TinyGo: Getting the upper hen (GopherCon 2022)

TinyGo is a Go compiler for small places such as microcontroller or web. Join Donia for a demo and see live temperature and humidity data displayed on dashboards.

Starting from a basic understanding of what TinyGo is, you will learn how to:

- Use the appropriate driver for your hardware
- Retrieve data from a thermometer and humidity captor
- Communicate with your microcontroller using WiFi
- Build a dashboard with temperature and humidity data
- Check that your hens are doing well, from your couch

And, if you still do not want to adopt chickens, you can let your creativity flow by building your own project, using our favourite language.

Talk/Attendee Level: All Attendees
________

Join the #tinygo channel on Gophers slack and find the code on my github:
https://github.com/doniacld/tiny-hen

Transcript

1. TinyGo: Getting the
   upper hen
   GopherCon, Chicago - 08 October 2022
   Donia Chaiehloudj
   Powder
   @doniacld


   View Slide

2. My ideal hen house 01
   What is TinyGo?
   What’s the plan?
   Demo time
   Things I learned
   02
   03
   04
   05
   06
   What’s next?


   View Slide

3. MY IDEAL HEN HOUSE
   01. My ideal hen house
   ● Monitor my hen house
   ○ temperature
   ○ humidity
   ● Visualise the metrics


   View Slide

4. THE GOAL
   01. My ideal hen house


   View Slide

5. — TinyGo website at tinygo.org
   TinyGo is a compiler for
   the Go programming
   language but for
   smaller kinds of
   systems.


   View Slide

6. SMALL SYSTEMS
   02. What is TinyGo?
   ● Microcontrollers (86 boards)
   ● WebAssembly
   ● Tiny CLI


   View Slide

7. TINYGO COMPILER: HISTORY
   https://aykevl.nl/
   02. What is TinyGo?
   Ayke exploring
   existing projects
   01/02/19
   TinyGo 0.1
   TinyGo used by
   the industry
   TinyGo adopted by
   users for side projects
   03/02/19
   FOSDEM
   @aurelievache


   View Slide

8. TINYGO COMPILER: ANOTHER GO COMPILER
   The LLVM Project is a collection of modular and reusable compilers.
   https://tinygo.org/docs/concepts/compiler-internals/pipeline/
   02. What is TinyGo?


   View Slide

9. GO VS TINYGO: HELLO WORLD SIZE
   ❯ go build -o bin/helloworld-go hello/hello_world.go
   ❯ tinygo build -o bin/helloworld-tinygo hello/hello_world.go
   ❯ ll bin/
   total 5120
   -rwxr-xr-x 1 doniacld staff 1.8M Aug 14 18:40 helloworld-go
   -rwxr-xr-x 1 doniacld staff 29K Aug 14 18:41 helloworld-tinygo
   go version go1.18.5 darwin/arm64
   0.24.0 darwin/amd64 (using go version go1.18.5 and LLVM version 14.0.0)
   02. What is TinyGo?


   View Slide

10. FLASH COMMAND
    tinygo flash -target= .go
    1. Compiles the program on your computer
    2. Writes it on chip memory (ROM)
    3. Runs it on the chip
    NB: Built-in led is blinking while writing
    02. What is TinyGo?


    View Slide

11. FLASH COMMAND
    tinygo flash -target= .go
    1. Compiles the program on your computer
    2. Writes it on chip memory (ROM)
    3. Runs it on the chip
    NB: Built-in led is blinking while writing
    02. What is TinyGo?


    View Slide

12. LET’S DEBUG
    02. What is TinyGo?


    View Slide

13. DEBUGGING TOOLS
    ❯ ll /dev/tty.*
    02. What is TinyGo?
    Serial port: connector by which a device sends data one bit at a time.


    View Slide

14. https://github.com/doniacld/tinygo-discovery/blob/main/hello/hello_gophers.go
    https://github.com/doniacld/tinygo-discovery/blob/main/utils/read_serial.go
    READ FROM THE SERIAL PORT
    02. What is TinyGo?
    ❯ go run hello_gophers.go
    2022/08/14 18:23:14 Hi Chicago! What's up GopherCon US 2022?
    2022/08/14 18:23:15 Hi Chicago! What's up GopherCon US 2022?
    ❯ go run utils/read_serial.go -port /dev/cu.usbmodem1401
    1970/01/01 00:00:03 Hi Chicago! What's up GopherCon US 2022?
    1970/01/01 00:00:04 Hi Chicago! What's up GopherCon US 2022?


    View Slide

15. ELECTRICAL CIRCUIT
    03. What’s the plan?
    Arduino Nano 33 IoT DHT22
    DATA
    GROUND
    VCC


    View Slide

16. THE BIG PICTURE
    03. What’s the plan?


    View Slide

17. PRODUCTION ENVIRONMENT
    03. What’s the plan?


    View Slide

18. USEFUL TINYGO PACKAGES
    https://github.com/doniacld/tinygo-discovery/blob/main/tiny-hen/main.go
    03. What’s the plan?


    View Slide

19. MEASUREMENT PSEUDO CODE
    https://github.com/doniacld/tinygo-discovery/blob/main/tiny-hen/main.go
    03. What’s the plan?


    View Slide

20. THE GOOD OLD GO WEB SERVER
    https://xkcd.com/910/
    03. What’s the plan?


    View Slide

21. GO WEB SERVER: PROMETHEUS GAUGE DEFINITIONS
    https://github.com/doniacld/tiny-hen/blob/main/cmd/prommetric/metric.go
    03. What’s the plan?


    View Slide

22. INFRASTRUCTURE
    03. What’s the plan?


    View Slide

23. Demo time
    https://tinyurl.com/gopher-praying-sticker


    View Slide

24. TINYGO CHEAT SHEET
    05. Things I learned
    ● TinyGo: Go compiler for small places
    ● Flash: tinygo flash -target= main.go
    ● TinyGo drivers examples are a treasure chest 💎
    ● Hardware recommendations: samd21/samd51 board, or an rp2040 or TinyGo Playground
    ● Enter the IoT world with your current skills and your IDE (VS code plugin, GoLand plugin)


    View Slide

25. WHAT’S NEXT?
    ● Use async protocol (MQTT)
    ● Long range WiFi board (LoRaWAN)
    ● Deploy in the cloud
    ● Add a fox detection system
    https://tinyurl.com/gopher-far-west-sticker
    06. What’s next?


    View Slide

26. https://github.com/doniacld/tinygo-discovery
    https://github.com/doniacld/tiny-hen
    @doniacld


    View Slide

27. https://github.com/doniacld/tinygo-discovery
    https://github.com/doniacld/tiny-hen
    @doniacld
    Thank you 🐣
