  1. Life of a document in Elasticsearch
    Alexander Reelsen - @spinscale
    Boaz Leskes - @bleskes

    View Slide

  2. { } CC-BY-ND 4.0
    Agenda
    2
    Life of a document in Elasticsearch

    View Slide

  3. { } CC-BY-ND 4.0
    Agenda
    3
    Life of a document in Elasticsearch
    How, when and where is a document
    stored/processed in Elasticsearch?

    View Slide

  4. { } CC-BY-ND 4.0
    About us
    Core developer & Marvel lead
    4
    Core & Shield developer
    Boaz Leskes
    Alexander Reelsen

    View Slide

  5. { } CC-BY-ND 4.0
    Exhibit A: A JSON document
    {
    "name" : "Elasticsearch - The definitive guide",
    "pages" : 721, "isbn13" : "978-1449358549",
    "authors" : [ "Clinton Gormley" , "Zachary Tong" ],
    "publish_date" : "2015/01/31",
    "category" : "IT > Search Engines",
    "description" : "Whether you need full-text search
    or real-time analytics...",
    }
    5

    View Slide

  6. { } CC-BY-ND 4.0
    Exhibit A: A JSON document
    PUT /books/book/978-1449358549
    {
    "name" : "Elasticsearch - The definitive guide",
    "pages" : 721, "isbn13" : "978-1449358549",
    "authors" : [ "Clinton Gormley" , "Zachary Tong" ],
    "publish_date" : "2015/01/31",
    "category" : "IT > Search Engines",
    "description" : "Whether you need full-text search
    or real-time analytics...",
    }
    6

    View Slide

  7. { } CC-BY-ND 4.0
    Indexing a document
    7
    Elasticsearch
    Client
    PUT /books/book/978-1449358549
    200 OK

    View Slide

  8. { } CC-BY-ND 4.0
    Indexing a document
    8
    Client
    PUT /books/book/978-1449358549
    200 OK
    ?

    View Slide

  9. { } CC-BY-ND 4.0
    Receiving: Where to store it?
    9
    node  1
    C
    PUT /books/book/978-1449358549
    {
    }

    View Slide

  10. { } CC-BY-ND 4.0
    Receiving: Where to put it?
    10
    node  1
    C
    PUT /books/book/978-1449358549
    {
    }
    hash(978-1449358549) % number_of_shards

    View Slide

  11. { } CC-BY-ND 4.0
    Receiving: Where to put it?
    11
    node  1
    C
    PUT /books/book/978-1449358549
    {
    }
    node  2

    View Slide

  12. { } CC-BY-ND 4.0
    Next step: Analysis
    12
    Each field is put into the inverted index
    {
    "name" : "Elasticsearch - The definitive guide",
    "pages" : 721, "isbn13" : "978-1449358549",
    "authors" : [ "Clinton Gormley" , "Zachary Tong" ],
    "publish_date" : "2015/01/31",
    "category" : "IT > Search Engines",
    "description" : "Whether you need full-text search
    or real-time analytics...",
    }

    View Slide

  13. { } CC-BY-ND 4.0
    Analysis
    13
    Each field is put into the inverted index
    Clinton Gormley ->
    Input Tokenization Analysis
    Clinton  Gormley [Clinton,  Gormley] [clinton,  gormley]
    Zachary  Tong [Zachary,  Tong] [zachary,  tong]

    View Slide

  14. { } CC-BY-ND 4.0
    Analysis
    14
    Resulting in a postings list
    Clinton Gormley ->
    Value Document  ID
    clinton 1
    gormley 1
    tong 1
    zachary 1

    View Slide

  15. { } CC-BY-ND 4.0
    Lucene at work: Field by field
    {
    "name" : "Elasticsearch - The definitive guide",
    "pages" : 721, "isbn13" : "978-1449358549",
    "authors" : [ "Clinton Gormley" , "Zachary Tong" ],
    "publish_date" : "2015/01/31",
    "category" : "IT > Search Engines",
    "description" : "Whether you need full-text search
    or real-time analytics...",
    }
    15

    View Slide

  16. { } CC-BY-ND 4.0
    Special case: _all field
    {
    "name" : "Elasticsearch - The definitive guide",
    "pages" : 721, "isbn13" : "978-1449358549",
    "authors" : [ "Clinton Gormley" , "Zachary Tong" ],
    "publish_date" : "2015/01/31",
    "category" : "IT > Search Engines",
    "description" : "Whether you need full-text search
    or real-time analytics...",
    }
    16

    View Slide

  17. { } CC-BY-ND 4.0
    Special case: _source field
    {
    "name" : "Elasticsearch - The definitive guide",
    "pages" : 721, "isbn13" : "978-1449358549",
    "authors" : [ "Clinton Gormley" , "Zachary Tong" ],
    "publish_date" : "2015/01/31",
    "category" : "IT > Search Engines",
    "description" : "Whether you need full-text search
    or real-time analytics...",
    }
    17

    View Slide

  18. { } CC-BY-ND 4.0
    Multifields
    PUT /books/book/_mapping
    {
    "book" : {
    "properties" : {
    "authors": {
    "type": "string", "analyzer": "standard",
    "fields": { "raw": { "type": "string", "index": “not_analyzed" } }
    }
    }
    }
    }
    18
    Sorting & Aggregations

    View Slide

  19. { } CC-BY-ND 4.0
    Multifields
    19
    Resulting in multiple postings lists
    Field: authors Value Document  ID
    clinton 1
    gormley 1
    tong 1
    zachary 1
    Value Document  ID
    Clinton  Gormley 1
    Zachary  Tong 1
    Field: authors.raw

    View Slide

  20. { } CC-BY-ND 4.0
    Completion suggester
    • Auto-complete, search-as-you-type
    • Data structure is stored on disk on indexing, then loaded
    into memory
    20

    View Slide

  21. { } CC-BY-ND 4.0
    Term vectors
    • Handy when hit highlighting huge documents
    • An index of a single document
    • Allows to easily find sorted unique terms as well as
    original positions and offsets
    21

    View Slide

  22. { } CC-BY-ND 4.0
    Buffering documents
    22
    buffer
    buffer

    View Slide

  23. { } CC-BY-ND 4.0
    Buffering documents
    23
    buffer
    buffer

    View Slide

  24. { } CC-BY-ND 4.0
    Buffering documents
    24
    buffer segment

    View Slide

  25. { } CC-BY-ND 4.0
    Elasticsearch refresh
    25
    buffer
    translog

    View Slide

  26. { } CC-BY-ND 4.0
    Elasticsearch refresh
    26
    buffer
    translog
    segment

    View Slide

  27. { } CC-BY-ND 4.0
    Indexing a document
    27
    buffer
    translog

    View Slide

  28. { } CC-BY-ND 4.0
    Elasticsearch refresh
    28
    buffer
    translog
    segment

    View Slide

  29. { } CC-BY-ND 4.0
    Elasticsearch flush
    29
    buffer
    translog
    segment
    fsync

    View Slide

  30. { } CC-BY-ND 4.0
    Where are we now?
    • Document received via network
    • Document received on the correct node
    • Document analyzed, stored in translog & buffer
    • Client is still waiting for a response
    30

    View Slide

  31. { } CC-BY-ND 4.0
    Replication on indexing
    31
    Document level replication
    node  1
    b0 b1
    node  2
    b1 b0
    node  3
    b1 b0
    C

    View Slide

  32. { } CC-BY-ND 4.0
    Replication on indexing
    32
    Document level replication
    node  1
    b0 b1
    node  2
    b1 b0
    node  3
    b1 b0
    C

    View Slide

  33. { } CC-BY-ND 4.0
    Replication on indexing
    33
    Document level replication
    node  1
    b0 b1
    node  2
    b1 b0
    node  3
    b1 b0
    C

    View Slide

  34. { } CC-BY-ND 4.0
    Replication on indexing
    34
    Document level replication
    node  1
    b0 b1
    node  2
    b1 b0
    node  3
    b1 b0
    C

    View Slide

  35. { } CC-BY-ND 4.0
    Replication on indexing
    35
    Document level replication
    node  1
    b0 b1
    node  2
    b1 b0
    node  3
    b1 b0
    C

    View Slide

  36. { } CC-BY-ND 4.0
    Replication on indexing
    36
    Document level replication
    node  1
    b0 b1
    node  2
    b1 b0
    node  3
    b1 b0
    C
    Document got written 6 times!
    HTTP/1.1 200 OK

    View Slide

  37. { } CC-BY-ND 4.0
    Searching
    37

    View Slide

  38. { } CC-BY-ND 4.0
    Searches: Collecting node
    38
    node  1
    b0 b1
    node  2
    b1 b0
    node  3
    b1 b0
    C
    query hits node
    GET /books/book/_search?q=elasticsearch

    View Slide

  39. { } CC-BY-ND 4.0
    Searches: Collecting node
    39
    node  1
    b0 b1
    node  2
    b1 b0
    node  3
    b1 b0
    C
    QUERY phase executed on each shard

    View Slide

  40. { } CC-BY-ND 4.0
    Searches: Collecting node
    40
    node  1
    b0 b1
    node  2
    b1 b0
    node  3
    b1 b0
    C
    QUERY results are sorted

    View Slide

  41. { } CC-BY-ND 4.0
    Searches: Collecting node
    41
    node  1
    b0 b1
    node  2
    b1 b0
    node  3
    b1 b0
    C
    FETCH phase executed

    View Slide

  42. { } CC-BY-ND 4.0
    Searches: Collecting node
    42
    node  1
    b0 b1
    node  2
    b1 b0
    node  3
    b1 b0
    C
    FETCH results are returned

    View Slide

  43. { } CC-BY-ND 4.0
    Searches: Collecting node
    43
    node  1
    b0 b1
    node  2
    b1 b0
    node  3
    b1 b0
    C

    View Slide

  44. { } CC-BY-ND 4.0
    Search types
    • Full text search
    – Goes on disk, access segments, execute search
    • Aggregation
    – Loads data into memory from segments, executes on
    in-memory data structure
    44

    View Slide

  45. { } CC-BY-ND 4.0
    Memory: Fielddata
    GET /books/book/_search?search_type=count
    {
    "aggs" : {
    "author-top10" : {
    "terms" : {
    "field" : “authors.raw"
    }
    }
    }
    }
    45

    View Slide

  46. { } CC-BY-ND 4.0
    Memory: Fielddata
    46
    This does not work for aggs
    Clinton Gormley ->
    Term Document  ID
    clinton 1
    gormley 1
    tong 1
    zachary 1

    View Slide

  47. { } CC-BY-ND 4.0
    Memory: Fielddata
    47
    Uninverting the index from a raw field
    Document  ID Term
    1 Clinton  Gormley,  Zachary  Tong
    Term Document  ID
    Clinton  Gormley 1
    Zachary  Tong 1

    View Slide

  48. { } CC-BY-ND 4.0
    Memory: Fielddata
    • Used for sorting & aggregations
    • All values of a field are loaded into the heap
    • Per segment data structure
    • Can take a lot of memory
    48

    View Slide

  49. { } CC-BY-ND 4.0
    Doc values
    49
    On-Disk vs. in-memory
    PUT /books/book/_mapping
    {
    "book" : {
    "properties" : {
    "authors": {
    "type": "string", "analyzer": "standard",
    "fields": { "raw": { "type": "string", "index": "not_analyzed",
    "doc_values" : true } }
    }
    }
    }
    }

    View Slide

  50. { } CC-BY-ND 4.0
    Where are we now?
    • Original source is sent to collecting node during queries
    • Document lives in a segment as part of a shard/index
    • Document fields live in memory as part of fielddata
    • Segments are put into the filesystem cache by the OS
    50

    View Slide

  51. { } CC-BY-ND 4.0
    Scaling your cluster
    51

    View Slide

  52. { } CC-BY-ND 4.0
    Relocation
    52
    Let’s offload our fast node
    node  1
    0P
    STARTED
    1P
    STARTED
    node  2
    node.box_type: ssd node.box_type: hdd
    PUT /books/
    {
    "settings" : {
    “index.routing.allocation.include.box_type" : “ssd"
    }
    }

    View Slide

  53. { } CC-BY-ND 4.0
    Relocation
    53
    Let’s offload our fast node
    node  1
    0P
    STARTED
    1P
    STARTED
    node  2
    node.box_type: ssd node.box_type: hdd
    PUT /books/_settings
    {
    "index.routing.allocation.include.box_type" : "hdd"
    }

    View Slide

  54. { } CC-BY-ND 4.0
    Relocation
    54
    Let’s offload our fast node
    node  1
    0P
    STARTED
    1P
    RELOCATING
    node  2
    node.box_type: ssd node.box_type: hdd
    PUT /books/_settings
    {
    "index.routing.allocation.include.box_type" : "hdd"
    }
    1P
    INITIALIZING

    View Slide

  55. { } CC-BY-ND 4.0
    Relocation
    55
    Let’s offload our fast node
    node  1
    0P
    STARTED
    node  2
    node.box_type: ssd node.box_type: hdd
    PUT /books/_settings
    {
    "index.routing.allocation.include.box_type" : "hdd"
    }
    1P
    STARTED

    View Slide

  56. { } CC-BY-ND 4.0
    Relocation
    56
    Let’s offload our fast node
    node  1
    0P
    RELOCATING
    node  2
    node.box_type: sdd node.box_type: hdd
    PUT /books/_settings
    {
    "index.routing.allocation.include.box_type" : "hdd"
    }
    1P
    STARTED
    1P
    INITIALIZING

    View Slide

  57. { } CC-BY-ND 4.0
    Relocation
    57
    Let’s offload our fast node
    node  1 node  2
    node.box_type: ssd node.box_type: hdd
    PUT /books/_settings
    {
    "index.routing.allocation.include.box_type" : "hdd"
    }
    1P
    STARTED
    1P
    STARTED

    View Slide

  58. { } CC-BY-ND 4.0
    Relocation
    58
    What does RELOCATING mean?
    • Point in time snapshot is copied (segments)
    • Write operations occur and create new
    segments
    • All write operations are stored in translog
    • This translog is sent to the other node and
    replayed
    node  1
    0P
    STARTED
    1P
    RELOCATING

    View Slide

  59. { } CC-BY-ND 4.0
    Relocation
    • Process of copying whole shards across the cluster
    • Triggered by
    – adding/removing nodes from the cluster
    – exceeded disk thresholds
    – shard allocation filtering
    59

    View Slide

  60. { } CC-BY-ND 4.0
    Where are we now?
    • Relocation moves shards across the cluster
    • Document is duplicated by being copied from one node
    to another, as part of a segment
    • Segments are kept open until operation is complete
    60

    View Slide

  61. { } CC-BY-ND 4.0
    Backup your data
    61

    View Slide

  62. { } CC-BY-ND 4.0
    How to backup?
    62
    node  1
    b0 b1
    node  2
    b1 b0
    node  3
    b1 b0

    View Slide

  63. { } CC-BY-ND 4.0
    How to backup?
    63
    node  1
    b0 b1
    node  2
    b1 b0
    node  3
    b1 b0
    Repository
    S3, FS,
    HDFS
    Azure

    View Slide

  64. { } CC-BY-ND 4.0
    How to backup?
    64
    node  1
    b0 b1
    node  2
    b1 b0
    node  3
    b0 b1
    S3, FS,
    HDFS
    Azure C PUT /_snapshot/books/20150310
    b1
    b0

    View Slide

  65. { } CC-BY-ND 4.0
    Restore from a snapshot
    65
    node  1 node  2 node  3
    C POST /_snapshot/books/20150310/_restore
    b0
    b1

    View Slide

  66. { } CC-BY-ND 4.0
    Restore from a snapshot
    66
    node  1 node  2 node  3
    C POST /_snapshot/books/20150310/_restore
    b1
    b0 b1
    b0

    View Slide

  67. { } CC-BY-ND 4.0
    Deleting data
    67

    View Slide

  68. { } CC-BY-ND 4.0
    Index deletion
    68
    node  1
    b0 b1
    node  2
    b1 b0
    node  3
    b0 b1
    C
    DELETE /books/

    View Slide

  69. { } CC-BY-ND 4.0
    Index deletion
    69
    node  1 node  2 node  3
    C
    DELETE /books/

    View Slide

  70. { } CC-BY-ND 4.0
    Document deletion
    70
    node  1
    b0 b1
    node  2
    b1 b0
    node  3
    b0 b1
    C
    DELETE /books/book/978-1449358549

    View Slide

  71. { } CC-BY-ND 4.0
    Document deletion
    • Segments are immutable
    • Deletes are soft, document ids are added in a tombstone
    file to be marked for deletion
    • Actual deletion happens on next merge of that segment
    71

    View Slide

  72. { } CC-BY-ND 4.0
    Lucene merges
    72
    segment
    • Segments are created all the time when
    indexing data
    • Merging creates one big segment from
    several smaller ones

    View Slide

  73. { } CC-BY-ND 4.0
    Lucene merges
    73
    segment
    segment

    View Slide

  74. { } CC-BY-ND 4.0
    Lucene merges
    74
    segment
    segment
    segment

    View Slide

  75. { } CC-BY-ND 4.0
    Lucene merges
    75
    segment
    segment
    segment
    segment

    View Slide

  76. { } CC-BY-ND 4.0
    Lucene merges
    76
    segment
    segment
    segment
    segment document exists twice!

    View Slide

  77. { } CC-BY-ND 4.0
    Lucene merges
    77
    segment
    segment
    segment
    segment

    View Slide

  78. { } CC-BY-ND 4.0
    Lucene merges
    78
    segment

    View Slide

  79. { } CC-BY-ND 4.0
    Don’t be afraid of data duplication!
    79

    View Slide

  80. { } CC-BY-ND 4.0
    Don’t be afraid of data duplication!
    ... if you are aware of its lifecycle!
    80

    View Slide

  81. { }
    Thanks for listening!
    Questions?
    @bleskes
    @spinscale

    View Slide

  82. { }
    This work is licensed under the Creative Commons
    Attribution-NoDerivatives 4.0 International License.
    To view a copy of this license, visit:
    http://creativecommons.org/licenses/by-nd/4.0/
    or send a letter to:
    Creative Commons
    PO Box 1866
    Mountain View, CA 94042
    USA
    CC-BY-ND 4.0

    View Slide
