Securing Front Ends at Scale: Paving our way to a post-XSS world

Jen Ozmen Aaron Shim Aug 2024 Securing Front Ends at
Scale: Paving our Way to a Post-XSS World

• Software Engineer @ Google • Focusing on deploying security
mitigations to Google’s web services Intro Jen

• Software Engineer @ Google • Focus on Web Security
adoption • Previously: Google Workspace, GCP Intros - Aaron

Quick intro to Cross Site Scripting (XSS) Content Security Policy
(CSP) and its different flavors Securing your apps against XSS at scale Perfect Types and the Post-XSS world Call to Action 01 02 03 04 05 Agenda

Cross Site Scripting (XSS) 01

XSS 35.6% Non-web issues 49.1% Mobile app vulnerabilities Business logic
(authorization) Server/network misconfigurations ... Google Vulnerability Reward Program payouts

• Risk: user input gets interpreted as code What is
XSS? <p>Description: foobar</p> <p>Description: <script>alert(1337)</script></p> <div onclick="code()"> data <script> code() </script> </div> • Malicious scripts are injected into otherwise benign and trusted websites

• Allows the attacker to take control of the account
of the logged in user– the attacker can do anything that the victim can What is XSS? • Client-side Remote code execution (RCE)

DOM XSS is a client-side XSS variant caused by many
JavaScript APIs not being secure by default. • User controlled strings get converted into code • Many dangerous and error-prone DOM sinks like innerHTML Example: https://example.com/#<img src=x onerror=alert('xss')> How does XSS happen? var foo = location.hash.slice(1); document.querySelector('#foo').innerHTML = foo;

CSP and its different flavors 02

Before we begin… 2.1

Nonce-only CSP 2.2a

Content-Security-Policy: script-src 'nonce-{random}' 'report-sample'; object-src 'none'; base-uri 'none'; report-uri <your_reporting_endpoint>

Hash-based CSP 2.2b

Content-Security-Policy: script-src 'sha256-<base64-encoded-hash>' 'report-sample'; object-src 'none'; base-uri 'none'; report-uri <your_reporting_endpoint>
web.dev/articles/strict-csp#choose-hash

<!DOCTYPE html> <html> <head> <title>Page Title</title>  <script src="a.js"></script> <script src="b.js"></script> </head> <body> <h1>HTML Page</h1> <p>With some text</p> </body> </html> <!DOCTYPE html> <html> <head> <meta http-equiv="Content-Security-Policy" content="script-src 'strict-dynamic' 'sha256-NKwxejNe15ufvZg7F00NO4xNKmrnza4Z7HGPhGjt7/c=' https: 'unsafe-inline';object-src 'none';base-uri 'self';"> <title>Page Title</title>  <link rel="preload" href="a.js" as="script" /> <link rel="preload" href="b.js" as="script" />  <script> var scripts = ['a.js','b.js']; scripts.forEach(function(scriptUrl) { var s = document.createElement('script'); s.src = scriptUrl; s.async = false; // preserve execution order. document.body.appendChild(s); }); </script> </head> <body> <h1>HTML Page</h1> <p>With some text</p> </body> </html>

Trusted Types 2.3

Element.innerHTML HTMLFormElement.action window.open HTMLAreaElement.href HTMLMediaElement.src HTMLFrameElement.src HTMLSourceElement.src HTMLTrackElement.src HTMLInputElement.src location.assign
location.href document.write HTMLButtonElement.formAction HTMLFrameElement.srcdoc HTMLImageElement.src HTMLEmbededElement.src HTMLScriptElement.textContent HTMLInputElement.formAction HTMLScriptElement.innerText HTMLBaseElement.href

The idea behind Trusted Types Require strings for passing (HTML,
URL, script URL) values to DOM sinks. HTML string Script string Script URL string becomes

The idea behind Trusted Types Require strings for passing (HTML,
URL, script URL) values to DOM sinks. typed objects HTML string Script string Script URL string TrustedHTML TrustedScript TrustedScriptURL becomes

Content-Security-Policy: require-trusted-types-for 'script'; report-uri <your_reporting_endpoint>

var foo = location.hash.slice(1); document.querySelector('#foo').innerHTML = foo;

if(self.trustedTypes && self.trustedTypes.createPolicy){ const myTrustedHTMLPolicy = trustedTypes.createPolicy('my-trusted-html-policy', { createHTML: (input)
=> { // Sanitize the input here if needed return DOMPurify.sanitize(input); } }); element.innerHTML = myTrustedHTMLPolicy.createHTML(value)); } else { element.innerHTML = value; } element.innerHTML = DOMPurify.sanitize(input, { RETURN_TRUSTED_TYPE: true });

Securing your apps against XSS 03

Before we begin… bughunters.google.com/blog/5896512897417216/a-recipe-for-scaling-security

Use Frameworks Enforce Early Rely on the Right Tools Be
Mindful of Third-Party Dependencies 01 02 03 04 Tactics

Frameworks, frameworks, frameworks! 3.1

Frameworks with context-aware templating and secure-by-default feature support Avoids backend-introduced
XSS Take the burden of security off of the feature developer

Enforce Early! 3.2

// https://vitejs.dev/guide/api-plugin.html#configureserver const myPlugin = () => ({ name: 'configure-server',
configureServer(server) { server.middlewares.use((req, res, next) => { res.setHeader('Content-Security-Policy', "require-trusted-types-for 'script'"); res.setHeader('Content-Security-Policy', "script-src ‘sha256-RFWPLDbv2BY+rCkDzsE+0fr8ylGr2R2faWMhq4lfEQc=’"); next(); }) }, })

github.com/google/strict-csp www.npmjs.com/package/strict-csp

const s = new StrictCsp(htmlString); // Refactor sourced scripts so
that we can set a strict hash-based CSP s.refactorSourcedScriptsForHashBasedCsp(); // Hash inline scripts from this html file, if there are any const scriptHashes = s.hashAllInlineScripts(); // Generate a strict CSP as a string const strictCsp = StrictCsp.getStrictCsp(scriptHashes, { enableBrowserFallbacks: true, }); // Set this CSP via a meta tag s.addMetaTag(strictCsp); const htmlStringWithCsp = s.serializeDom(); Source: github.com/google/strict-csp/blob/main/strict-csp/README.md

configureServer(server) { server.middlewares.use((req, res, next) => { res.setHeader('Content-Security-Policy', "require-trusted-types-for 'script'"); res.setHeader('Content-Security-Policy', "script-src ‘sha256-RFWPLDbv2BY+rCkDzsE+0fr8ylGr2R2faWMhq4lfEQc=’"); next(); }) }, })

configureServer(server) { server.middlewares.use((req, res, next) => { let data = ''; res.on('data', (chunk) => { data += chunk; // Accumulate the response data }); res.on('end', () => { const s = new StrictCsp(data); // Refactor sourced scripts so that we can set a strict hash-based CSP s.refactorSourcedScriptsForHashBasedCsp(); // Hash inline scripts from this html file, if there are any const scriptHashes = s.hashAllInlineScripts(); // Generate a strict CSP as a string const strictCsp = StrictCsp.getStrictCsp(scriptHashes, { enableBrowserFallbacks: true, }); // Send the CSP as response headers res.setHeader('Content-Security-Policy', "require-trusted-types-for 'script'"); res.setHeader('Content-Security-Policy', strictCsp); // Send the modified data at once const htmlStringWithCsp = s.serializeDom(); res.end(htmlStringWithCsp); next(); }); }) }, }) Note: Speciﬁcally for Vite, this works better with https://vitejs.dev/guide/api-plugin#transformindexhtml but this example shows how the previous two slides can be combined in a framework-agnostic way

Tools 3.3

Tools for Understanding Features / Violations 3.3a

csp-evaluator.withgoogle.com/ chrome.google.com/webstore/detail/fjoham lofnakbnbfjkohkbdigoodcejf

UNDER ACTIVE DEVELOPMENT

Tools for Refactoring: APIs that steer you correctly 3.3b

[ { "filePath": "[...]/index.js", "messages": [ { "ruleId": "safety-web/trusted-types-checks", "message":
"[ban-element-innerhtml-assignments] Assigning directly to Element#innerHTML can result in XSS vulnerabilities.", "line": 15, "column": 1, "messageId": "ban_element_innerhtml_assignments", "endLine": 15, "endColumn": 48 } ] } ] github.com/google/safety-web web.dev/articles/trusted-types#ﬁx-violations element.innerHTML = value;

element.innerHTML = value; import {sanitizeHtml} from 'safevalues'; import {safeElement} from
'safevalues/dom'; ... const safeHtmlValue = sanitizeHtml(value); ... safeElement.setInnerHtml(element, safeHtmlValue); github.com/google/safevalues/blob/main/src/dom/xss-d om-remediation.md

Third-Party Dependencies 04

The Post-XSS World 04

Secure by Default Frameworks Abstract away challenging security decisions away
from the web developer Opinionated Wrapper APIs Guide developers towards safer coding patterns github.com/google/sa fevalues Static Analysis Check for potentially dangerous patterns and warn developers as early in the feedback loop as possible github.com/google/sa fety-web Runtime Enforcement Guarantee that insecure code will not run for the client web.dev/articles/strict -csp web.dev/articles/trust ed-types A Pipeline of Protections (devs) (users)

from the web developer Opinionated Wrapper APIs Guide developers towards safer coding patterns github.com/google/sa fevalues Static Analysis Check for potentially dangerous patterns and warn developers as early in the feedback loop as possible Runtime Enforcement Guarantee that no insecure DOM APIs will run on the client A Pipeline of Protections (devs) (users)

from the web developer New Web APIs? Is it possible to provide safe-by-default APIs as a part of the web platform? Static Analysis Check for potentially dangerous patterns and warn developers as early in the feedback loop as possible Runtime Enforcement Guarantee that no insecure DOM APIs will run on the client Trusted Types v2 / Perfect Types (devs) (users)

A part of a bigger picture! blog.google/technology/safety-security/tackling-cybersecurity-vulnerabilities-through-secu re-by-design/ research.google/pubs/secure-by-design-at-google/

Conclusion & Call to Action 05
