Adding some flavor to our apps

Having many applications to manage and maintain can be a pain. Being a multi-brand company, tripsta needs to publish one app per brand (airtickets, travelplanet24 and tripsta). Through this presentation, you will get a glimpse on how we tackle this problem using the flavor mechanism provided by Gradle. What are the benefits as well as the problems and how to overcome them.

Transcript

1. Adding some flavor to our apps How tripsta is maintaining three apps with a common code-base
2. about us | gradle | our implementation | problems | Q&A
3. 3 about us 3 Trusted Brands Available in over 50 countries Available in 20 countries Available in Greece
5. about us Started as a side project in 2009 About Android development 5
6. about us First major refactor 6 3 apps, more than 40 markets
7. about us First major refactor 6 3 apps, more than 40 markets
8. about us First major refactor 6 3 apps, more than 40 markets
9. about us The problems 7 1. High development time 2. More bugs 3. Difficult maintenance 4. More unhappy droids Having 3 separate codebases means: !
10. about us | gradle | our implementation | problems | Q&A
11. 9 gradle Gradle build tool • Officially supported by Google • Open source • XML vs Groovy • Product Flavors Version Gradle -> 4.1 Gradle build tool -> 3.0.0 Android Studio -> 3.0
12. 10 gradle Build types A set of properties used when building your app Usually configured for different stages of the development lifecycle (i.e debug, release) At least one is required 3 build types Release Debug Staging
13. 11 gradle Product flavors • Useful for creating multiple versions of your application • Maintainability • Per-flavor configurations • Single code base 2 product flavors Full Demo
14. 12 gradle Flavor dimensions A flavor dimension can be used to combine multiple flavors into a group • At least one dimension Error:All flavors must now belong to a named flavor dimension. • Group flavors (brand, type etc) • Ordering matters As of Gradle plugin 3.0 and later
15. 13 gradle Flavor dimensions 2 dimensions 4 flavors
16. 14 gradle Variants The combination of build types, flavor dimensions and product flavor creates a build variant A total of 12 different variants
17. 15 gradle Source sets Each flavor has its own source set(s). By default Android Studio will generate the “main” source set and directory which is used by all flavors. Additional source sets for each flavor can also be created. Can even overwrite default source sets. * Caution when defining .java classes. *
18. 16 gradle Flavor-specific configuration Variant filters • For cases were a specific flavor should be omitted, a variant filter can be used All staging build types for fdroid flavor will be ignored Less clutter
19. 17 gradle Flavor-specific configuration Flavor specific dependencies • Add different dependancies for according to the variant of your app • Add different version of dependancies if targeting different api levels per flavor
20. 18 gradle Flavor-specific configuration Dynamic manifest • Each flavor gets their own manifest • Cross-flavor requirements can be applied using the ${applicationId} variable in the main manifest: <permission android:name="${applicationId}.permission.C2D_MESSAGE" android:protectionLevel="signature" />
21. 19 gradle Building Ordering is important! • Source code in the java/ is combined into a single output • Manifests and values/ (xml) are merged • Resources in the res/ and asset/ directories are packaged together assemble<flavor(s)><buildType> assembleFdroid -> Builds all Fdroid variants assembleFullPlaystoreRelease -> Builds the FullPlaystore flavor for Release
22. 20 gradle BuildConfig demoFdroidDebug fullPlaystoreRelease
23. about us | gradle | our implementation | problems | Q&A
24. 22 our implementation Getting started Manifest entries
25. 23 our implementation Getting started Folder structure
26. 24 our implementation Properties • Different endpoints • Different markets based on brand • Analytics • Testable • No merging !
27. 25 our implementation UI elements ../airtickets/res/mipmap/ic_launcher.png ../airtickets/res/values/strings.xml airtickets App icon and name travelplanet24 ../travelplanet24/res/mipmap/ic_launcher.png ../travelplanet24/res/values/strings.xml
28. 26 our implementation UI elements main flavor colors.xml airtickets flavor colors.xml tripsta flavor colors.xml Same goes for themes! Colors
29. 27 our implementation UI elements Drawables, Layouts & Strings • Keep things that are common under the main flavor folder • Split layouts into multiple sub-layouts. Easier to reuse and ideal for flavoring • Branded strings are split into their respective flavor folder Strings are merged. Drawables and layouts are not! Remember
30. 28 our implementation UI elements - Example
31. 28 Common sidebar_row.xml Per flavor Menu drawables Selector style String texts our implementation UI elements - Example
32. our implementation 29 Common RecyclerView Per flavor result_row.xml Drawables, colors & texts
33. our implementation 29 Common RecyclerView Per flavor result_row.xml Drawables, colors & texts
34. our implementation 29 Common RecyclerView Per flavor result_row.xml Drawables, colors & texts
35. 30 our implementation
36. 31 abstract BasePriceAlertListActivity Per flavor Implement onMoreControlsSelected(View view) Handle different view functionality our implementation
37. 32 our implementation Deep linking Must have different URI per brand Achievable by making a manifest file for each flavor travelplanet24 manifest snippet airtickets manifest snippet
38. 33 our implementation Release Jenkins https://jenkins.io/

 Automation Server
 Continuous Integration
 Continuous Delivery Fastlane
 https://fastlane.tools/

 Automation Tool
 Android and iOS
 Written in Ruby
39. our implementation 34 Setup fastlane init fastlane supply init ApplicationId Private key from Play Console
40. 35 Create lanes for any task you want to automate Create .env files for each flavor Fastfile our implementation fastlane alpha --env airtickets fastlane beta --env travelplanet24 Deploy airtickets flavor on alpha channel Promote travelplanet24 flavor to beta channel fastlane <lane> - -env <flavor>
41. 36 our implementation Monitor - Analytics Each flavor is represented as a different app in analytics Easier to keep track Engage to users Run campaigns specifically for certain flavors
