1. Building a Reactive System with Akka Konrad Malawski (@ktosopl) - Akka Team Henrik Engström (@h3nk3) - Telemetry Team O’Reilly Software Architecture Conference, NYC - April 2016
2. Free e-book and printed report. bit.ly/why-reactive Covers what reactive actually is. Implementing in existing architectures. Thoughts from the team that’s building reactive apps since more than 6 years.
4. • “TRADITIONAL” AND REACTIVE APPLICATIONS • ACTOR MODEL AND DISTRIBUTED PROGRAMMING • INTRODUCTION • AKKA CLUSTERING AND PERSISTENCE • AKKA STREAMS • AKKA HTTP • TESTING AKKA Actors / Streams / HTTP • WHAT FEATURES ARE COMING SOON? AGENDA
5. “TRADITIONAL” AND REACTIVE APPLICATIONS
6. WANT TO FOLLOW ALONG? https://github.com/henrikengstrom/sa-2017- akka
7. IT IS 2017 AND WE STILL USE • Synchronous local and remote calls • Single machine apps - scaling is an afterthought • Non resilient approaches Result: brittle, slow, non-scalable applications
8. WHAT CAN WE DO ABOUT IT? Use message driven/asynchronous programming
9. PROBLEM SOLVED!?
10. REACTIVE MANIFESTO http://www.reactivemanifesto.org/ • Created in September 2014, +18k signatures • Consists of four traits • Responsive • Resilient • Elastic • Message Driven
11. RESPONSIVE
12. RESILIENT
13. E L A S T I C
14. MESSAGE DRIVEN
15. The many meanings of Reactive reactivemanifesto.org
18. How to think about these techniques? bit.ly/why-reactive
19. AKKA
20. Akka is the Enabler of Reactive Systems • Individual entities, actors, that can contain state • Communication done by message passing • Lock-free concurrency • Loosely coupled and distributable • Fault tolerance via Supervision
21. Akka is a Toolkit • A Toolkit, not a Framework • Multitude modules and components – “pick-and-choose” • Performance and distribution always a goal • Resilient and asynchronous from its very core
22. ACTOR MODEL AND DISTRIBUTED PROGRAMMING
23. What is an Actor? • Behavior (processing) - An actor reacts on messages it receives • State (storage) - An actor is shielded from the rest of the world - no need for synchronization! • Communication - An actor interacts with other actors exclusively via messages • "One actor is no actor" - they come in systems
24. Anatomy of an Akka Actor
25. Anatomy of an ActorSystem
26. INTRODUCTION
27. VOCABULARY • Drone - autonomous, field-deployed UAV,
 sends metrics/position to backend system • DroneShadow - backend “mirror” of field-deployed Drone,
 keeps metrics and represents drone in backend model • Backend - single MicroService,
 backed by Akka Cluster for resilience/load-balancing
28. VOCABULARY • DroneManager - the (one) thing keeping track of drones • Micro-service - has a single responsibility,
 it absolutely does not mean “one node”! • Distributed Journal - backing datastore of the single service,
 often Cassandra, SQL or similar. Service should “own your data.”
29. HIGH-LEVEL ARCHITECTURE OVERVIEW
30. HIGH-LEVEL ARCHITECTURE OVERVIEW
31. AKKA ACTOR BASICS
32. LET’S CODE!
33. • Message passing (events are a kind of message) • Distribution via Location Transparency • Lock-free & simple Concurrency • Very powerful abstraction underneath everything we’ll talk about Akka Actors:
34. AKKA CLUSTERING AND PERSISTENCE
35. HIGH-LEVEL ARCHITECTURE OVERVIEW
36. LET’S CODE!
37. FAILURE SCENARIO: Node Failure
38. HIGH-LEVEL ARCHITECTURE OVERVIEW
40. FAILURE SCENARIO: State Recovery (Akka Persistence)
42. http://developer.lightbend.com/docs/akka-commercial-addons/1.0.1/split-brain-resolver.html // application.conf akka.cluster.downing-provider-class = "com.lightbend.akka.sbr.SplitBrainResolverProvider" • Static Quorum - static, very predictable (like zk) • Keep Majority - dynamic, supports dynamic growth • Keep Oldest - keep “most stable” members • Keep Referee - keep “precious side” Split Brain / Failure Detection
43. http://developer.lightbend.com/docs/akka-commercial-addons/1.0.1/split-brain-resolver.html • Simple timeout - known as “auto down” • very naive, • not really intended for real-world usage. Naive Failure Detection
44. • Battle-tested Membership Protocol • Powerful distribution mechanism • Application aware Sharding • Scale-out & Resilience (+2400 nodes) Akka Cluster:
45. • EventSourcing style persistence • Pluggable Journals (Cassandra, SQL, Mongo, Dynamo, and more …) • Trivial to plug in • Enables CQRS-style architectures • Powers AtLeastOnceDelivery Akka Persistence:
46. AKKA STREAMS
47. Fast Publisher Slow Subscriber Akka Streams - BackPressure
48. Subscriber usually has some kind of buffer. Push model
49. Push model
50. Push model
51. Push model
52. What if the buffer overflows? Push model
53. Use bounded buffer, drop messages + require re-sending Push model
54. Kernel does this! Routers do this! (TCP) Use bounded buffer, drop messages + require re-sending Push model
55. Increase buffer size… Well, while you have memory available! Push model
56. Reactive Streams explained Reactive Streams explained in 1 slide
57. Fast Publisher will send at-most 3 elements. This is pull-based-backpressure. Reactive Streams: “dynamic push/pull”
58. JEP-266 – soon…! public final class Flow { private Flow() {} // uninstantiable @FunctionalInterface public static interface Publisher<T> { public void subscribe(Subscriber<? super T> subscriber); } public static interface Subscriber<T> { public void onSubscribe(Subscription subscription); public void onNext(T item); public void onError(Throwable throwable); public void onComplete(); } public static interface Subscription { public void request(long n); public void cancel(); } public static interface Processor<T,R> extends Subscriber<T>, Publisher<R> { } }
59. Reactive Streams: goals 1) Avoiding unbounded buffering across async boundaries 2)Inter-op interfaces between various libraries
60. Reactive Streams: goals 1) Avoiding unbounded buffering across async boundaries 2)Inter-op interfaces between various libraries Argh, implementing a correct RS Publisher or Subscriber is so hard!
61. 1) Avoiding unbounded buffering across async boundaries 2)Inter-op interfaces between various libraries Reactive Streams: goals Argh, implementing a correct RS Publisher or Subscriber is so hard!
62. Reactive Streams: goals Argh, implementing a correct RS Publisher or Subscriber is so hard! You should be using Akka Streams instead! 1) Avoiding unbounded buffering across async boundaries 2)Inter-op interfaces between various libraries
63. HIGH-LEVEL ARCHITECTURE OVERVIEW
64. LET’S CODE!
65. • Fully Typed API • Asynchronous Back-Pressure • First impl. to pass Reactive Streams standard • Reactive Streams coming to JDK9 • Powerful composable ScalaDSL and JavaDSL • Open Materializer API (e.g. Intel GearPump) Akka Streams:
66. AKKA HTTP
67. HIGH-LEVEL ARCHITECTURE OVERVIEW
68. A core feature not obvious to the untrained eye…! Quiz time! TCP is a ______ protocol? Akka HTTP
69. A core feature not obvious to the untrained eye…! Quiz time! TCP is a STREAMING protocol! Akka HTTP
70. Streaming in Akka HTTP http://doc.akka.io/docs/akka/2.4.7/scala/stream/stream-customize.html#graphstage-scala “Framed entity streaming” https://github.com/akka/akka/pull/20778 HttpServer as a: Flow[HttpRequest, HttpResponse]
71. Streaming in Akka HTTP http://doc.akka.io/docs/akka/2.4.7/scala/stream/stream-customize.html#graphstage-scala “Framed entity streaming” https://github.com/akka/akka/pull/20778 HttpServer as a: Flow[HttpRequest, HttpResponse] HTTP Entity as a: Source[ByteString, _]
72. Streaming in Akka HTTP http://doc.akka.io/docs/akka/2.4.7/scala/stream/stream-customize.html#graphstage-scala “Framed entity streaming” https://github.com/akka/akka/pull/20778 HttpServer as a: Flow[HttpRequest, HttpResponse] HTTP Entity as a: Source[ByteString, _] Websocket connection as a: Flow[ws.Message, ws.Message]
73. LET’S CODE!
74. It’s turtles buffers all the way down!
75. Streaming from Akka HTTP
76. Streaming from Akka HTTP
77. Streaming from Akka HTTP No demand from TCP = No demand upstream = Source won’t generate tweets => Bounded memory stream processing!
78. FAILURE SCENARIO 1
79. HIGH-LEVEL ARCHITECTURE OVERVIEW
80. HIGH-LEVEL ARCHITECTURE OVERVIEW
81. HIGH-LEVEL ARCHITECTURE OVERVIEW
82. FAILURE SCENARIO 2
83. HIGH-LEVEL ARCHITECTURE OVERVIEW
84. HIGH-LEVEL ARCHITECTURE OVERVIEW
85. HIGH-LEVEL ARCHITECTURE OVERVIEW
86. • “Streaming-first” HTTP Server • Powerful composable ScalaDSL and JavaDSL • Built completely on Akka Streams • Trivially exposes TCP level flow control to Akka Streams as backpressure • Simple inter-op with Actors, Futures, Streams • HTTP/2 coming very soon Akka HTTP:
87. TESTING ASYNCHRONOUS CODE WITH AKKA
88. TestKits and tools provided • Asynchronous is hard • Testing asynchronous code is hard • We’ve prepared plenty tools to make it simple
89. TestKits and tools provided • Akka Actors - TestKit • Akka Streams - TestSource / TestSink
90. LET’S CODE!
91. • All major modules come with dedicated TestKit • Actors, Streams, MultiJVM testing (!) • Makes asynchronous code simpler to test Akka Testing:
92. STREAMING INTEGRATION WITH “ALPAKKA”
93. Alpakka is a community driven project • Community of Akka Streams “Connectors” • Akka Streams == Reactive Streams impl
 == everyone profits! • Similar in goals to Apache Camel • “inter-op all the things!” • We’ve prepared plenty tools to make it simple
94. Alpakka – a community for Stream connectors http://developer.lightbend.com/docs/alpakka/current/ Google Pub/Sub … … … … … … …
95. Alpakka – a community for Stream connectors http://developer.lightbend.com/docs/alpakka/current/
96. Alpakka – a community for Stream connectors http://developer.lightbend.com/docs/alpakka/current/
97. LET’S CODE!
98. • Vibrant community of Akka Streams developers • Tens of integrations already, more coming as-we-speak • All fully Streaming and Back-pressure Aware and s Akka “Alpakka”:
99. MONITORING
100. MONITORING FEATURES (2017-04) • Akka Actors • Akka Remoting and Clustering • Lagom Circuit Breakers • Dispatchers / Thread Pools • Various backend integration (ES, StatsD, …) • Sandbox environment (EKG) for easy exploration
101. Example Integration: Datadog
102. • Commercial monitoring • Get the full picture about your applications in production • Highly optimized, fine-tuned by core Lightbend teams Lightbend Monitoring:
103. SUMMING UP
104. ARCHITECTURE • Resilient & Elastic from the ground up • High-performance & Asynchronous all-the-way • Highly Self-Healing / Resilient • Well established API endpoints (HTTP/WS/SSE) • Highly reusable & composable code • See Reactive Streams (j.u.c.Flow in JDK9)
105. CODE • Full feature parity between Java & Scala DSL (always!) • Asynchronous all-the-way • Understandable and well-defined failure scenarios • Start local, go distributed with no or minimal changes • Highly reusable & composable code • Brought to you by leaders of Reactive Streams
106. WHAT FEATURES ARE COMING SOON?
107. Next steps for Akka New Akka Remoting (benchmarked 1,000,000+ msg/s (!)), (built using Akka Streams, Aeron) More integrations for Akka Streams stages, project Alpakka. Akka Typed actively progressing (!). Akka HTTP/2 Proof of Concept in progress. Akka HTTP as default backend of Play Framework. Highly Available CRDTs with Akka Distributed Data.
108. MONITORING • Awesome monitoring of asynchronous code • Coming soon: • Tracing across Actors, Futures, HTTP • Smart Cluster Sharding insights • Akka HTTP metrics and events
109. We <3 contributions • Easy to contribute: • https://github.com/akka/akka/issues?q=is%3Aissue+is%3Aopen+label%3Aeasy-to- contribute • https://github.com/akka/akka/issues?q=is%3Aissue+is%3Aopen+label%3A%22nice-to- have+%28low-prio%29%22 • Akka: akka.io && github.com/akka • Reactive Streams: reactive-streams.org • Mailing list: • https://groups.google.com/group/akka-user • Public chat rooms: • http://gitter.im/akka/dev developing Akka • http://gitter.im/akka/akka using Akka
110. Lightbend booth / sponsor area O’Reilly’s “Ask the Experts” Henrik’s talk on Wednesday @ 4.50 pm… Catch us here: Catch us here
111. EOF Q/A Konrad Malawski (@ktosopl) - Akka Team Henrik Engström (@h3nk3) - Telemetry Team
