The Challenges of Container Configuration

The Challenges of Container Configuration

Talk from Craft 2016 all about configuration and containers

98234c645fe8c935edc0fec0186d28b8?s=128

Gareth Rushgrove

April 29, 2016
Tweet

Transcript

  1. (without introducing more risk) The Challenges of Container Configuration Puppet

    Gareth Rushgrove New capabilities and associated problems
  2. (without introducing more risk) Gareth Rushgrove @garethr

  3. (without introducing more risk) Gareth Rushgrove

  4. (without introducing more risk) Configuration What is it and why

    should I care
  5. (without introducing more risk) Gareth Rushgrove

  6. (without introducing more risk) synonyms: design, grouping, marshalling Gareth Rushgrove

  7. (without introducing more risk) Designing your infrastructure Gareth Rushgrove

  8. (without introducing more risk) Marshalling your containers Gareth Rushgrove

  9. (without introducing more risk) - Immutability and containers - Runtime

    vs build time - Who configures the orchestrator? Gareth Rushgrove
  10. (without introducing more risk) Mainly Docker and Kubernetes examples, but

    should be generally applicable Gareth Rushgrove
  11. (without introducing more risk) Everything is immutable now? Assumptions vs

    reality
  12. (without introducing more risk) Gareth Rushgrove

  13. (without introducing more risk) Gareth Rushgrove $ docker run -d

    ubuntu:16.04 /bin/sh \ -c "while true; do echo hello world; sleep 1; done"
  14. (without introducing more risk) Gareth Rushgrove $ docker exec a7a01beb14de

    touch /tmp/surprise
  15. (without introducing more risk) Gareth Rushgrove $ docker diff a7a01beb14de

    C /tmp A /tmp/surprise
  16. (without introducing more risk) Containers are not immutable by default

    Gareth Rushgrove
  17. (without introducing more risk) Containers are not immutable by default

    Gareth Rushgrove
  18. (without introducing more risk) Gareth Rushgrove $ docker run --read-only

    -d ubuntu:16.04 /bin/sh \ -c "while true; do echo hello world; sleep 1; done"
  19. (without introducing more risk) Gareth Rushgrove $ docker exec 379150b2cf05

    touch /tmp/surprise touch: cannot touch '/tmp/surprise': Read-only file syste
  20. (without introducing more risk) Suggestion Enable read-only where possible Gareth

    Rushgrove
  21. (without introducing more risk) Many applications won’t start with a

    read-only filesystem Gareth Rushgrove
  22. (without introducing more risk) Gareth Rushgrove 1 import logging 2

    from logging.handlers import RotatingFileHandler 3 4 from flask import Flask 5 6 app = Flask(__name__) 7 8 @app.route('/') 9 def home(): 10 app.logger.info('log request') 11 return "We'll never get to here" 12 13 if __name__ == '__main__': 14 handler = RotatingFileHandler('app.log', maxBytes=10000, backupCount 15 handler.setLevel(logging.INFO) 16 app.logger.addHandler(handler) 17 app.run(debug=True, host='0.0.0.0')
  23. (without introducing more risk) Gareth Rushgrove 1 import logging 2

    from logging.handlers import RotatingFileHandler 3 4 from flask import Flask 5 6 app = Flask(__name__) 7 8 @app.route('/') 9 def home(): 10 app.logger.info('log request') 11 return "We'll never get to here" 12 13 if __name__ == '__main__': 14 handler = RotatingFileHandler('app.log', maxBytes=10000, backupCount 15 handler.setLevel(logging.INFO) 16 app.logger.addHandler(handler) 17 app.run(debug=True, host='0.0.0.0')
  24. (without introducing more risk) Gareth Rushgrove $ docker run --read-only

    -p 5000:5000 garethr/flaskapp Traceback (most recent call last): File "app.py", line 14, in <module> handler = RotatingFileHandler('app.log', maxBytes=10000, backupCount=1) File "/usr/lib/python2.7/logging/handlers.py", line 117, in __init__ BaseRotatingHandler.__init__(self, filename, mode, encoding, delay) File "/usr/lib/python2.7/logging/handlers.py", line 64, in __init__ logging.FileHandler.__init__(self, filename, mode, encoding, delay) File "/usr/lib/python2.7/logging/__init__.py", line 913, in __init__ StreamHandler.__init__(self, self._open()) File "/usr/lib/python2.7/logging/__init__.py", line 943, in _open stream = open(self.baseFilename, self.mode) IOError: [Errno 30] Read-only file system: '/app/app.log'
  25. (without introducing more risk) tmpfs support added in Docker 1.10

    Gareth Rushgrove
  26. (without introducing more risk) Gareth Rushgrove $ docker run --read-only

    --tmpfs /tmp \ -d ubuntu:16.04 /bin/sh \ -c "while true; do echo hello world; sleep 1; done"
  27. (without introducing more risk) Gareth Rushgrove $ docker exec 222331443d28

    touch /tmp/surprise
  28. (without introducing more risk) Gareth Rushgrove $ docker diff 222331443d28

  29. (without introducing more risk) Gareth Rushgrove $ docker exec 222331443d28

    ls /tmp surprise
  30. (without introducing more risk) Suggestion Use tmpfs only where needed

    Gareth Rushgrove
  31. (without introducing more risk) Remember Without technical controls you only

    have social guarantees of immutability Gareth Rushgrove
  32. (without introducing more risk) Build vs Run And the relationship

    between them
  33. (without introducing more risk) Given an image - What machine

    built this image? - Are all the licenses compatible? - Who supports this image? - Does this image contain malware? Gareth Rushgrove
  34. (without introducing more risk) Given a running container - Who

    built it? - How was it built? - What software does it contain? - Is the software up-to-date? Gareth Rushgrove
  35. (without introducing more risk) Gareth Rushgrove FROM ubuntu:16.04 RUN apt-get

    update && \ apt-get install -y python-pip python-dev build-essent apt-get clean && \ rm -rf /var/lib/apt/lists/* RUN pip install flask COPY . /app WORKDIR /app ENTRYPOINT ["python"] CMD ["app.py"]
  36. (without introducing more risk) Gareth Rushgrove FROM ubuntu:16.04 RUN apt-get

    update && \ apt-get install -y python-pip python-dev build-essent apt-get clean && \ rm -rf /var/lib/apt/lists/* RUN pip install flask COPY . /app WORKDIR /app ENTRYPOINT ["python"] CMD ["app.py"] Where did this base image come from?
  37. (without introducing more risk) Gareth Rushgrove FROM ubuntu:16.04 RUN apt-get

    update && \ apt-get install -y python-pip python-dev build-essent apt-get clean && \ rm -rf /var/lib/apt/lists/* RUN pip install flask COPY . /app WORKDIR /app ENTRYPOINT ["python"] CMD ["app.py"] What packages are installed? At what version? Where are those packages from?
  38. (without introducing more risk) Gareth Rushgrove FROM ubuntu:16.04 RUN apt-get

    update && \ apt-get install -y python-pip python-dev build-essent apt-get clean && \ rm -rf /var/lib/apt/lists/* RUN pip install flask COPY . /app WORKDIR /app ENTRYPOINT ["python"] CMD ["app.py"] What version of flask is this?
  39. (without introducing more risk) Gareth Rushgrove FROM ubuntu:16.04 RUN apt-get

    update && \ apt-get install -y python-pip python-dev build-essent apt-get clean && \ rm -rf /var/lib/apt/lists/* RUN pip install flask COPY . /app WORKDIR /app ENTRYPOINT ["python"] CMD ["app.py"] What was in this folder at build time?
  40. (without introducing more risk) The importance of time Gareth Rushgrove

  41. (without introducing more risk) How often are images rebuilt? Gareth

    Rushgrove
  42. (without introducing more risk) Rebuilding only on code change ignores

    environmental factors Gareth Rushgrove
  43. (without introducing more risk) Versioning and metadata Gareth Rushgrove

  44. (without introducing more risk) Gareth Rushgrove LABEL vendor="ACME\ Incorporated" \

    com.example.is-beta \ com.example.version="0.0.1-beta" \ com.example.release-date="2015-02-12"
  45. (without introducing more risk) Gareth Rushgrove LABEL vendor="ACME\ Incorporated" \

    com.example.is-beta \ com.example.version="0.0.1-beta" \ com.example.release-date="2015-02-12" What time? What timezone?
  46. (without introducing more risk) Gareth Rushgrove $ docker inspect -f

    "{{json .Config.Labels }}" \ 4fa6e0f0c678 | jq { "vendor": "ACME Incorporated", "com.example.is-beta": "", "com.example.version": "0.0.1-beta", "com.example.release-date": "2015-02-12" }
  47. (without introducing more risk) Suggestion Decide upon and enforce metadata

    standards Gareth Rushgrove
  48. (without introducing more risk) Gareth Rushgrove LABEL com.example.git.repository="https://github.com/pupp com.example.git.sha="dc123cfb5ed4dca43a84be34a99d7c com.example.build.time="2016-04-24T15:43:05+00:00"

    com.example.build.builder=“jenkins1.example.com" \ com.example.docs="https://github.com/puppetlabs/doc ...
  49. (without introducing more risk) Suggestion Embed Dockerfiles in images Gareth

    Rushgrove
  50. (without introducing more risk) Gareth Rushgrove $ docker inspect -f

    "{{json .Config.Labels }}" \ garethr/alpine \ | jq { "net.morethanseven.dockerfile": "/Dockerfile", }
  51. (without introducing more risk) Gareth Rushgrove $ docker run -i

    -t garethr/alpine cat /Dockerfile FROM alpine LABEL net.morethanseven.dockerfile="/Dockerfile" RUN apk add --update bash && rm -rf /var/cache/apk/* COPY Dockerfile /
  52. (without introducing more risk) Suggestion Provide an API for your

    containers Gareth Rushgrove
  53. (without introducing more risk) Gareth Rushgrove $ docker inspect -f

    "{{json .Config.Labels }}" \ garethr/alpine \ | jq { "com.example.api.packages": "apk info -vv" }
  54. (without introducing more risk) Gareth Rushgrove $ docker run -i

    -t garethr/alpine apk info -vv musl-1.1.11-r2 - the musl c library (libc) implementation busybox-1.23.2-r0 - Size optimized toolbox of many common UNIX alpine-baselayout-2.3.2-r0 - Alpine base dir structure and init openrc-0.15.1-r3 - OpenRC manages the services, startup and shu alpine-conf-3.2.1-r6 - Alpine configuration management scripts
  55. (without introducing more risk) DEMO

  56. (without introducing more risk) Who configures the scheduler? Higher level

    configuration
  57. (without introducing more risk) Schedulers/orchestrators abstract you from - Where

    individual containers run - Balancing due to new resources - Balancing due to failed resources Gareth Rushgrove
  58. (without introducing more risk) This results in a constraints based

    system Gareth Rushgrove
  59. (without introducing more risk) Which means those constraints need to

    be explicit and correct Gareth Rushgrove
  60. (without introducing more risk) Gareth Rushgrove $ docker daemon \

    --label com.example.environment="production" \ --label com.example.storage="ssd"
  61. (without introducing more risk) Gareth Rushgrove $ docker run -d

    -P \ -e constraint:storage==ssd --name db mysql
  62. (without introducing more risk) Gareth Rushgrove 1 template: 2 metadata:

    3 labels: 4 app: guestbook 5 tier: frontend 6 spec: 7 containers: 8 - name: php-redis 9 image: gcr.io/google_samples/gb-frontend:v4 10 resources: 11 requests: 12 cpu: 100m 13 memory: 100Mi 14 env: 15 - name: GET_HOSTS_FROM 16 value: dns 17 # If your cluster config does not include a dns service, th 18 # instead access environment variables to find service host 19 # info, comment out the 'value: dns' line above, and uncomm
  63. (without introducing more risk) How do you manage properties for

    all of your hosts? Gareth Rushgrove
  64. (without introducing more risk) Gareth Rushgrove $ docker daemon \

    --label com.example.environment="production" \ --label com.example.storage="ssd" Does this machine really have an SSD? What if someone swaps the drive?
  65. (without introducing more risk) Suggestion Use properties of hosts as

    labels Gareth Rushgrove
  66. (without introducing more risk) Gareth Rushgrove $ facter | head

    -n 20 architecture => x86_64 domain => local facterversion => 2.4.6 fqdn => Pro.local gid => staff hardwareisa => i386 hardwaremodel => x86_64 hostname => Pro id => garethr interfaces => lo0,gif0,stf0,en0,p2p0,awdl0,en1,en2,bridge0,vboxnet0,vboxnet1,v ipaddress => 192.168.0.5 ipaddress_en0 => 192.168.0.5
  67. (without introducing more risk) Gareth Rushgrove $ facter -j os

    | jq { "os": { "name": "Darwin", "family": "Darwin", "release": { "major": "14", "minor": "5", "full": "14.5.0" } } }
  68. (without introducing more risk) Gareth Rushgrove $ docker daemon \

    --label net.example.os=`facter operatingsystem` \ --label net.example.virtual=`facter is_virtual` \ --label net.example.kernel=`facter kernelversion` \ ...
  69. (without introducing more risk) Orchestrators also tend to introduce new

    higher-level primitives Gareth Rushgrove
  70. (without introducing more risk) Docker Networks, Kubernetes Services, ReplicationControllers, Chronos

    Jobs Gareth Rushgrove
  71. (without introducing more risk) Many with imperative interfaces Gareth Rushgrove

  72. (without introducing more risk) Gareth Rushgrove $ kubectl get pod

    mypod -o yaml \ | sed 's/\(image: myimage\):.*$/\1:v4/' \ | kubectl replace -f -
  73. (without introducing more risk) Gareth Rushgrove $ docker network create

    bob c0a0f4538d259515813b771264688d37aaedb41098379a0d73ec0ca08 $ docker network create bob Error response from daemon: network with name bob already
  74. And everything configured in YAML Gareth Rushgrove

  75. Code plus data has advantages over data alone Gareth Rushgrove

  76. The language to represent the data should be a simple,

    data-only format such as JSON or YAML, and programmatic modification of this data should be done in a real programming language Gareth Rushgrove Borg, Omega, and Kubernetes, ACM Queue, Volume 14, issue 1 http://queue.acm.org/detail.cfm?id=2898444 “
  77. Avoid repetition Combine external inputs Correctness Abstractions Gareth Rushgrove -

    - - -
  78. Suggestion Use a higher level programming tool for generating config

    data Gareth Rushgrove
  79. (without introducing more risk) Gareth Rushgrove jsonnet.org

  80. (without introducing more risk) Gareth Rushgrove $ cat test.jsonnet //

    Example jsonnet file { person1: { name: "Alice", welcome: "Hello " + self.name + "!", }, person2: self.person1 { name: "Bob" }, }
  81. (without introducing more risk) Gareth Rushgrove $ jsonnet test.jsonnet |

    jq { "person1": { "name": "Alice", "welcome": "Hello Alice!" }, "person2": { "name": "Bob", "welcome": "Hello Bob!" } }
  82. (without introducing more risk) Gareth Rushgrove $ jsonnet test.jsonnet |

    json2yaml --- person1: name: "Alice" welcome: "Hello Alice!" person2: name: "Bob" welcome: "Hello Bob!"
  83. (without introducing more risk) DEMO

  84. (without introducing more risk) Gareth Rushgrove garethr/kubernetes

  85. (without introducing more risk) Gareth Rushgrove kubernetes_pod { 'sample-pod': ensure

    => present, metadata => { namespace => 'default', }, spec => { containers => [{ name => 'container-name', image => 'nginx', }] }, }
  86. (without introducing more risk) Gareth Rushgrove apiVersion: v1 kind: Pod

    metadata: namespace: default name: sample-pod spec: container: - image: nginx name: container-name
  87. (without introducing more risk) Gareth Rushgrove controller_service_pair { 'redis-master': app

    => 'redis', role => 'master', tier => 'backend', port => 6379, }
  88. (without introducing more risk) Gareth Rushgrove apiVersion: v1 kind: Service

    metadata: name: redis-master labels: app: redis tier: backend role: master spec: ports: # the port that this service should serve on - port: 6379 targetPort: 6379 selector: app: redis tier: backend role: master --- apiVersion: v1 kind: ReplicationController metadata: name: redis-master # these labels can be applied automatically # from the labels in the pod template if not set labels: app: redis role: master tier: backend spec: # this replicas value is default # modify it according to your case replicas: 1 # selector can be applied automatically # from the labels in the pod template if not set # selector: # app: guestbook # role: master # tier: backend
  89. (without introducing more risk) DEMO

  90. (without introducing more risk) Conclusions New technology means old problems

  91. (without introducing more risk) The difference between how you think

    something works and how it actually works risks hard-to-debug production issues Gareth Rushgrove
  92. (without introducing more risk) Containers introduce new and old configuration

    problems Gareth Rushgrove
  93. (without introducing more risk) Configuration management is the discipline aimed

    at minimising those risks Gareth Rushgrove
  94. (without introducing more risk) Start with principles Gareth Rushgrove

  95. (without introducing more risk) - Identification - Control - Status

    accounting - Verification Gareth Rushgrove Military Handbook Configuration Management Guidance MIL-HDBK-61B
  96. (without introducing more risk) Apply them to your container based

    infrastructure today Gareth Rushgrove
  97. (without introducing more risk) Questions? And thanks for listening
