TMPA-2017: Functional Parser of Markdown Language Based on Monad Combining and Monoidal Source Stream Representation

TMPA-2017: Functional Parser of Markdown Language Based on Monad Combining and Monoidal Source Stream Representation

TMPA-2017: Tools and Methods of Program Analysis
3-4 March, 2017, Hotel Holiday Inn Moscow Vinogradovo, Moscow

Functional Parser of Markdown Language Based on Monad Combining and Monoidal Source Stream Representation
Georgy Lukyanov, Artem Pelenitsyn, Southern Federal University

For video follow the link: https://youtu.be/fDGG46gnOi0
Would like to know more?
Visit our website:
www.tmpaconf.org
www.exactprosystems.com/events/tmpa

Follow us:
https://www.linkedin.com/company/exactpro-systems-llc?trk=biz-companies-cym
https://twitter.com/exactpro

Exactpro

March 23, 2017
Tweet

More Decks by Exactpro

Other Decks in Technology

Transcript

  1. functional parser of markdown language based on monad combining and

    monoidal source stream representation . Georgiy Lukjanov ([email protected]) Assistant professor Artem Pelenitsin ([email protected]) TMPA conference, 3 Feb 2017 Southern Federal University, Rostov-on-Don, Russia
  2. Goals . ∙ Explore approaches to structuring of computation with

    multiple side-effects provided by modern Haskell libraries 2 / 22
  3. Goals . ∙ Explore approaches to structuring of computation with

    multiple side-effects provided by modern Haskell libraries ∙ Monad Transformers 2 / 22
  4. Goals . ∙ Explore approaches to structuring of computation with

    multiple side-effects provided by modern Haskell libraries ∙ Monad Transformers ∙ Algebraic effects and effects handlers (specifically Extensible Effects) 2 / 22
  5. Goals . ∙ Explore approaches to structuring of computation with

    multiple side-effects provided by modern Haskell libraries ∙ Monad Transformers ∙ Algebraic effects and effects handlers (specifically Extensible Effects) ∙ As a case study, build parsers combinators libraries and restricted Markdown parsers using these approaches 2 / 22
  6. Goals . ∙ Explore approaches to structuring of computation with

    multiple side-effects provided by modern Haskell libraries ∙ Monad Transformers ∙ Algebraic effects and effects handlers (specifically Extensible Effects) ∙ As a case study, build parsers combinators libraries and restricted Markdown parsers using these approaches ∙ Compare these approaches in terms of expressibility and performance 2 / 22
  7. Parsers . Informal definition A parser is a program that

    converts text into some kind of AST (abstract syntax tree) 3 / 22
  8. Parsers . Informal definition A parser is a program that

    converts text into some kind of AST (abstract syntax tree) ∙ Auto-generated, by bottom-up parser generators (YACC) 3 / 22
  9. Parsers . Informal definition A parser is a program that

    converts text into some kind of AST (abstract syntax tree) ∙ Auto-generated, by bottom-up parser generators (YACC) ∙ Manually-written (e.g. top-down recursive descent) 3 / 22
  10. Parser Combinators . ∙ Model parsers as higher-order functions map

    :: (a → b) → [a] → [b] map [ ] = [ ] map f (x : xs) = f x : map f xs 4 / 22
  11. Parser Combinators . ∙ Model parsers as higher-order functions map

    :: (a → b) → [a] → [b] map [ ] = [ ] map f (x : xs) = f x : map f xs ∙ Construct complex parsers from small set of basic ones alphanum :: Parser r Char alphanum = letter <|> digit 4 / 22
  12. Parser Combinators . ∙ Model parsers as higher-order functions map

    :: (a → b) → [a] → [b] map [ ] = [ ] map f (x : xs) = f x : map f xs ∙ Construct complex parsers from small set of basic ones alphanum :: Parser r Char alphanum = letter <|> digit ∙ Mirror grammar rules in source code of the parser 4 / 22
  13. Parser as a Monad . Parser data type newtype Parser

    a = Parser { parse :: String → Maybe (a, String)} 5 / 22
  14. Parser as a Monad . Parser data type newtype Parser

    a = Parser { parse :: String → Maybe (a, String)} Monad instance for Parser instance Monad Parser where return t = Parser $ λs → Just (t, s) m > > = k = Parser $ λs → do (u, v) ← parse m s (x, y) ← parse (k u) v return (x, y) 5 / 22
  15. Types and Effects: main notions . ∙ Pure/Impure functions and

    referential transparency Pure function show :: (Show a) ⇒ a → String 6 / 22
  16. Types and Effects: main notions . ∙ Pure/Impure functions and

    referential transparency Pure function show :: (Show a) ⇒ a → String IO action putStrLn :: String → IO () 6 / 22
  17. Types and Effects: main notions . ∙ Static guarantees on

    computations permissions Computation with static environment readUser :: (MonadReader Database m) ⇒ UserID → m UserData 7 / 22
  18. Types and Effects: main notions . ∙ Static guarantees on

    computations permissions Computation with static environment readUser :: (MonadReader Database m) ⇒ UserID → m UserData ∙ Combining multiple effects 7 / 22
  19. Types and Effects: main notions . ∙ Static guarantees on

    computations permissions Computation with static environment readUser :: (MonadReader Database m) ⇒ UserID → m UserData ∙ Combining multiple effects Static environment and ‘mutable’ state handler :: (MonadReader Config m , MonadState Database m) ⇒ m a 7 / 22
  20. Haskell frameworks for effects typing . Monad Transformers — type

    class based class (Monad m) ⇒ MonadState m where get :: m (StateType m) put :: StateType m → m () newtype StateT s m a = StateT {runStateT :: s → m (a, s)} instance (Monad m) ⇒ MonadState (StateT s m) where get = StateT $ λs → return (s, s) put s = StateT $ \_ → return ((), s) instance MonadTrans (StateT s) where ... instance (MonadIO m) ⇒ MonadIO (StateT s m) where ... 8 / 22
  21. Haskell frameworks for effects typing . Extensible Effects — free

    monad based data Free f a where Pure :: a → Free f a Impure :: f (Free f a) → Free f a data State s v where Get :: State s s Put :: !s → State s () instance Functor (State s) type FState s = Free (State s) 9 / 22
  22. Parser as a monadic stack . Parser newtype Parser a

    = Parser (StateT String Maybe a) 10 / 22
  23. Parser as a monadic stack . Parser newtype Parser a

    = Parser (StateT String Maybe a) Running a parser parse :: Parser a → String → Maybe (a, String t) parse (Parser p) s = runStateT p s 10 / 22
  24. Parser as a Union of Effects . type Parsable r

    = (Member Fail r, Member (State String) r) type Parser r a = Parsable r ⇒ Eff r a 11 / 22
  25. Parser as a Union of Effects . type Parsable r

    = (Member Fail r, Member (State String) r) type Parser r a = Parsable r ⇒ Eff r a Running a parser (handling effects) parse :: Eff (Fail ’: State String ’ : [ ]) a → String → (Either () a, String) parse p inp = run $ runState (runError p) inp 11 / 22
  26. Basic parsers . Unconditional consumer item :: Parser r Char

    item = do s ← get case s of [ ] → put s > > die (x : xs) → put xs > > pure x 12 / 22
  27. Basic parsers . Unconditional consumer item :: Parser r Char

    item = do s ← get case s of [ ] → put s > > die (x : xs) → put xs > > pure x Conditional consumer sat :: (Char → Bool) → Parser r Char sat p = do x ← item if p x then return x else die 12 / 22
  28. Parsers combinators . Determenistic alternative combinator alt :: Parser r

    a → Parser r a → Parser r a alt ma mb = do s ← get catchExc ma $ λea → put s > > catchExc mb $ λeb → die 13 / 22
  29. Parsers combinators . Determenistic alternative combinator alt :: Parser r

    a → Parser r a → Parser r a alt ma mb = do s ← get catchExc ma $ λea → put s > > catchExc mb $ λeb → die Repetition combinator many :: Parser r a → Parser r [a] many v = many_v where many_v = some_v ‘alt‘ (pure [ ]) some_v = (fmap (:) v) < ∗ > many_v 13 / 22
  30. Restricted Markdown AST . Document type Document = [Block] Block

    data Block = Blank | Header (Int, Line) | Paragraph [Line] | UnorderedList [Line] | BlockQuote [Line] 14 / 22
  31. Constructing AST . Parser for Document doc :: Parser Document

    doc = many block where block = blank <|> header <|> paragraph <|> unorderdList <|> blockquote <|> blockMath Parser for headers header :: Parser Block header = do hashes ← token $ some $ char ’#’ text ← nonEmptyLine return $ Header (length hashes, text) 15 / 22
  32. Performance benchmarks. MTL . Estimate Confidence interval Mean time 121

    μs [119 μs, 126 μs] σ 10.0 μs [20.2 μs, 3.84 μs] 16 / 22
  33. Performance benchmarks. Freer EE . Estimate Confidence interval Mean time

    7.53 ms [7.44 ms, 7.66 ms] σ 289 μs [194 μs, 436 μs] 17 / 22
  34. String-like types in Haskell . String Essentially a [Char] —

    poor performance ByteString High performance, but low-level interface Text Unicode-oriented high performance type 18 / 22
  35. Text-oriented Monoids . Input-polymorphic base parser item :: TextualMonoid t

    ⇒ Parser t Char item = do s ← splitCharacterPrefix ◦ remainder < $ > get case s of Nothing → throwError Just (c, rest) → put rest ∗ > pure c ‘uncons’-like function splitCharacterPrefix :: TextualMonoid t ⇒ t → Maybe (Char, t) 19 / 22
  36. Conclusion and results . 1. Parsers combinators library and Markdown

    parser based on Monad Transformers. ∙ https://github.com/geo2a/markdown_monparsing 2. Parsers combinators library and Markdown parser based on Extensible Effects. ∙ https://github.com/geo2a/ext-effects-parsers ∙ https://github.com/geo2a/ext-effects-markdown 3. Performance comparison of Monad Transformers and Extensible Effects based libraries. 20 / 22
  37. References . ∙ Monadic Parser Combinators // Graham Hutton, Erik

    Meijer – Department of Computer Science, University of Nottingham, 1996 ∙ Adding Structure to Monoids // Mario Blaževic – Stilo International plc ∙ Extensible Effects An Alternative to Monad Transformers // Oleg Kiselyov, Amr Sabry, Cameron Swords – Indiana University, USA ∙ Freer monads and more extensible effects // Oleg Kiselyov, Hiromi Ishii 21 / 22
  38. Questions? . Results outline 1. Parsers combinators library and Markdown

    parser based on Monad Transformers. 2. Parsers combinators library and Markdown parser based on Extensible Effects. 3. Performance comparison of Monad Transformers and Extensible Effects based libraries. Georgiy Lukyanov [email protected] Artem Pelenitsin [email protected] 22 / 22
