DDD17 - Web Applications Automated Security Testing in a Continuous Delivery Pipeline

Slides from "Web Applications Automated Security Testing in a Continuous Delivery Pipeline" workshop, made during Drupal Developers Days 2017 at Seville, Spain

Transcript

1. Web Applications
   Automated Security Testing
   in a Continuous Delivery Pipeline
   At #DrupalDevDaysSeville by @FedirFr


   View Slide

2. About this workshop
   ● Duration 2 hours
   ● 100% open source powered
   ● Intermediate technical level required
   ● Oriented Developers / QA / Operations / CTO / ...
   ● Interactive, study-oriented ...


   View Slide

3. Workshop content
   ● Theoretical part
   ● Introduction to Web security
   ○ Major security risks
   ○ Pentesting types
   ● Insecure code
   ● Drupalxploitable project
   ● Practical part
   ● Vulnerable site create / study
   ● Manual security testing with
   scanners
   ● Manual security testing using Zed
   Attack Proxy GUI
   ● Automated security testing


   View Slide

4. Introduction in Web Security


   View Slide

5. Major Risks


   View Slide

6. Pentesting methods - Black-box
   ● We don't know what is inside
   ● Testing as an external user


   View Slide

7. Pentesting methods - Grey-box
   ● We have advanced access to the project


   View Slide

8. Pentesting methods - White-box
   ● We know all about the project
   ● We have the access to the project code


   View Slide

9. Manual Penetration Testing
   Scanner Target


   View Slide

10. Manual Penetration Testing with Proxy
    Web browser Attack Proxy Target


    View Slide

11. Automating Penetration Testing
    Web browser Attack Proxy Target
    Security Framework
    CI Bugtraceker


    View Slide

12. Classical continuous delivery model - https://en.wikipedia.org/wiki/Continuous_delivery


    View Slide

13. How to write
    (in)secure code
    for Drupal 8


    View Slide

14. Current situation for Drupal 8
    ● https://www.drupal.org/docs/8/security/writing-secure-code-for-drupal-8
    a. Sanitizing on output to avoid Cross Site Scripting (XSS) attacks : t(), Html::escape
    Xss::filter() or Xss::filterAdmin()
    b. Checking URLs UrlHelper::stripDangerousProtocols(), UrlHelper::filterBadProtocol(),
    SafeMarkup::format().
    c. Use the database abstraction layer to avoid SQL injection attacks


    View Slide

15. Bad code example - SQL Injection
    db_query('SELECT foo FROM {table} t WHERE t.name = '. $_GET['user']);
    Exploit example : https://www.exploit-db.com/exploits/34993/


    View Slide

16. Bad code example - XSS exploits
    - --- modules/system/system.admin.inc 2013-04-03 17:29:52.000000000 -0400
    +++ modules/system/system.admin.inc 2013-08-07 10:47:29.277279676 -0400
    @@ -979,10 +979,10 @@ function _system_modules_build_row($info
    );
    // Set the basic properties.
    $form['name'] = array(
    - - '#markup' => $info['name'],
    + '#markup' => check_plain($info['name']),
    );
    $form['description'] = array(
    - - '#markup' => t($info['description']),
    + '#markup' => t("@desc", array('@desc' => $info['description'])),
    );
    $form['version'] = array(
    '#markup' => $info['version'],
    http://seclists.org/fulldisclosure/2013/Aug/158


    View Slide

17. There are much more risks ...
    SQL, HTML, iFrame, SSI, OS Command, PHP, XML, XPath, LDAP, Host Header and SMTP injections
    Cross-Site Scripting (XSS), Cross-Site Tracing (XST) and Cross-Site Request Forgery (CSRF)
    AJAX and Web Services issues (jQuery/JSON/XML/SOAP/WSDL)
    Authentication, authorization and session issues, file upload flaws and backdoor files
    Arbitrary file access, directory traversals, local and remote file inclusions (LFI/RFI)
    Configuration issues: Man-in-the-Middle, cross-domain policy files, information disclosures,...
    HTTP parameter pollution, HTTP response splitting and HTTP verb tampering
    Insecure DistCC, FTP, NTP, Samba, SNMP, VNC and WebDAV configurations
    HTML5 ClickJacking, Cross-Origin Resource Sharing (CORS) and web storage issues
    XML External Entity attacks (XXE) and Server Side Request Forgery (SSRF)
    Heartbleed and Shellshock vulnerability (OpenSSL), Denial-of-Service (DoS) attacks
    Parameter tampering, cookie and password reset poisoning ...


    View Slide

18. Drupalxploitable


    View Slide

19. About Drupalxploitable
    ● Purposefully vulnerables Drupal installation
    ● Basically : “a very crappy Drupal site”
    ● Open source (github)


    View Slide

20. Existing projects in PHP world
    Damn Vulnerable Web Application (DVWA)
    http://www.dvwa.co.uk/
    Mutillidae
    http://www.irongeek.com/i.php?page=mutillidae/mutillidae-deliberately-vulnerable-php-owasp-top-10
    WebGoatPHP
    https://github.com/shivamdixit/WebGoatPHP
    buggy web application
    http://www.itsecgames.com/


    View Slide

21. And even standalone distribution
    Metasploitable
    https://sourceforge.net/projects/metasploitable/


    View Slide

22. Practical part


    View Slide

23. Used infrastructure
    ● Virtualbox VM
    ○ Ubuntu 16.04 LTS server 64 bit
    ○ Jenkins CI
    ○ OWASP ZAP, sqlmap, CMSMap ...
    ○ Drupal 8 vulnerable site for manual and automatic testing


    View Slide

24. SSH
    Access from host by 2222 port (mapped to 22)
    $ ssh drupal@127.0.0.1 -p 2222
    SSH credentials : root / password
    Jenkins
    Access from the host: http://127.0.0.1:8180/
    Internal VM access: http://127.0.0.1:8080/
    Admin credentials : admin / password
    Drupal / Apache
    Access from the host: http://127.0.0.1:8280/
    Internal VM access: http://127.0.0.1/
    Admin credentials : drupal / drupal
    Virtualbox - Services description


    View Slide

25. sqlmap
    python sqlmap.py -v 2 --url=http://127.0.0.1/user/ --user-agent=SQLMAP
    --delay=1 --retries=2 --keep-alive --threads=5 --batch --dbms=MySQL --os=Linux
    --level=5 --risk=2 --banner --is-dba --dbs --tables --technique=BEUST -s
    /tmp/scan_report.txt --flush-session -t /tmp/scan_trace.txt --fresh-queries


    View Slide

26. CMSmap
    python cmsmap.py -t http://127.0.0.1 -f D
    https://github.com/Dionach/CMSmap


    View Slide

27. droopescan
    droopescan scan drupal -u http://127.0.0.1/ -t 8
    https://github.com/droope/droopescan


    View Slide

28. gauntlt
    https://github.com/gauntlt/gauntlt
    https://github.com/gauntlt/gauntlt-demo/tree/master/examples
    Uses natural language in a Given, When, Then Gherkin syntax to describe
    security requirements as features.


    View Slide

29. bdd-security
    https://github.com/continuumsecurity/bdd-security
    https://www.continuumsecurity.net/bdd-security/
    Selenium + OWASP ZAP + Nessus + SSLyze + Internal security tools


    View Slide

30. OWASP ZAP


    View Slide

31. OWASP ZAP - Simple scan
    zap-cli quick-scan --self-contained --start-options '-config api.disablekey=true'
    http://127.0.0.1/
    zap-cli --api-key coeoobt6fof9k4g3iajshtnp7v quick-scan --self-contained
    --spider -r http://127.0.0.1/
    * API key could be found in ~/.ZAP/config.xml of current user.


    View Slide

32. OWASP ZAP - Simple scan with ZAPR
    zapr --debug --summary http://127.0.0.1


    View Slide

33. OWASP ZAP - Running as a daemon
    /opt/zaproxy/zap.sh -daemon -host 0.0.0.0 -port 8480
    Also, Docker usage possible : https://github.com/zaproxy/zaproxy/wiki/Docker


    View Slide

34. OWASP ZAP - Plugins management
    Install all plugins, take some time :
    su jenkins /opt/zaproxy/zap.sh -daemon -host 0.0.0.0 -port 8480 -addoninstallall
    Install selected plugin :
    su jenkins /opt/zaproxy/zap.sh -daemon -host 0.0.0.0 -port 8480 -addoninstall exportreport
    * Plugins will be installed in the ~/.ZAP folder of user, who launches ZAP.
    ** Plugins keys could be found here :
    https://github.com/zaproxy/zap-extensions/releases


    View Slide

35. OWASP ZAP
    https://github.com/zaproxy/zaproxy/wiki/Docker
    zap.sh -daemon -host 0.0.0.0 -port 8480
    zap-x.sh -daemon -host 0.0.0.0 -port 8080
    zap-cli quick-scan --self-contained \
    --start-options '-config api.disablekey=true' http://target


    View Slide

36. Configure Jenkins CI security
    project


    View Slide

37. Ubuntu server VM
    Jenkins CI
    Server
    Drupalxploitable
    Owasp ZED
    Attack Proxy
    Report results
    Run security scan
    Drupal automated security testing model


    View Slide

38. Jenkins CI - Plugins used
    ● Official OWASP ZAP Jenkins Plugin
    ● Environment Injector Plugin


    View Slide

39. Jenkins - OWASP ZAP Plugin - Configuration
    https://wiki.jenkins-ci.org/display/JENKINS/ZAProxy+Plugin


    View Slide

40. Ressources
    ● https://martijnvanlambalgen.wordpress.com/2015/10/18/automating-your-vulnerability-scan-with-owasp-zap/
    ● https://www.securify.nl/blog/SFY20150303/automating_security_tests_using_owasp_zap_and_jenkins.html
    ● https://tools.pentestbox.org/
    ● https://www.owasp.org/index.php/OWASP_Vulnerable_Web_Applications_Directory_Project
    ● http://connect.ed-diamond.com/MISC/MISC-087/Pourquoi-inclure-la-securite-dans-votre-pipeline-DevOps
    ● https://www.owasp.org/index.php/Automated_Audit_using_SQLMap
    ● https://myexploit.wordpress.com/information-gathering-sqlmap/
    ● https://insights.sei.cmu.edu/devops/2016/01/adding-security-to-your-devops-pipeline.html
    ● https://www.slideshare.net/wickett/pragmatic-security-and-rugged-devops-sxsw-2015
    ● https://es.slideshare.net/StephendeVries2/automating-security-tests-for-continuous-integration
    ● https://www.drupal.org/docs/8/security/writing-secure-code-for-drupal-8
    ● https://www.drupal.org/node/101496
    ● https://www.drupal.org/taxonomy/term/127
    ● https://www.owasp.org/index.php/How_to_write_insecure_code
    ● https://es.slideshare.net/StephendeVries2/continuous-and-visible-security-testing-with-bddsecurity
    ● https://theagileadmin.com/2015/12/03/security-tooling-delivered-by-docker/


    View Slide

41. Special thanks
    ● To my company @AgenceStratis, which understands the importance of
    open source culture and supports it
    ● To Mikke Schirén (@mikkdroid) from wunderkraut, who really helped us
    with Jenkins 2 configuration during the workshop day
    ● To Drupal Developer Days Sevilla team for great organization of the event.


    View Slide
