GraphQL integration with Redux

Transcript

1. Angular Meetup
 Leipzig GraphQL integration with Redux
2. Table of content I. Redux (ngrx) II. GraphQL Subscriptions (data resources) III. Apollo Cache IV. Apollo ngrx-cache
3. Angular Meetup
 Leipzig Redux
4. Consider using Redux You should when: • multiple components needs to access the same state but do not have any parent/child relationship • you start to feel awkward passing down the state to multiple components with props Dan Abramov says “Flux libraries are like glasses: you’ll know when you need them.”
5. Consider using Redux And in fact it worked like that for me. Be aware that Redux is not useful for smaller apps. It really shines in bigger ones.
6. Apollos local state management ??? Slides about Apollo: https://goo.gl/w1mjrZ Minimize query Redux Apollo Client Client Server UI Components Compose results Normalize
7. Redux architecture ACTION REDUCER STATE COMPONENT Store Send To Mutate Render Dispatch
8. Three Principles • Single source of truth • State is read-only • Changes are made with pure functions
9. @ngrx - actions The principle of Redux says the only way to change the state is by sending a signal to the store Actions must have a type field that indicates the type of action being performed
10. @ngrx - actions import { Action } from '@ngrx/store'; export const START = '[Entry] start timer'; export const STARTED = '[Entry] timer started'; export class Start implements Action { readonly type = START; constructor(public payload: { project: number }) { } } export class Started implements Action { readonly type = STARTED; constructor(public payload: Entry) { } } export type All = Start | Started;
11. @ngrx - selectors import { createSelector } from '@ngrx/store'; import { IDB } from '../IDB.interface'; function getEntryState(db: IDB): Entry[] { return db.entryBranch; } export const getAll = createSelector( getEntryState, (state: Entry[]) => state ); export const getActive = createSelector( getEntryState, (state: Entry[]) => state.filter(entry => !entry.end) );
12. @ngrx - reducers Reducers produce the state of the application A reducer is just a pure function. A reducer takes two parameters: the current state and an action const rootReducer = (state = initialState, action) => state;
13. @ngrx - reducers export function EntryReducer(state = initialEntryBranch, action: EntryActions.All): EntryState { switch (action.type) { case EntryActions.START: { return { ...state, ...action.payload }; } case EntryActions.STARTED: { return { ...state, ...action.payload }; } default: { return state; } } }
14. @ngrx - effects import * as entry from './entry.actions'; import { EntryResource } from './entry.resource'; @Injectable() export class EntryEffects { @Effect() start$: Observable<Action> = this.actions$.pipe( ofType<entry.Start>(entry.START), switchMap(({ payload }) => this.er.start(payload).pipe( map(payload => new entry.Started(payload)), catchError(err => of(new entry.Error(err))) ) ) ); constructor(private actions$: Actions, private er: EntryResource) { } }
15. Angular Meetup
 Leipzig GraphQL Subscriptions
16. GraphQL query const queryRef = this.apollo.watchQuery<any>({ query: gql` query getEntries { entries { id data } } ` });
17. GraphQL subscribe queryRef.subscribeToMore({ document: gql` subscription entryChanged { entryChanged { id data } } `, onError: console.error, updateQuery: (prev, { subscriptionData }) => subscriptionData.data ? { ...prev, entries: [ ...prev.entries.filter((entry: Entry) => entry.id !== subscriptionData.data.entryChanged.id), subscriptionData.data.entryChanged ] } : prev });
18. Angular Meetup
 Leipzig Apollo - Cache
19. Caching data apollo-cache-inmemory is the default cache implementation for Apollo Client 2.0. InMemoryCache is a normalized data store that supports all of Apollo Client 1.0’s features without the dependency on Redux. import { InMemoryCache } from 'apollo-cache-inmemory'; import { HttpLink } from 'apollo-link-http'; import ApolloClient from 'apollo-client'; const cache = new InMemoryCache(); const client = new ApolloClient({ link: new HttpLink(), cache }); In some instances, you may need to manipulate the cache directly, such as updating the store after a mutation.
20. Configuration The InMemoryCache constructor takes an optional config object with properties to customize your cache: • addTypename: A boolean to determine whether to add __typename to the document (default: true) • dataIdFromObject: A function that takes a data object and returns a unique identifier to be used when normalizing the data in the store. • fragmentMatcher: By default, the InMemoryCache uses a heuristic fragment matcher. If you are using fragments on unions and interfaces, you will need to use an IntrospectionFragmentMatcher. • cacheRedirects (previously known as cacheResolvers or customResolvers): A map of functions to redirect a query to another entry in the cache before a request takes place. This is useful if you have a list of items and want to use the data from the list query on a detail page where you’re querying an individual item.
21. Normalization InMemoryCache will attempt to use the commonly found primary keys of id and _id for the unique identifier if they exist along with __typename on an object If id and _id are not specified, or if __typename is not specified, InMemoryCache will fall back to the path to the object in the query, such as ROOT_QUERY.allPeople.0 const cache = new InMemoryCache({ dataIdFromObject: object => object.key || null });
22. Store structure { "Entry:14":{"id":14,"project":1,"start":1537971622,"end":null,"__typename":"Entry"}, "Entry:15":{"id":15,"project":2,"start":1537971624,"end":1537974315,"__typename":"Entry"}, "ROOT_QUERY":{ "entries":[ {"type":"id","generated":false,"id":"Entry:14","typename":"Entry"}, {"type":"id","generated":false,"id":"Entry:15","typename":"Entry"} ], "projects":[ {"type":"id","generated":false,"id":"Project:2","typename":"Project"}, {"type":"id","generated":false,"id":"Project:1","typename":"Project"} ] }, "Project:2":{"id":2,"name":"p2","__typename":"Project"}, "Project:1":{"id":1,"name":"p1","__typename":"Project"}, "ROOT_SUBSCRIPTION":{"entryChanged":{"type":"id","generated":false,"id":"Entry:22","typename":"Entry"}}, "ROOT_MUTATION":{"stopTimer({\"end\":1537974315,\"id\":15})":{"type":"id","generated":false,"id":"Entry: 15","typename":"Entry"}} }
23. Store structure { "<Typename>:<ID>":{...}, "ROOT_QUERY":{ "QUERY_KEY":[ REFERENCE ] } }
24. Store structure { "type": "id", "generated": false, "id": "Project:2", "typename": "Project" }
25. Direct Cache Access const { todo } = apollo.readQuery({ query: gql` query ReadTodo { todo(id: 5) { id text completed } } `, }); To interact directly with your cache, you can use the Apollo Client class methods readQuery, readFragment, writeQuery, and writeFragment.
26. Angular Meetup
 Leipzig Apollo - ngrx-Cache
28. Setup ngrx cache @NgModule({ imports: [ StoreModule.forRoot({ apollo: apolloReducer, }), NgrxCacheModule, ], }) class AppModule { constructor(ngrxCache: NgrxCache) { const cache = ngrxCache.create({}); } } Put apolloReducer under apollo in your State and import NgrxCacheModule
29. Redux architecture with Apollo ACTION Apollo REDUCER STATE COMPONENT Store Send To Mutate Render Dispatch
30. Apollo reducer at work
31. How to use Just run your GraphQL queries in effects and receive data asynchronously from store automatically
32. How to use function getEntryState(db: IDB): Entry[] { return ((db.apollo.ROOT_QUERY || {}) .entries || []) .map((ref: RootQuery) => ref.id) .map((id: string) => db.apollo[id]); } export const getAll = createSelector( getEntryState, state => state ); Minor changes in selectors
33. Helper for the Apollo store The biggest advantage now is to be able to connect the data in selectors. But how do we read from the store export const isApolloRef = (obj: any): Boolean => { return obj && obj.type === 'id' && typeof obj.id !== 'undefined' && typeof obj.typename !== 'undefined'; }; export const resolve = (apollo: any, key: string, obj?: any): any => (typeof (obj || apollo[key]) === 'object') ? Object.keys(obj || apollo[key]) .reduce((res: any, prop) => { !obj && isApolloRef((obj || apollo[key])[prop]) ? res[prop] = resolve(apollo, (obj || apollo[key])[prop].id) : res[prop] = obj && obj[prop] || resolve(apollo, null, apollo[key][prop]); return res; }, Array.isArray(obj || apollo[key]) ? [] : {}) : (obj || apollo[key]);
34. How to use import { Store } from '@ngrx/store'; import { IDB } from '../state-management/IDB.interface'; import * as entry from '../state-management/entry/entry.actions'; import * as fromEntry from '../state-management/entry/entry.reducer'; export class EntriesComponent { public entries$: Observable<Entry[]>; constructor( private store: Store<IDB>) { this.entries$ = this.store.select(fromEntry.getAll); this.store.dispatch(new entry.Load()); } } <ul> <li *ngFor="let entry of entries$ | async">{{ entry | json }}</li> </ul> import { Store } from '@ngrx/store'; import { IDB } from '../state-management/IDB.interface'; import * as entry from '../state-management/entry/entry.actions'; import * as fromEntry from '../state-management/entry/entry.reducer'; export class EntriesComponent { public entries$: Observable<Entry[]>; constructor( private store: Store<IDB>) { this.entries$ = this.store.select(fromEntry.getAll); this.store.dispatch(new entry.Load()); } } <ul> <li *ngFor="let entry of entries$ | async">{{ entry | json }}</li> </ul>
35. Angular Meetup
 Leipzig this.store.dispatch(new question.Ask()); github.com/fr0gM4ch1n3
 goo.gl/t2Sw69 Angular Meetup
 Leipzig
