  1. Ansible and
    Google Cloud Platform
    Eric Johnson, Technical Program Manager
    Kenneth Rimey, Senior Software Engineer
    AnsibleFest SFO 2014

    View full-size slide

  2. Agenda: October 14th, 2014
    Whirlwind Tour of Google Cloud Platform
    Google Compute Engine
    Using Ansible and Compute Engine (demo)
    1
    2
    3

    View full-size slide

  3. Whirlwind Tour of Google Cloud Platform
    Google Compute Engine
    Using Ansible and Compute Engine (demo)
    1
    2
    3
    Agenda: October 14th, 2014

    View full-size slide

  4. Storage
    Cloud Storage Cloud SQL
    Cloud
    Datastore
    Compute
    Compute
    Engine
    App Engine
    App Services
    BigQuery
    Cloud
    Endpoints
    Google Cloud Platform
    Cloud DNS

    View full-size slide

  5. For the past 15 years, Google
    has been building out the
    world’s fastest, most powerful,
    highest quality cloud
    infrastructure on the planet.
    Images by Connie
    Zhou
    Why Google Cloud Platform?

    View full-size slide

  6. Whirlwind Tour of Google Cloud Platform
    Google Compute Engine
    Using Ansible and Compute Engine (demo)
    1
    2
    3
    Agenda: October 14th, 2014

    View full-size slide

  7. • Virtual Machines
    • Linux / Windows / Custom
    • very small <-> VERY LARGE
    • Persistent Disks
    • SSD and "standard"
    • Up to 10TB per VM
    • Shared r/o across many VMs
    • Global snapshots
    • Advanced Networking
    • Global private network
    • Load-balancing (L3 and L7)
    • Custom routes / Firewall rules
    Google Compute Engine

    View full-size slide

  8. • Enterprise Ready
    • 24x7 Support
    • 99.95% monthly SLA
    • ISO 27001, SSAE-16 SOC 1,2,3
    • Accessible Through
    • Web @ https://cloud.google.com/console
    • Cloud SDK command-line utility
    • REST API
    • Partners (Commercial and FOSS)
    • Simplified Pricing
    • Per-minute billing (10m minimum)
    • Sustained-use discounts (up to 30% reduction)
    Google Compute Engine

    View full-size slide

  9. Whirlwind Tour of Google Cloud Platform
    Google Compute Engine
    Using Ansible and Compute Engine (demo)
    1
    2
    3
    Agenda: October 14th, 2014

    View full-size slide

  10. Live Test (before)
    http://www.erjohn.so
    $ dig www.erjohn.so +noall +answer

    View full-size slide

  11. Demo
    Ansible playbook that defines,
    1. 4 Compute Engine instances (2 per zone)
    2. Create a Firewall Rule and Load-Balancer
    3. Set up a DNS record for the LB IP
    4. Deploy "app" and manage software
    (in a non-typical way...)
    Region: us-central1
    Target Pool (lb-tp)
    us-central1-a
    app1
    app3
    us-central1-b
    app2
    app4
    Forwarding Rules
    tcp:80 ➔ lb-tp
    GCP APIs
    $ ansible-playbook gce-demo.yml

    View full-size slide

  12. GCE Authentication
    group_vars/all
    1 ---
    2 # file: group_vars/all
    3 pid: graphite-demos
    4 email: [email protected]
    5 pem: /home/erjohnso/pkey.pem

    View full-size slide

  13. The "gce-demo" playbook
    gce-demo.yml
    1 - name: Create Compute Engine instances
    2 hosts: local
    3 gather_facts: False
    4 vars:
    5 zones:
    6 - { zname: "us-central1-a", inames: ["app1", "app3"] }
    7 - { zname: "us-central1-b", inames: ["app2", "app4"] }
    8 mdff: {"startup-script": "/home/erjohnso/fest/files/startup-script.sh",
    9 "agent": "/home/erjohnso/fest/files/ptc_agent.py"}
    10 tasks:
    11 - name: Bring up the instances, two per zone
    12 gce:
    13 instance_names: "{{ item.inames }}"
    14 zone: "{{ item.zname }}"
    15 machine_type: "n1-standard-1"
    16 image: "debian-7"
    17 tags: ["http-server", "apache", "prod"]
    18 metadata_from_file: "{{ mdff }}"
    19 scopes: ["projecthosting", "pubsub"]
    20 project_id: "{{ pid }}"
    21 with_items: zones
    22

    View full-size slide

  14. The "gce-demo" playbook
    gce-demo.yml
    23 - name: Set up networking and DNS
    24 hosts: local
    25 gather_facts: False
    26 tasks:
    27 - name: Allow HTTP traffic
    28 gce_net:
    29 fwname: target-http-server
    30 name: default
    31 allowed: tcp:80
    32 target_tags: http-server
    33 project_id: "{{ pid }}"

    View full-size slide

  15. The "gce-demo" playbook
    gce-demo.yml
    34 - name: Create the load-balancer, healthcheck, and add members
    35 gce_lb:
    36 name: lb
    37 httphealthcheck_name: lb-hc
    38 region: "us-central1"
    39 members:
    40 - "us-central1-a/app1"
    41 - "us-central1-a/app3"
    42 - "us-central1-b/app2"
    43 - "us-central1-b/app4"
    44 httphealthcheck_name: lb-hc
    45 httphealthcheck_port: 80
    46 httphealthcheck_path: /
    47 project_id: "{{ pid }}"
    48 register: gcelb

    View full-size slide

  16. The "gce-demo" playbook
    gce-demo.yml
    49 - name: Create an A record for www.erjohn.so
    50 gc_dns:
    51 command: create
    52 name: erjohnso
    53 record: www.erjohn.so.
    54 ttl: 600
    55 record_type: A
    56 value: "{{ gcelb.external_ip }}"
    57 project_id: "{{ pid }}"

    View full-size slide

  17. The "gce-demo" playbook
    gce-demo.yml
    82 - name: Deploy apache, mod_headers, and custom web page
    83 hosts: gce_instances
    84 sudo: yes
    85 tasks:
    86 - name: Install python-apt
    87 command: apt-get install python-apt -y
    88 - name: Install apache on instances
    89 apt: pkg=apache2 state=present
    90 - name: Create custom index.html
    91 template: src=index.html.j2 dest=/var/www/index.html
    92 - name: Set file stats on index.html
    93 file: path=/var/www/index.html owner=root group=root mode=0644
    94 - name: Deploy modified apache conf
    95 copy: src=apache2.conf dest=/etc/apache2/apache2.conf
    96 owner=root group=root mode=0644
    97 - name: Enable mod_headers
    98 file: path=/etc/apache2/mods-enabled/headers.load
    99 src=/etc/apache2/mods-available/headers.load state=link
    100 - name: Re-load apache
    101 service: name=apache2 state=reloaded

    View full-size slide

  18. Live Test (after)
    http://www.erjohn.so
    $ dig www.erjohn.so +noall +answer

    View full-size slide

  19. Sub-Demo: Continuous Deployment
    us-central1-a
    app1
    app3
    us-central1-b
    app2
    app4
    GCP APIs
    pub/sub
    instance tags
    CD with Ansible and Google Cloud Platform,
    1. PTC Agent deployed via metadata during instance create
    2. "App" development with git hosted in
    Google Cloud Repositories
    3. Ansible configures the VM and "app" locally

    View full-size slide

  20. Recall...
    gce-demo.yml
    1 - name: Create Compute Engine instances
    2 hosts: local
    3 gather_facts: False
    4 vars:
    5 zones:
    6 - { zname: "us-central1-a", inames: ["app1", "app3"] }
    7 - { zname: "us-central1-b", inames: ["app2", "app4"] }
    8 mdff: {"startup-script": "/home/erjohnso/fest/files/startup-script.sh",
    9 "agent": "/home/erjohnso/fest/files/ptc_agent.py"}
    10 tasks:
    11 - name: Bring up the instances, two per zone
    12 gce:
    13 instance_names: "{{ item.inames }}"
    14 zone: "{{ item.zname }}"
    15 machine_type: "n1-standard-1"
    16 image: "debian-7"
    17 tags: ["http-server", "apache", "prod"]
    18 metadata_from_file: "{{ mdff }}"
    19 scopes: ["projecthosting", "pubsub"]
    20 project_id: "{{ pid }}"
    21 with_items: zones
    22

    View full-size slide

  21. Sub-Demo
    app1
    Google Cloud
    PubSub
    GCE
    Metadata service
    Google Cloud
    Repositories
    PTC Agent
    (topic)
    $ git push
    $ gcloud compute instances add-tags ...
    10011
    00110
    11011
    01100
    00010
    10011
    00110
    11011
    01100
    00010
    v1
    v2

    View full-size slide

  22. Details
    • PTC Agent
    • Listens for code push events and instance tag change events
    • On event, a "start" script in top-level of configuration tree executes ansible-playbook
    • Configuration - Pure Ansible
    • Role to deploy Apache, custom web page (our "app"), and a debugging script
    • Application "versions" deployed are based on instance tags (prod or canary)
    • Uses a local dynamic inventory script for classification by instance tags
    • Debugging
    • /cgi-bin/ptcd

    View full-size slide

  23. Demo Flow
    1. Start the demo: All machines have prod instance tag and v1 deployed
    a. site.yml initially only specifies 'v1.yml'
    b. v1.yml targets machines with the prod tag (e.g. tag_apache:&tag_prod )
    2. We start the "canary" rollout verification using production traffic
    a. Select an instance and change its instance tags (prod -> canary)
    b. Enable both v1.yml and v2.yml (v2.yml targets tag_apache:&tag_canary )
    c. Commit and push
    d. Verify that the canary instance is running v2 and others are still running v1
    i. Revert? Yes, flip canary instance tags back to prod (no need to commit/push!)
    3. Assuming we like this, proceed with remainder of rollout
    a. Comment out v1.yml in the site.yml
    b. Edit v2.yml and set the target to tag_apache:&tag_prod
    c. Commit and push

    View full-size slide

  24. Umm... Why?
    • Pros
    • New machines come up fully configured automatically (auto-scaling, PoG, etc)
    • Demo used instance metadata, but could use project-metadata
    • Scalable to very large sets of machines
    • Good prototype for adapting to your needs (git branches vs versions, environments, etc)
    • Cons
    • No all-up view of state of managed machines
    • Needs thought toward ACLs around update mechanism (who can git push / change tags)
    • Can be difficult to debug, no immediate feedback
    • Scopes can be challenging
    • Alternative: Ansible Tower!
    • All-up views
    • ACLs, audit history
    • Hands-free scheduled updates
    • Visualization

    View full-size slide

  25. Available now and more coming!
    • Existing modules: gce, gce_net, gce_pd, gce_lb, gc_storage, inventory plugin
    • Create, destroy instances + dynamic inventory
    • Create, destroy networks, firewall rules
    • Create, destroy Persistent Disks
    • Create, destroy load balancer, healthchecks
    • Create, destroy buckets, objects
    Available
    Now!!
    Coming
    Soon!!
    • The gc_dns module [PR being reviewed]
    • Create, destroy managed-zones
    • Create, update DNS records
    • New metadata_from_file for GCE module
    • More things to come...

    View full-size slide

  26. Google confidential │ Do not
    distribute
    $500 in Cloud Platform
    credit to launch your idea!
    Build. Store. Analyze.
    On the same infrastructure
    that powers Google
    Start building
    Go to g.co/cloudstarterpack
    Click ‘Apply Now’ and complete the
    application with promo code: ansible-con
    Starter Pack
    Offer Description
    1
    2
    3

    View full-size slide

  27. cloud.google.com - Thank you!
    Read more at
    ● Compute Engine: https://cloud.google.com/products/compute-engine
    ● Ansible + Compute Engine: http://docs.ansible.com/guide_gce.html
    ● ... and look for the new gc_dns module soon! [pull-request #110]
    Get Started on Google Cloud Platform
    ● $500 credit, http://g.co/cloudstarterpack (use promo code: ansible-con)
    Questions? {'Freenode': 'erjohnso', 'GitHub': 'erjohnso', 'Twitter': 'no!'}
