Looking at yourself: Linux Introspection tales

Introspection information, used originally by debuggers, has come a long way into playing a greater role in the functioning of Linux.

Now its used by tracers, profilers, and then by eBPF, in libbpf, in the verifier and other parts of the kernel, being always available and fast to access.

This talk will tell the history of a tool initially used for looking for alignment holes, all the way to being used in the kernel build process, and will touch many aspects of this journey.

Old and new tricks will be described, touching perf, eBPF, rust, clang, you name it.

Arnaldo Carvalho de Melo, Red Hat

Transcript

1. LOOKING AT YOURSELF Linux introspection tales Arnaldo Carvalho de Melo acme@redhat.com
2. WHAT IS THIS ABOUT? Type information Introspection Adaptation
3. SHRINKING SOCKETS Linux 2.4 struct sock Big union All protocols
4. SHRUNK SOCKET Reduce CPU cache utilization Remove alignment holes Reorder struct fields Combine some bitfields Demote others To better pack
5. SOCKET HIERARCHY struct sock struct tcp_sock struct tcp6_sock struct udp_sock And all the others
6. NEVERENDING STORY Date: Mon Nov 15 11:02:37 2021 -0800 From: Eric Dumazet Move sk_bind_phc next to sk_peer_lock to fill a hole. @@ -489,5 +489,6 @@ struct sock { u16 sk_busy_poll_budget; #endif spinlock_t sk_peer_lock; + int sk_bind_phc; struct pid *sk_peer_pid; const struct cred *sk_peer_cred; @@ -498,5 +499,4 @@ struct sock { seqlock_t sk_stamp_seq; #endif u16 sk_tsflags; - int sk_bind_phc; u8 sk_shutdown;
7. SOME MORE $ git log -2 --oneline 1ace2b4d2b4e1db8f 1ace2b4d2b4e1db8 net: shrink struct sock by 8 bytes 1b31debca8328448 ipv6: shrink struct ipcm6_cookie $
8. TEDIOUS Manual Can we automate this? gdb knows about types, how?
9. DWARF Debugging With Arbitrary Record Formats Executable and Linkable Format's friend More recently we got ORC too
10. PAHOLE Read DWARF Rebuild source from type info Augmented with alignment info Showing the holes Cacheline boundaries Lots more
11. EXAMPLE $ pahole -C list_head ~/git/build/v5.18-rc6+/vmlinux struct list_head { struct list_head * next; /* 0 struct list_head * prev; /* 8 /* size: 16, cachelines: 1, members: 2 */ /* last cacheline: 16 bytes */ }; $
12. CERN ATLAS MIGRATION 32-bit to 64-bit C++ long/pointer: 32 to 64-bit
13. AN ALIGNMENT HOLE # pahole -C _IO_FILE ~/bin/perf | head struct _IO_FILE { int _flags; /* 0 /* XXX 4 bytes hole, try to pack */ char * _IO_read_ptr; /* 8 char * _IO_read_end; /* 16 char * _IO_read_base; /* 24 char * _IO_write_base; /* 32 char * _IO_write_ptr; /* 40 #
14. PAHOLE --REORGANIZE To elliminate holes Demotes bitfields show-reorg-steps __alignment__ attribute false sharing
15. PAHOLE --REORGANIZE 2 DWARF now has attribute align Use that in the reorg algo
16. --REORGANIZE EXAMPLE $ pahole --reorganize task_struct | tail /* --- cacheline 142 boundary (9088 bytes) was 56 bytes ago --- struct thread_struct thread __attribute__((__aligned__(64))); /* /* size: 13560, cachelines: 212, members: 252 */ /* sum members: 13487, holes: 2, sum holes: 57 */ /* sum bitfield members: 79 bits, bit holes: 2, sum bit holes: 4 /* paddings: 6, sum paddings: 49 */ /* forced alignments: 2, forced holes: 1, sum forced holes: 56 * /* last cacheline: 56 bytes */ }; /* saved 136 bytes and 2 cachelines! */ $
17. CTF Dtrace Solaris In the kernel image Introspection SparcLinux
18. MULTI-FORMAT Type info agnostic DWARF and CTF CTF reader CTF encoder
19. CONVERSION From DWARF to CTF For testing
20. DWARF PROBLEMS kernel community problems with unwinding object files: Compile Units All types represented per CU debuginfo files are big hundreds of megabytes
21. BPF NEEDS TYPE INFO To pretty print maps Later: CO-RE
22. BTF BPF Type Format Reused the CTF infra in pahole First BTF producer: clang bpf target First BTF consumer: Linux kernel
23. BPF DEDUP Looks at all objects Removes type duplicates
24. BTF READER For testing /sys/kernel/btf/vmlinux Wow, that is fast!
25. PAHOLE + BTF Its always there So inform just the type
26. PAHOLE + BTF $ pahole spinlock_t typedef struct spinlock spinlock_t; $
27. PAHOLE + BTF $ pahole spinlock struct spinlock { union { struct raw_spinlock rlock; /* 0 }; /* 0 /* size: 4, cachelines: 1, members: 1 */ /* last cacheline: 4 bytes */ }; $
28. EXPAND IT! $ pahole -E spinlock struct spinlock { union { struct raw_spinlock { /* typedef arch_spinlock_t */ struct qspinlock { union { /* typedef atomic_t */ struct { int counter; /* 0 4 */ } val; /* 0 4 */ struct { /* typedef u8 -> __u8 */ unsigned char locked; /* 0 1 */ /* ypedef u8 -> __u8 */ unsigned char pending; /* 1 1 */ }; /* 0 2 */ struct { /* typedef u16 -> __u16 */ short unsigned int locked_pending; /* 0 2 */ /* typedef u16 -> __u16 */ short unsigned int tail; /* 2 2 */ }; /* 0 4 */ }; /* 0 4 */ } raw_lock; /* 0 4 */ } rlock; /* 0 4 */ }; /* 0 4 */ /* size: 4, cachelines: 1, members: 1 */ /* last cacheline: 4 bytes */ }; $
29. WHERE IS IT? libbpf loads it kernel verifies Gets associated to the prog/map fd Tools can retrieve it
30. BPFTOOL BPF Generates vmlinux.h With all kernel types bpftool btf dump file /sys/kernel/btf/vmlinux format c
31. PAHOLE --COMPILE Reconstruct compilable source code Like bpftool
32. WHERE ELSE? /sys/kernel/btf/ vmlinux and modules modules refer to types in vmlinux
33. PROGRAM LINES .BTF_ext ELF section perf annotate BPF source code
34. ADAPTABILITY: USE CASE Author: Namhyung Kim Date: Wed May 18 15:47:23 2022 -0700 perf record: Handle argument change in sched_switch Recently sched_switch tracepoint added a new argument for prev_state, but it's hard to handle the change in a BPF program. Instead, we can check the function prototype in BTF before loading the program.
35. ADAPTABILITY: TOOL LOADER static void check_sched_switch_args(void) { struct btf *btf = bpf_object__btf(skel->obj); struct btf_type *t1, *t2, *t3; u32 type_id = btf__find_by_name_kind(btf, "bpf_trace_sched_swi BTF_KIND_TYPEDEF); t1 = btf__type_by_id(btf, type_id); t2 = btf__type_by_id(btf, t1->type); if (t3 && btf_is_func_proto(t3) && btf_vlen(t3) == 4) { // new format: pass prev_state as 4th arg skel->rodata->has_prev_state = true; } }
36. ADAPTABILITY: BPF SKEL CHANGE +++ b/tools/perf/util/bpf_skel/off_cpu.bpf.c +const volatile bool has_prev_state = false; +SEC("tp_btf/sched_switch") +int on_switch(u64 *ctx) { + struct task_struct *prev, *next; + int prev_state; + + if (!enabled) return 0; + prev = (struct task_struct *)ctx[1]; + next = (struct task_struct *)ctx[2]; + + if (has_prev_state) + prev_state = (int)ctx[3]; + else + prev_state = get_task_state(prev); + return off_cpu_stat(ctx, prev, next, prev_state); +}
37. RUNNING IT # perf record --off-cpu ^C[ perf record: Woken up 1924 times to write data ] [ perf record: Captured and wrote 483.936 MB perf.data (8857075 samp # ls -la perf.data -rw-------. 1 root root 507845510 May 31 00:45 perf.data #
38. OBSERVING IT # bpftool prog | grep on_switch -A4 634: tracing name on_switch tag 3d6d5a513a933c28 gpl loaded_at 2022-05-30T22:37:17+0200 uid 0 xlated 1392B jited 913B memlock 4096B map_ids 497,498,493,494,495 btf_id 602 pids perf(393176) #
39. SHOW ME THE CODE # bpftool prog dump jited id 634 int on_switch(u64 * ctx): bpf_prog_3d6d5a513a933c28_on_switch: ; int on_switch(u64 *ctx) 0: nopl 0x0(%rax,%rax,1) 5: xchg %ax,%ax 7: push %rbp 8: mov %rsp,%rbp b: sub $0x38,%rsp 12: push %rbx 13: push %r13 15: push %r14 17: push %r15 19: mov %rdi,%r15 ; if (!enabled) 1c: movabs $0xffffb53a400d2000,%rdi 26: mov 0x0(%rdi),%edi ; if (!enabled) 29: test %rdi,%rdi 2c: je 0x0000000000000386
40. SHOW ME THE CODE: 2 ; next = (struct task_struct *)ctx[2]; 32: mov 0x10(%r15),%r14 ; prev = (struct task_struct *)ctx[1]; 36: mov 0x8(%r15),%rbx ; if (has_prev_state) 3a: movabs $0xffffb53a400f6000,%rdi 44: movzbq 0x0(%rdi),%rdi ; prev_state = (int)ctx[3]; 49: mov $0x1,%edi ; if (bpf_core_field_exists(t->__state)) 4e: mov $0x18,%edi 53: mov %rbx,%rdx 56: add %rdi,%rdx 59: mov %rbp,%rdi ; 5c: add $0xffffffffffffffd8,%rdi ; return BPF_CORE_READ(t, __state); 60: mov $0x4,%esi 65: callq 0xffffffffd5f13f50 ; return BPF_CORE_READ(t, __state); 6a: mov -0x28(%rbp),%r13d
41. WHERE ARE THE MAPS # bpftool map | grep off_cpu -A3 490: array name off_cpu_.rodata flags 0x480 key 4B value 3B max_entries 1 memlock 4096B btf_id 628 frozen pids perf(393176) #
42. ITS CONTENTS # bpftool map dump id 490 [{ "value": { ".rodata": [{ "has_prev_state": false },{ "needs_cgroup": false },{ "uses_cgroup_v1": false } ] } } #
43. THE FEATURE # perf report --stdio --call-graph=no # Childr Self Command Shared Object Symbol # ...... ...... ............... .................. ................ 81.66% 0.00% sched-messaging libc-2.33.so [.] __libc_start_ 81.66% 0.00% sched-messaging perf [.] cmd_bench 81.66% 0.00% sched-messaging perf [.] main 81.66% 0.00% sched-messaging perf [.] run_builtin 81.43% 0.00% sched-messaging perf [.] bench_sched_m 40.86% 40.86% sched-messaging libpthread-2.33.so [.] __read 37.66% 37.66% sched-messaging libpthread-2.33.so [.] __write 2.91% 2.91% sched-messaging libc-2.33.so [.] __poll ... As you can see it spent most of off-cpu time in read and write in bench_sched_messaging(). The --call-graph=no was added just to the output concise here.
44. perf annotate
45. nospectre_v1 + nospectre_v2
46. PAHOLE IN THE KERNEL BUILD LD [M] drivers/media/usb/gspca/gspca_zc3xx.o AR drivers/media/built-in.a AR drivers/built-in.a GEN .version CHK include/generated/compile.h LD vmlinux.o MODPOST vmlinux.symvers MODINFO modules.builtin.modinfo GEN modules.builtin CC .vmlinux.export.o LD .tmp_vmlinux.btf BTF .btf.vmlinux.bin.o LD .tmp_vmlinux.kallsyms1 KSYMS .tmp_vmlinux.kallsyms1.S AS .tmp_vmlinux.kallsyms1.S LD .tmp_vmlinux.kallsyms2 KSYMS .tmp_vmlinux.kallsyms2.S AS .tmp_vmlinux.kallsyms2.S LD vmlinux
47. MODULES TOO LD [M] arch/x86/kvm/kvm-amd.ko BTF [M] arch/x86/kernel/cpu/mce/mce-inject.ko BTF [M] arch/x86/events/rapl.ko LD [M] arch/x86/kvm/kvm-intel.ko LD [M] arch/x86/kvm/kvm.ko BTF [M] arch/x86/kvm/kvm-amd.ko LD [M] crypto/adiantum.ko BTF [M] crypto/adiantum.ko BTF [M] arch/x86/kvm/kvm-intel.ko LD [M] crypto/aegis128.ko BTF [M] crypto/aegis128.ko LD [M] crypto/aes_ti.ko BTF [M] arch/x86/kvm/kvm.ko
48. NEW BPF/BTF FEATURES pahole as an enabler Eventually compilers will produce BTF But you have to dedup when generating vmlinux Generate BTF info for VARs after linking Covenient when developing new features
49. BTF TAGS clang generates new DWARF tags pahole converts to BTF_KIND_TAG kernel BPF verifier uses __rcu, percpu, etc
50. KERNEL BUILD PAHOLE CAPABILITY QUERY $ cat scripts/pahole-flags.sh #!/bin/sh if [ "${pahole_ver}" -ge "118" ] && [ "${pahole_ver}" -le "121" ]; t # pahole 1.18 through 1.21 can't handle zero-sized per-CPU v extra_paholeopt="${extra_paholeopt} --skip_encoding_btf_vars fi if [ "${pahole_ver}" -ge "121" ]; then extra_paholeopt="${extra_paholeopt} --btf_gen_floats" fi if [ "${pahole_ver}" -ge "122" ]; then extra_paholeopt="${extra_paholeopt} -j" fi echo ${extra_paholeopt} $ scripts/pahole-flags.sh --btf_gen_floats -j $ pahole --version v1.23 $
51. RUST reordering of struct fields pahole --reorganize done by rust rejected by kernel BTF verifier kernel build: pahole --lang_exclude rust pahole should put fields in order instead when generating BTF for rust kernel objects DWARF compile_unit tag has DW_AT_producer
52. DWARF LANGS static const char *languages[] = { [DW_LANG_Ada83] = "ada83", SNIP [DW_LANG_C11] = "c11", [DW_LANG_C89] = "c89", [DW_LANG_C99] = "c99", [DW_LANG_C] = "c", [DW_LANG_Cobol74] = "cobol74", SNIP [DW_LANG_C_plus_plus_14] = "c++14", [DW_LANG_C_plus_plus] = "c++", [DW_LANG_D] = "d", [DW_LANG_Dylan] = "dylan", [DW_LANG_Fortran03] = "fortran03", SNIP [DW_LANG_PLI] = "pli", [DW_LANG_Python] = "python", [DW_LANG_RenderScript] = "renderscript", [DW_LANG_Rust] = "rust",
53. };
54. PRETTY PRINTING IN THE KERNEL bpf_seq_printf_btf bpf_snprintf_btf BPF helper
55. BPF_SNPRINTF_BTF HELPER static struct btf_ptr b = { }; b.ptr = skb; b.type_id = __builtin_btf_type_id(struct sk_buff, 1); bpf_snprintf_btf(str, sizeof(str), &b, sizeof(b), 0, 0)
56. BPF_SNPRINTF_BTF HELPER Default output looks like this: (struct sk_buff){ .transport_header = (__u16)65535, .mac_header = (__u16)65535, .end = (sk_buff_data_t)192, .head = (unsigned char *)0x000000007524fd8b, .data = (unsigned char *)0x000000007524fd8b, .truesize = (unsigned int)768, .users = (refcount_t){ .refs = (atomic_t){ .counter = (int)1, }, }, }
57. FLAGS Flags modifying display are as follows: - BTF_F_COMPACT: no formatting around type information - BTF_F_NONAME: no struct/union member names/types - BTF_F_PTR_RAW: show raw (unobfuscated) pointer values; equivalent to %px. - BTF_F_ZERO: show zero-valued struct/union members; they are not displayed by default
58. PAHOLE PRETTY PRINTING $ pahole --prettify=- --header elf64_hdr < /bin/bash { .e_ident = { 127, 69, 76, 70, 2, 1, 1, 0, 0, 0, 0, 0, 0, 0, .e_type = 3, .e_machine = 62, .e_version = 1, .e_entry = 204224, .e_phoff = 64, .e_shoff = 1388016, .e_flags = 0, .e_ehsize = 64, .e_phentsize = 56, .e_phnum = 13, .e_shentsize = 64, .e_shnum = 32, .e_shstrndx = 31, }, $
59. ITS IN THE KERNEL BTF $ pahole elf64_hdr struct elf64_hdr { unsigned char e_ident[16]; /* 0 Elf64_Half e_type; /* 16 Elf64_Half e_machine; /* 18 Elf64_Word e_version; /* 20 Elf64_Addr e_entry; /* 24 Elf64_Off e_phoff; /* 32 Elf64_Off e_shoff; /* 40 Elf64_Word e_flags; /* 48 Elf64_Half e_ehsize; /* 52 Elf64_Half e_phentsize; /* 54 Elf64_Half e_phnum; /* 56 Elf64_Half e_shentsize; /* 58 Elf64_Half e_shnum; /* 60 Elf64_Half e_shstrndx; /* 62 /* size: 64, cachelines: 1, members: 14 */ }; $
60. BTFGEN For older kernels Generates kernel eBPF needed by a prog Modified libbpf looks at it as the kernel BPF Does its CO-RE work
61. TETRAGON Cilium Security BTF required N-level filtering
62. THE END BTF dedup: BTF CO-RE: acme@kernel.org http://vger.kernel.org/~acme/prez/kernel-recipes-202 https://facebookmicrosites.github.io/bpf/blog/2018/1 enhancement.html> https://facebookmicrosites.github.io/bpf/blog/2020/0 portability-and-co-re.html https://twitter.com/acmel
