Should Kubernetes have a DSL for configuration?

Slides used for the introduction to my Birds of a Feather session at KubeCon EU in Berlin. A discussion of various approaches to using programming languages to configure Kubernetes rather than writing the raw data.

Transcript

1. (without introducing more risk)
   Should Kubernetes
   have a DSL?
   Puppet
   Gareth Rushgrove
   Alternative configuration options for K8


   View Slide

2. (without introducing more risk)
   @garethr


   View Slide

3. (without introducing more risk)
   Gareth Rushgrove


   View Slide

4. (without introducing more risk)
   What we’ll cover
   This session


   View Slide

5. - Setting the scene
   - Open discussion
   - Summary
   Gareth Rushgrove


   View Slide

6. (without introducing more risk)
   The argument
   Why not (only) YAML


   View Slide

7. Gareth Rushgrove
   Brian Grant, Google, Kubernetes Config SIG
   “We've had a few complaints that YAML is
   ugly, error prone, hard to read, etc. Are
   there any other alternatives we might want
   to support?


   View Slide

8. Gareth Rushgrove


   View Slide

9. (without introducing more risk)
   Gareth Rushgrove
   API wire format as user interface
   template:
   metadata:
   labels:
   app: guestbook
   tier: frontend
   spec:
   containers:
   - name: php-redis
   image: gcr.io/google_samples/gb-frontend:v4
   resources:
   requests:
   cpu: 100m
   memory: 100Mi
   env:


   View Slide

10. The language to represent the data should
    be a simple, data-only format such as JSON
    or YAML, and programmatic modification of
    this data should be done in a real
    programming language
    Gareth Rushgrove
    Borg, Omega, and Kubernetes, ACM Queue, Volume 14, issue 1 http://queue.acm.org/detail.cfm?id=2898444
    “


    View Slide

11. The reality is probably closer to most people
    hand writing YAML files
    Gareth Rushgrove


    View Slide

12. Code allows us to
    - Avoid repetition
    - Combine external inputs
    - Enforce correctness
    - Introduce abstractions
    Gareth Rushgrove


    View Slide

13. (without introducing more risk)
    Configuration language for JSON data
    Jsonnet


    View Slide

14. (without introducing more risk)
    jsonnet.org


    View Slide

15. (without introducing more risk)
    kubernetes examples


    View Slide

16. (without introducing more risk)
    kubecfg


    View Slide

17. (without introducing more risk)
    Gareth Rushgrove
    Jsonnet template
    $ cat squid.jsonnet
    local squid = {
    namespace:: "squid",
    squid_service: kube.Service("proxy") {
    metadata+: { namespace: $.namespace },
    target_pod: $.squid.spec.template,
    port: 80,
    },
    squid_data: kube.PersistentVolumeClaim("proxy") {
    metadata+: { namespace: $.namespace },


    View Slide

18. (without introducing more risk)
    A REPL for Kubernetes
    Kubeplay


    View Slide

19. (without introducing more risk)
    errordeveloper/kubeplay


    View Slide

20. (without introducing more risk)
    Gareth Rushgrove
    A REPL for Kubernetes
    $ ./kubeplay
    kubeplay (namespace="*")> pods # list pods in the cluster

    kubeplay (namespace="*")> @pod = _.any # pick a random pod from the list
    kubeplay (namespace="*")> puts @pod.to_json # output the pod definition
    {
    "metadata": {
    ...
    },
    "spec": {
    ...
    "containers": [
    {


    View Slide

21. (without introducing more risk)
    Gareth Rushgrove
    Ruby based DSL
    @metadata = replicasets("*/").to_ruby.items.map do |k,v|
    v.metadata
    end
    @metadata.each do |i|
    puts "Name:\t#{i.name}"
    puts "Labels:\t#{i.labels}"
    puts
    end


    View Slide

22. (without introducing more risk)
    Declarative Domain Specific Language
    Puppet


    View Slide

23. (without introducing more risk)
    garethr/garethr-kubernetes


    View Slide

24. (without introducing more risk)
    Gareth Rushgrove
    Puppet DSL
    kubernetes_pod { 'sample-pod':
    ensure => present,
    metadata => {
    namespace => 'default',
    },
    spec => {
    containers => [{
    name => 'container-name',
    image => 'nginx',
    }]
    },
    }


    View Slide

25. (without introducing more risk)
    More Domain Specific Language
    Terraform


    View Slide

26. (without introducing more risk)
    maxmanuylov/terraform-provider-kubernetes


    View Slide

27. (without introducing more risk)
    Gareth Rushgrove
    Terraform provider
    resource "kubernetes_resource" "mypod" {
    # Required, must link on the corresponding "kubernetes_cluster" data s
    cluster = "${data.kubernetes_cluster.main.cluster}"
    collection = "pods"
    name = "mypod"
    labels {
    a = "b"
    }
    }


    View Slide

28. (without introducing more risk)
    A compiled typed JVM language for config
    Kotlin DSL


    View Slide

29. (without introducing more risk)
    k8-kotlin-dsl


    View Slide

30. (without introducing more risk)
    Gareth Rushgrove
    Ingress in Kotlin
    import com.fkorotkov.kubernetes.*
    import io.fabric8.kubernetes.api.model.IntOrString
    import io.fabric8.kubernetes.client.DefaultKubernetesClient
    fun main(args: Array) {
    val client = DefaultKubernetesClient().inNamespace("default")
    client.extensions().ingresses().createOrReplace(
    ingress {
    metadata {
    name = "example-ingress"
    }
    spec {
    backend {


    View Slide

31. (without introducing more risk)
    A scala language for kubernetes config
    Skuber


    View Slide

32. (without introducing more risk)
    Skuber


    View Slide

33. (without introducing more risk)
    Gareth Rushgrove
    RC in Scala
    import skuber._
    import skuber.json.format._
    val nginxSelector = Map("app" -> "nginx")
    val nginxContainer = Container("nginx",image="nginx").exposePort(80)
    val nginxController=
    ReplicationController("nginx",nginxContainer,nginxSelector)
    .withReplicas(5)
    val nginxService = Service("nginx")
    .withSelector(nginxSelector)
    .exposeOnNodePort(30001 -> 80)
    import scala.concurrent.ExecutionContext.Implicits.global


    View Slide

34. (without introducing more risk)
    Useful parts of potential solutions
    Notable mentions


    View Slide

35. (without introducing more risk)
    JSON Schema


    View Slide

36. (without introducing more risk)
    Open API/Swagger


    View Slide

37. (without introducing more risk)
    Discussion
    And thanks for listening


    View Slide
