The Twelve-Factor App

Kristian Glass
September 20, 2014

The Twelve-Factor App

http://12factor.net/ - what, why, how

From PyCon UK 2014

Kristian Glass

September 20, 2014
Tweet

More Decks by Kristian Glass

Other Decks in Programming

Transcript

  1. The Twelve-Factor App
    Kristian Glass
    @doismellburning
    http://www.doismellburning.co.uk/talks/django12factor
    1

    View full-size slide

  2. •I do development
    •I do operations
    •I write code and care how
    it runs
    2

    View full-size slide

  3. What is Twelve Factor?
    “A methodology for building
    web apps”
    3

    View full-size slide

  4. Core Concept
    Clean interface between
    app and underlying
    system
    4

    View full-size slide

  5. #1
    One code repository,
    many deploys
    5

    View full-size slide

  6. #2
    Explicitly declare
    and isolate
    dependencies
    6

    View full-size slide

  7. So, virtualenv and
    requirements.txt
    ?
    7

    View full-size slide

  8. $ pip install -r requirements.txt!
    # …!
    Downloading/unpacking gevent!
    Running setup.py egg_info for package gevent!
    # …!
    gevent/libevent.h:9:19: error: event.h: No
    such file or directory!
    # …!
    error: command 'gcc-4.2' failed with exit
    status 1
    8

    View full-size slide

  9. So how?
    •Containers/VMs
    •OS packages (ish)
    9

    View full-size slide

  10. #3
    Read config from
    the environment
    10

    View full-size slide

  11. What is Config?
    Everything likely to vary
    between deploys
    11

    View full-size slide

  12. Config Examples
    •Service URLs (Database, mail,
    etc.)
    •Service credentials
    •Debug flag
    12

    View full-size slide

  13. Why do this?
    •Separation of responsibility
    •Language and framework
    independent
    •Avoid leakage of secrets
    13

    View full-size slide

  14. But config files?
    •Apps read from environment
    •Environment may come from
    files
    14

    View full-size slide

  15. How do I populate the
    environment?
    • foreman
    • honcho
    • envdir
    • supervisor
    • bash scripts
    • and more…
    15

    View full-size slide

  16. Using Django?
    https://github.com/doismellburning/
    django12factor
    16

    View full-size slide

  17. #4
    Treat backing services
    as attached resources
    17

    View full-size slide

  18. Attached Resources
    •No distinction between
    local/external resources
    •Loose coupling
    18

    View full-size slide

  19. #5
    Distinct build/
    release/run stages
    19

    View full-size slide

  20. Build / Release?
    build :: Code ->
    Executable!
    !
    release :: Config ->
    Executable -> Release
    Artefact
    20

    View full-size slide

  21. Example: Building a Django Project
    $ git clone!
    $ virtualenv!
    $ pip install -r
    requirements.txt!
    $ manage.py collectstatic !
    $ fpm
    21

    View full-size slide

  22. Releases
    •New config? New release
    •New code? New build,
    new release
    22

    View full-size slide

  23. Run stage
    As simple as possible
    23

    View full-size slide

  24. Why?
    •Do hard work in advance
    •Optimise the common
    case
    24

    View full-size slide

  25. #6
    Run as stateless
    process(es)
    25

    View full-size slide

  26. Stateless Processes
    •Persist data to external services
    •Assume nothing about RAM/
    disk
    •No sticky sessions
    26

    View full-size slide

  27. #7
    Export services via
    port binding
    27

    View full-size slide

  28. What does this mean?
    •Your app should offer its services
    by some protocol on some port
    •Self-contained services: run and
    go
    28

    View full-size slide

  29. #8
    Scale out with
    processes
    29

    View full-size slide

  30. Process model
    •More load? More processes
    •Background jobs? Worker processes
    •Don’t daemonise, that’s manager’s
    job
    30

    View full-size slide

  31. #9
    Start quickly, stop
    nicely
    31

    View full-size slide

  32. Start quickly, stop nicely
    •Disposable apps
    •Auto-scale easily
    •Deploy quickly and easily
    32

    View full-size slide

  33. #10
    Keep environments
    as similar as possible
    33

    View full-size slide

  34. Three prod/dev gaps
    •Time gap
    •People gap
    •Tools gap
    34

    View full-size slide

  35. Time gap
    •“Production is weeks
    behind dev”
    •Solution: Deploy more
    35

    View full-size slide

  36. People gap
    •“Developers write
    code, Ops run it”
    •Solution: DevOps
    36

    View full-size slide

  37. Tool gap
    •“It works on my machine”
    •Solution: Use the same
    tools everywhere
    37

    View full-size slide

  38. #11
    Treat logs as event
    streams
    38

    View full-size slide

  39. Logs as event streams
    •No logfile / routing / storage
    handling
    •Spit logs out to stdout
    •One event, one line
    39

    View full-size slide

  40. #12
    Admin tasks as part
    of your app
    40

    View full-size slide

  41. What does that mean?
    •Django management commands are a
    great example
    •$ python manage.py syncdb!
    •No private folders of “useful snippets”
    •Keep them with the app
    41

    View full-size slide

  42. Recap
    1. One codebase
    2. Dependencies
    3. Config in environment
    4. Backing Services
    5. Build, release, run
    6. Stateless processes
    7. Port binding
    8. Scale with processes
    9. Disposability
    10. Dev/prod parity
    11. Logs as event stream
    12. Admin processes
    42

    View full-size slide

  43. Recap
    •It does not matter what
    language
    •It does not matter what
    framework
    43

    View full-size slide

  44. Questions?
    http://www.doismellburning.co.uk/talks/django12factor
    44

    View full-size slide
