Crafting Seamless UX by Preserving App State in Android (By: Adil Soomro) - Google I/O Extended Lahore 2023

Talk by Adil Soomro (https://www.linkedin.com/in/adilsoomro/) at Google I/O Extended Lahore 2023 by GDG Lahore.

Transcript

1. Crafting Seamless UX by Preserving App State in Android
2. Adil Soomro Co Founder BooleanBites Scan to download slide
3. Agenda What is a state and why preserve How app lose state How to preserve state Conclusion 01 02 03 04
4. State concept and data blueprints View vs Jetpack Compose Stateless vs. Stateful User expectations and system behavior What is a State and why preserve
5. // Imperative Style ViewB b = new ViewB(...); b.setColor(red); b.clearChildren(); ViewC c3 = new ViewC(...); b.add(c3); String text = "Large Heading"; TextView textView = new TextView(...); textView.setText(text); ... text = "Large Heading Changed"; textView.setText(text); // Declarative Style return ViewB( color = Color.RED ) { ViewC() } var text = mutableStateOf("Android") ... Text( text = text, ), ... text = "Large Heading"; ...
6. Theme changes, Device orientation changes App resizes System running low on memory Configuration Changes User can swipe away your app App crashes in background App updated in background System need resources Unexpected app dismissal How app lose state
8. Opting out of some changes Save transient data Rebuilding Save transient data for State Configuration Changes Recover from unexpected state Save data to storage System need resources Unexpected app dismissal How to preserve state
9. ViewModel Preserve State Survives configuration changes In memory Limited by available memory Quick reads/writes Navigation caches them if the destination is in the back stack
10. public class SavedStateViewModel extends ViewModel { private static final String NAME_KEY = "name"; private SavedStateHandle mState; public SavedStateViewModel(SavedStateHandle savedStateHandle) { mState = savedStateHandle; } // Expose an immutable LiveData LiveData<String> getName() { // getLiveData obtains observable object for the key, wrapped in a LiveData return mState.getLiveData(NAME_KEY); } void saveNewName(String newName) { // Sets a new value for the object associated to the key mState.set(NAME_KEY, newName); } }
11. mSavedStateViewModel = new ViewModelProvider(this).get(SavedStateViewModel.class); // Show the ViewModel property's value in a TextView mSavedStateViewModel.getName().observe(this, new Observer<String>() { @Override public void onChanged(String savedString) { ((TextView) findViewById(R.id.saved_vm_tv)) .setText(getString(R.string.saved_in_vm, savedString)); } }); // Save button findViewById(R.id.save_bt).setOnClickListener(v -> { String newName = ((EditText)findViewById(R.id.name_et)) .getText().toString(); mSavedStateViewModel.saveNewName(newName); });
12. Persistent Storage Preserve State Survives configuration changes, system needing resources, and unexpected app dismissal On disk Limited by disk space Slow reads/writes Application data LiveData Room
13. Saved State API Preserve State Survives config changes, and the system needing resources In memory Limited by the Bundle Slow reads/writes Large objects or lists
14. Saved State API Preserve State View Api Compose onSaveInstanceState rememberSaveable ViewModel Integration SavedStateHandle
15. onSaveInstanceState class ChatBubbleView(context: Context, ...) : View(context, ...) { private var isExpanded = false override fun onSaveInstanceState() : Parcelable { super.onSaveInstanceState() return bundleOf(IS_EXPANDED to isExpanded) } override fun onestoreInstanceState(state: Parcelable) { isExpanded = (state as Bundle) getBoolean(IS_EXPANDED) super.onRestoreInstanceState(null) } companion object { private const val IS_EXPANDED = "is expanded" } }
16. @Composable fun ChatBubble(message: Message) { var showDetails by rememberSaveable { mutableStateOf(false) } ClickableText( text = AnnotatedString(message.content), onClick = { showDetails = !showDetails } ) if (showDetails) { Text(message.timestamp) } } rememberSaveable
17. class ConversationViewModel ( savedStateHandle: SavedStateHandle ): ViewModel() { var message by savedStateHandle.saveable( stateSaver = TextFieldValue.Saver) { mutableStateOf(TextFieldValue("")) } private set fun update(newMessage: TextFieldValue) { message = newMessage } fun send() { /* Send current message to the data layer */ } } SavedStateHandle
18. UI Logic rememberSaveable onSaveInstanceState Business Logic SavedStateHandle SavedStateHandle Jetpack Compose View System Saved State API Preserve State
19. Storage location In memory In memory Disk/Network Survives Config Changes Yes Yes Yes Survives system initiated death No Yes Yes Survives user complete activity dismiss/finish No No Yes Data limitation Space is limited ~ 50KB, primitive data Available disk space / cost Read write time Quick Slow (serialization) Slow (Disk / Network IO) ViewModel Save API Persistent Storage How to preserve state
20. Best Practices Preserve State Avoid static object references Avoid large object references Use save state approaches Look for edge cases Do run some tests with Test apis
21. Thank You Adil Soomro Co Founder BooleanBites Scan to download slide
22. SOCIAL MEDIA adil_soomro AdilSoomro
23. “Good design is as little design as possible.” Dieter Rams
25. Optional tag here
