Nodevember 2015: The dirty secrets of building large, highly available, scalable HTTP APIs

Most HTTP APIs sites show how to implement the GET /hello sample and provide a list of links that developers can use to get more information about different topics.
While those are definitely useful, large APIs that are to be consumed by other developers span a range of cross-cutting concerns that is hard to be aware of when you start to build them. In this talk we will go over some of these concerns, such as authentication, authorization, documentation, validation, rate limiting, geo-redundancy, and no downtime deployments, and will provide specific examples based on what we do at Auth0.

Transcript

1. The dirty little secrets of building large, highly available, scalable HTTP APIs by @dschenkelman
2. Why? var  express  =  require('express');   var  app  =  express();   app.get('/',  function  (req,  res)  {      res.send('Hello  World!');   });   var  server  =  app.listen(3000,  function  ()  {      var  host  =  server.address().address;      var  port  =  server.address().port;      console.log('Example  app  listening  at  http://%s:%s',  host,  port);   });
3. Developers
4. Evolution
5. Pillars
6. Validation
7. enabled:  true
8. enabled:  1
9. enabled:  1.0
10. enabled:  "false"
11. JSON Schemas "enabled":  {   "type":  "boolean"   }
12. Errors for developers {      "statusCode":  400,      "error":  "Bad  Request",      "message":  "Payload  validation  error:   'Expected  type  boolean  but  found  type   string'  on  property  enabled   (<code>true</code>  if  the  rule  is   enabled,  <code>false</code>   otherwise).",      "errorCode":  "invalid_body"   }
13. ratify const  ZSchemaErrors  =  require('z-­‐schema-­‐errors');   const  errorReporters  =  ['headers',  'query',  'path',   'payload'].reduce((current,  part)  =>  {      current[part]  =  ZSchemaErrors.init({/*...*/});      return  current;   },  {});   plugins.push({      register:  require('ratify'),      options:  {          errorReporters:  errorReporters,          /*...*/      }   });
14. Documentation
15. Old API Explorer
16. Auto-generate docs
17. Swagger
18. Leverage validation "enabled":  {   "type":  "boolean",   "description":  "<code>true</code>  if   the  connection  is  enabled,   <code>false</code>  (default)  otherwise"   }
19. Customize
20. AuthN & AuthZ
21. Token Exchange API Client API Server 1. Credentials 2. API Token 3. Requests
22. Granular Security
23. Decentralized Issuance
24. Expiration Control
25. Debuggability
26. JSON Web Token JWT
27. Authenticate For all endpoints
28. Authorize Per endpoint
29. Blacklisting
30. T-shirt time
31. Stress tests
32. Devops Stress
33. What to do…
34. Rate Limiting
35. Token Bucket
36. limitd #port  to  listen  on   port:  9001   #db  path   db:  /var/limitd/database   #define  the  bucket  types   buckets:      customers:          size:  10          per_second:  10
37. 429 X-­‐RateLimit-­‐Limit   Maximum  amount   X-­‐RateLimit-­‐Remaining   How  many  there  are  left   X-­‐RateLimit-­‐Reset   When  will  bucket  be  full  again
38. patova plugins.push({      register:  require('patova'),      options:  {          event:  'onPostAuth',  //  when  to  perform  the  limit  check          type:  'tenant',  //  bucket          address:  env.LIMITD_SERVER,          extractKey:  function(request,  reply,  done){              const  key  =  request.auth.credentials.__tenant;              done(null,  key);          }      }   });
39. Geo Redundancy
40. Data Center Failure
41. Natural Disasters
42. Cloud Provider Failure
43. Our Setup
44. Our Setup App Instances MongoDB Elastic Search App Instances MongoDB Elastic Search MongoDB
45. The switch
46. Changes
47. Experiments
48. feature-change const  feature_change  =  require('feature-­‐change');   var  options  =  {      expected:  function(cb){              mongo_search(mongo_opts,  cb);      },      actual:  function(cb){              es_search(es_opts,  cb);      },      logAction:  function(current_result,  new_result){              //  invoked  when  there  is  a  difference  in  the  results              //  (useful  for  logging)      }   };   feature_change(options,  function(err,  result){          //  this  is  the  original  callback  you  were  using  for  mongo          //  err  and  result  always  come  from  mongo_search   });
49. Iron out differences
50. Wrap up
51. Shipping is important
52. Remember: evolve
53. Validation & Docs • http://json-schema.org • http://swagger.io • https://auth0.com/docs/api/v2 (example of branded auto-generated docs) • https://github.com/mac-/ratify
54. AuthN & AuthZ • https://tools.ietf.org/html/rfc7519 • http://jwt.io/ • https://auth0.com/blog/2014/12/02/using-json- web-tokens-as-api-keys/ • https://auth0.com/blog/2015/03/10/blacklist-json- web-token-api-keys/ • https://github.com/auth0/hapi-auth-jwt
55. Rate limiting • http://tools.ietf.org/html/rfc6585 • https://github.com/limitd • https://github.com/dschenkelman/patova
56. Geo Redundancy • http://highscalability.com/blog/2014/12/1/auth0- architecture-running-in-multiple-cloud-providers- and-r.html • https://auth0.com/availability-trust • http://docs.mongodb.org/master/tutorial/deploy- geographically-distributed-replica-set/
57. Feature Changes • http://zachholman.com/talk/move-fast-break- nothing/ • https://auth0.com/blog/2015/10/27/feature- changes-at-auth0/ • https://github.com/dschenkelman/feature- change
58. Thanks https://github.com/dschenkelman/api-secrets-talk @dschenkelman
