(Advanced) Redis
Search
Jan De Poorter
February 12, 2013
Programming
8
400
(Advanced) Redis
Everything we learned at a client project using Redis - Talk given at #ArrrrUG
Jan De Poorter
February 12, 2013
Tweet
Share
Other Decks in Programming
See All in Programming
LINEヤフー データグループ紹介
lycorp_recruit_jp
0
1.8k
PicoRuby on Rails
makicamel
2
120
deno-redisの紹介とJSRパッケージの運用について (toranoana.deno #21)
uki00a
0
180
Discover Metal 4
rei315
2
110
『自分のデータだけ見せたい!』を叶える──Laravel × Casbin で複雑権限をスッキリ解きほぐす 25 分
akitotsukahara
2
610
“いい感じ“な定量評価を求めて - Four Keysとアウトカムの間の探求 -
nealle
1
2k
Google Agent Development Kit でLINE Botを作ってみた
ymd65536
2
220
ニーリーにおけるプロダクトエンジニア
nealle
0
730
ruby.wasmで多人数リアルタイム通信ゲームを作ろう
lnit
3
350
Hypervel - A Coroutine Framework for Laravel Artisans
albertcht
1
110
Flutterで備える!Accessibility Nutrition Labels完全ガイド
yuukiw00w
0
140
なぜ適用するか、移行して理解するClean Architecture 〜構造を超えて設計を継承する〜 / Why Apply, Migrate and Understand Clean Architecture - Inherit Design Beyond Structure
seike460
PRO
3
730
Featured
See All Featured
How to Create Impact in a Changing Tech Landscape [PerfNow 2023]
tammyeverts
53
2.8k
The Art of Delivering Value - GDevCon NA Keynote
reverentgeek
15
1.5k
The Psychology of Web Performance [Beyond Tellerrand 2023]
tammyeverts
48
2.9k
ReactJS: Keep Simple. Everything can be a component!
pedronauck
667
120k
Imperfection Machines: The Place of Print at Facebook
scottboms
267
13k
Distributed Sagas: A Protocol for Coordinating Microservices
caitiem20
331
22k
Rails Girls Zürich Keynote
gr2m
94
14k
Measuring & Analyzing Core Web Vitals
bluesmoon
7
500
Creating an realtime collaboration tool: Agile Flush - .NET Oxford
marcduiker
30
2.1k
The Cult of Friendly URLs
andyhume
79
6.5k
VelocityConf: Rendering Performance Case Studies
addyosmani
331
24k
Designing for Performance
lara
609
69k
Transcript
(advanced) Redis Advanced is between brackets because we don’t claim
to be advanced users, we just have gained a lot of experience
Jan De Poorter @defv
Redis?
NoSQL
:-D
No, but srsly
Redis is an in-memory key-value data-structure server
in memory with “best effort” persistence
Data structure server Strings SET, SETNX, GET, INCR, DECR, APPEND,
... Hashes HSET, HGET, HGETALL, HDEL, HLEN, ... Lists LPUSH, LPOP, LINDEX, LLEN, LRANGE, ... Sets & Sorted sets SADD, SPOP, SMEMBERS, SDIFF, ZADD, ...
some libraries Ruby redis-rb (gem) hiredis-rb (gem) Node redis (npm)
hiredis (npm)
Q-Music Our use case was the API for the new
Q-Music website and the iPhone and Android applications.
High volume
Pub-Sub
BG jobs with Sidekiq
Some do’s
Serialize values
2 class QApi::Redis 3 class << self 4 def redis
5 @redis ||= Redis.new(config) 6 end ... 181 def set(key, data) 182 redis.set key, to_json(data) 183 end 184 185 def get(key) 186 from_json redis.get(key) 187 end 188 216 private 217 def from_json(result) 218 case result 219 when Array 220 result.map { |r| from_json(r) } 221 when Hash 222 result 223 when nil 224 nil 225 else 226 MultiJson.decode(result) 227 end 228 rescue MultiJson::DecodeError 229 result 230 end 231 232 def to_json(data) 233 MultiJson.encode(data) 234 end 262 end 263 end
Save references
# Write LPUSH plays {“id”: 42, ”title”:”99 Bottles of Rum”}
LPUSH plays {“id”: 49, ”title”:”The Drunken Sailor”} LPUSH plays {“id”: 42, ”title”:”99 Bottles of Rum”} # Read LRANGE plays 0 -1 don’t do this
it’s fine with 100 items
but becomes huge with 90 000 items
or 1 000 000 Justin Bieber mentions ;-)
# Write SET tracks:42 {“id”: 42, ”title”:”99 Bottles of Rum”}
SET tracks:49 {“id”: 42, ”title”:” The Drunken Sailor”} LPUSH plays tracks:42 LPUSH plays tracks:49 LPUSH plays tracks:42 # Read LRANGE plays 0 -1 MGET tracks:42 tracks:49 do this instead
or in Ruby 82 def list_from_references(list, options) 83 references =
redis.lrange list, 84 options[:start], options[:stop] 85 if references.any? 86 from_json redis.mget(*references) 87 else 88 [] 89 end 90 end
Some don’t’s
RDB vs AOF
RDB does fork()
doubling memory usage
Our dataset was 4GB
We had ~8GB of memory
No BGSAVE’s for 4 days
:-(
appendonly yes
Slow(er) start-up
Can be optimized
Monitoring
data:~$ redis-cli redis > INFO redis_version:2.4.16 ... connected_clients:152 ... used_memory:2744963744
used_memory_human:2.56G used_memory_peak:6150240632 used_memory_peak_human:5.73G ... changes_since_last_save:9576 last_save_time:1360661315 redis >
PUBLISH & SUBSCRIBE overload
WebSocket clients
1 client == 1 connection == 1 subscription
Works perfect in development
Works perfect in staging
but in production...
1 new event
sent to 3500 connected clients
Takes about 0.3 seconds
Up to 4 messages per second
:-(
Move logic to websocket server
:-(
1 type of msg == 1 subscription
:-)
MULTI / EXEC
> MULTI OK > RENAME bl:1 bld:1 QUEUED > RENAME
bl:2 bld:2 QUEUED > EXEC 1) OK 2) OK
Works great on 1000’s of commands
Not so much on 1 million commands...
Don’t exceed ~10k commands in 1 transaction
master/slave
no library support
DIY
We didn’t
Limited connections
Redis < 2.6
/* Max number of fd supported */ #define AE_SETSIZE (1024*10)
No more then ~10k connections allowed
Redis >= 2.6
The sky is the limit
(actually, the linux max FD is the limit)
Questions?
