Scaling a Swagger-based Web API with Google Cloud Endpoints - Nordic APIs Platform Summit 2016

Web APIs are and more often specified with API definition languages like Swagger (now named Open API Spec), as it can help you generate nice interactive documentation, server skeletons, and client SDKs, mocks, and more, making it simpler to get started both producing and consuming an API.

In this session, Guillaume will demonstrate how to define a Web API with Swagger / Open API Spec, and scale it using Cloud Endpoints, on the Google Cloud Platform.

Transcript

1. Proprietary + Confidential
   Scale a Swagger-based Web API
   with Google Cloud Endpoints
   Guillaume Laforge
   Staff Developer Advocate
   Google Cloud Platform
   @glaforge
   Slides available here:
   bit.ly/endpoints-nordic
   Cloud Endpoints
   https://cloud.google.com/endpoints/


   View Slide

2. Proprietary + Confidential
   Scale a Swagger-based Web API
   with Google Cloud Endpoints
   Guillaume Laforge
   Staff Developer Advocate
   Google Cloud Platform
   @glaforge
   What does
   Swagger bring
   to the table?


   View Slide

3. Proprietary + Confidential
   Scale a Swagger-based Web API
   with Google Cloud Endpoints
   Guillaume Laforge
   Staff Developer Advocate
   Google Cloud Platform
   @glaforge
   How do we Scale
   in the Cloud?
   Google-style!


   View Slide

4. Proprietary + Confidential
   Scale a Swagger-based Web API
   with Google Cloud Endpoints
   Guillaume Laforge
   Staff Developer Advocate
   Google Cloud Platform
   @glaforge
   So what’s
   Cloud Endpoints


   View Slide

5. Proprietary + Confidential
   @glaforge
   Ok, OpenAPI Specs!


   View Slide

6. Proprietary + Confidential
   @glaforge
   Ok, OpenAPI Specs!
   Cloud
   Endpoints
   mastermind!


   View Slide

7. Proprietary + Confidential
   Benefits of OpenAPI Specs
   Contract
   First is
   Trendy !
   @glaforge


   View Slide

8. Contract as
   the Source
   of Truth


   View Slide

9. Facilitates Team
   Communication,
   Collaboration


   View Slide

10. Great for Tooling


    View Slide

11. Great for Tooling
    Client SDKs
    Server skeletons


    View Slide

12. Great for Tooling
    Client SDKs
    Server skeletons
    Test stubs
    Static & live mocks


    View Slide

13. Great for Tooling
    Client SDKs
    Server skeletons
    Test stubs
    Static & live mocks
    Static documentation


    View Slide

14. Great for Tooling
    Client SDKs
    Server skeletons
    Test stubs
    Static & live mocks Sandbox & live playground
    Static documentation
    API Portal w/ provisioning


    View Slide

15. Great for Tooling
    Client SDKs
    Server skeletons
    Test stubs
    Static & live mocks Sandbox & live playground
    Static documentation
    API Portal w/ provisioning
    Be careful with code generation
    overwriting customisations


    View Slide

16. Proprietary + Confidential
    Scale a Swagger-based Web API
    with Google Cloud Endpoints
    Guillaume Laforge
    Staff Developer Advocate
    Google Cloud Platform
    @glaforge
    How do we Scale
    in the Cloud?
    Google-style!


    View Slide

17. Proprietary + Confidential
    The various compute options
    on Google Cloud Platform
    @glaforge


    View Slide

18. Proprietary + Confidential
    Google App Engine — GAE
    Flex and Standard
    “Deploy your code,
    we’ll scale it
    for you!”
    @glaforge


    View Slide

19. Proprietary + Confidential
    Google Container Engine — GKE
    Powered by Kubernetes & Docker
    OSS Kubernetes
    based container
    clustering
    @glaforge


    View Slide

20. Proprietary + Confidential
    Google Compute Engine — GCE
    Customize your VM images
    Full control:
    Reusable and
    customisable VMs
    @glaforge


    View Slide

21. Proprietary + Confidential
    Scale a Swagger-based Web API
    with Google Cloud Endpoints
    Guillaume Laforge
    Staff Developer Advocate
    Google Cloud Platform
    @glaforge
    So what’s
    Cloud Endpoints


    View Slide

22. Proprietary + Confidential
    Cloud Endpoints
    API Management on Google Cloud Platform
    @glaforge


    View Slide

23. Proprietary + Confidential
    What is API Management?
    @glaforge


    View Slide

24. Proprietary + Confidential
    ● API Management from Google
    ● This architecture serves hundreds
    of billions of requests per day
    ● All configuration happens through
    Open API Spec (JSON/HTTP & gRPC)
    Cloud Endpoints
    @glaforge


    View Slide

25. Proprietary + Confidential
    Three key aspects
    For public / private / mobile / µ-services use cases
    @glaforge


    View Slide

26. Proprietary + Confidential
    Three key aspects
    For public / private / mobile / µ-services use cases
    Control access,
    authenticate users
    SECURE
    @glaforge


    View Slide

27. Proprietary + Confidential
    Three key aspects
    For public / private / mobile / µ-services use cases
    Logging and monitoring
    of key metrics
    SECURE MONITOR
    @glaforge


    View Slide

28. Proprietary + Confidential
    Three key aspects
    For public / private / mobile / µ-services use cases
    Speed and scalability
    SECURE MONITOR SCALE
    @glaforge


    View Slide

29. Proprietary + Confidential
    @glaforge


    View Slide

30. Proprietary + Confidential
    Extensible Service Proxy
    Why a server-local proxy?
    Extremely thin
    Eliminates network hop
    Simpler, better security
    Scales with your app
    <1 ms latency
    @glaforge


    View Slide

31. Proprietary + Confidential
    Extensible Service Proxy
    Why a server-local proxy?
    Extremely thin
    Eliminates network hop
    Simpler, better security
    Scales with your app
    <1 ms latency
    Will be
    Open
    Sourced
    @glaforge


    View Slide

32. Pancake
    DEMO


    View Slide

33. Proprietary + Confidential
    Proprietary + Confidential
    What else?
    @glaforge


    View Slide

34. Proprietary + Confidential
    JSON-HTTP/1.1
    Use Open API specs
    to manage RESTful
    APIs written in any
    language and with
    any framework.
    Proto-HTTP/2
    Use gRPC to build
    highly efficient
    HTTP/2-based APIs
    Choose your protocol
    @glaforge


    View Slide

35. Proprietary + Confidential
    Write once; serve twice
    ● At Google, our gRPC APIs serve both gRPC and
    REST/JSON surfaces
    ● Proxy allows you to write a gRPC backend and
    serve both REST/JSON and gRPC
    ● The only API management product that allows
    managing gRPC-based APIs
    @glaforge


    View Slide

36. Proprietary + Confidential
    Summary
    Guillaume Laforge
    Staff Developer Advocate
    Google Cloud Platform
    @glaforge


    View Slide

37. Summary
    Manage
    Open
    Choice
    JSON Web Tokens,
    Auth0, Firebase
    API Keys, Custom...
    Secure
    Monitor
    Scale


    View Slide

38. Summary
    Manage
    Open
    Choice
    Secure
    Monitor
    Scale
    Dashboard with
    API Metrics
    and API Logs


    View Slide

39. Summary
    Manage
    Open
    Choice
    Secure
    Monitor
    Scale


    View Slide

40. Summary
    Manage
    Open
    Choice
    Protocol
    Tech
    Scale
    JSON / HTTP
    Or gRPC


    View Slide

41. Summary
    Manage
    Open
    Choice
    Protocol
    Tech
    Scale
    Any Language
    Any Framework


    View Slide

42. Summary
    Manage
    Open
    Choice
    Protocol
    Tech
    Scale
    3rd party cloud,
    or on-premise


    View Slide

43. Summary
    Manage
    Open
    Choice
    Standard
    OSS


    View Slide

44. Summary
    Manage
    Open
    Choice
    Standard
    OSS


    View Slide

45. Current state & supported platforms
    ● BETA: Cloud Endpoints for JSON / HTTP REST APIs
    ○ App Engine Flex, Container Engine, Compute Engine
    ○ Other clouds + on premise via Kubernetes
    ● ALPHA: Cloud Endpoints for gRPC
    ○ Same (except GAE Flex w/ HTTP/1.1 support only)
    @glaforge


    View Slide

46. Proprietary + Confidential
    Thanks for
    your attention!
    Guillaume Laforge
    Staff Developer Advocate
    Google Cloud Platform
    @glaforge
    Slides available here:
    bit.ly/endpoints-nordic
    Cloud Endpoints
    https://cloud.google.com/endpoints/


    View Slide

47. References
    Slides of this presentation
    http://bit.ly/nordic-endpoints
    Google Cloud Endpoints
    https://cloud.google.com/endpoints/
    Managing gRPC APIs with Google Cloud Endpoints
    http://www.slideshare.net/WenchengLu/managing-grpc-apis-with-google-cloud-endpoints
    Choosing a compute option on Google Cloud Platform
    https://cloud.google.com/docs/choosing-a-compute-option
    @glaforge


    View Slide

48. Picture credits — public domain images
    Truth newspaper
    https://pixabay.com/fr/v%C3%A9rit%C3%A9-journal-actualit%C3%A9s-imprim%C3%A9-166853/
    Women working together
    https://pixabay.com/fr/femmes-travail-d-%C3%A9quipe-l-%C3%A9quipe-1209678/
    Drill
    https://pixabay.com/fr/t%C3%AAte-de-forage-foret-perceuse-m%C3%A9tal-444504/
    Pancakes
    https://pixabay.com/fr/cr%C3%AApe-cr%C3%AApes-manger-alimentaire-640865/
    Room service icon
    https://pixabay.com/fr/service-de-chambre-serviteur-service-297071/
    @glaforge


    View Slide

49. Proprietary + Confidential
    Appendix


    View Slide

50. Proprietary + Confidential
    ---
    swagger: "2.0"
    info:
    description: "No description"
    version: "1.0.0"
    title: "pancakes-api"
    contact: {}
    host: "pancakes-endpoint-demo.appspot.com"
    paths:
    /pancakes:
    get:
    summary: "Retrieve the pancakes"
    operationId: "getAllPancakes"
    produces:
    - "application/json"
    parameters: []
    responses:
    200:
    description: "Status 200"
    schema:
    type: "array"
    items:
    $ref: "#/definitions/Pancake"
    security:
    - api_key: []
    swagger2.yaml
    post:
    summary: "Add a new pancake"
    operationId: "createPancake"
    consumes:
    - "application/json"
    produces:
    - "application/json"
    parameters:
    - in: "body"
    name: "body"
    required: false
    schema:
    $ref: "#/definitions/Pancake"
    responses:
    201:
    description: "Status 201"
    schema:
    $ref: "#/definitions/Pancake"
    security:
    - api_key: []


    View Slide

51. Proprietary + Confidential
    /pancakes/{pancakeId}:
    get:
    summary: "Retrieve a particular pancake"
    operationId: "getPancakeById"
    produces:
    - "application/json"
    parameters:
    - name: "pancakeId"
    in: "path"
    description: "The unique pancake ID"
    required: true
    type: "string"
    responses:
    200:
    description: "Status 200"
    schema:
    $ref: "#/definitions/Pancake"
    security:
    - api_key: []
    swagger2.yaml
    securityDefinitions:
    api_key:
    type: "apiKey"
    name: "key"
    in: "query"
    definitions:
    Pancake:
    type: "object"
    required:
    - "title"
    properties:
    id:
    type: "string"
    description: "The unique pancake ID"
    title:
    type: "string"
    description: "Pancake title"


    View Slide

52. Proprietary + Confidential
    FROM gcr.io/google_appengine/openjdk8
    VOLUME /tmp
    ADD build/distributions/pancakes.tar /
    ENV JAVA_OPTS='-Djava.security.egd=file:/dev/./urandom'
    ENTRYPOINT ["/pancakes/bin/start"]
    EXPOSE 8081
    Dockerfile


    View Slide

53. Proprietary + Confidential
    kube-cfg.yaml
    apiVersion: v1
    kind: Service
    metadata:
    name: esp-pancakes
    spec:
    ports:
    - port: 80
    targetPort: 8080
    protocol: TCP
    name: http
    selector:
    app: esp-pancakes
    type: LoadBalancer
    ---
    apiVersion: extensions/v1beta1
    kind: Deployment
    metadata:
    name: esp-pancakes
    spec:
    replicas: 1
    template:
    metadata:
    labels:
    app: esp-pancakes
    spec:
    containers:
    - name: esp
    image: b.gcr.io/endpoints/endpoints-runtime:0.3
    args: [
    "-p", "8080",
    "-a", "127.0.0.1:8081",
    "-s", "pancakes-endpoint-demo.appspot.com",
    "-v", "2016-10-24r0",
    ]
    ports:
    - containerPort: 8080
    - name: pancakes-image
    image: gcr.io/pancakes-endpoint-demo/pancakes-image:latest
    ports:
    - containerPort: 8081


    View Slide

54. Proprietary + Confidential
    SERVICE: “esp-pancakes”
    CONTAINER: “esp” APP-CONTAINER:
    “pancakes-image”
    APP
    80 8080 8081 8081


    View Slide
