低い • 運用・保守コスト: 低い ※ ASM の Control Plane は Self (In-Cluster) 方式も選択可能 -
AbemaTV, Inc. All Rights Reserved Service Mesh: 技術選定 39 Istio
• Data Plane: Envoy Proxy • 提供: Self • サポート: コミュニティ • ランニングコスト: 低い • 運用・保守コスト: 激難 ASM & App Mesh • Data Plane: Envoy Proxy • 提供: Managed ※ • サポート: GCP & AWS • ランニングコスト: 低い • 運用・保守コスト: 低い ※ ASM の Control Plane は Self (In-Cluster) 方式も選択可能 -
AbemaTV, Inc. All Rights Reserved Service Mesh: 技術選定 40 Istio
• Data Plane: Envoy Proxy • 提供: Self • サポート: コミュニティ • ランニングコスト: 低い • 運用・保守コスト: 激難 ASM & App Mesh • Data Plane: Envoy Proxy • 提供: Managed ※ • サポート: GCP & AWS • ランニングコスト: 低い • 運用・保守コスト: 低い クラウド各社が提供する Managed Service を採用 ※ ASM の Control Plane は Self (In-Cluster) 方式も選択可能 -
AbemaTV, Inc. All Rights Reserved 各クラウドの Service Mesh Solution を活用したサービス間通信を実現
Service Mesh: 概要 Micro Services Micro Services Micro Services API Gateways region: ap-northeast-1 AWS Cloud Micro Services CloudFront Micro Services Ingress Micro Services Edge Proxies Kubernetes Cluster App Mesh Micro Services Micro Services Micro Services API Gateways Micro Services Ingress region: asia-east1 Micro Services Cloud CDN Micro Services Edge Proxies Kubernetes Cluster Anthos Service Mesh Micro Services Micro Services Micro Services API Gateways Micro Services Ingress region: asia-northeast1 Micro Services Cloud CDN Micro Services Edge Proxies Kubernetes Cluster Anthos Service Mesh Plain mTLS 41 -
AbemaTV, Inc. All Rights Reserved Service Mesh: 詳細 42 Namespace:
api-gateway Sidecar の Envoy Proxy Container 経由でサービス間通信が可能 Plain mTLS Ingress Anthos Service Mesh Namespace: service-a Namespace: service-b Namespace: service-c API Gateways API Gateway API Gateways Envoy Proxy API Gateways Service A API Gateways Envoy Proxies API Gateways Service B API Gateways Envoy Proxies API Gateways Service C API Gateways Envoy Proxies Auto Injection by Kubernetes Cluster Pod: API Gateway Pod: Service A Pod: Service B Pod: Service C -
AbemaTV, Inc. All Rights Reserved Service Mesh: 詳細 43 Kubernetes
Cluster Namespace: api-gateway Sidecar の Envoy Proxy Container 経由でサービス間通信が可能 Plain mTLS Ingress AWS App Mesh Namespace: service-a Namespace: service-b Namespace: service-c API Gateways API Gateway API Gateways Envoy Proxy API Gateways Service A API Gateways Envoy Proxies API Gateways Service B API Gateways Envoy Proxies API Gateways Service C API Gateways Envoy Proxies Auto Injection by AWS Cloud Pod: API Gateway Pod: Service A Pod: Service B Pod: Service C -
AbemaTV, Inc. All Rights Reserved Service Mesh によるサービス間通信 • 共通
SDK から脱却 • セキュリティ担保のために内部通信に Mutual TLS を選択可能 • サービスのコンテキストを持たない横断チームによるトラフィック管理の実現 サービス側に意識させることなく信頼性を向上 • リトライ可能なレスポンスコードに対して、自動的に Backoff Retry を行う • リトライが好ましくないなど、サービス特性に合わせた個別設定を上書きできる • 異常なリクエストを検出した場合は Circuit Breaker によって影響範囲を最小化する 44 Service Mesh: まとめ -
AbemaTV, Inc. All Rights Reserved Secret Resource: 経緯 46 暗号化したファイルをPUSH
kubesec を利用、Default Namespace のみの運用 • Secret Resource Manifest 自体を暗号化 • 復号のために KMS へアクセスし鍵を取得 • 1つの Secret を複数のサービスで利用 背景 開発者に依存した適用方法、複数 Namespace 運用の開始 • 開発者の Local 環境で復号・Apply、一貫性がない • 明確にマイクロサービスの分離を行うために、 Namespace を分割 ◦ 同じ内容の Secret Resource を複数の Namespace で作成するケースが発生 課題 -
AbemaTV, Inc. All Rights Reserved Secret Resource: 経緯 47 暗号化したファイルをPUSH
kubesec を利用、Default Namespace のみの運用 • Secret Resource Manifest 自体を暗号化 • 復号のために KMS へアクセスし鍵を取得 • 1つの Secret を複数のサービスで利用 背景 開発者に依存した適用方法、複数 Namespace 運用の開始 • 開発者の Local 環境で復号・Apply、一貫性がない • 明確にマイクロサービスの分離を行うために、 Namespace を分割 ◦ 同じ内容の Secret Resource を複数の Namespace で作成するケースが発生 課題 暗号化 復号化 開発者 Key Management Service 鍵取得 暗号化 暗号化したファイルをPUSH Kubernetes Engine 開発者 Key Management Service 鍵取得 復号 暗号化したファイルを取得 復号したファイルをApply -
AbemaTV, Inc. All Rights Reserved Secret Resource: 経緯 48 暗号化したファイルをPUSH
kubesec を利用、Default Namespace のみの運用 • Secret Resource Manifest 自体を暗号化 • 復号のために KMS へアクセスし鍵を取得 • 1つの Secret を複数のサービスで利用 背景 開発者に依存した適用方法、複数 Namespace 運用の開始 • 開発者の Local 環境で復号・Apply、一貫性がない • 明確にマイクロサービスの分離を行うために、 Namespace を分割 ◦ 同じ内容の Secret Resource を複数の Namespace で作成するケースが発生 課題 Namespace default Secret wildcard.abema.tv Namespace A Secret wildcard.abema.tv Namespace B Secret wildcard.abema.tv Namespace C Secret wildcard.abema.tv -
AbemaTV, Inc. All Rights Reserved Secret Resource: 経緯 49 暗号化したファイルをPUSH
kubesec を利用、Default Namespace のみの運用 • Secret Resource Manifest 自体を暗号化 • 復号のために KMS へアクセスし鍵を取得 • 1つの Secret を複数のサービスで利用 背景 開発者に依存した適用方法、複数 Namespace 運用の開始 • 開発者の Local 環境で復号・Apply、一貫性がない • 明確にマイクロサービスの分離を行うために、 Namespace を分割 ◦ 同じ内容の Secret Resource を複数の Namespace で作成するケースが発生 課題 Secret も CD を導入可能にし 一貫性を持った管理手法に変更 -
AbemaTV, Inc. All Rights Reserved Secret Resource: ExternalSecrets ExternalSecrets https://github.com/external-secrets/kubernetes-external-secrets
51 OSS 秘匿情報を 外部サービスに保管 Kubernetes エコシステム クラウド各社に対応 -
AbemaTV, Inc. All Rights Reserved Secret Resource: ExternalSecrets 52 kube-apiserver
app Namespace app Namespace app Namespace External Secrets Secrets External Secrets Controller AWS Secrets Manager GCP Secret Manager OR 1. Get ExternalSecrets 3. Upsert Secrets 2. Fetch secrets properties -
AbemaTV, Inc. All Rights Reserved GCP Secret Manager / AWS
SecretsManager で一元管理 Secret Resource: ExternalSecrets 53 kube-apiserver app Namespace app Namespace app Namespace External Secrets Secrets External Secrets Controller AWS Secrets Manager GCP Secret Manager OR 1. Get ExternalSecrets 3. Upsert Secrets 2. Fetch secrets properties { "crt": "-----BEGIN CERTIFICATE-----\nMIIHJTXXX-----END CERTIFICATE-----", "key": "-----BEGIN PRIVATE KEY-----\nMIIEvgXXX-----END PRIVATE KEY-----" } -
AbemaTV, Inc. All Rights Reserved 開発者は ExternalSecret Resource を作成しデプロイ Secret
Resource: ExternalSecrets 54 kube-apiserver app Namespace app Namespace app Namespace External Secrets Secrets External Secrets Controller AWS Secrets Manager GCP Secret Manager OR 1. Get ExternalSecrets 3. Upsert Secrets 2. Fetch secrets properties apiVersion: kubernetes-client.io/v1 kind: ExternalSecret metadata: name: wildcard-abema-tv namespace: example spec: backendType: gcpSecretsManager projectId: examples template: type: kubernetes.io/tls data: - name: tls.crt key: wildcard_abema_tv version: latest property: crt - name: tls.key key: wildcard_abema_tv version: latest property: key -
AbemaTV, Inc. All Rights Reserved ExternalSecrets Controller が自動でSecrets Resourceを作成・更新 Secret
Resource: ExternalSecrets 55 kube-apiserver app Namespace app Namespace app Namespace External Secrets Secrets External Secrets Controller AWS Secrets Manager GCP Secret Manager OR 1. Get ExternalSecrets 3. Upsert Secrets 2. Fetch secrets properties -
AbemaTV, Inc. All Rights Reserved Secret Resource: Secret management by
PipeCD https://pipecd.dev/ 56 CyberAgent DP室 開発 OSS GitOps Continuous Delivery Tool Git で秘匿情報 を安全に保持 -
AbemaTV, Inc. All Rights Reserved Secret Resource: Secret management by
PipeCD app Namespace app Namespace app Namespace Secrets 開発者 57 PipeCD Console 1. Encrypt Confidential value 2. Get Public key Piped Agent Key Pair 3. Push File include encrypt value 4. Pull Files 5. Upsert Resource include Confidential value -
AbemaTV, Inc. All Rights Reserved Secret Resource: Secret management by
PipeCD app Namespace app Namespace app Namespace Secrets 開発者 58 PipeCD Console 1. Encrypt Confidential value 2. Get Public key Piped Agent Key Pair 3. Push File include encrypt value 4. Pull Files 5. Upsert Resource include Confidential value 開発者が PipeCD Console で暗号化 -
AbemaTV, Inc. All Rights Reserved Secret Resource: Secret management by
PipeCD app Namespace app Namespace app Namespace Secrets 開発者 59 PipeCD Console 1. Encrypt Confidential value 2. Get Public key Piped Agent Key Pair 3. Push File include encrypt value 4. Pull Files 5. Upsert Resource include Confidential value 暗号化文字列を元に Manifest を作成し、Git に Push apiVersion: pipecd.dev/v1beta1 kind: KubernetesApp spec: encryption: encryptedSecrets: token: XXXXXXXX decryptionTargets: - secret.yaml input: namespace: example apiVersion: v1 kind: Secret metadata: name: example namespace: example type: Opaque data: token: "{{ .encryptedSecrets.token }}" -
AbemaTV, Inc. All Rights Reserved Secret Resource: Secret management by
PipeCD app Namespace app Namespace app Namespace Secrets 開発者 60 PipeCD Console 1. Encrypt Confidential value 2. Get Public key Piped Agent Key Pair 3. Push File include encrypt value 4. Pull Files 5. Upsert Resource include Confidential value PipeCD デプロイ時に自動でDecrypt -
AbemaTV, Inc. All Rights Reserved • CloudPlatformTeam が提供する秘匿情報の暗号化に利用 • 現在は
TLS 証明書が主 Secret Resource: 使い分け 61 • 各サービス毎に必要な秘匿情報 の暗号化に利用 • 環境変数、SaaS API Key、Token etc... ExternalSecrets -
AbemaTV, Inc. All Rights Reserved 62 Secret Resource: まとめ GCP
/ AWS ともに同じ手法で Secret Resource の管理が可能に • 開発者に GKE / EKS を極力意識させない Gitリポジトリに秘匿情報を配置しない • 外部のリソースを利用して暗号化することで、 Git リポジトリ単体では復号不可 に -
AbemaTV, Inc. All Rights Reserved Role Based Access Control (RBAC)
とは • Resource へのアクセス権限管理を Role 型で取り扱う仕組み • 必要権限セットを持った Role を作成し、UserAccount / ServiceAccount に付与 (Binding) Role Based Access Control: 説明 64 apiVersion: rbac.authorization.k8s.io/v1 kind: ClusterRole metadata: name: secret-reader rules: - apiGroups: [""] resources: ["secrets"] verbs: ["get", "watch", "list"] apiVersion: rbac.authorization.k8s.io/v1 kind: ClusterRoleBinding metadata: name: read-secrets-global subjects: - kind: User name: [email protected] apiGroup: rbac.authorization.k8s.io roleRef: kind: ClusterRole name: secret-reader apiGroup: rbac.authorization.k8s.io -
AbemaTV, Inc. All Rights Reserved Kubernetes UserAccount の仕様に微妙に違いが・・・ Role Based
Access Control: 検証 65 GKE • IAM に付与した Role による権限 + ClusterRoleBinding / RoleBinding で リンクした権限 • どちらかに付与されている権限で 操作可能 EKS • ClusterRoleBinding / RoleBinding で リンクした権限でのみ操作可能 • IAM エンティティに AdministratorAccess が付与されていても、 それだけでは操作不可 -
AbemaTV, Inc. All Rights Reserved Role Based Access Control: 経緯
66 暗号化したファイルをPUSH GCP IAM に依存 • User Account / ServiceAccount 共に GCP IAMにて権限管理 • GCP の GKE Owner / Editor などをそのまま利用 • 誰でも Secret Resource を編集できる状態 背景 クラウド各社に依存せず、不必要な権限を外したい • EKS を利用するにあたり権限管理手法を統一したい • 権限を絞ることで、開発者を守りたい 課題 Kubernetes RBAC のみで完結させる -
AbemaTV, Inc. All Rights Reserved Role Based Access Control: Role
設計 67 1 User が複数の Namespace を担当することが多い ABEMA の開発組織に沿った形に • owner : すべての権限 • editor : 全 Namespace の Secret リソースを除いた編集権限 • viewer : 全 Namespace の Secret リソースを除いた閲覧権限 • restricted-editor : 特定 Namespace の Secret リソースを除いた編集権限 • restricted-viewer : 特定 Namespace の Secret リソースを除いた閲覧権限 -
AbemaTV, Inc. All Rights Reserved RBAC 向け Google グループ を活用し社内
Identity Provider (IDP)と連携 Role Based Access Control: User Account on GCP 68 開発者 IDP 1. 認証 Cloud IAM Kubernetes Engine 2. リクエスト -
AbemaTV, Inc. All Rights Reserved RBAC 向け Google グループ を活用し社内
Identity Provider (IDP)と連携 Role Based Access Control: User Account on GCP 69 開発者 IDP 1. 認証 Cloud IAM Kubernetes Engine 2. リクエスト group.editor ├─ user.x └─ user.y group.owner ├─ user.a └─ user.b group.owner └─ オーナー group.editor ├─ 閲覧 └─ Terraform 管理外のサービス編集者 group.owner └─ owner 向け ClusterRole group.editor └─ editor 向け ClusterRole gke-security-group ├─ group.owner └─ group.editor -
AbemaTV, Inc. All Rights Reserved SAML Federation を活用し社内 Identity Provider
(IDP) と連携 Role Based Access Control: User Account on AWS 70 開発者 IDP 1. 認証 AWS Cloud (開発 アカウント) 2. SAML認証 AWS Cloud (サービスプロバイダー アカウント) SAML用 AWSサインイン エンドポイント STS 3. リクエスト IAM EKS -
AbemaTV, Inc. All Rights Reserved SAML Federation を活用し社内 Identity Provider
(IDP) と連携 Role Based Access Control: User Account on AWS 71 開発者 IDP 1. 認証 AWS Cloud (開発 アカウント) 2. SAML認証 AWS Cloud (サービスプロバイダー アカウント) SAML用 AWSサインイン エンドポイント STS 3. リクエスト IAM EKS group.owner = role/aws-abema-owner group.editor = role/aws-abema-editor role/aws-abema-owner └─ AdministratorAccess role/aws-abema-editor ├─ ReadOnlyAccess └─ Terraform 管理外のサービス Editor group.editor ├─ user.x └─ user.y group.owner ├─ user.a └─ user.b role/aws-abema-owner └─ owner 向け ClusterRole role/aws-abema-editor └─ editor 向け ClusterRole -
AbemaTV, Inc. All Rights Reserved Role Based Access Control: まとめ
72 • GKE / EKS ともに同じ Role を設定 ◦ ABEMA のポリシーとして運用可能に ◦ 変更時も同時反映、運用コストの低減 -
AbemaTV, Inc. All Rights Reserved Node Pool: 経緯 74 新しい
Kubernetes Cluster を構築 • AWS の活用や日本国内リージョンの活用 • 既存 Kubernetes Cluster の構成自体に課題 背景 -
AbemaTV, Inc. All Rights Reserved Node Pool: 経緯 75 同一スペックノード
同一スペックノード Proxy VM Kubernetes Cluster Internet Service pod Service pod 既存の Node Pool 構成 -
AbemaTV, Inc. All Rights Reserved Node Pool: 経緯 76 新しい
Kubernetes Cluster を東京リージョンに構築 • AWS の活用や日本国内リージョンの活用 • 既存 Kubernetes Cluster の構成自体に課題 運用コストが高い • ノードのリソース使用効率が悪い • NAT 用の Proxy VM が乱立 • クラスタのリソース不足で担当者が手動でノード追加 背景 課題 -
AbemaTV, Inc. All Rights Reserved Node Pool: 経緯 77 運用コストが高い
• ノードのリソース使用効率が悪い • 固定 IP 用の Proxy VM が乱立 • クラスタのリソース不足で担当者が手動でノード追加 課題 40%未使用 60%利用 95%利用 -
AbemaTV, Inc. All Rights Reserved Node Pool: 経緯 78 運用コストが高い
• ノードのリソース使用効率が悪い • NAT 用の Proxy VM が乱立 • Cluster のリソース不足で担当者が手動でノード追加 課題 Service pod Proxy VM Proxy VM Kubernetes Cluster Internet -
AbemaTV, Inc. All Rights Reserved Node Pool: 経緯 79 運用コストが高い
• ノードのリソース使用効率が悪い • NAT 用の Proxy VM が乱立 • Cluster のリソース不足で担当者が手動でノード追加 課題 -
AbemaTV, Inc. All Rights Reserved Node Pool: 経緯 80 新しい
Kubernetes Cluster を東京リージョンに構築 • AWS の活用や日本国内リージョンの活用 • 既存 Kubernetes Cluster の構成自体に課題 運用コストが高い • ノードのリソース使用効率が悪い • NAT 用の Proxy VM が乱立 • Cluster のリソース不足で担当者が手動でノード追加 背景 課題 リソース使用効率が高く、開発者が利用しやすい Cluster を提供したい -
AbemaTV, Inc. All Rights Reserved これらの要件を満たせる設計を行うこととした • ワークロードの特性に合わせた Node Pool
によるリソース使用効率の改善 • NAT 用の Node Pool を用意し接続元グローバル IP の振る舞いを変更 • オートスケールできる Node Pool を追加 Node Pool: 要件 81 -
AbemaTV, Inc. All Rights Reserved これらの要件を満たせる設計を行うこととした • ワークロードの特性に合わせた Node Pool
によるリソース使用効率の改善 • NAT 用の Node Pool を用意し接続元グローバル IP の振る舞いを変更 • オートスケールできる Node Pool を追加 Node Pool: 要件 82 -
AbemaTV, Inc. All Rights Reserved これらの要件を満たせる設計を行うこととした • ワークロードの特性に合わせた Node Pool
によるリソース使用効率の改善 • NAT 用の Node Pool を用意し接続元グローバル IP の振る舞いを変更 • オートスケールできる Node Pool を追加 Node Pool: 要件 83 -
AbemaTV, Inc. All Rights Reserved これらの要件を満たせる設計を行うこととした • ワークロードの特性に合わせた Node Pool
によるリソース使用効率の改善 • NAT 用の Node Pool を用意し接続元グローバル IP の振る舞いを変更 • オートスケールできる Node Pool を追加 Node Pool: 要件 84 -
AbemaTV, Inc. All Rights Reserved 実現しようとすると以下の課題が発生した • Node Pool の種類が増えると開発者がどこに起動させればよいかわからない
• GKE, EKS と構成が異なるとプラットフォームごとに対応を変える必要がある • Node のスケールイン、スケールアウトでそれぞれの課題が発生する Node Pool: 新たな課題 85 -
AbemaTV, Inc. All Rights Reserved 実現しようとすると以下の課題が発生した • Node Pool の種類が増えると開発者がどこに起動させればよいかわからない
• GKE, EKS と構成が異なるとプラットフォームごとに対応を変える必要がある • Node のスケールイン、スケールアウトでそれぞれの課題が発生する Node Pool: 新たな課題 86 -
AbemaTV, Inc. All Rights Reserved 実現しようとすると以下の課題が発生した • Node Pool の種類が増えると開発者がどこに起動させればよいかわからない
• GKE, EKS と構成が異なるとプラットフォームごとに対応を変える必要がある • Node のスケールイン、スケールアウトでそれぞれの課題が発生する Node Pool: 新たな課題 87 Kubernetes Engine -
AbemaTV, Inc. All Rights Reserved 実現しようとすると以下の課題が発生した • Node Pool の種類が増えると開発者がどこに起動させればよいかわからない
• GCP, AWS と構成が異なるとプラットフォームごとに対応を変える必要がある • Node のスケールイン、スケールアウトでそれぞれの課題が発生する Node Pool: 新たな課題 88 Kubernetes Cluster Service pod Service pod pod が再起動されてしま う -
AbemaTV, Inc. All Rights Reserved 実現しようとすると以下の課題が発生した • Node Pool の種類が増えると開発者がどこに起動させればよいかわからない
• GCP, AWS と構成が異なるとプラットフォームごとに対応を変える必要がある • Node のスケールイン、スケールアウトでそれぞれの課題が発生する Node Pool: 新たな課題 89 Kubernetes Cluster Service pod Service pod Node が起動するまで Pending 状態となる -
AbemaTV, Inc. All Rights Reserved Node Pool: 新たな課題 90 Kubernetes
Cluster Node が起動するのに数 分かかる Service pod Service pod 実現しようとすると以下の課題が発生した • Node Pool の種類が増えると開発者がどこに起動させればよいかわからない • GCP, AWS と構成が異なるとプラットフォームごとに対応を変える必要がある • Node のスケールイン、スケールアウトでそれぞれの課題が発生する -
AbemaTV, Inc. All Rights Reserved Node Pool: 設計 91 Managed
NAT Service Kubernetes Cluster Node Pool: High CPU Type (Fixed) Node Pool: High CPU Node Pool (Auto Scalable) Node Pool: High Memory Type (Fixed) Node Pool: High Memory Node Pool (Auto Scalable) Node Pool: High CPU Type (Fixed) Node Pool: High CPU Node Pool (Auto Scalable) Node Pool: High Memory Type (Fixed) Node Pool: High Memory Node Pool (Auto Scalable) -
AbemaTV, Inc. All Rights Reserved Node Pool: 設計 92 Managed
NAT Service Kubernetes Cluster Node Pool: High CPU Type (Fixed) Node Pool: High CPU Node Pool (Auto Scalable) Node Pool: High Memory Type (Fixed) Node Pool: High Memory Node Pool (Auto Scalable) Node Pool: High CPU Type (Fixed) Node Pool: High CPU Node Pool (Auto Scalable) Node Pool: High Memory Type (Fixed) Node Pool: High Memory Node Pool (Auto Scalable) -
AbemaTV, Inc. All Rights Reserved Node Pool: 設計 93 Managed
NAT Service Kubernetes Cluster Node Pool: High CPU Type (Fixed) Node Pool: High CPU Node Pool (Auto Scalable) Node Pool: High Memory Type (Fixed) Node Pool: High Memory Node Pool (Auto Scalable) Node Pool: High CPU Type (Fixed) Node Pool: High CPU Node Pool (Auto Scalable) Node Pool: High Memory Type (Fixed) Node Pool: High Memory Node Pool (Auto Scalable) -
AbemaTV, Inc. All Rights Reserved Node Pool: 設計 94 Managed
NAT Service Kubernetes Cluster Node Pool: High CPU Type (Fixed) Node Pool: High CPU Node Pool (Auto Scalable) Node Pool: High Memory Type (Fixed) Node Pool: High Memory Node Pool (Auto Scalable) Node Pool: High CPU Type (Fixed) Node Pool: High CPU Node Pool (Auto Scalable) Node Pool: High Memory Type (Fixed) Node Pool: High Memory Node Pool (Auto Scalable) -
AbemaTV, Inc. All Rights Reserved Node Pool: 設計 95 Managed
NAT Service Kubernetes Cluster Node Pool: High CPU Type (Fixed) Node Pool: High CPU Node Pool (Auto Scalable) Node Pool: High Memory Type (Fixed) Node Pool: High Memory Node Pool (Auto Scalable) Node Pool: High CPU Type (Fixed) Node Pool: High CPU Node Pool (Auto Scalable) Node Pool: High Memory Type (Fixed) Node Pool: High Memory Node Pool (Auto Scalable) -
AbemaTV, Inc. All Rights Reserved 内容 • 適切な Node Pool
をチェックシートで判断した Kustomize Patch を適用 • GKE は ip-masq-agent と Cloud NAT , EKS は NAT Gateway で NAT 化 • Node リソースは AWS に合わせて GCP では Custom Instance を活用 • Auto Scale を無効にした Fixed Node Pool を活用 • Balloon Pod を活用した即時スケールアウト Node Pool: 課題の解決方法 96 -
AbemaTV, Inc. All Rights Reserved 内容 • 適切な Node Pool
をチェックシートで判断した Kustomize Patch を適用 • GKE は ip-masq-agent と Cloud NAT , EKS は NAT Gateway で NAT 化 • Node リソースは AWS に合わせて GCP では Custom Instance を活用 • Auto Scale を無効にした Fixed Node Pool を活用 • Balloon Pod を活用した即時スケールアウト Node Pool: 課題の解決方法 97 -
AbemaTV, Inc. All Rights Reserved チェックシート 98 NAT IP を
利用する 1 vCPU に対して Memory 2 GiB 以下 再配置を 許容できる 再配置を 許容できる NAT IP を 利用する NAT IP を 利用する NAT IP を 利用する Yes ex: High CPU Workload No ex: High Memory Workload Yes No Yes No private-cpu .yaml Yes No public-cpu .yaml private-cpu -asg.yaml Yes No public-cpu -asg.yaml private-mem -asg.yaml Yes No public-mem- asg.yaml private-mem .yaml Yes No public-mem .yaml -
AbemaTV, Inc. All Rights Reserved 目的 • Node Pool の選択方法の簡略化
内容 • Node Pool 毎の Patch を提供 • PriorityClass, NodeAffinity を設定 Kustomize Patch 99 apiVersion: apps/v1 kind: Deployment metadata: name: deployment spec: template: spec: priorityClassName: middle-priority affinity: nodeAffinity: requiredDuringSchedulingIgnoredDuringExecution: nodeSelectorTerms: - matchExpressions: - key: type operator: In values: - public-cpu - public-cpu-asg preferredDuringSchedulingIgnoredDuringExecution: - weight: 100 preference: matchExpressions: - key: type operator: In values: - public-cpu-asg ※ public-cpu-asg.yaml ファイル -
AbemaTV, Inc. All Rights Reserved 内容 • 適切な Node Pool
をチェックシートで判断した Kustomize Patch を適用 • GKE は ip-masq-agent と Cloud NAT , EKS は NAT Gateway で NAT 化 • Node リソースは AWS に合わせて GCP では Custom Instance を活用 • Auto Scale を無効にした Fixed Node Pool を活用 • Balloon Pod を活用した即時スケールアウト Node Pool: 課題の解決方法 100 -
AbemaTV, Inc. All Rights Reserved GKE の NAT 構成 101
Cloud NAT GKE Cluster ※ Subnet Public Node Pools Nodes ip-masq-agent-public DaemonSet Private Node Pools Nodes ip-masq-agent-private DaemonSet ※ GKE Cluster は Public Cluster を利用している -
AbemaTV, Inc. All Rights Reserved EKS の NAT 構成 102
NAT Gateway EKS Cluster Subnet: public Public Node Pools Nodes Private Node Pools Nodes Subnet: private -
AbemaTV, Inc. All Rights Reserved 内容 • 適切な Node Pool
をチェックシートで判断した Kustomize Patch を適用 • GKE は ip-masq-agent と Cloud NAT , EKS は NAT Gateway で NAT 化 • Node リソースは AWS に合わせて GCP では Custom Instance を活用 • Auto Scale を無効にした Fixed Node Pool を活用 • Balloon Pod を活用した即時スケールアウト Node Pool: 課題の解決方法 103 -
AbemaTV, Inc. All Rights Reserved 目的 • クラウド各社の差異を吸収する 設計 •
AWS の Instance Type に合わせる • CPU, Memory でそれぞれ定義する • Terraform では次のように指定できる Custom Instance 104 variable "cpu_machine_type" { // 8 vCPU 16 GiB Memory default = "n2-custom-8-16384" } variable "mem_machine_type" { // 4 vCPU 32 GiB Memory default = "n2-custom-4-32768" } ※ EKS の Terraform Variables ファイル variable "cpu_machine_type" { // 8 vCPU 16 GiB Memory default = "c5.2xlarge" } variable "mem_machine_type" { // 4 vCPU 32 GiB Memory default = "r5.xlarge" } ※ GKE の Terraform Variables ファイル -
AbemaTV, Inc. All Rights Reserved 内容 • 適切な Node Pool
をチェックシートで判断した Kustomize Patch を適用 • GKE は ip-masq-agent と Cloud NAT , EKS は NAT Gateway で NAT 化 • Node リソースは AWS に合わせて GCP では Custom Instance を活用 • Auto Scale を無効にした Fixed Node Pool を活用 • Balloon Pod を活用した即時スケールアウト Node Pool: 課題の解決方法 105 -
AbemaTV, Inc. All Rights Reserved 目的 • Pod の再配置を減らす 設計
• Auto Scale しない Node Pool を提供 Fixed Node Pool 106 ※ Node Pool の用途を記載した資料 -
AbemaTV, Inc. All Rights Reserved 内容 • 適切な Node Pool
をチェックシートで判断した Kustomize Patch を適用 • GKE は ip-masq-agent と Cloud NAT , EKS は NAT Gateway で NAT 化 • Node リソースは AWS に合わせて GCP では Custom Instance を活用 • Auto Scale を無効にした Fixed Node Pool を活用 • Balloon Pod を活用した即時スケールアウト Node Pool: 課題の解決方法 107 -
AbemaTV, Inc. All Rights Reserved 目的 • Node スケールアウト時間の短縮 設計
• Balloon Pod 用の Priority Class (-5) を定義 • 通常の Pod よりも優先度を低くする • 約 6 割の Resource Request を設定する Balloon Pod 108 apiVersion: apps/v1 kind: Deployment metadata: namespace: balloon name: balloon-private-cpu spec: template: spec: priorityClassName: balloon-priority containers: - name: app image: google/cloud-sdk:alpine resources: requests: cpu: 4800m # 6割のリソース memory: 9.6Gi # 6割のリソース ※ Balloon Pod の Deployment Manifest ファイル -
AbemaTV, Inc. All Rights Reserved Balloon Pod 109 application pod
application pod balloon pod -
AbemaTV, Inc. All Rights Reserved Balloon Pod 110 application pod
application pod balloon pod application pod New Scheduled evicted -
AbemaTV, Inc. All Rights Reserved Balloon Pod 111 application pod
application pod balloon pod application pod Pending pod -
AbemaTV, Inc. All Rights Reserved Balloon Pod 112 application pod
application pod balloon pod New Node application pod -
AbemaTV, Inc. All Rights Reserved コスト最適化 • Auto Scale Node
Pool の活用により必要に応じたキャパシティを確保 • ワークロードの特性に合わせた Node Pool により Node リソース使用効率を改善 利便性の向上 • Balloon Pod による Node スケールアウト時間を短縮 • 全ての Kubernetes Cluster において同一手段による NAT 化を実現 • 全ての Kubernetes Cluster において同一手段による Node Pool の選択を実現 Node Pool: まとめ 113 -
AbemaTV, Inc. All Rights Reserved 透過的なマルチクラウド活用の基盤構築 • 冗長化用途での活用 • フルマネージドサービスの活用
• シームレスなクラウド間連携 • セキュリティ/コスト管理の整備 115 まとめ GCP AWS Container Monitoring Authentication ServiceMesh Security -
AbemaTV, Inc. All Rights Reserved 高可用性プラットフォームへの挑戦 • Multi Region Kubernetes
Cluster • 東日本/西日本レベルでの災害に対する冗長化 • 更なる同時接続数を許容できるキャパシティ 今後の展望 116
