Harnessing the Complexity of Cellular Network
Data with Smart Monitoring
Alexander Suleykin,
Peter Panfilov
Higher School of Economics , Moscow, 2019
www.hse.ru

View Slide

Complexity Problem: User Domain.
Overview of mobile users worldwide
Number of mobile users worldwide between 2010 and 2020 (in millions)

View Slide

Complexity Problem: Data Communication Domain.
High speed data streams
• Core and Radio network high speed data
interaction
• Constant data streaming with zero-downtime
infrastructure
• For 1 million active users > than 0.25 Gb/s
data speed for 10 core network protocols
• Need for real-time, distributed, fault-tolerant
and reliable data processing

View Slide

Complexity Problem: Technology Domain
Protocols and technology difference
• Different data transfer technologies (2G, 3G,
4G, 5G)
• Packet switch and circuit switch data
transmission
• Data and metadata transmission
• Different vendors with many solutions and
compression/decompression data techniques
• Result: Many protocols for Core and Radio
network within technology

View Slide

Complexity Problem: Network Infrastructure Domain
Network Infrastructure elements complexity

View Slide

Smart Monitoring System
SMS vision relies on the use of modern ICT (digitization) to efficiently
manage and maximize the utility of network infrastructures in order to
improve the QoS and network performance
In SMS projects, data from sensors monitoring the system state are
used to drive computations that in turn can dynamically adapt the
monitoring process as the complex system evolves.

View Slide

Smart Monitoring System for Cellular Network
The development of a SMS for CN data entails the ability to
dynamically incorporate more accurate information for
network controlling purposes through obtaining real-time
measurements from the network meters, various kinds of
sensors, base stations, and other sources, including models.

View Slide

Smart Monitoring System for Cellular Network
Highly distributed nature of data sources in the CNs dictates the
extensive use of distributed computing infrastructures while data
complexity requres introducing a sophisticated means of data
dimensionality reduction, data understanding, knowledge discovery
and decision support.
These are now covered by Big Data R&D area.

View Slide

Big Data Methods and Techniques
Big Data for CN Monitoring
MapReduce MPP In-Memory
Computing
Message
Oriented
Middleware
Programming
Languages
Big Data Tools & Applications
Lambda-
Driven AF
CN Monitoring
Powerful hardware

View Slide

Big Data in CN Operational Planning
Why Big Data Enabled approach has not yet applied?
• Fragmentation of department’s goals
• The lack of experience
• The complexity of streaming network data
• The complexity of architectural framework
• Infrastructure Cost
• Unclear Use Cases

View Slide

Big Data Driven Framework for CN's SMS
How to make SMS system smarter?
• DDDAS — The Distributed Data-Driven Application System Concept
• Lambda — A Distributed computing architecture for Big Data apps
• Spark — distributed computing infrastructure for machine learning

View Slide

DDDAS Paradigm in Smart Modeling/Measurement
Application System
The Dynamic Data Driven Application Systems (DDDAS) concept
entails the ability to incorporate dynamically data into an executing
application simulation, and in reverse, the ability of applications to
dynamically steer measurement processes.
Such dynamic data inputs can be acquired in real-time on-line or they
can be archival data.

View Slide

DDDAS Paradigm in Smart Modeling/Measurement
Application System
The DDDAS concept offers the promise of improving modeling
methods, augmenting the analysis and prediction capabilities of
application simulations, improving the efficiency of
simulations and the effectiveness of measurement systems.
Source: Darema, F. (2004). “Dynamic Data Driven Applications Systems: A New Paradigm for Application
Simulations and Measurements.” International Conference on Computational Science.

View Slide

DDDAS R&D International Cooperative Efforts
Advances and technology capabilities required and enabled through the
DDDAS concept are fostered through the DDDAS Program announced in
2005, with seeding efforts in the area having started previously (2000 – 2005)
through the NSF ITR Program.
The DDDAS Program was co-sponsored by multiple Directorates and Offices
of NSF, NOAA and NIH, and in cooperation with Programs in the European
Community and the United Kingdom. Over 30 DDDAS-related projects were
supported by NSF grants in 2005 competition
See more at: http://www.dddas.org/index.html).

View Slide

DDDAS has been widely adopted in several problems such
as supply chain systems, controlling and operation planning
of microgrids, controlling aerospace vehicles and etc.
Source: Fujimoto, Richard M. et al. “Dynamic data driven application systems for smart cities and urban infrastructures.” 2016 Winter
Simulation Conference (WSC) (2016): 1143-1157

View Slide

DDDAS has been widely adopted in several problems such
as supply chain systems, controlling and operation planning
of microgrids, controlling aerospace vehicles and etc.
There is an example of the Instrumented Oil-Field DDDAS
project that has enabled a new generation of data-driven,
interactive and dynamically adaptive strategies for
subsurface characterization and oil reservoir management.

View Slide

DDDAS in Smart Power Grids
Self-configuring adaptive simulation. Demand plays a
vital role in operational planning and controlling the
power grid. DDDAS addresses the issue by feeding real
time data from smart meters into simulation model to
adapt the model to the changes in the real system.
Multi agent modelling and multi objectivity. Power
grids depend upon many interacting dynamic systems.
Through two way communication, each customer has
information about time varying prices and demand
profile of the power grid. Each customer may behave
based on its own objective characteristics. Therefore, in
order to obtain a global optimum solution, each
customer should be modeled as an agent in the
simulation model.
Modular modeling. In a simulation-based planning and
control framework of complex systems, computational
efficiency is necessary not to disrupt a dynamically
changing system. An intelligent modeling techniques
should be developed for efficiency in these simulations.
Source: Fujimoto, Richard M. et al. “Dynamic data driven
application systems for smart cities and urban infrastructures.” 2016
Winter Simulation Conference (WSC) (2016): 1143-1157

View Slide

DDDAS in Smart Telerobotic Surgery System
Source: Cardullo, F.M., Lewis, H.W., III, and Panfilov, P.B. (2006). Building TelePresence Framework for Performing Robotic Surgical
Procedures.9th Annual International Workshop on Presence (PRESENCE 2006),Cleveland,Aug.24-26,2006,106-115.

View Slide

DDDAS as an Adaptive Control Application System
In the proposed telepresence framework the real-time simulator acts
as a predictor, providing information to the surgeon consistent with
the no delay situation. Clearly, dynamics models both for the robot
dynamics and organ dynamics are necessary for the simulator to
function in this way.
The image preprocessor portion is the essential corrector.
The intelligent controller is designed as an invigilator.
The total integrated surgical telerobotics system is to behave as the human
surgeon would if there were not a performance encumbering delay.
Source: Cardullo, F.M., Lewis, H.W., III, and Panfilov, P.B. (2006). Building TelePresence Framework for Performing Robotic Surgical
Procedures.9th Annual International Workshop on Presence (PRESENCE 2006),Cleveland,Aug.24-26,2006,106-115.

View Slide

Lambda — a Distributed Computing Architecture for Big
Data Application Systems
1. All data entering the system is dispatched
to both the batch layer and the speed layer
for processing.
2. The batch layer has two functions:
(i) managing the master dataset (an
immutable, append-only set of raw data),
and
(ii) to pre-compute the batch views.
3. The serving layer indexes the batch
views so that they can be queried in low-
latency, ad-hoc way.
4. The speed layer compensates for the
high latency of updates to the serving layer
and deals with recent data only.
5. Any incoming query can be answered by
merging results from batch views and real-
time views.

View Slide

Lambda Architecture and Apache Spark
Batch layer
The batch layer precomputes results using a distributed processing
system that can handle very large quantities of data. Output is typically
stored in a read-only database, with updates completely replacing
existing precomputed views.
Apache Hadoop is the de facto standard batch-processing system
used in most high-throughput architectures.

View Slide

Software Infrastructure for Distributed Applications
Design

View Slide

Apache Spark Ecosystem for Big Data Application
Systems

View Slide

The Proposed Big Data Driven Smart Monitoring
Framework for the Cellular Network Data — a Concept

View Slide

The Proposed Big Data Driven SMS Framework for the
Cellular Network Data — an Implementation

View Slide

Big Data tools for CNSMS. Part 1
1. Cellular Network (CN)
GERAN,
UTRAN, E-RAN
MSC
MME Other Nodes
Radio Subsystem
SGSN
Core Subsystem
2. Cellular Network Probes
Data
Aggregations
Vendor Specific Probes
Data
Enrichment
Geo-
Positioning

View Slide

3. Big Data enabled real-time parsing for Cellular compressed data
High-
performance
applications
Data Parsing applications
4. Message-Oriented Middleware
Lambda-Driven Architectural principles
Many data
consumers

View Slide

5. Big Data Storage and queries
Big Data Storage
6. Other data sources
Available data sources
In-memory
DBs
Reliable
distributed
storage
Big Data SQL
Schema on
Read
NoSQL DBs SQL DBs
7. Real-time and offline data models
Reliable, high
performance
models
Different model types

View Slide

9. Decision makers
Radio
Subsystem
Decision makers
10. External environment
Geo-reports
External data consumers
Advertisement
campaigns
CS and PS Core Marketing
Revenue
Assurance

View Slide

Practical Use Case
• Roaming users near real-time analysis
• 3G and 4G networks, Map and Diameter
protocols respectively
• Streaming data
• The goal is to filter only users with specific values
of VLRs and HLRs that we know that these users
have left the country
• After filtering data are available in MoM layer of
framework for as many data consumers as
needed
Project Description

View Slide

Real-time model for roaming users detection example.
Data description – GsmMap protocol
Field Type Description
Start Time (secs) int Call Start Time (seconds)
Start Time (micro secs) int Call Start Time (usecs)
End Time (secs) int Call End Time (seconds)
End Time (micro secs) int Call End Time (usecs)
OPC string Originating Point Code
DPC string Destination Point Code
Originating TID int Originating TID
LMSI int LMSI
Equipment Id smallint The value is the ID of the GeoProbe that
created the call record, unique in the system.
Last Message
Component
string This field identifies component type of the last
TCAP message.
Call Type string This field indicates the call type that generated
this data record. The available types are listed
after this table.
IMSI string IMSI
MSISDN string MSISDN
IMEI String This field contains the International Mobile
Equipment Identifier. This identity uniquely the
mobile equipment
RAW GsmMap fields - Streaming
Field Type Description
End Time (secs) int Call End Time (seconds)
Originating TID int Originating TID
Last Message
Component
string This field identifies component type of the last
TCAP message.
Call Type string This field indicates the call type that generated
this data record. The available types are listed
after this table.
IMSI string IMSI
MSISDN string MSISDN
IMEI String This field contains the International Mobile
Equipment Identifier. This identity uniquely the
mobile equipment
Filtered GsmMap fields

View Slide

Data description – Diameter protocol
RAW Diameter fields - Streaming Filtered Diameter fields
Field Name Type Description
starttimesecs int Start Time of the event (seconds in UNIX time)
starttimeusecs int Start Time of the event (micro secs)
endtimesecs int End Time of the event (seconds in UNIX time)
endtimeusecs int End Time of the event (micro secs)
sourceipaddress string Source IP Address of the first message in the
first transaction that initiated the data record
destinationipaddress string Destination IP Address of the first message in
the first transaction that initiated the data record
Session Status int This fields contains the Session Record Status
value
equipmentid int This field contains an IP Probe ID that identifies
the call record within the GeoProbe system
imsi string IMSI of the mobile device
imei string IMEI of the mobile device
msisdn string MSISDN
originrealm string Realm of the originator of the Diameter message
originhost string The endpoint that originated the Diameter
message
Transaction type string The information about type of Diameter
transaction, options are described below
Field Name Type Description
Timestamp int End Time of the event (seconds in UNIX time)
Session Status int This fields contains the Session Record Status
value
imsi string IMSI of the mobile device
imei string IMEI of the mobile device
msisdn string MSISDN
originrealm string Realm of the originator of the Diameter message
Transaction type string The information about type of Diameter
transaction, options are described below

View Slide

Common Experimental setup
Common Experimental parameters
• Real Cellular network with about 60 000 events
per second for both protocols
• Spark application and YARN resource manager
• Source and destination data app – Kafka as
MoM layer representation
• Hortonworks Spark installation

View Slide

Spark and Yarn Experimental setup
Spark and Yarn Experimental parameters
• 3 nodes for YARN allocated with 918 GB
memory;
• Percentage of physical CPU allocated for all
containers on a node is 80%;
• 1 second interval between jobs;

View Slide

Results
• Average Scheduling Delay is 14 ms, Average Processing Time is 464 ms and Total Delay is 478 ms.
Result messages in Kafka - Diameter:

View Slide

Experimental Results
Average service delay (ASD) for batch processing is much longer
than Spark delay. Apache Spark streaming runs its jobs with only
0.015 seconds delay, while traditional batch processing has 0.5
seconds delay;
Average processing time (APT) shows that the same amount of
data might be processed in 45 seconds intervals, while Spark
streaming process data in 0.464 time intervals.
It is achieved because Spark jobs runs each second, and the data
processing is really fast, in-memory and efficient;
Average interval time (AIT) between Spark jobs is 1 second,
while interval between batch jobs is usually 1 minute.
Batch processing cannot run faster because of overheads before
job start. Each start of job takes some additional resources and
needs some time to start job itself. For batch processing it is larger
than for streaming;

View Slide

Future Tasks
• Research different use cases
• Research and create Real-time Big Data cellular network monitoring “hub” based on Apache spark
application
• Research ETL Big Data tools for cellular network monitoring
• Research other possible data sources for different models
• Research different tools for application’s monitoring

View Slide

Thank you for your attention!

View Slide

Harnessing the Complexity of Mobile Network Data with Smart Monitoring

Harnessing the Complexity of Mobile Network Data with Smart Monitoring

Exactpro
PRO

More Decks by Exactpro

Other Decks in Research

Featured

Transcript

Harnessing the Complexity of Mobile Network Data with Smart Monitoring

Harnessing the Complexity of Mobile Network Data with Smart Monitoring

Exactpro PRO

More Decks by Exactpro

Other Decks in Research

Featured

Transcript

Exactpro
PRO
