Android Programming Basics

Android Programming Basics

Introduction to Android app development using Android Studio

1ec13070abf6996a0bc06b9be103ea85?s=128

Eueung Mulyana

August 28, 2017
Tweet

Transcript

  1. 1 / 89 PPTB (ET-4044) Android Programming Basics Eueung Mulyana

    https://eueung.github.io/012017/android1 CodeLabs | Attribution-ShareAlike CC BY-SA
  2. Outline Android & Android Studio App Development Building Your First

    App 2 / 89
  3. Notes Android Studio 2.3.3 (Stable Channel) A copy of the

    latest OpenJDK comes bundled with Android Studio 2.2 and higher, and this is the JDK version recommended for your Android projects. Ref: [Con gure Android Studio] 3 / 89
  4. Android & Android Studio 4 / 89

  5. 5 / 89 What is Android Mobile operating system based

    on Linux kernel User Interface for touch screens Used on over 80% of all smartphones Powers devices such as watches, TVs, and cars Over 2 Million Android apps in Google Play store Highly customizable for devices / by vendors Open source Ref: Android Developer Fundamentals
  6. Android Versions 6 / 89

  7. 7 / 89 Android Studio + Android SDK O cial

    Android IDE Develop, run, debug, test, and package apps Monitors and performance tools Virtual devices Project views Visual layout editor Ref: Android Developer Fundamentals
  8. 8 / 89 Logical Areas 1. Toolbar 2. Navigation Bar

    3. Editor Window 4. Tool Window Bar (Expand/Collapse) 5. Tool Window 6. Status Bar
  9. 9 / 89 Layout Editor Project Window (1) Palette of

    UI Elements (2) Selectors (3) Design Pane (6) Component Tree (7) Design/Text Tabs (8)
  10. 10 / 89 Layout Editor Properties Pane (4) Text Property

    of TextView (5)
  11. App Development 11 / 89

  12. 12 / 89 Android App One or more interactive screens

    Written using Java Programming Language and XML (*) Uses the Android Software Development Kit (SDK) Uses Android libraries and Android Application Framework Executed by Android Runtime Virtual machine (ART) Ref: Android Developer Fundamentals
  13. 13 / 89 Android Challenges Multiple screen sizes and resolutions

    Performance: make your apps responsive and smooth Security: keep source code and user data safe Compatibility: run well on older platform versions Marketing: understand the market and your users (Hint: It doesn't have to be expensive, but it can be.)
  14. 14 / 89 App Building Blocks Resources: layouts, images, strings,

    colors as XML and media les Components: activities, services,... and helper classes as Java code Manifest: information about app for the runtime Build con guration: APK versions in Gradle con g les
  15. 15 / 89 Component Types Activity is a single screen

    with a user interface Service performs long-running tasks in background Content provider manages shared set of data Broadcast receiver responds to system-wide announcements
  16. 16 / 89 Think of Android as a Hotel Your

    App is the guest The Android System is the hotel manager Services are available when you request them (Intents) In the foreground (Activities) such as registration In the background (Services) such as laundry Calls you when a package has arrived (Broadcast Receiver) Access the city's tour companies (Content Provider) Ref: Android Developer Fundamentals
  17. Android Studio Building Your First App 17 / 89

  18. 18 / 89 Building Your First App 1. Create an

    Android Project 2. Run Your App 3. Build a Simple User Interface 4. Start Another Activity
  19. Create an Android Project 19 / 89

  20. Start a New Project 20 / 89

  21. Adjust Application name (& Company domain) 21 / 89

  22. Set Target Devices 22 / 89

  23. Co ee Time ... (If SDK components not yet locally

    available) 23 / 89
  24. Add Empty Activity 24 / 89

  25. Adjust Activity Name (& Layout Name) 25 / 89

  26. Project Window | app>java> ... >MainActivity.java 26 / 89

  27. app>res>layout>activity_main.xml (Design View) 27 / 89

  28. app>res>layout>activity_main.xml (Text View) 28 / 89

  29. app>manifests>AndroidManifest.xml 29 / 89

  30. @string/app_name 30 / 89

  31. @string/app_name 31 / 89

  32. Run Your App On an Emulator | On a Real

    Device 32 / 89
  33. Launch AVD Manager 33 / 89

  34. Create Virtual Device 34 / 89

  35. Select Hardware | Phone 35 / 89

  36. Download System Image (If it's not already there) 36 /

    89
  37. Co ee Time ... 37 / 89

  38. Select System Image 38 / 89

  39. Verify -> Finish 39 / 89

  40. Launch this AVD in the Emulator 40 / 89

  41. AVD Launched 41 / 89

  42. Run the App 42 / 89

  43. Select Target 43 / 89

  44. Showtime! 44 / 89

  45. Run Your App On an Emulator | On a Real

    Device 45 / 89
  46. 46 / 89 USB Debugging Settings>General >About Device Note: Titles

    may vary!
  47. 47 / 89 USB Debugging Build Number

  48. 48 / 89 USB Debugging Build Number | Tap 7x!

  49. 49 / 89 USB Debugging Settings>Developer Options

  50. 50 / 89 USB Debugging Settings>Developer Options | USB Debugging

    Note: Titles may vary!
  51. Run | Select Target 51 / 89

  52. 52 / 89 Done! Installed on the Device

  53. Build a Simple User Interface 53 / 89

  54. Show Blueprint, Show Constraints, Autoconnect O & Default Margin 16

    54 / 89
  55. Component Tree | Replace TextView with EditText | Adjust/Drag Constraint

    Anchors 55 / 89
  56. Add Button | Adjust/Drag Constraint Anchors | Note: Baseline Constraint

    56 / 89
  57. Change the UI Strings | String Resources 57 / 89

  58. Change the UI Strings | Translation Editor 58 / 89

  59. Properties | @string/edit_message (Remove text) 59 / 89

  60. Properties | @string/button_send 60 / 89

  61. Select Both | Center Horizontally 61 / 89

  62. A Chain Between the Two Views 62 / 89

  63. Button | Left & Right Margin ->16 63 / 89

  64. Text | Left Margin ->16 | Width Indicator -> Match

    Constraints 64 / 89
  65. activity_main.xml (Text) 65 / 89

  66. Run & Test 66 / 89

  67. Start Another Activity 67 / 89

  68. sendMessage() Method Stub | Alt + Enter -> Import class

    68 / 89
  69. Connect sendMessage() to the Button 69 / 89

  70. app | Create a New Empty Activity 70 / 89

  71. DisplayMessageActivity 71 / 89

  72. DisplayMessageActivity.java 72 / 89

  73. MainActivity.java 73 / 89

  74. activity_display_message.xml | textAppearance 74 / 89

  75. Run & Test 75 / 89

  76. AVD - Landscape 76 / 89

  77. 77 / 89 Run & Test Real Device | SM-N750

  78. 78 / 89 Run & Test Real Device | SM-N750

  79. MainActivity.java | Di 79 / 89

  80. package com.example.em.exampleapplication01; import android.content.Intent; import android.support.v7.app.AppCompatActivity; import android.os.Bundle; import android.view.View;

    import android.widget.EditText; public class MainActivity extends AppCompatActivity { public static final String EXTRA_MESSAGE = "com.example.em.exampleapplication01.MESSAGE"; @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); setContentView(R.layout.activity_main); } public void sendMessage(View view) { Intent intent = new Intent(this, DisplayMessageActivity.class); EditText editText = (EditText) findViewById(R.id.editText); String message = editText.getText().toString(); intent.putExtra(EXTRA_MESSAGE, message); startActivity(intent); } } 80 / 89 MainActivity.java
  81. package com.example.em.exampleapplication01; import android.content.Intent; import android.support.v7.app.AppCompatActivity; import android.os.Bundle; import android.widget.TextView;

    public class DisplayMessageActivity extends AppCompatActivity { @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); setContentView(R.layout.activity_display_message); // Get the Intent that started this activity and extract the string Intent intent = getIntent(); String message = intent.getStringExtra(MainActivity.EXTRA_MESSAGE); // Capture the layout's TextView and set the string as its text TextView textView = (TextView) findViewById(R.id.textView); textView.setText(message); } } 81 / 89 DisplayMessageActivity.java
  82. activity_main.xml | Di 82 / 89

  83. <?xml version="1.0" encoding="utf-8"?> <android.support.constraint.ConstraintLayout xmlns:android="http://schemas.android.com/apk/res/android" xmlns:app="http://schemas.android.com/apk/res-auto" xmlns:tools="http://schemas.android.com/tools" android:layout_width="match_parent" android:layout_height="match_parent" tools:context="com.example.em.exampleapplication01.MainActivity">

    <EditText android:id="@+id/editText" android:layout_width="0dp" android:layout_height="wrap_content" android:layout_marginTop="16dp" android:ems="10" android:hint="@string/edit_message" android:inputType="textPersonName" app:layout_constraintLeft_toLeftOf="parent" app:layout_constraintTop_toTopOf="parent" app:layout_constraintRight_toLeftOf="@+id/button" android:layout_marginLeft="16dp" /> <Button android:id="@+id/button" android:layout_width="wrap_content" android:layout_height="wrap_content" android:layout_marginLeft="16dp" android:layout_marginRight="16dp" android:onClick="sendMessage" android:text="@string/button_send" app:layout_constraintBaseline_toBaselineOf="@+id/editText" app:layout_constraintLeft_toRightOf="@+id/editText" app:layout_constraintRight_toRightOf="parent" /> </android.support.constraint.ConstraintLayout> 83 / 89 activity_main.xml
  84. <?xml version="1.0" encoding="utf-8"?> <android.support.constraint.ConstraintLayout xmlns:android="http://schemas.android.com/apk/res/android" xmlns:app="http://schemas.android.com/apk/res-auto" xmlns:tools="http://schemas.android.com/tools" android:layout_width="match_parent" android:layout_height="match_parent" tools:context="com.example.em.exampleapplication01.DisplayMessageActivity">

    <TextView android:id="@+id/textView" android:layout_width="wrap_content" android:layout_height="wrap_content" android:layout_marginTop="16dp" android:text="TextView" android:textAppearance="@style/TextAppearance.AppCompat.Display1" app:layout_constraintLeft_toLeftOf="parent" app:layout_constraintRight_toRightOf="parent" app:layout_constraintTop_toTopOf="parent" /> </android.support.constraint.ConstraintLayout> 84 / 89 activity_display_message.xml
  85. AndroidManifest.xml | Di 85 / 89

  86. <?xml version="1.0" encoding="utf-8"?> <manifest xmlns:android="http://schemas.android.com/apk/res/android" package="com.example.em.exampleapplication01"> <application android:allowBackup="true" android:icon="@mipmap/ic_launcher" android:label="@string/app_name"

    android:roundIcon="@mipmap/ic_launcher_round" android:supportsRtl="true" android:theme="@style/AppTheme"> <activity android:name=".MainActivity"> <intent-filter> <action android:name="android.intent.action.MAIN" /> <category android:name="android.intent.category.LAUNCHER" /> </intent-filter> </activity> <activity android:name=".DisplayMessageActivity" android:parentActivityName=".MainActivity" </application> </manifest> 86 / 89 AndroidManifest.xml
  87. Refs/Resources 87 / 89

  88. Refs/Resources 1. Getting Started | Android Developers 2. Dashboards |

    Android Developers 3. Android Developer Fundamentals | Google Developers Training | Google Developers 4. Introduction - Android Developer Fundamentals Course - Practicals 88 / 89
  89. 89 / 89 END Eueung Mulyana https://eueung.github.io/012017/android1 CodeLabs | Attribution-ShareAlike

    CC BY-SA
