Asynchronous Data Streams with Kotlin Flow

Kotlin Flow is a declarative mechanism for working with asynchronous data streams that builds on top of Kotlin coroutines and structured concurrency. Kotlin Flows are doing the same revolution in simplicity for data streams that suspending functions did for data values.

In this talk we will discuss the challenges of working with asynchronous streams and how Kotlin Flows solve them. We will study the basics of Kotlin Flow design, see their typical usage patterns, peek behind the scenes and into some of the implementation details, checkout flow performance and see how they enable writing safe, reliable, and leak-free systems. We will also discuss how they relate to and incorporate ideas from reactive extensions and reactive streams, how they are similar and different, and how they can be used together.

Transcript

1. Copenhagen
   Denmark
   ASYNCHRONOUS
   DATA STREAMS WITH
   KOTLIN FLOW
   ROMAN ELIZAROV
   @relizarov
   Copenhagen
   Denmark


   View Slide

2. RECAP ON KOTLIN
   COROUTINES
   Kotlin Coroutines FTW


   View Slide

3. Callback hell before
   fun requestTokenAsync(): Promise { … }
   fun createPostAsync(token: Token, item: Item): Promise …
   fun processPost(post: Post) { … }
   fun postItem(item: Item) {
   requestTokenAsync()
   .thenCompose { token -> createPostAsync(token, item) }
   .thenAccept { post -> processPost(post) }
   }


   View Slide

4. Direct style with Kotlin Corou6nes
   suspend fun requestToken(): Token { … }
   suspend fun createPost(token: Token, item: Item): Post { … }
   fun processPost(post: Post) { … }
   suspend fun postItem(item: Item) {
   val token = requestToken()
   val post = createPost(token, item)
   processPost(post)
   }
   Like regular code


   View Slide

5. Direct style with Kotlin Coroutines
   suspend fun requestToken(): Token { … }
   suspend fun createPost(token: Token, item: Item): Post { … }
   fun processPost(post: Post) { … }
   suspend fun postItem(item: Item) {
   val token = requestToken()
   val post = createPost(token, item)
   processPost(post)
   }


   View Slide

6. Asynchronous yet sequen6al
   suspend fun requestToken(): Token { … }
   suspend fun createPost(token: Token, item: Item): Post { … }
   fun processPost(post: Post) { … }
   suspend fun postItem(item: Item) {
   val token = requestToken()
   val post = createPost(token, item)
   processPost(post)
   }


   View Slide

7. Asynchronous yet sequential
   suspend fun requestToken(): Token { … }
   suspend fun createPost(token: Token, item: Item): Post { … }
   fun processPost(post: Post) { … }
   suspend fun postItem(item: Item) {
   val token = requestToken()
   val post = createPost(token, item)
   processPost(post)
   }


   View Slide

8. Asynchronous yet sequential
   suspend fun requestToken(): Token { … }
   suspend fun createPost(token: Token, item: Item): Post { … }
   fun processPost(post: Post) { … }
   suspend fun postItem(item: Item) {
   val token = requestToken()
   val post = createPost(token, item)
   processPost(post)
   }


   View Slide

9. suspend fun foo(): Response One response
   suspend fun foo(): List Many responses


   View Slide

10. suspend fun foo(): List


    View Slide

11. suspend fun foo(): List = buildList {
    …
    }


    View Slide

12. suspend fun foo(): List = buildList {
    add(compute("A"))
    add(compute("B"))
    add(compute("C"))
    }


    View Slide

13. suspend fun foo(): List = buildList {
    add(compute("A"))
    add(compute("B"))
    add(compute("C"))
    }
    fun main() = runBlocking {
    val list = foo()
    for (x in list) println(x)
    }


    View Slide

14. suspend fun foo(): List = buildList {
    add(compute("A"))
    add(compute("B"))
    add(compute("C"))
    }
    fun main() = runBlocking {
    val list = foo()
    for (x in list) println(x)
    }


    View Slide

15. suspend fun foo(): List = buildList {
    add(compute("A"))
    add(compute("B"))
    add(compute("C"))
    }
    fun main() = runBlocking {
    val list = foo()
    for (x in list) println(x)
    }


    View Slide

16. main()
    foo()
    suspend fun foo(): List = buildList {
    add(compute("A"))
    add(compute("B"))
    add(compute("C"))
    }
    fun main() = runBlocking {
    val list = foo()
    for (x in list) println(x)
    }


    View Slide

17. main()
    foo()
    suspend fun foo(): List = buildList {
    add(compute("A"))
    add(compute("B"))
    add(compute("C"))
    }
    fun main() = runBlocking {
    val list = foo()
    for (x in list) println(x)
    }


    View Slide

18. main()
    foo() A
    suspend fun foo(): List = buildList {
    add(compute("A"))
    add(compute("B"))
    add(compute("C"))
    }
    fun main() = runBlocking {
    val list = foo()
    for (x in list) println(x)
    }


    View Slide

19. main()
    foo()
    suspend fun foo(): List = buildList {
    add(compute("A"))
    add(compute("B"))
    add(compute("C"))
    }
    fun main() = runBlocking {
    val list = foo()
    for (x in list) println(x)
    }
    B
    A


    View Slide

20. main()
    foo()
    suspend fun foo(): List = buildList {
    add(compute("A"))
    add(compute("B"))
    add(compute("C"))
    }
    fun main() = runBlocking {
    val list = foo()
    for (x in list) println(x)
    }
    C
    B
    A


    View Slide

21. main()
    foo()
    suspend fun foo(): List = buildList {
    add(compute("A"))
    add(compute("B"))
    add(compute("C"))
    }
    fun main() = runBlocking {
    val list = foo()
    for (x in list) println(x)
    }
    List
    C
    B
    A


    View Slide

22. main()
    foo()
    suspend fun foo(): List = buildList {
    add(compute("A"))
    add(compute("B"))
    add(compute("C"))
    }
    fun main() = runBlocking {
    val list = foo()
    for (x in list) println(x)
    }
    List
    C
    B
    A


    View Slide

23. main()
    foo()
    List
    A B C
    B C
    A
    suspend fun foo(): List = buildList {
    add(compute("A"))
    add(compute("B"))
    add(compute("C"))
    }
    fun main() = runBlocking {
    val list = foo()
    for (x in list) println(x)
    }


    View Slide

24. main()
    foo()
    List
    A B C
    B C
    A
    suspend fun foo(): List = buildList {
    add(compute("A"))
    add(compute("B"))
    add(compute("C"))
    }
    fun main() = runBlocking {
    val list = foo()
    for (x in list) println(x)
    }


    View Slide

25. Channel
    receive()
    send()


    View Slide

26. fun CoroutineScope.foo(): ReceiveChannel = produce {
    …
    }


    View Slide

27. fun CoroutineScope.foo(): ReceiveChannel = produce {
    send(compute("A"))
    send(compute("B"))
    send(compute("C"))
    }


    View Slide

28. fun CoroutineScope.foo(): ReceiveChannel = produce {
    send(compute("A"))
    send(compute("B"))
    send(compute("C"))
    }
    fun main() = runBlocking {
    val channel = foo()
    for (x in channel) println(x)
    }


    View Slide

29. fun CoroutineScope.foo(): ReceiveChannel = produce {
    send(compute("A"))
    send(compute("B"))
    send(compute("C"))
    }
    fun main() = runBlocking {
    val channel = foo()
    for (x in channel) println(x)
    }


    View Slide

30. fun CoroutineScope.foo(): ReceiveChannel = produce {
    send(compute("A"))
    send(compute("B"))
    send(compute("C"))
    }
    fun main() = runBlocking {
    val channel = foo()
    for (x in channel) println(x)
    }


    View Slide

31. main()
    foo()
    fun CoroutineScope.foo(): ReceiveChannel = produce {
    send(compute("A"))
    send(compute("B"))
    send(compute("C"))
    }
    fun main() = runBlocking {
    val channel = foo()
    for (x in channel) println(x)
    }


    View Slide

32. main()
    foo()
    fun CoroutineScope.foo(): ReceiveChannel = produce {
    send(compute("A"))
    send(compute("B"))
    send(compute("C"))
    }
    fun main() = runBlocking {
    val channel = foo()
    for (x in channel) println(x)
    }


    View Slide

33. main()
    foo()
    Channel
    fun CoroutineScope.foo(): ReceiveChannel = produce {
    send(compute("A"))
    send(compute("B"))
    send(compute("C"))
    }
    fun main() = runBlocking {
    val channel = foo()
    for (x in channel) println(x)
    }


    View Slide

34. main()
    foo()
    Channel
    fun CoroutineScope.foo(): ReceiveChannel = produce {
    send(compute("A"))
    send(compute("B"))
    send(compute("C"))
    }
    fun main() = runBlocking {
    val channel = foo()
    for (x in channel) println(x)
    }


    View Slide

35. main()
    foo()
    Channel
    fun CoroutineScope.foo(): ReceiveChannel = produce {
    send(compute("A"))
    send(compute("B"))
    send(compute("C"))
    }
    fun main() = runBlocking {
    val channel = foo()
    for (x in channel) println(x)
    }


    View Slide

36. main()
    foo()
    send
    Channel
    A
    fun CoroutineScope.foo(): ReceiveChannel = produce {
    send(compute("A"))
    send(compute("B"))
    send(compute("C"))
    }
    fun main() = runBlocking {
    val channel = foo()
    for (x in channel) println(x)
    }


    View Slide

37. main()
    foo()
    send
    Channel
    A
    A
    fun CoroutineScope.foo(): ReceiveChannel = produce {
    send(compute("A"))
    send(compute("B"))
    send(compute("C"))
    }
    fun main() = runBlocking {
    val channel = foo()
    for (x in channel) println(x)
    }


    View Slide

38. main()
    foo()
    send send
    Channel
    A
    A B
    fun CoroutineScope.foo(): ReceiveChannel = produce {
    send(compute("A"))
    send(compute("B"))
    send(compute("C"))
    }
    fun main() = runBlocking {
    val channel = foo()
    for (x in channel) println(x)
    }


    View Slide

39. main()
    foo()
    send send
    Channel
    A B
    A B
    fun CoroutineScope.foo(): ReceiveChannel = produce {
    send(compute("A"))
    send(compute("B"))
    send(compute("C"))
    }
    fun main() = runBlocking {
    val channel = foo()
    for (x in channel) println(x)
    }


    View Slide

40. main()
    foo()
    send send send
    Channel
    A B
    A B C
    fun CoroutineScope.foo(): ReceiveChannel = produce {
    send(compute("A"))
    send(compute("B"))
    send(compute("C"))
    }
    fun main() = runBlocking {
    val channel = foo()
    for (x in channel) println(x)
    }


    View Slide

41. main()
    foo()
    send send send
    Channel
    A B C
    A B C
    fun CoroutineScope.foo(): ReceiveChannel = produce {
    send(compute("A"))
    send(compute("B"))
    send(compute("C"))
    }
    fun main() = runBlocking {
    val channel = foo()
    for (x in channel) println(x)
    }


    View Slide

42. main()
    foo()
    send send send
    Channel
    A B C
    A B C
    fun CoroutineScope.foo(): ReceiveChannel = produce {
    send(compute("A"))
    send(compute("B"))
    send(compute("C"))
    }
    fun main() = runBlocking {
    val channel = foo()
    for (x in channel) println(x)
    }


    View Slide

43. main()
    foo()
    send send send
    Channel
    A B C
    A B C
    fun CoroutineScope.foo(): ReceiveChannel = produce {
    send(compute("A"))
    send(compute("B"))
    send(compute("C"))
    }
    fun main() = runBlocking {
    val channel = foo()
    for (x in channel) println(x)
    }


    View Slide

44. main()
    foo()
    send send send
    Channel
    A B C
    A B C ❌
    fun CoroutineScope.foo(): ReceiveChannel = produce {
    send(compute("A"))
    send(compute("B"))
    send(compute("C"))
    }
    fun main() = runBlocking {
    val channel = foo()
    for (x in channel) println(x)
    }


    View Slide

45. Channel is hot


    View Slide

46. fun main() = runBlocking {
    val channel = foo()
    for (x in channel) println(x)
    }
    Channel is hot


    View Slide

47. Channel is hot
    fun main() = runBlocking {
    val channel = foo()
    // for (x in channel) println(x)
    }


    View Slide

48. main()
    foo()
    Channel
    fun CoroutineScope.foo(): ReceiveChannel = produce {
    send(compute("A"))
    send(compute("B"))
    send(compute("C"))
    }
    fun main() = runBlocking {
    val channel = foo()
    // for (x in channel) println(x)
    }


    View Slide

49. main()
    foo()
    send
    Channel

    A
    fun CoroutineScope.foo(): ReceiveChannel = produce {
    send(compute("A"))
    send(compute("B"))
    send(compute("C"))
    }
    fun main() = runBlocking {
    val channel = foo()
    // for (x in channel) println(x)
    }


    View Slide

50. fun CoroutineScope.foo(): ReceiveChannel



    View Slide

51. KOTLIN FLOW
    Image: Markus Trienke, Sunset over dri6 ice


    View Slide

52. fun foo(): Flow = flow {
    …
    }


    View Slide

53. fun foo(): Flow = flow {
    …
    }


    View Slide

54. fun foo(): Flow = flow {
    emit(compute("A"))
    emit(compute("B"))
    emit(compute("C"))
    }


    View Slide

55. fun main() = runBlocking {
    val flow = foo()
    flow.collect { x -> println(x) }
    }
    fun foo(): Flow = flow {
    emit(compute("A"))
    emit(compute("B"))
    emit(compute("C"))
    }


    View Slide

56. fun main() = runBlocking {
    val flow = foo()
    flow.collect { x -> println(x) }
    }
    fun foo(): Flow = flow {
    emit(compute("A"))
    emit(compute("B"))
    emit(compute("C"))
    }


    View Slide

57. fun main() = runBlocking {
    val flow = foo()
    flow.collect { x -> println(x) }
    }
    fun foo(): Flow = flow {
    emit(compute("A"))
    emit(compute("B"))
    emit(compute("C"))
    }


    View Slide

58. main()
    foo()
    fun main() = runBlocking {
    val flow = foo()
    flow.collect { x -> println(x) }
    }
    fun foo(): Flow = flow {
    emit(compute("A"))
    emit(compute("B"))
    emit(compute("C"))
    }


    View Slide

59. main()
    foo()
    fun main() = runBlocking {
    val flow = foo()
    flow.collect { x -> println(x) }
    }
    fun foo(): Flow = flow {
    emit(compute("A"))
    emit(compute("B"))
    emit(compute("C"))
    }


    View Slide

60. main()
    foo()
    Flow
    fun main() = runBlocking {
    val flow = foo()
    flow.collect { x -> println(x) }
    }
    fun foo(): Flow = flow {
    emit(compute("A"))
    emit(compute("B"))
    emit(compute("C"))
    }


    View Slide

61. main()
    foo()
    Flow
    fun main() = runBlocking {
    val flow = foo()
    flow.collect { x -> println(x) }
    }
    fun foo(): Flow = flow {
    emit(compute("A"))
    emit(compute("B"))
    emit(compute("C"))
    }


    View Slide

62. main()
    foo()
    collect
    Flow
    fun main() = runBlocking {
    val flow = foo()
    flow.collect { x -> println(x) }
    }
    fun foo(): Flow = flow {
    emit(compute("A"))
    emit(compute("B"))
    emit(compute("C"))
    }


    View Slide

63. main()
    foo()
    emit
    collect
    A
    Flow
    fun main() = runBlocking {
    val flow = foo()
    flow.collect { x -> println(x) }
    }
    fun foo(): Flow = flow {
    emit(compute("A"))
    emit(compute("B"))
    emit(compute("C"))
    }


    View Slide

64. main()
    foo()
    emit
    A
    collect
    A
    Flow
    fun main() = runBlocking {
    val flow = foo()
    flow.collect { x -> println(x) }
    }
    fun foo(): Flow = flow {
    emit(compute("A"))
    emit(compute("B"))
    emit(compute("C"))
    }


    View Slide

65. main()
    foo()
    emit
    A
    collect
    A
    Flow
    fun main() = runBlocking {
    val flow = foo()
    flow.collect { x -> println(x) }
    }
    fun foo(): Flow = flow {
    emit(compute("A"))
    emit(compute("B"))
    emit(compute("C"))
    }


    View Slide

66. main()
    foo()
    emit emit
    A
    collect
    A B
    Flow
    fun main() = runBlocking {
    val flow = foo()
    flow.collect { x -> println(x) }
    }
    fun foo(): Flow = flow {
    emit(compute("A"))
    emit(compute("B"))
    emit(compute("C"))
    }


    View Slide

67. main()
    foo()
    emit emit
    A B
    collect
    A B
    Flow
    fun main() = runBlocking {
    val flow = foo()
    flow.collect { x -> println(x) }
    }
    fun foo(): Flow = flow {
    emit(compute("A"))
    emit(compute("B"))
    emit(compute("C"))
    }


    View Slide

68. main()
    foo()
    emit emit
    A B
    collect
    A B
    Flow
    fun main() = runBlocking {
    val flow = foo()
    flow.collect { x -> println(x) }
    }
    fun foo(): Flow = flow {
    emit(compute("A"))
    emit(compute("B"))
    emit(compute("C"))
    }


    View Slide

69. main()
    foo()
    emit emit emit
    A B
    collect
    A B C
    Flow
    fun main() = runBlocking {
    val flow = foo()
    flow.collect { x -> println(x) }
    }
    fun foo(): Flow = flow {
    emit(compute("A"))
    emit(compute("B"))
    emit(compute("C"))
    }


    View Slide

70. main()
    foo()
    emit emit emit
    A B C
    collect
    A B C
    Flow
    fun main() = runBlocking {
    val flow = foo()
    flow.collect { x -> println(x) }
    }
    fun foo(): Flow = flow {
    emit(compute("A"))
    emit(compute("B"))
    emit(compute("C"))
    }


    View Slide

71. main()
    foo()
    emit emit emit
    A B C
    collect
    A B C
    Flow
    fun main() = runBlocking {
    val flow = foo()
    flow.collect { x -> println(x) }
    }
    fun foo(): Flow = flow {
    emit(compute("A"))
    emit(compute("B"))
    emit(compute("C"))
    }


    View Slide

72. main()
    foo()
    emit emit emit
    A B C
    collect
    A B C ❌
    Flow
    fun main() = runBlocking {
    val flow = foo()
    flow.collect { x -> println(x) }
    }
    fun foo(): Flow = flow {
    emit(compute("A"))
    emit(compute("B"))
    emit(compute("C"))
    }


    View Slide

73. main()
    foo()
    emit emit emit
    A B C
    collect
    A B C ❌
    Flow
    fun main() = runBlocking {
    val flow = foo()
    flow.collect { x -> println(x) }
    }
    fun foo(): Flow = flow {
    emit(compute("A"))
    emit(compute("B"))
    emit(compute("C"))
    }


    View Slide

74. fun main() = runBlocking {
    val flow = foo()
    flow.collect { x -> println(x) }
    }
    Flow is cold ❄


    View Slide

75. fun main() = runBlocking {
    val flow = foo()
    // flow.collect { x -> println(x) }
    }
    Flow is cold ❄



    View Slide

76. Flow is declara6ve


    View Slide

77. Flow is declarative
    fun foo(): Flow = flow {
    emit(compute("A"))
    emit(compute("B"))
    emit(compute("C"))
    }
    Declaration


    View Slide

78. fun strings(): Flow = flow {
    emit("A")
    emit("B")
    emit(”C")
    }


    View Slide

79. fun strings(): Flow = flow {
    …
    }
    fun foo(): Flow =
    strings().map { name ->
    compute(name)
    }


    View Slide

80. fun strings(): Flow = flow {
    …
    }
    fun foo(): Flow =
    strings().map { name ->
    compute(name)
    }


    View Slide

81. fun strings(): Flow = flow {
    …
    }
    fun foo(): Flow =
    strings().map { name ->
    compute(name)
    }


    View Slide

82. fun strings(): Flow = flow {
    …
    }
    fun foo(): Flow =
    strings().map { name ->
    compute(name)
    }
    Operators


    View Slide

83. fun foo(): Flow =
    flowOf("A", "B", "C").map { name ->
    compute(name)
    }
    Operators


    View Slide

84. Flow vs List
    fun foo(): Flow =
    flowOf("A", "B", "C").map { name ->
    compute(name)
    }
    suspend fun foo(): List =
    listOf("A", "B", "C").map { name ->
    compute(name)
    }


    View Slide

85. fun foo(): Flow =
    flowOf("A", "B", "C").map { name ->
    compute(name)
    }
    suspend fun foo(): List =
    listOf("A", "B", "C").map { name ->
    compute(name)
    }
    Defined – Declarative
    Runs – Impera:ve
    suspend fun Flow.collect(…) Runs the flow
    Flow vs List


    View Slide

86. fun foo(): Flow =
    flowOf("A", "B", "C").map { name ->
    compute(name)
    }
    suspend fun foo(): List =
    listOf("A", "B", "C").map { name ->
    compute(name)
    }
    Defined – Declara:ve
    Runs – Imperative
    suspend fun Flow.toList(): List Runs the flow
    Flow vs List


    View Slide

87. fun foo(): Flow =
    flowOf("A", "B", "C").map { name ->
    compute(name)
    }
    suspend fun foo(): List =
    listOf("A", "B", "C").map { name ->
    compute(name)
    }
    Flow vs List
    Execu6on order


    View Slide

88. fun foo(): Flow =
    flowOf("A", "B", "C").map { name ->
    compute(name)
    }
    suspend fun foo(): List =
    listOf("A", "B", "C").map { name ->
    compute(name)
    } B C
    A
    Flow vs List


    View Slide

89. fun foo(): Flow =
    flowOf("A", "B", "C").map { name ->
    compute(name)
    }
    suspend fun foo(): List =
    listOf("A", "B", "C").map { name ->
    compute(name)
    } B C
    A map
    Flow vs List


    View Slide

90. fun foo(): Flow =
    flowOf("A", "B", "C").map { name ->
    compute(name)
    }
    suspend fun foo(): List =
    listOf("A", "B", "C").map { name ->
    compute(name)
    } B C
    A
    B’ C’
    A’
    map
    Flow vs List


    View Slide

91. fun foo(): Flow =
    flowOf("A", "B", "C").map { name ->
    compute(name)
    }
    suspend fun foo(): List =
    listOf("A", "B", "C").map { name ->
    compute(name)
    } B C
    A
    B’ C’
    A’
    map
    A
    A’
    Flow vs List


    View Slide

92. fun foo(): Flow =
    flowOf("A", "B", "C").map { name ->
    compute(name)
    }
    suspend fun foo(): List =
    listOf("A", "B", "C").map { name ->
    compute(name)
    } B C
    A
    B’ C’
    A’
    map
    A
    B’
    A’
    B
    Flow vs List


    View Slide

93. fun foo(): Flow =
    flowOf("A", "B", "C").map { name ->
    compute(name)
    }
    suspend fun foo(): List =
    listOf("A", "B", "C").map { name ->
    compute(name)
    } B C
    A
    B’ C’
    A’
    map
    A
    B’ C’
    A’
    B C
    Flow vs List
    React on emi2ed values


    View Slide

94. Flow is reac6ve
    RxJava
    Project
    Reactor
    Kotlin Flow
    Reactive Streams Specification


    View Slide

95. Publisher
    org.reactivestreams
    Publisher


    View Slide

96. fun Publisher.asFlow(): Flow
    org.reactivestreams
    Publisher
    kotlinx.coroutines.flow
    Flow


    View Slide

97. fun Flow.asPublisher(): Publisher
    fun Publisher.asFlow(): Flow
    org.reactivestreams
    Publisher
    kotlinx.coroutines.flow
    Flow


    View Slide

98. WHY FLOW?
    What’s the difference?


    View Slide

99. A
    A’
    mapper
    fun map(mapper: (T) -> R): Flowable
    fun flatMapSingle(mapper: (T) -> SingleSource): Flowable
    Synchronous
    Asynchronous
    Flowable


    View Slide

100. A
     A’
     mapper
     fun map(mapper: (T) -> R): Flowable
     fun flatMapSingle(mapper: (T) -> SingleSource): Flowable
     fun filter(predicate: (T) -> Boolean): Flowable
     A
     A
     predicate

     Synchronous
     Asynchronous
     Synchronous
     Asynchronous
     Flowable


     View Slide

101. A
     A’
     Flow
     fun map(transform: suspend (T) -> R): Flow
     transform


     View Slide

102. A
     A’
     transform
     Flow
     fun map(transform: suspend (T) -> R): Flow


     View Slide

103. A
     A’
     transform fun map(transform: suspend (T) -> R): Flow
     Flow
     fun filter(predicate: suspend (T) -> Boolean): Flow
     A
     predicate
     A


     View Slide

104. Operator avoidance
     startWith(value) onStart { emit(value) }
     delaySubscription(time) onStart { delay(time) }
     startWith(flow) onStart { emitAll(flow) }
     delayEach(time) onEach { delay(time) }
     onErrorReturn(value) catch { emit(value) }
     onErrorResume(flow) catch { emitAll(flow) }
     generate(…) flow { … }
     Composable


     View Slide

105. Reactive + = ❤


     View Slide

106. FLOW
     UNDER THE HOOD
     Image: Flow by Grant Tarrant


     View Slide

107. interface Flow {
     suspend fun collect(collector: FlowCollector)
     }
     interface FlowCollector {
     suspend fun emit(value: T)
     }


     View Slide

108. flow.collect { value ->
     println(value)
     }
     collect
     1


     View Slide

109. flow.collect { value ->
     println(value)
     }
     val flow = flow {
     emit("A")
     }
     collect
     1


     View Slide

110. flow.collect { value ->
     println(value)
     }
     val flow = flow {
     emit("A")
     }
     collect
     1


     View Slide

111. flow.collect { value ->
     println(value)
     }
     val flow = flow {
     emit("A")
     }
     collect
     1
     λ


     View Slide

112. flow.collect { value ->
     println(value)
     }
     val flow = flow {
     emit("A")
     }
     collect
     1
     λ


     View Slide

113. flow.collect { value ->
     println(value)
     }
     val flow = flow {
     emit("A")
     }
     collect
     emit
     λ
     1
     2
     λ


     View Slide

114. flow.collect { value ->
     println(value)
     }
     val flow = flow {
     emit("A")
     }
     collect
     emit
     λ
     println
     1
     2
     3
     λ


     View Slide

115. flow.collect { value ->
     println(value)
     }
     val flow = flow {
     emit("A")
     }
     collect
     λ
     emit
     λ
     println
     1
     2
     3 ^
     4
     ^
     5


     View Slide

116. flow.collect { value ->
     println(value)
     }
     val flow = flow {
     emit("A")
     emit("B")
     }
     collect
     λ
     emit
     λ
     println
     emit
     println


     View Slide

117. flow.collect { value ->
     println(value)
     }
     val flow = flow {
     emit("A")
     delay(100)
     emit("B")
     }
     collect
     λ
     emit
     λ
     println
     emit
     println
     Asynchronous emi@er


     View Slide

118. flow.collect { value ->
     delay(100)
     println(value)
     }
     val flow = flow {
     emit("A")
     delay(100)
     emit("B")
     }
     collect
     λ
     emit
     λ
     println
     emit
     println
     Backpressure


     View Slide

119. Simple design


     View Slide

120. Simple design ⇒ performance


     View Slide

121. Kotlin Flow Plays Scrabble
     • Benchmark originally developed by José Paumard
     • Implemented for RxJava by David Karnok


     View Slide

122. Kotlin Flow Plays Scrabble
     • Benchmark originally developed by José Paumard
     • Implemented for RxJava by David Karnok
     SequencePlaysScrabble 9.824 ± 0.190 ms/op
     https://github.com/Kotlin/kotlinx.coroutines/tree/develop/benchmarks/src/jmh/kotlin/benchmarks/flow/scrabble/README.md


     View Slide

123. Kotlin Flow Plays Scrabble
     • Benchmark originally developed by José Paumard
     • Implemented for RxJava by David Karnok
     SequencePlaysScrabble 9.824 ± 0.190 ms/op
     RxJava2PlaysScrabbleOpt 23.653 ± 0.379 ms/op
     https://github.com/Kotlin/kotlinx.coroutines/tree/develop/benchmarks/src/jmh/kotlin/benchmarks/flow/scrabble/README.md


     View Slide

124. Kotlin Flow Plays Scrabble
     • Benchmark originally developed by José Paumard
     • Implemented for RxJava by David Karnok
     SequencePlaysScrabble 9.824 ± 0.190 ms/op
     RxJava2PlaysScrabbleOpt 23.653 ± 0.379 ms/op
     FlowPlaysScrabbleOpt 13.958 ± 0.278 ms/op
     https://github.com/Kotlin/kotlinx.coroutines/tree/develop/benchmarks/src/jmh/kotlin/benchmarks/flow/scrabble/README.md


     View Slide

125. FLOW IS
     ASYNCHRONOUS


     View Slide

126. FLOW IS
     ASYNCHRONOUS
     YET SEQUENTIAL


     View Slide

127. main()
     emit emit emit
     A B C
     collect
     A B C ❌
     100 ms 100 ms 100 ms 100 ms
     100 ms 100 ms 100 ms
     700 ms
     Single corouDne


     View Slide

128. GOING
     CONCURRENT
     WITH A FLOW
     Image: Channels by Tom Doel


     View Slide

129. flow.buffer().collect { … }


     View Slide

130. flow.buffer().collect { … }
     main()
     emit emit emit
     A B C
     collect
     A B C ❌
     100 ms 100 ms 100 ms 100 ms
     400 ms
     100 ms 100 ms
     100 ms


     View Slide

131. flow.buffer().collect { … }
     main()
     emit emit emit
     A B C
     collect
     A B C
     Separate corouDne


     View Slide

132. flow.buffer().collect { … }
     main()
     send send send
     A B C
     collect
     A B C ❌
     Channel
     Declarative & safe


     View Slide

133. FLOW
     EXECUTION CONTEXT
     Image: Context by Bart Everson


     View Slide

134. fun foo(): Flow =
     flowOf("A", "B", "C").map { name ->
     compute(name)
     }


     View Slide

135. fun foo(): Flow =
     flowOf("A", "B", "C").map { name ->
     compute(name)
     }
     fun main() = runBlocking {
     val flow = foo()
     flow.collect { x -> println(x) }
     }
     Where does it execute?


     View Slide

136. fun foo(): Flow =
     flowOf("A", "B", "C").map { name ->
     compute(name)
     }
     .flowOn(Dispatchers.Default)
     fun main() = runBlocking {
     val flow = foo()
     flow.collect { x -> println(x) }
     }
     Executes in background


     View Slide

137. fun foo(): Flow =
     flowOf("A", "B", "C").map { name ->
     compute(name)
     }
     .flowOn(Dispatchers.Default)
     Executes in collector’s context
     fun main() = runBlocking {
     val flow = foo()
     flow.collect { x -> println(x) }
     }
     Context preservation


     View Slide

138. FLOW IN REACTIVE UI


     View Slide

139. fun events(): Flow


     View Slide

140. fun events(): Flow
     scope.launch {
     …
     }


     View Slide

141. fun events(): Flow
     scope.launch {
     events().collect { event ->
     …
     }
     }


     View Slide

142. fun events(): Flow
     scope.launch {
     events().collect { event ->
     updateUI(event)
     }
     }


     View Slide

143. fun events(): Flow
     scope.launch {
     events().collect { event ->
     updateUI(event)
     }
     }
     “Subscribe” to events


     View Slide

144. fun events(): Flow
     events()
     .onEach { event -> updateUI(event) }
     .launchIn(scope)
     “Subscribe” to events


     View Slide

145. fun events(): Flow
     events()
     .onEach { event -> updateUI(event) }
     .launchIn(scope)
     “Subscribe” to events


     View Slide

146. MANAGING LIFETIME


     View Slide

147. Observable
     • ……….
     • …..
     • ……..


     View Slide

148. Observable
     • ……….
     • …..
     • ……..
     subscribe
     observable.subscribe { event ->
     updateUI(event)
     }


     View Slide

149. Observable
     • ……….
     • …..
     • ……..
     subscribe
     SubscripIon
     observable.subscribe { event ->
     updateUI(event)
     }


     View Slide

150. Observable
     • ……….
     • …..
     • ……..
     subscribe
     SubscripIon
     val composite = CompositeDisposable()
     composite.add(observable.subscribe { event ->
     updateUI(event)
     })


     View Slide

151. Observable
     • ……….
     • …..
     • ……..
     subscribe
     SubscripIon
     val composite = CompositeDisposable()
     composite.add(observable.subscribe { event ->
     updateUI(event)
     })
     composite.clear()


     View Slide

152. Flow
     • ……….
     • …..
     • ……..
     launch
     Job
     CorouIneScope
     Structured Concurrency


     View Slide

153. Flow
     • ……….
     • …..
     • ……..
     launch
     Job
     events()
     .onEach { event -> updateUI(event) }
     .launchIn(scope)


     View Slide

154. Flow
     • ……….
     • …..
     • ……..
     launch
     Job
     val scope = MainScope()
     events()
     .onEach { event -> updateUI(event) }
     .launchIn(scope)


     View Slide

155. Flow
     • ……….
     • …..
     • ……..
     launch
     Job
     val scope = MainScope()
     events()
     .onEach { event -> updateUI(event) }
     .launchIn(scope)
     scope.cancel()


     View Slide

156. Flow
     • ……….
     • …..
     • ……..
     launch
     Job
     val scope = MainScope()
     events()
     .onEach { event -> updateUI(event) }
     .launchIn(scope)
     scope.cancel()


     View Slide

157. LiveData
     • ……….
     • …..
     • ……..
     observe
     data.observe(livecycleOwner) { event ->
     updateUI(event)
     }


     View Slide

158. STATUS & ROADMAP
     What’s next?


     View Slide

159. Status & Roadmap
     Flow is stable in kotlinx.corouInes version 1.3.0
     Future improvements
     ØOut-of-the box support for UI models (StateFlow / EventFlow)
     ØSharing / caching flows
     ØConcurrency / parallelism operators
     ØChunking / windowing operators
     Want more? Give us your feedback
     h2ps://github.com/Kotlin/kotlinx.corouInes/issues


     View Slide

160. Learn more
     vKotlin Flow by example guide
     https://kotlinlang.org/docs/reference/coroutines/flow.html
     vAPI docs
     https://kotlin.github.io/kotlinx.coroutines/kotlinx-coroutines-core/
     vStories in my blog
     https://medium.com/@elizarov


     View Slide

161. #KotlinConf
     THANK YOU
     AND
     REMEMBER
     TO VOTE
     Roman Elizarov @relizarov
     #KotlinConf


     View Slide
