  1. Build Software to Test Software
    exactpro.com
    Early Detection of Frozen Processes
    in Loaded Systems
    July 2021
    Maxim Nikiforov, Danila Gorkavchenko, Alexey Chistov,
    Andrey Novikov, Murad Mamedov

    View Slide

  2. 2 Build Software to Test Software
    exactpro.com
    1. Introduction:
    a. What system we are testing
    b. Purpose and objectives
    2. Initial data preparation:
    a. Preprocessing data and converting it into tabular form
    b. Providing access to the data
    3. Data preparation and modelling:
    a. Two types of datasets
    b. Processing attempts, results, etc
    c. Proposed DLC of the tool
    4. Results and next steps
    Structure

    View Slide

  3. 3 Build Software to Test Software
    exactpro.com
    Part 1
    Introduction

    View Slide

  4. 4 Build Software to Test Software
    exactpro.com
    Target Testing System
    ● Testing system contains 350+ processes
    ● 200+ processes are active during the
    business day
    ● Components are deployed over 30
    servers
    ● They perform various real-time activities
    and more than 100 batch activities of
    different types
    Application Servers
    Components 1
    30
    19
    1
    Inactive during BAU run
    Active Components

    View Slide

  5. 5 Build Software to Test Software
    exactpro.com
    Activities in Target System
    There are the following types of
    activities:
    ● Events that run several
    times per day
    ● Daily events
    ● Ad-hoc events
    ● Weekly/Monthly events
    How to describe an activity:
    ● Unique ID
    ● Activity type
    ● Start time
    ● End time
    ● Completion status

    View Slide

  6. 6 Build Software to Test Software
    exactpro.com
    Statistical Information Logs
    1. Special process in the testing platform
    monitors all processes and gets all the
    information from them.
    2. Then this process writes this
    information to log files with a 1-10
    second interval.
    Initial format of the logs after collection:
    Comp. 1 Comp. 2 Comp. N
    ...
    Stat.
    Logs
    Collector
    Each line contains:
    ● Timestamp
    ● Component ID
    ● Group ID of the parameters
    ● List of parameters in a custom format
    There are 2 groups of parameters:
    ● Critical documented parameters < 1%
    ● Other parameters

    View Slide

  7. 7 Build Software to Test Software
    exactpro.com
    Current Monitoring of Events and Statistics
    1. Target System monitoring limitations:
    ● Administrative frontend with text information only
    ● No graphic representation
    ● It is not possible to view the history of updates
    ● The system provides Interfaces for external monitoring
    infrastructure
    2. Additional Monitoring for QA purposes
    ● It is implemented in Grafana
    ● Only a small part of all values is monitored (critical
    parameters), but the number of them is too high to fit into
    one dashboard.
    ● Real-time activity visualization
    Examples of QA activities and Critical parameters monitoring:

    View Slide

  8. 8 Build Software to Test Software
    exactpro.com
    Goal
    ● To develop an automated approach to predicting deviations before they become obvious
    ● It should be possible to adapt it to other systems
    ● Logs with statistical parameters will be used for the analysis
    ● Ideally, it should indicate the root cause of the problem to the operational user (QA)

    View Slide

  9. 9 Build Software to Test Software
    exactpro.com
    Part 2
    Initial Data Preparation

    View Slide

  10. 10 Build Software to Test Software
    exactpro.com
    Easy Access to the Data
    Raw SUT logs
    SUT logs in csv
    format
    Activity Data
    Joint Logs and
    Activity Data
    suitable for further
    analysis
    Converter from Raw logs to CSV
    Framework that provides easy
    access to necessary information
    about the activities and logs

    View Slide

  11. 11 Build Software to Test Software
    exactpro.com
    Log Converter to CSV Format
    08:01:00 : Comp1: Group1: Param1=10, Param2=99, Param3=4
    08:01:01 : Comp1: Group1: Param1=11, Param2=98, Param3=4
    Raw Log Format:
    ● The conversion is executed on a daily basis and takes 15 minutes to convert daily logs (30gb)
    ● Size of logs is reduced by 93 %
    ● Data is unified now
    ● Avg. number of columns is 7.5k
    Comp1 - Group1 - Param1 Comp1 - Group1 - Param2 Comp1 - Group1 - Param3
    8:01:00 10 99 4
    8:01:01 11 98 4
    CSV format:

    View Slide

  12. 12 Build Software to Test Software
    exactpro.com
    Data Processing Framework
    ● Pandas dataframe as output
    ● Now it is very easy to access the data:
    one-line command to get a dataframe
    ● Doesn’t upload unnecessary information to
    the memory, supports additional filtering
    Data Collection for the period of time
    Data Collection for the certain activity

    View Slide

  13. 13 Build Software to Test Software
    exactpro.com
    Part 3
    Data Preparation and Modelling

    View Slide

  14. 14 Build Software to Test Software
    exactpro.com
    High Level Plan of the Research
    Predict activity duration
    Dataset v1
    “Activity-based DataSet”
    Dataset v2
    “Time-based Dataset”
    Each row in the
    dataset contains data
    for a run of sum
    activity. It can be easily
    prepared based on the
    historical data. It is for
    the research purposes
    only.
    Each row of the dataset contains data for some
    period of time for several activities, as they can
    be executed simultaneously in the system.
    The dataset can be created in real time and is
    supposed to be used in production.

    View Slide

  15. 15 Build Software to Test Software
    exactpro.com
    1
    2
    3

    N
    Run id
    Timestamp
    00:00:01
    00:00:02
    00:00:03

    Activity
    Duration
    Time until
    activity is
    completed
    Aggregated parameters (max, min,
    mean for each value in system
    logs)
    Activity parameters:
    Start time, End time,
    ID, Status
    Datasets in Details
    Aggregated parameters (max,
    min, mean for each value in
    system logs)
    Time since start
    for each activity,
    if activity is
    started
    Dataset v1:
    Dataset v2:
    Target feature

    View Slide

  16. 16 Build Software to Test Software
    exactpro.com
    Dataset v1 Preparation Pipeline
    Data collected
    from CSV files
    Dataset with
    numbers only
    - Handle object columns
    - Handle unique ids
    Dataset v1
    Drop constant
    columns
    Drop Correlated
    Columns
    All statistical parameters are
    aggregated using a set of
    functions (min, mean, max)
    1
    2
    3
    4
    5
    2.5M x 7.5k
    2.5M x 8.3k
    11k x 25k
    11k x 4.5k
    11k x 2.3k
    Dataset shape:

    View Slide

  17. 17 Build Software to Test Software
    exactpro.com
    Training a Model for 1 Activity Type
    Data = One Activity Type
    Model = Decision Tree
    Metrics = Root Mean Squared Error
    Results:
    RMSE = 202 sec
    STD = 45 sec

    View Slide

  18. 18 Build Software to Test Software
    exactpro.com
    Training a Single Model for All Activities
    Data = All activities
    Model = Decision Tree
    Metrics = Root Mean Squared Error
    Results:
    RMSE = 767 sec

    View Slide

  19. 19 Build Software to Test Software
    exactpro.com
    Problem 1: Different Number of Runs For Activities
    We can see that the count of runs is not the
    same for different types of activities:
    Min: 1, Max: 2000+
    Additional RMSE is produced by activities
    with a low number of runs.
    Solution:
    ● Use activities with the number of runs
    of more than 5

    View Slide

  20. 20 Build Software to Test Software
    exactpro.com
    ● if we use the default train-test split
    function, some activity types can be
    missed either in the train or the test
    dataset
    Solution:
    ● Change the approach and make sure
    that all activities are in both sets with
    the expected ratio
    Problem 2: Default Train-Test Split Function

    View Slide

  21. 21 Build Software to Test Software
    exactpro.com
    Problem 3: Avg. Duration of Different Types of Activities is Different
    ● Longer activities produce
    bigger RMSE, even if the
    model has good performance
    for short activities
    ● It is required to normalise the
    target value before training
    Solution:
    ● Logarithmic target value
    ● Stop using the absolute value of RMSE in seconds and calculate it based on the
    target value

    View Slide

  22. 22 Build Software to Test Software
    exactpro.com
    Attempts to Diminish the RMSE Value
    In this case, if we normalize the
    target column values by the average
    value, the related model predicts the
    target value more accurately.
    Also, if we limit the maximum value
    of a certain activity duration by 75
    percentile, it decreases the RMSE
    value.
    However, it eliminates values for bad
    activity runs. Therefore, the model
    trained only on good runs and looks
    like it is an inappropriate approach.

    View Slide

  23. 23 Build Software to Test Software
    exactpro.com
    Comparison of Different Models
    ● Accuracy of the model, if we train it using
    RandomForest, is always better than
    when we train model using DecisionTree;
    ● It takes much longer time to train a model
    using RandomForest.

    View Slide

  24. 24 Build Software to Test Software
    exactpro.com
    Checking if it is Possible to Predict the Duration of an Activity
    100%
    75%
    50%
    25 %
    Timeline, sec
    Avg. duration of activity

    View Slide

  25. 25 Build Software to Test Software
    exactpro.com
    Prediction Based on Joint Dataset with Time Marker
    100%
    75%
    50%
    25 %
    Timeline, sec
    Avg. duration of activity
    ● Dataset becomes 3 times bigger
    ● Performance improvement is due to time reference field
    ● In the dataset, we have several records of data for a single activity run. The approach can be
    used further for activities with low numbers of runs

    View Slide

  26. 26 Build Software to Test Software
    exactpro.com
    Checking Model Accuracy when a Model is Trained on Successful Runs
    and Testing On Failed Runs
    In this case, we train the model only on successful
    runs and compare the accuracy of the model when
    we test it on successful runs and failed runs.
    ● Average RMSE in case of testing on
    successful runs: 10,7 %;
    ● Average RMSE in case of testing on failed
    runs: 326 %

    View Slide

  27. 27 Build Software to Test Software
    exactpro.com
    Overnight
    Business
    Hours
    Proposed Daily Life Cycle
    Collect logs and
    activity data at EOD
    Multiply data
    Is data
    enough?
    No
    Preprocess data and
    train model
    Listen to logs in real
    time and predict
    activity duration
    Yes

    View Slide

  28. 28 Build Software to Test Software
    exactpro.com
    Part 4
    Results and Next Steps

    View Slide

  29. 29 Build Software to Test Software
    exactpro.com
    Summary
    ● We created a framework to access the statistics logs data, which itself can be useful for regular QA
    tasks
    ● We applied different approaches and models to increase the quality of training for Dataset v1,
    however, the performance is still too low, and there is a lot of room for improvement
    ● We prepared a time-based Dataset
    ● We started a PoC of the tool that allows to monitor the target system in real time

    View Slide

  30. 30 Build Software to Test Software
    exactpro.com
    Next Steps
    ● Fine tune the model by altering aggregator functions
    ● Find out how much data we need to start acceptable prediction in production runs
    ● Check whether the results for DS v1 are applicable for DS v2
    ● Complete the PoC of the product
    ● Predict failures of the activities

    View Slide

  31. 31 Build Software to Test Software
    exactpro.com
    Thank you!

    View Slide
