NgRx Refactoring Patterns enhanced with ngrx-ducks

In this talk, you will learn about the following mechanisms to improve the maintainability of your Redux Store.

- Property Pattern
- createReducer Factory
- @ngrx/entity
- @ngrx/router-store
- ngrx-data
- ngrx-ducks

Transcript

1. Redux Refactoring Patterns @GregOnNet co-IT.eu GmbH We Empower Outstanding Business Solutions + Quaaaaak…
2. MY FRIEND OSCAR Meet Oscar 1. My Colleage 2. He works with 3. Passionated about Software Development
3. MY FRIEND OSCAR Meet Oscar 1. …He is not an early morning person.
4. Your Code Should Always Feel Like Home.
5. @GregOnNet Gregor Woiwode CTO
6. AGENDA Our Review With Oscar 1. Property Pattern 2. @ngrx/entity 3. @ngrx/router-store 4. selectors 5. ngrx-data 6.???
7. REDUX ARCHITECTURE Recap ACTION STATE COMPONENT STORE Dispatch Send To Mutate Render Inspired by @ToddMotto REDUCERS
8. export function reducer(state = initialState, action: NotesActions): State { switch (action.type) { case NotesActionTypes.CreateNoteSuccess: { return { ...state, notes: [...state.notes, action.payload], loaded: true, loading: false } } case NotesActionTypes.LoadNotesSuccess: { return { ...state, notes: ...action.payload, loaded: true, loading: false } /* ... */ Redundant Code
9. export function reducer(state = initialState, action: NotesActions): State { switch (action.type) { case NotesActionTypes.CreateNoteSuccess: { return { ...state, notes: [...state.notes, action.payload], loaded: true, loading: false } } case NotesActionTypes.LoadNotesSuccess: { return { ...state, notes: ...action.payload, loaded: true, loading: false } /* ... */ Redundant Code
10. /* ... */ case NotesActionTypes.LoadAdditionalNotesSuccess: { return { ...state, notes: [...state.notes, ...action.payload], loaded: true, loading: false } } case NotesActionTypes.DeleteSingleNoteSuccess: { return { ...state, notes: state.notes.filter(note => note.guid !== action.payload.guid), loaded: true, loading: false } } /* ... */ Remove By Filtering
11. OSCAR‘S PROBLEM Large Switch-Case-Statements 1. Lot‘s of list operations we may not need every time 2. Hard to maintain 3. Less readable
12. Property Pattern SIMPLIFY STATE MUTATIONS
13. PROPERTY PATTERN Convert Collections To Dictionaries export interface State { notes: Note[]; } export interface State { notes: { [key: string]: Note }; } List to Object
14. PROPERTY PATTERN Delete Single Object return { ...state, notes: state.notes.filter(note => note.guid !== action.payload.guid ) } const { [action.payload.guid]: deleted, ...withoutDeleted } = state.notes; return { ...state, notes: withoutDeleted, }
15. MY FRIEND OSCAR Oscar asks… Maybe accessing data is more efficient. But the code complexity has increased. How can we benefit from this approach?
16. PROPERTY PATTERN Review Less Collection Operations More Performant Operations Less Readable Code
17. @ngrx/entity SIMPLIFY REDUCERS
18. @ngrx/entity Entity State export interface State extends EntityState<Note> {} export interface State<T> { ids: string[]; entities: { [id: string]: T }; } Leverages Property Pattern
19. @ngrx/entity Entity Adapter import { createEntityAdapter } from '@ngrx/entity'; const adapter = createEntityAdapter<T>(); The mighty helper
20. @ngrx/entity Entity Mutators Operations for single objects and collections
21. @ngrx/entity Simplify Mutations return adapter.removeOne( action.payload, state ); const { [action.payload.guid]: deleted, ...withoutDeleted } = state.notes; return { ...state, notes: withoutDeleted, } 1. Enusres Immutability 2. Applies State Mutation
22. @ngrx/entity Entity Selectors const adapter = createEntityAdapter<T>(); export const { selectAll, selectEntities, selectIds, selectTotal } = adapter.getSelectors();
23. @ngrx/entity Use Entity Selectors export class NotesDashboardComponent { notes$: Observable<Note[]>; constructor(private store: Store<fromNotes.State>) { this.notes$ = this.store.pipe(select(fromNotes.selectAll)); } }
24. Demo ENTITY ADAPTER
25. PROPERTY PATTERN Review Less Code Duplication Reusable Mutators & Selectors
26. MY FRIEND OSCAR Oscar asks… @ngrx/entity is nice, thanks. Can we tidy up these Switch-Case-Statements now?
27. createReducer SIMPLIFY REDUCER INFRASTRUCTURE
28. CREATE REDUCER Switch-Case-Anatomy Infrastructure UI-Logic case: a case: b case: …
29. CREATE REDUCER Factory Pattern To The Rescue const mutators: ActionHandlers<State> = { [NotesActionTypes.CreateNote]: notes.addOne, [NotesActionTypes.LoadNotesSuccessful]: notes.addMany }; export function reducer(state = initialState, action) { return createReducer<State>(mutators)(state, action); } Refer to last slide for the source
30. Demo REMOVE SWITCH-CASE-STATEMENTS
31. PROPERTY PATTERN Review Reduced Infrastructure Code Reducers do not need to be enhanced as Requirements change
32. MY FRIEND OSCAR Oscar asks… Small things can have a great impact to quality. But wait since you are here…
33. OSCAR‘S PROBLEM He thinks he breakse the Redux Pattern Shouldn’t the store be able to answer every question of a Component?
34. SINGLE SOURCE OF TRUTH How to deal with location state? /* ... */ export class NoteDetailsComponent { note$: Observable<Note>; constructor( private route: ActivatedRoute, private store: Store<fromNotes.State>) { this.note$ = this.route.params.pipe( switchMap(params => this.store.pipe(state => state.notes.entities[params.guid]) ) ); } }
35. @ngrx/router-store SIMPLIFY LOCATION STATE HANDLING
36. @ngrx/router-store Setup import { StoreRouterConnectingModule } from '@ngrx/router-store'; @NgModule({ imports: [ /* ... */ StoreRouterConnectingModule, ] /* ... */ }) export class AppModule {}
37. @ngrx/router-store Types & Reducer Come For Free import * as fromRouter from '@ngrx/router-store'; export interface State { routerReducer: fromRouter.RouterReducerState<RouterStateUrl>; } export const reducers: ActionReducerMap<State> = { routerReducer: fromRouter.routerReducer };
38. @ngrx/router-store Enhance The State Tree Store Notes Router State provided by @ngrx/router-store
39. @ngrx/router-store Access The Router State import { createFeatureSelector } from '@ngrx/store'; export const getRouterState = createFeatureSelector('routerReducer');
40. @ngrx/router-store Read Router State export const currentDetails = createSelector( getEntities, getRouterState, (notes, router) => entities[router.state.params.guid] ); RoutingComponent select
41. @ngrx/router-store The Reducer‘s Outcome Let’s traverse through the whole state tree! Of Cause Not!
42. Demo COMPRESS ROUTER STATE
43. PROPERTY PATTERN Review Store is Single Source of Truth again Reduced Complexity of Component Component does not rely on ActivatedRoute anymore
44. MY FRIEND OSCAR Oscar asks… This feels more correct than before, thanks. Wait! There is one very last thing…
45. OSCAR‘S PROBLEM I Can See A Revenent Pattern…. We only do CRUD operations. Do we need to repeat ourselves for every entity?
46. “ I see reccurring patterns…
47. Looking for the right answer…
48. ngrx-data SIMPLIFY STORE USING CONVENTIONS
49. Know, Can Do… Put Your Know-How Into Action!
50. NGRX-DATA Overview Actions Reducers Effects Data Services Dynamically sets up…
51. Configure an entity export const entityMetadata: EntityMetadataMap = { Note: { selectId: (note: Note) => note.guid } }; export const pluralNames = { Note: 'Notes' }; NGRX-DATA
52. Setup Entity Cache NGRX-DATA NgrxDataModule.forRoot({ entityMetadata, pluralNames }),
53. NGRX-DATA Data Services import { Note } from '../../models/note'; @Injectable() export class NotesBoard extends EntityCollectionServiceBase<Note> { constructor(entityServiceFactory: EntityCollectionServiceFactory) { super('Note', entityServiceFactory); } }
54. Convention Based Data Services NGRX-DATA localhost:4200/api/notes/<id> root entityName parameters
55. ngrx-data Built-In Functions Of A Data Service Mutators & Selectors for the given entity.
56. Demo CONFIGURE NGRX-DATA
57. NGRX-DATA Get Rid Of Unneeded Files Delete Delete Custom Configuration
58. NGRX-DATA Review Less Files to maintain Scales good for many entities Highly Configurable Handles Loading State automatically High Learning Curve Lot‘s of things happen behind the scenes
59. ngrx-ducks Leverage OCP for Redux
60. NGRX Criticism Touch lots of files Boilerplate vs. Explicit Setup Distributed Setup (Actions, Reducers, Selectors, Effects) It is easy to forget parts of the setup (ActionType) High Learning Curve Lot‘s of things happen behind the scenes
61. NGRX Redux the bad parts REDUCER ACTION TYPES DISPATCHER ACTIONS EFFECT ACTION REDUCER MAP ACTIONS$ ACTION CREATORS
62. NGRX Redux the good parts ACTIONS
63. Your Code Should Always Feel Like Home.
64. NGRX-DUCKS What if… 1. … we could automate the creation of an action 2. … an Action knows about it‘s case reducer 3. … an Acion could dispatch itself 4. … we have one object strucure providing us every thing we need?
65. NGRX-DUCKS Duck, Duck, Ducks, Re-Ducks
66. Demo INTRODUCING NGRX-DUCKS
67. NGRX-DUCKS Documentation
68. NGRX-DUCKS Give it a try npm install @co-it/ngrx-ducks
69. NGRX-DUCKS Review Consume Redux as a Service TypeScript Compiler saves us for mistakes Serves Open Closed Principle Supports AoT Supports AoT … Setting up Dynamic Services is hard
70. co-IT.eu GmbH We Empower Outstanding Business Solutions Thank you! @GregOnNet NGRX-KEEP Demo https://github.com/GregOnNet/ngrx-keep.git
71. CREDITS Icons - from www.flaticon.com by Vectors Market - from www.flaticon.com by Freepik - from www.flaticon.com by Freepik
