Abstract:
Capybara has allowed us to build complex and ambitious applications with the confidence that everything comes together in the user experience we're targeting. As the capabilities of the web have grown, interactions and behavior in our applications have become more complex and harder to test. Our tests become coupled to CSS selectors, fail intermittently, take longer and our confidence dwindles. In this talk, I'll go over best practices for working with a large Capybara test suite and dig into APIs and options we can use to handle complex apps such as a chat app not written in Ruby.

Given at RailsConf 2015. Slides are edited down from the version used for the presentation (i.e. adding captions and combining slides).

Transcript

1. Ambitious Capybara Eduardo Gutierrez github.com/ecbypi | @ecbypi
2. Brought to you by…
4. Little Known Facts • Capybaras (Hydrochoerus hydrochaeris) originate from South America • Pronunciation of the name is under heavy debate: capybara vs capybeara
5. Advanced Facts • Capybaras are semi-aquatic • They can roam over areas spanning 25 acres • Very friendly animals, many people have them as pets
6. Balancing Act Readability Performance Maintainability
7. Balancing Act Maintainability VS Readability • Some may argue these are very similar • Imagine a large DSL that is very readable but potentially hard to maintain (i.e. Rails’ routing DSL) • On the other hand, imagine well factored code that encompasses a complex problem, but still requires a stiff learning curve
8. Keeping it Ambitious Readability Performance Maintainability Our Ideal
9. Keeping it Ambitious Readability Performance Maintainability Sweet Spot
10. And for capybara? Readability • Written as stories a user or developer new to the project could understand Maintainability • Growable / refactor-able to introduce new patterns and features Performance • Fast feedback, whether on CI on a developer machine or iterating on a feature
11. Readability • Avoid raw selectors in feature specs as much as possible, especially CSS classes • Leverage capybara DSL as much as possible by using semantic markup • Is the user story described by your feature actually readable as a user story
12. Readability Let’s refactor a feature test scenario "sign in the user" do create(:user, email: "test@fake-example.com") visit sign_in_page fill_in "user_email", with: "test@fake-example.com" fill_in "user_password", with: "password" click_button "Sign In” expect(current_path).to eq profile_path end
13. Readability scenario "sign in the user" do create(:user, email: "test@fake-example.com") visit sign_in_page fill_in "user_email", with: "test@fake-example.com" fill_in "user_password", with: "password" click_button "Sign In” expect(current_path).to eq profile_path end These tests are using DOM IDs to fill in inputs
14. Readability = simple_form_for :user, url: :sign_in do |f| = f.input :email, label: false, placeholder: "email..." = f.input :password, label: false, placeholder: "password..." = f.button :submit, value: "Sign In” Template removes labels in favor of the placeholders
15. Readability = simple_form_for :user, url: :sign_in do |f| = f.input :email, label_html: { class: "hide" }, placeholder: "email..." = f.input :password, label_html: { class: "hide" }, placeholder: "password..." = f.button :submit, value: "Sign In” Can use a utility class to hide them instead
16. Readability scenario "sign in the user" do create(:user, email: "test@fake-example.com") visit sign_in_page fill_in "Email", with: "test@fake-example.com" fill_in "Password", with: "password" click_button "Sign In" expect(current_path).to eq profile_path end Tests now are now more readable
17. Readability Randomized with seed 36225 . Finished in 3.26 seconds (files took 3.43 seconds to load) 1 example, 0 failures Tests still pass
18. Readability scenario "sign in the user", :js do create(:user, email: "test@fake-example.com") visit sign_in_page fill_in "Email", with: "test@fake-example.com" fill_in "Password", with: "password" click_button "Sign In" expect(current_path).to eq profile_path end Test will fail when using `js: true` because Capybara ignores hidden elements in these tests
19. Readability Randomized with seed 3941 F Failures: 1) Login page can sign in the user Failure/Error: fill_in Capybara::ElementNotFound: Unable to find field "Email" # ./spec/features/sign_in_spec:6:in `block (2 levels) in <top (required)>' Finished in 3.72 seconds (files took 3.24 seconds to load) 1 example, 1 failure
20. Readability = simple_form_for :user, url: :sign_in do |f| = f.input :email, label_html: { class: "accessible-hide" }, placeholder: "email..." = f.input :password, label_html: { class: "accessible-hide" }, placeholder: "password..." = f.button :submit, value: "Sign In” Use an accessible method of hiding elements
21. Readability .accessible-hide { position: absolute !important; height: 1px; width: 1px; overflow: hidden; clip: rect(1px 1px 1px 1px); /* IE6, IE7 */ clip: rect(1px, 1px, 1px, 1px); } This will be visible to screen readers and capybara http://snook.ca/archives/html_and_css/hiding-content-for-accessibility
22. Readability Randomized with seed 7651 . Finished in 2.75 seconds (files took 3.28 seconds to load) 1 example, 0 failures
23. Readability Let’s work on another test: scenario "search users by birthdate", :js do create( :user, name: "John", birthdate: Time.zone.local(1985, 10, 30) ) visit search_path find(".open-datepicker").click # fill in datepicker with Wed, Oct 30, 1985 click_button "Search" expect(page).to have_css ".search-result:contains('John')" end
24. Readability scenario "search users by birthdate", :js do create( :user, name: "John", birthdate: Time.zone.local(1985, 10, 30) ) visit search_path find(".open-datepicker").click # fill in datepicker with Wed, Oct 30, 1985 click_button "Search" expect(page).to have_css ".search-result:contains('John')" end ASIDE: We’ll fill this in later
25. Readability .input %label{ for: "birthday" } Birthday of Contact %input{ type: :hidden, id: "birthday" } %input{ type: :text, disabled: "" } %button.hide{ type: :button } %button{ type: :button } Simplified datepicker markup
26. Readability scenario "search users by birthdate", :js do create( :user, name: "John", birthdate: Time.zone.local(1985, 10, 30) ) visit search_path find(".open-datepicker").click # fill in datepicker with Wed, Oct 30, 1985 click_button "Search" expect(page).to have_css ".search-result:contains('John')" end Using hard-coded CSS / Sizzle selectors
27. Readability scenario "search users by birthdate", :js do create( :user, name: "John", birthdate: Time.zone.local(1985, 10, 30) ) visit search_path # MAYBE ? Unfortunately no... click_button ".open-datepicker" # fill in datepicker with Wed, Oct 30, 1985 click_button "Search" expect(page).to have_css ".search-result:contains('John')" end
28. Readability # XPath::HTML.button(locator) # Trimmed and reformatted def button(locator) locator = locator.to_s button = descendant(:input)[ attr(:type).one_of('submit', 'reset', 'image', 'button') ] [ attr(:id).equals(locator) | attr(:value).is(locator) | attr(:title).is(locator) ] # ... end `title` is a valid attribute to lookup buttons
29. Readability .input %label{ for: "birthday" } Birthday of Contact %input{ type: :hidden, id: "birthday" } %input{ type: :text, disabled: "" } %button.hide{ title: "Clear Input", type: :button } %button{ title: "Open Calendar", type: :button }
30. Readability scenario "search users by birthdate", :js do create( :user, name: "John", birthdate: Time.zone.local(1985, 10, 30) ) visit search_path click_button "Open Calendar" # fill in datepicker with Wed, Oct 30, 1985 click_button "Search" expect(page).to have_css ".search-result:contains('John')" end
31. Readability scenario "search users by birthdate", :js do create( :user, name: "John", birthdate: Time.zone.local(1985, 10, 30) ) visit search_path click_button "Open Calendar" # fill in datepicker with Wed, Oct 30, 1985 click_button "Search" expect(page).to have_css ".search-result", text: "John" end capybara queries can use `:text` option instead
32. Readability %ul - @results.each do |result| %li.search-result = result.name What do we have to hook into here besides tag names or CSS classes?
33. Readability How about attributes? According to the HTML5 spec: • Custom data attributes are intended to store custom data private to the page or application, for which there are no more appropriate attributes or elements. data-
34. Readability Lets add our own custom selectors for elements: Capybara.add_selector(:models_element) do xpath { |name| XPath.css("[data-collection='#{name}']") } end Capybara.add_selector(:model_element) do xpath { |name| XPath.css("[data-resource='#{name}']") } end
35. Readability And define helpers to make them easier to use: module ResourceDomElements def model_element(model_name, options = {}) find(:model_element, model_name, options) end def have_model_element(model_name, options) have_selector :model_element, model_name, options end end
36. Readability And metaprogram even more painless helpers module ResourceDomElements RESOURCES = %w( search_result ) RESOURCES.each do |model_name| class_eval <<-METHODS, __FILE__, __LINE__ + 1 def #{model_name}_element(options = {}) model_element('#{model_name}', options) end def have_#{model_name}_element(options = {}) have_model_element('#{model_name}', options) end METHODS end end
37. Readability %ul - @results.each do |result| %li.search-result{ data: { resource: :search_result } } = result.name
38. Readability scenario "search users by birthdate", :js do create( :user, name: "John", birthdate: Time.zone.local(1985, 10, 30) ) visit search_path click_button "Open Calendar" # fill in datepicker with Wed, Oct 30, 1985 click_button "Search" expect(page).to have_search_result_element text: "John" end
39. Filling in the Datepicker scenario "search users by birthdate", :js do create( :user, name: "John", birthdate: Time.zone.local(1985, 10, 30) ) visit search_path click_button "Open Calendar" # fill in datepicker with Wed, Oct 30, 1985 click_button "Search" expect(page).to have_search_result_element text: "John" end
40. Filling in the Datepicker Click right table cell Change selects
41. Filling in the Datepicker
42. Filling in the Datepicker
43. Capybara::Element find(:button, "Submit") # => Capybara::Element
44. Capybara::Element def click_button(locator, options={}) find(:button, locator, options).click end
45. Filling in the Datepicker find( 'select.ui-datepicker-year option', text: birthdate.year.to_s ).select_option
46. Filling in the Datepicker find( 'select.ui-datepicker-month option', text: birthdate.strftime('%b') ).select_option
47. Filling in the Datepicker find( a.ui-state-default:not(.ui-priority-secondary)', text: birthdate.day.to_s, match: :first ).click
48. Filling in the Datepicker scenario "search users by birthdate", :js do birthdate = Time.zone.local(1985, 10, 30) create(:user, name: "John", birthdate: birthdate) visit search_path click_button "Open Calendar" within "#ui-datepicker-div" do find( 'select.ui-datepicker-year option', text: birthdate.year.to_s ).select_option find( 'select.ui-datepicker-month option', text: birthdate.strftime('%b') ).select_option find( 'a.ui-state-default:not(.ui-priority-secondary)', text: birthdate.day.to_s, match: :first ).click end click_button "Search" expect(page).to have_search_result_element text: "John" end
49. Maintainability scenario "search users by birthdate", :js do birthdate = Time.zone.local(1985, 10, 30) create(:user, name: "John", birthdate: birthdate) visit search_path click_button "Open Calendar" within "#ui-datepicker-div" do find( 'select.ui-datepicker-year option', text: birthdate.year.to_s ).select_option find( 'select.ui-datepicker-month option', text: birthdate.strftime('%b') ).select_option find( 'a.ui-state-default:not(.ui-priority-secondary)', text: birthdate.day.to_s, match: :first ).click end click_button "Search" expect(page).to have_search_result_element text: "John" end All in one test, likely to be used elsewhere
50. Maintainability scenario "search users by birthdate", :js do birthdate = Time.zone.local(1985, 10, 30) create(:user, name: "John", birthdate: birthdate) visit search_path choose_date birthdate, from: "Birthday of Contact" click_button "Search" expect(page).to have_search_result_element text: "John" end
51. Maintainability module DatepickerSteps def choose_date(date, options) within "[data-datepicker-input]", text: options[:from] do click_button "Open Calendar" end within "#ui-datepicker-div" do find( 'select.ui-datepicker-year option', text: date.year.to_s ).select_option find( 'select.ui-datepicker-month option', text: date.strftime('%b') ).select_option find( 'a.ui-state-default:not(.ui-priority-secondary)', text: date.day.to_s, match: :first ).click end end end Extract another steps module
52. Maintainability scenario "search users by birthdate", :js do birthdate = Time.zone.local(1985, 10, 30) create(:user, name: "John", birthdate: birthdate) visit search_path choose_date birthdate, from: "Birthday of Contact" click_button "Search" expect(page).to have_search_result_element text: “John" expect(page).to have_datepicker_input( "Birthday of Contact", with: birthdate ) end
53. Maintainability module DatepickerSteps def have_datepicker_input(label_text, options = {}) with = options[:with].strftime("%a, %B %d, %Y") have_field label_text, with: value, disabled: true end end
54. Maintainability module DatepickerSteps def have_datepicker_input(label_text, options = {}) with = options[:with].strftime("%a, %B %d, %Y") have_field label_text, with: value, disabled: true end end
55. Capybara::Selector Capybara.add_selector(:field) do xpath { |locator| XPath::HTML.field(locator) } filter(:checked, boolean: true) { |node, value| not(value ^ node.checked?) } filter(:unchecked, boolean: true) { |node, value| (value ^ node.checked?) } filter(:disabled, default: false, boolean: true) { |node, value| not(value ^ node.disabled?) } filter(:with) { |node, with| node.value == with.to_s } filter(:type) do |node, type| if ['textarea', 'select'].include?(type) node.tag_name == type else node[:type] == type end end describe do |options| desc, states = "", [] desc << " of type #{options[:type].inspect}" if options[:type] desc << " with value #{options[:with].to_s.inspect}" if options.has_key?(:with) states << 'checked' if options[:checked] || (options.has_key?(:unchecked) && ! options[:unchecked]) states << 'not checked' if options[:unchecked] || (options.has_key?(:checked) && ! options[:checked]) states << 'disabled' if options[:disabled] desc << " that is #{states.join(' and ')}" unless states.empty? desc end end https://github.com/jnicklas/capybara/blob/master/lib/capybara/selector.rb#L114-L137
57. Performance within helper • Use to scope multiple assertions in the same part of the DOM • Avoids searching through the same parts of the DOM multiple times within
58. Performance - scenario "add new address from the addresses listing", :js do visit addresses_page expect(page).to have_address_element count: 30 click_button "Add Address" fill_in "Street", with: "77 Mass Ave" fill_in "City", with: "Cambridge" select "MA", from: "State" fill_in "Postal Code", with: "02139" select "United States", from: "Country" click_button "Add Address" expect(page).to have_address_element text: "77 Mass Ave" end within
59. Performance - scenario "add new address from the addresses listing", :js do visit addresses_page expect(page).to have_address_element count: 30 click_button "Add Address" within modal_dialogue(text: "New Address") do fill_in "Street", with: "77 Mass Ave" fill_in "City", with: "Cambridge" select "MA", from: "State" fill_in "Postal Code", with: "02139" select "United States", from: "Country" click_button "Add Address" end expect(page).to have_address_element text: "77 Mass Ave" end within
60. Be wary of elements not found in current scope within modal_dialogue(text: "New Address") do fill_in "Street", with: "77 Mass Ave" fill_in "City", with: "Cambridge" select "MA", from: "State" fill_in "Postal Code", with: "02139" select "United States", from: "Country" choose_date 2.months.from_now, from: "Expires At" # => raises `Capybara::ElementNotFound` click_button "Add Address" end Performance - within date picker does not exist in modal_dialogue
61. Performance Write features as QA scripts • Avoid single test for each happy and sad path • Setup / teardown of each test can be expensive • Most useful on pages with a significant amount of markup (~1200+)
62. Performance - QA Scripts def language_fluency_form find(".new_language_ability") end scenario "allows viewing, adding, editing and removing them" do spanish = create(:language, name: "Spanish") create(:language, name: "French") applicant = create(:applicant) create( :language_ability, applicant: applicant, language: spanish, ability: 3 ) sign_in_applicant applicant visit language_abilities_path expect(current_path).to eq language_abilities_path within language_ability_element(text: "Spanish") do expect(page).to have_content "3" click_button "Edit" expect(page).to have_select "Change Fluency", selected: "3" expect(page).to have_button "Save" click_button "Cancel" expect(page).not_to have_select "Change Fluency" expect(page).to have_button "Edit" expect(page).to have_button "Delete" end within language_fluency_form do expect(page).to have_css( "option[disabled]", text: "Spanish", visible: false ) click_button "Add Language" expect(page).to have_css( ".input-error-message", count: 2, text: I18n.t("errors.messages.blank") ) chosen_select "French", from: "Language" choose "4" click_button "Add Language" expect(page).to have_chosen_select "Language", selected: "" expect(page).not_to have_field "Fluency" expect(page).to have_css( "option[disabled]", text: "French", visible: false ) end within language_ability_element(text: "French") do expect(page).to have_content "4" click_button "Edit" select "5", from: "Change Fluency" click_button "Save" expect(page).not_to have_select "Change Fluency" expect(page).to have_content "5" end within language_ability_element(text: "Spanish") do click_button "Delete" A single integration test for a page of the app
63. Performance - QA Scripts scenario "allows viewing, adding, editing and removing them" do spanish = create(:language, name: "Spanish") create(:language, name: "French") applicant = create(:applicant) create( :language_ability, applicant: applicant, language: spanish, ability: 3 ) sign_in_applicant applicant visit language_abilities_path expect(current_path).to eq language_abilities_path Create seed records
64. Performance - QA Scripts scenario "allows viewing, adding, editing and removing them" do spanish = create(:language, name: "Spanish") create(:language, name: "French") applicant = create(:applicant) create( :language_ability, applicant: applicant, language: spanish, ability: 3 ) sign_in_applicant applicant visit language_abilities_path expect(current_path).to eq language_abilities_path Create seed records Visit page under test
65. Performance - QA Scripts within language_ability_element(text: "Spanish") do expect(page).to have_content "3" click_button "Edit" expect(page).to have_select "Change Fluency", selected: "3" expect(page).to have_button "Save" click_button "Cancel" expect(page).not_to have_select "Change Fluency" expect(page).to have_button "Edit" expect(page).to have_button "Delete" end Check editing existing record
66. Performance - QA Scripts within language_ability_element(text: "Spanish") do expect(page).to have_content "3" click_button "Edit" expect(page).to have_select "Change Fluency", selected: "3" expect(page).to have_button "Save" click_button "Cancel" expect(page).not_to have_select "Change Fluency" expect(page).to have_button "Edit" expect(page).to have_button "Delete" end Ensure cancel works Check editing existing record
67. Performance - QA Scripts within language_fluency_form do expect(page).to have_css( "option[disabled]", text: "Spanish", visible: false ) click_button "Add Language" expect(page).to have_css( ".input-error-message", count: 2, text: I18n.t("errors.messages.blank") ) chosen_select "French", from: "Language" choose "4" click_button "Add Language" expect(page).to have_chosen_select "Language", selected: "" expect(page).not_to have_field "Fluency" expect(page).to have_css( "option[disabled]", text: "French", visible: false ) end Ensure selected languages are disabled Make sure client-side validations run
68. Performance - QA Scripts within language_fluency_form do expect(page).to have_css( "option[disabled]", text: "Spanish", visible: false ) click_button "Add Language" expect(page).to have_css( ".input-error-message", count: 2, text: I18n.t("errors.messages.blank") ) chosen_select "French", from: "Language" choose "4" click_button "Add Language" expect(page).to have_chosen_select "Language", selected: "" expect(page).not_to have_field "Fluency" expect(page).to have_css( "option[disabled]", text: "French", visible: false ) end Ensure selected languages are disabled Make sure client-side validations run Check form is updated correctly
69. Advanced Capybara::Window enables working between multiple windows within a single spec • SOA applications spread out across different domains • Client-side applications built in two repositories
70. Advanced scenario "ensure removed inventory is removed from the API", :js do CMS_URL = "http://localhost:3000" API_URL = "http://localhost:3001" cms_window = window_opened_by do visit CMS_URL create_product!(name: "Foo") end store_window = window_opened_by do visit API_URL expect(page).to have_product_element text: "Foo" end within_window cms_window do within product_element(text: "Foo") do click_button "Out of Stock" end end within_window store_window do visit API_URL expect(page).not_to have_product_element text: "Foo" end end
71. Resources • Initial inspiration: http://www.elabs.se/blog/51- simple-tricks-to-clean-up-your-capybara-tests • `ResourceDomElements`: https://gist.github.com/ ecbypi/3151818#file-resource_dom_elements-rb • Selectors API / options: https://github.com/jnicklas/ capybara/blob/master/lib/capybara/ selector.rb#L114-L242
