AWS Cloud Forensics & Incident Response

Transcript

1. AWS Cloud Forensics &
   Incident Response
   TUSHAR VERMA


   View Slide

2. whoami
   2
   DevSecOps Engineer at Shaadi.com
   Synack Red Team Member


   View Slide

3. Incident
   Response in
   Cloud
   3


   View Slide

4. Aspects of AWS incident response
   Preparation Operations
   Post-incident
   activity


   View Slide

5. 9/3/20XX Presentation Title 5


   View Slide

6. Design Goals of Cloud Response
   Establish response
   objectives
   01
   Respond using the
   cloud
   02
   Know what you have
   and what you need
   03
   Use redeployment
   mechanisms
   04
   Automate where
   possible
   05
   Choose scalable
   solutions
   06
   Learn and improve
   your process
   07


   View Slide

7. Cloud security incident domains
   SERVICE DOMAIN INFRASTRUCTURE DOMAIN APPLICATION DOMAIN


   View Slide

8. AWS SERVICES
   FOR INCIDENT
   RESPONSE


   View Slide

9. Aws cloudtrail
   Log/Identify all API actions performed within an
   account
   • Who performed it(Principal type, Source IP/Service, User
   Agent)
   • When it occurred(Date/Time)
   • Where it occurred(Region)
   • What occurred(API action performed)
   • Which resource(s) were affected(with configuration/parameter
   info)
   • Result(s) of action(success/error with associated result info


   View Slide

10. Amazon
    CLoudwatch
    Log target/ aggregation point for
    monitoring/querying/alerting on various
    logs:
    • Instance(System) Performance Metrics
    • OS/Application Logs
    • AWS Service Logs(Cloudtrail, GuardDuty, Security
    Hub
    • VPC flow logs


    View Slide

11. AWS Config
    • Logs resource configurations(changes)
    over time
    • Can also record instance OS/Software
    Configuration changes and updates
    • Leverage these logs to discover, map,
    track(and alert on) AWS resource
    relationships and changes in your
    account


    View Slide

12. VPC Flow Logs
    Netflow(ish) type network flow
    logs
    Collects and delivers network flow
    log record in aggression intervals


    View Slide

13. Other aws services for IR
    Amazon GuardDuty
    Amazon Security
    Hub
    Amazon Detective


    View Slide

14. Aws Incident
    response lifecycle


    View Slide

15. Preparation
    PEOPLE
    -Train security operations staff on AWS
    Process
    -Develop an incident response plan & strategy
    -Run drills & automate simulations where possible
    Technology
    -Build AWS accounts for security operations and log archive
    -Create read only and break glass roles for access to AWS accounts


    View Slide

16. Detection &
    Analysis
    DETECTION
    -Setup CloudTrail organisation trail
    -Enable amazon GuardDuty and aws security hub with security
    operations account as delegated admin
    -Monitor the GuardDuty & Security Hub findings
    ANALYSIS
    -Query CloudTrail logs with aws athena(or with your SIEM)
    -Leverage aws detective for investigations and triaging findings


    View Slide

17. Containment,
    Eradication &
    recovery
    CONTAINMENT
    -Disable/rotate IAM credentials
    -EC2 isolation through security groups and NACLs
    -System backup through snapshots
    Eradication
    -Leverage AWS Systems Manager to patch systems and run commands
    Recovery
    -Provision new infrastructure or modify NACLs/SGs back to original state
    Note: These are just an example


    View Slide

18. Post incident
    DOCUMENTATION
    -Complete answers to who, what,
    where, why, and How
    LESSONS LEARNED
    -Review IR processes and
    effectiveness with stakeholder


    View Slide

19. AWS CLOUD
    forensics


    View Slide

20. What is Cloud Forensics
    • Cloud Forensics can be defined as the application of
    computer forensics principles and procedures in a
    cloud computing environment.


    View Slide

21. Cloud Forensic Process Flow
    IDENTIFICATION EVIDENCE COLLECTION EXAMINATION &
    ANALYSIS
    PRESERVATION PRESENTATION &
    REPORTING


    View Slide

22. Significant Log Sources
    Cloudtrail
    Cloudtrail
    Insights
    Cloudwatch Logs GuardDuty
    VPC Flow Logs S3 Server Access Route53
    Load Balancer
    Logs


    View Slide

23. Isolation……
    Create a separate forensic
    VPC for compromised
    resources.
    This forensic VPC should
    not be connected to any
    other VPCs.
    Enable a logging
    mechanism, such as VPC
    flow logs
    Create Quarantine and
    Forensic Security Groups
    Create specific IAM roles
    with read-only access to
    resources
    Create a snapshot of the
    EC2 instance
    Store all log data to a
    separate S3 bucket with S3
    Object Lock and MFA delete
    Take a memory dump of the
    instance


    View Slide

24. Cloud forensics challenges
    • Accessibility of logs
    • Physical inaccessibility
    • Volatility of data
    • Identification of evidence at client side
    • Dependence of CSP trust


    View Slide

25. Get in touch at
    Twitter: @e11i0t_4lders0n
    LinkedIn: /in/tushars25
    Instagram: @e11i0t_4lders0n__
    Email: tushar.infosec@gmail.com


    View Slide

26. Thank you


    View Slide
