Advanced GORM - Beyond Relational

Talk by Graeme Rocher at SpringOne2GX 2014 on Advanced GORM

Transcript

1. © 2014 SpringOne 2GX. All rights reserved. Do not distribute without permission.
   Advanced GORM - Beyond Relational
   By Graeme Rocher


   View Slide

2. Agenda
   § Understanding GORM Internals
   § GORM Standalone
   § Tips and Tricks
   § Jumping into MongoDB
   § Unit testing with GORM
   § Summary / Q & A


   View Slide

3. GORM
   • Powerful multi-datastore
   query layer
   • Dynamic finders, criteria, and
   persistence methods
   • Integrated validation
   • Automatic mapping of entities
   to underlying datastore
   • Easy access to native APIs
   3


   View Slide

4. © 2014 SpringOne 2GX. All rights reserved. Do not distribute without permission.
   Understanding what makes GORM tick
   GORM Internals


   View Slide

5. Grails Data Mapping Project
   • https://github.com/grails/grails-data-mapping
   5


   View Slide

6. Built by Travis
   • https://travis-ci.org/grails/grails-data-mapping
   6


   View Slide

7. Developer Documentation
   • http://grails.github.com/grails-data-mapping/
   7


   View Slide

8. Important Subprojects
   • grails-datastore-core!
   – Core low level API
   • grails-datastore-gorm!
   – GORM API layer
   • grails-datastore-gorm-tck!
   – Test Suite
   8


   View Slide

9. © 2014 SpringOne 2GX. All rights reserved. Do not distribute without permission.
   Demo: Code Walkthrough


   View Slide

10. Contribute to GORM
    • GORM is huge and sprawling
    • Covers loads of data stores
    • Great area to contribute to the
    community. Some ideas:
    • Multi Tenancy
    • Elastic Search
    • Hadoop / HBase
    10


    View Slide

11. © 2014 SpringOne 2GX. All rights reserved. Do not distribute without permission.
    Use GORM outside of Grails
    GORM Standalone


    View Slide

12. What is GORM Standalone?
    • Easy initialisation of GORM outside of Grails
    • And a set of Spring Boot plugins
    • Required modularisation of codebase
    • Reduction of external dependencies
    • Simplification of GORM setup
    12


    View Slide

13. Standalone Entities
    • Annotated with grails.persistence.Entity
    13
    @Entity
    class  Person  {
           String  name
           static  constraints  =  {
                   name  blank:false
           }
    }


    View Slide

14. GORM for Hibernate Standalone
    • https://gist.github.com/graemerocher/c25ec929d9bcd1adcbea
    14
    @Grab("org.grails:grails-­‐datastore-­‐gorm-­‐hibernate4:3.1.2.RELEASE")
    @Grab("com.h2database:h2:1.3.164")
    !
    import  grails.orm.bootstrap.*
    !
    init  =  new  HibernateDatastoreSpringInitializer(Person)
    def  dataSource  =  new  DriverManagerDataSource(Driver.name,
    "jdbc:h2:prodDb;MVCC=TRUE;LOCK_TIMEOUT=10000;DB_CLOSE_ON_EXIT=FALS
    E",  'sa',  '')
    init.configureForDataSource(dataSource)


    View Slide

15. GORM for MongoDB Standalone
    • https://gist.github.com/graemerocher/9683650
    15
    @Grab("org.grails:grails-­‐datastore-­‐gorm-­‐mongodb:3.0.2.RELEASE")
    !
    import  grails.mongodb.bootstrap.*
    !
    init  =  new  MongoDbDataStoreSpringInitializer(Person)
    init.configure()


    View Slide

16. © 2014 SpringOne 2GX. All rights reserved. Do not distribute without permission.
    Demo: GORM Standalone


    View Slide

17. GORM for Hibernate in Spring Boot
    • Add gorm-hibernate4-spring-boot as a dependency
    !
    !
    !
    !
    • Then add persistent entities that are annotated with

    grails.persistence.Entity
    17
    compile  "org.grails:gorm-­‐hibernate4-­‐
    spring-­‐boot:1.0.0.RELEASE"


    View Slide

18. GORM for MongoDB in Spring Boot
    • Add gorm-mongodb-spring-boot as a dependency
    !
    !
    !
    !
    • Then add persistent entities that are annotated with

    grails.persistence.Entity
    18
    compile  "org.grails:gorm-­‐mongodb-­‐spring-­‐
    boot:1.1.0.RELEASE"


    View Slide

19. © 2014 SpringOne 2GX. All rights reserved. Do not distribute without permission.
    Take GORM to the next level
    Tips & Tricks


    View Slide

20. GORM Tips & Tricks
    • Understanding where queries
    • Working with DetachedCriteria
    • Using formula and column readers / writers
    • Going asynchronous
    20


    View Slide

21. Where Queries
    • Type-safe, composable query API
    21
    !
    DetachedCriteria  query  =
           Person.where  {
                   lastName  ==  "Simpson"
           }
    !
    def  results  =  query.list()


    View Slide

22. © 2014 SpringOne 2GX. All rights reserved. Do not distribute without permission.
    Demo: Where Queries


    View Slide

23. Hibernate Subqueries
    • Perform nested “in” or “notIn” sub queries that span domain
    classes using where queries:
    23
    def  employees  =  Employee.where  {
           region.continent  in  ['APAC',  "EMEA"]
    }.id()
    !
    def  results  =  Sale.where  {
         employee  in  employees  &&  total  >  50000
    }.employee.list()


    View Slide

24. Hibernate Correlated Subqueries
    • Declare aliases using “def” for cross query references:
    24
    def  query  =  Employee.where  {
           def  em1  =  Employee
           exists  Sale.where  {
                   def  s1  =  Sale
                   def  em2  =  employee
                   return  em2.id  ==  em1.id
           }.id()
    }
    def  results  =  query.list()


    View Slide

25. Hibernate Column Formula
    • A column can be a read-only formula
    25
    class  Product  {
           Float  price
           Float  taxRate
           Float  tax
           static  mapping  =  {
                   tax  formula:  'PRICE  *  TAX_RATE'
           }
    }


    View Slide

26. Hibernate Column Readers/Writers
    • New in 2.4: Implement custom column readers and writers
    to transform data when written or read from the database.
    26
    class  Name  {
           String  title
           static  mapping  =  {
                   title  write:'UPPER(?)',
                             read:'REPEAT(title,  2)'
           }
    }


    View Slide

27. Asynchronous GORM
    • Database operations are blocking
    • Can be helpful to isolate these blocking operations on a
    separately managed thread
    • Work underway in some NoSQL datastore on fully
    asynchronous drivers (MongoDB, CouchDB etc.)
    • No usable asynchronous SQL/JDBC drivers on the horizon
    (to my knowledge)
    27


    View Slide

28. Async Namespace
    • Any GORM method can become Async
    28
    import  static  grails.async.Promises.*
    !
    def  p1  =  Person.async.get(1L)
    def  p2  =  Person.async.get(2L)
    def  p3  =  Person.async.get(3L)
    def  results  =  waitAll(p1,  p2,  p3)


    View Slide

29. © 2014 SpringOne 2GX. All rights reserved. Do not distribute without permission.
    Demo: Async GORM


    View Slide

30. Async Tasks
    • Individual async method calls often too fine grained, use
    task method to implement Async GORM tasks
    30
    def  promise  =  Person.async.task  {
           withTransaction  {
                 def  person  =  findByFirstName("Homer")
                 person.firstName  =  "Bart"
                 person.save(flush:true)
           }
    }
    Person  updatedPerson  =  promise.get()


    View Slide

31. © 2014 SpringOne 2GX. All rights reserved. Do not distribute without permission.
    Go schemaless!
    Jumping into MongoDB


    View Slide

32. GORM for MongoDB
    • Geospacial querying
    • GeoJSON models
    • Full text search
    • Schemaless domain models
    • Projections via MongoDB
    aggregation
    • Stateless and Stateful modes
    • Custom user types
    32


    View Slide

33. GORM for MongoDB Internals
    • MongoEntityPersister implements persistence
    • MongoQuery implements querying aggregation
    • MongoSession implements batch inserts, updates and
    deletes
    • MongoGormStaticApi adds extra GORM methods
    • GeoJSONType and subclasses implement GeoJSON
    custom types
    • https://github.com/grails/grails-data-mapping/tree/master/
    grails-datastore-gorm-mongodb
    33


    View Slide

34. GORM, MongoDB & GeoJSON
    • Geo Data in MongoDB represented by GeoJSON types
    – http://geojson.org
    • Package grails.mongodb.geo contains GeoJSON
    types
    – Point, Polygon, LineString, MultiPoint,
    MultiLineString, MultiPolygon,
    GeometryCollection
    34


    View Slide

35. Geospacial Querying
    35
    def  point  =  new  Point(2,  1)
    def  p  =  new  Place(point:  point)
    !
    def  poly1  =  Polygon
         .valueOf([  [0.0,  0.0],  [3.0,  0.0],
    [3.0,  3.0],  [0.0,  3.0],  [0.0,  0.0]  ])
    !
    Place.findByPointGeoWithin(poly1)


    View Slide

36. MongoDB Text Search
    • Create text indices and use methods
    36
    Product.search('"Coffee  Cake"')
                                     .size()  ==  1
    Product.searchTop("cake").size()  ==  4
    Product.searchTop("cake",3).size()  ==  3
    Product.countHits('coffee')  ==  5


    View Slide

37. Schemaless Dynamic Properties
    • Add dynamic properties with the subscript operator
    37
    def  p  =  new  Plant(name:"Pineapple")
    p.save()
    p["color"]  =  "Yellow"
    p["hasLeaves"]  =  true


    View Slide

38. © 2014 SpringOne 2GX. All rights reserved. Do not distribute without permission.
    Demo: GORM for MongoDB


    View Slide

39. Other Implementations
    • Neo4j
    – http://grails.org/plugin/neo4j
    • Redis GORM
    – http://grails.org/plugin/redis-gorm
    • GORM for REST
    – http://grails.org/plugin/gorm-rest-client
    • Cassandra
    – https://github.com/grails/grails-data-mapping/
    39


    View Slide

40. © 2014 SpringOne 2GX. All rights reserved. Do not distribute without permission.
    Spin up GORM inside a unit test
    Unit Testing GORM


    View Slide

41. Hibernate in Unit Tests
    • Add a dependency on grails-datastore-test-
    support
    !
    !
    !
    • Provides HibernateTestMixin that will load Hibernate
    inside a unit test
    41
    test  "org.grails:grails-­‐datastore-­‐test-­‐
    support:1.0-­‐grails-­‐2.4"


    View Slide

42. Hibernate in Unit Tests
    42
    import  grails.test.mixin.TestMixin
    import  grails.test.mixin.gorm.Domain
    import  grails.test.mixin.hibernate.*
    import  spock.lang.Specification
    !
    @Domain(Person)
    @TestMixin(HibernateTestMixin)
    class  PersonSpec  extends  Specification  {
         …
    }


    View Slide

43. Summary
    • GORM provides a rich and diverse ecosystem
    • Goes far beyond relational databases
    • Can be used standalone or within Grails
    • Great area to contribute to!
    43


    View Slide

44. !
    Q & A


    View Slide

45. Stay Connected.
    !
    !
    !
    !
    Web: grails.org
    StackOverflow: http://stackoverflow.com/tags/grails
    Twitter: http://twitter.com/grailsframework
    LinkedIn: http://linkedin.com/groups/Grails-User-Group-39757
    Google+: https://plus.google.com/communities/
    109558563916416343008


    View Slide
