Helping Dagger Help You (Droidcon UK 2018)

As applications grow in size, Dagger can help mitigate the pain of dependency management and eliminate the boilerplate of manual dependency injection. Despite this, there are still pain points such as slower compilation times and how to inject objects like activities and views. This talk will cover functionality provided by libraries which build on top of Dagger to reduce these pain points. We'll learn what assisted injection is, why you might use it, and look at a library which simplifies the pattern. And finally we'll attempt to solve the build speed problem so that development builds are as fast as possible without sacrificing Dagger's compile-time safety.

Video: http://uk.droidcon.com/skillscasts/11617-helping-dagger-help-you

Transcript

1. Helping
   Dagger
   Help
   You
   @JakeWharton


   View Slide

2. boilerplate
   /ˈbɔɪləpleɪt/
   noun
   standardized pieces of text for use as clauses in
   contracts or as part of a computer program


   View Slide

3. verbosity
   /vəˈbɒsɪti/
   noun
   the fact or quality of using more words
   than needed; wordiness


   View Slide

4. View Slide

5. View Slide

6. Dagger


   View Slide

7. Dagger


   View Slide

8. Service Locator


   View Slide

9. Manual Dependency Injection


   View Slide

10. Manual Dependency Injection


    View Slide

11. Manual Dependency Injection


    View Slide

12. Service Locator


    View Slide

13. Dagger


    View Slide

14. Dagger


    View Slide

15. Dagger


    View Slide

16. class ProfilePresenter @Inject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer
    ) {
    // …
    }Y


    View Slide

17. class ProfilePresenter @Inject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer
    ) {
    // which profile do we load?
    }Y


    View Slide

18. class ProfilePresenter @Inject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer
    ) {
    // which profile do we load?
    // what initials do we render the avatar placeholder with?
    }Y


    View Slide

19. class ProfilePresenter @Inject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer
    ) {
    // which profile do we load?
    // what initials do we render the avatar placeholder with?
    // which image url do we download?
    }Y


    View Slide

20. class ProfilePresenter @Inject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer
    ) {
    lateinit var userId: String
    // which profile do we load?
    // what initials do we render the avatar placeholder with?
    // which image url do we download?
    }Y


    View Slide

21. class ProfilePresenter @Inject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer
    ) {
    lateinit var userId: String
    // which profile do we load?
    // what initials do we render the avatar placeholder with?
    // which image url do we download?
    }Y
    var userId: String = …


    View Slide

22. class ProfilePresenter @Inject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer
    ) {
    lateinit var userId: String
    // which profile do we load?
    // what initials do we render the avatar placeholder with?
    // which image url do we download?
    }Y
    var userId: String = …
    presenter.userId = userId


    View Slide

23. class ProfilePresenter @Inject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer
    ) {
    lateinit var userId: String
    // which profile do we load?
    // what initials do we render the avatar placeholder with?
    // which image url do we download?
    }Y
    var userId: String = …
    presenter.userId = userId
    // Use presenter…


    View Slide

24. class ProfilePresenter @Inject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer
    ) {
    lateinit var userId: String
    // …
    }Y
    var userId: String = …
    presenter.userId = userId
    // Use presenter…


    View Slide

25. class ProfilePresenter @Inject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    }Y
    var userId: String = …
    presenter.userId = userId
    // Use presenter…


    View Slide

26. class ProfilePresenter @Inject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    }Y
    // Use presenter…


    View Slide

27. class ProfilePresenter @Inject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    }Y
    // Use presenter…


    View Slide

28. class ProfilePresenter @Inject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    @UserId var userId: String
    ) {
    // …
    }Y
    // Use presenter…


    View Slide

29. class ProfilePresenter @Inject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    }Y
    // Use presenter…


    View Slide

30. class ProfilePresenter @Inject constructor(A
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    }Y


    View Slide

31. class ProfilePresenter(A
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    }Y


    View Slide

32. class ProfilePresenter(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    class Factory
    }Y


    View Slide

33. class ProfilePresenter(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    class Factory @Inject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer
    )G
    }Y


    View Slide

34. class ProfilePresenter(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    class Factory @Inject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer
    )G{
    fun create(userId: String)
    }Z
    }Y


    View Slide

35. class ProfilePresenter(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    class Factory @Inject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer
    )G{
    fun create(userId: String) =
    ProfilePresenter(imageLoader, profilePersistence,
    avatarRenderer, userId)
    }Z
    }Y


    View Slide

36. class ProfilePresenter(…) {
    // …
    class Factory @Inject constructor(…)G{
    fun create(userId: String) =
    ProfilePresenter(imageLoader, profilePersistence,
    avatarRenderer, userId)
    }Z
    }Y


    View Slide

37. class ProfilePresenter(…) {
    // …
    class Factory @Inject constructor(…) {
    fun create(userId: String) =
    ProfilePresenter(imageLoader, profilePersistence,
    avatarRenderer, userId)
    }Z
    }Y
    var userId: String = …


    View Slide

38. class ProfilePresenter(…) {
    // …
    class Factory @Inject constructor(…) {
    fun create(userId: String) =
    ProfilePresenter(imageLoader, profilePersistence,
    avatarRenderer, userId)
    }Z
    }Y
    var userId: String = …
    val presenter = presenterFactory.create(userId)
    // Use presenter…


    View Slide

39. class ProfilePresenter(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    class Factory @Inject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer
    ) {
    fun create(userId: String) =
    ProfilePresenter(imageLoader, profilePersistence,
    avatarRenderer, userId)
    }Z
    }Y


    View Slide

40. class ProfilePresenter(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    class Factory @Inject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence:val avatarRenderer: AvatarRenderer
    ) {
    fun create(userId: String) =
    ProfilePresenter(imageLoader, profilePersistence,
    avatarRenderer, userId)
    }Z
    }Y


    View Slide

41. class ProfilePresenter(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    class Factory @Inject constructor(
    val imageLoader: Provider,
    val profilePersistence: Provider,
    val avatarRenderer: Provider
    ) {
    fun create(userId: String) =
    ProfilePresenter(imageLoader.get(), profilePersistence.get(),
    avatarRenderer.get(), userId)
    }Z
    }Y


    View Slide

42. class ProfilePresenter(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    class Factory @Inject constructor(
    val imageLoader: Provider,
    val profilePersistence: Provider,
    val avatarRenderer: Provider
    ) {
    fun create(userId: String) =
    ProfilePresenter(imageLoader.get(), profilePersistence.get(),
    avatarRenderer.get(), userId)
    }Z
    }Y


    View Slide

43. class ProfilePresenter(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    class Factory @Inject constructor(
    val imageLoader: Provider,
    val profilePersistence: Provider,
    val avatarRenderer: Provider
    ) {
    fun create(userId: String) =
    ProfilePresenter(imageLoader.get(), profilePersistence.get(),
    avatarRenderer.get(), userId)
    }Z
    }Y


    View Slide

44. class ProfilePresenter(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    class Factory @Inject constructor(
    val imageLoader: Provider,
    val profilePersistence: Provider,
    val avatarRenderer: Provider
    ) {
    fun create(userId: String) =
    ProfilePresenter(imageLoader.get(), profilePersistence.get(),
    avatarRenderer.get(), userId)
    }Z
    }Y


    View Slide

45. class ProfilePresenter {
    private final ImageLoader imageLoader;
    private final ProfilePersistence profilePersistence;
    private final AvatarRenderer avatarRenderer;
    private final String userId;
    ProfilePresenter(
    ImageLoader imageLoader, ProfilePersistence profilePersistence,
    AvatarRenderer avatarRenderer, String userId) {
    this.imageLoader = imageLoader;
    this.profilePersistence = profilePersistence;
    this.avatarRenderer = avatarRenderer;
    this.userId = userId;
    }A
    // …
    static final class Factory {
    private final Provider imageLoader;


    View Slide

46. // …
    static final class Factory {
    private final Provider imageLoader;
    private final Provider profilePersistence;
    private final Provider avatarRenderer;
    @Inject Factory(Provider imageLoader,
    Provider profilePersistence,
    Provider avatarRenderer) {
    this.imageLoader = imageLoader;
    this.profilePersistence = profilePersistence;
    this.avatarRenderer = avatarRenderer;
    }B
    public ProfilePresenter create(String userId) {
    return new ProfilePresenter(imageLoader.get(),
    profilePersistence.get(), avatarRenderer.get(), userId);
    }C
    }D
    }E


    View Slide

47. class ProfilePresenter(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    class Factory @Inject constructor(
    val imageLoader: Provider,
    val profilePersistence: Provider,
    val avatarRenderer: Provider
    )G{
    fun create(userId: String) =
    ProfilePresenter(imageLoader.get(), profilePersistence.get(),
    avatarRenderer.get(), userId)
    }Z
    }Y
    i
    n
    t
    e
    r
    f
    a
    c
    e


    View Slide

48. class ProfilePresenter(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    interface FactoryG{
    fun create(userId: String): ProfilePresenter
    }Z
    }Y


    View Slide

49. class ProfilePresenter(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    interface Factory {
    fun create(userId: String): ProfilePresenter
    }Z
    }Y
    install(FactoryModuleBuilder()
    .build(ProfilePresenter::class.java))


    View Slide

50. class ProfilePresenter @Inject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    interface Factory {
    fun create(userId: String): ProfilePresenter
    }Z
    }Y
    install(FactoryModuleBuilder()
    .build(ProfilePresenter::class.java))


    View Slide

51. class ProfilePresenter @Inject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    @Assisted var userId: String
    ) {
    // …
    interface Factory {
    fun create(userId: String): ProfilePresenter
    }Z
    }Y
    install(FactoryModuleBuilder()
    .build(ProfilePresenter::class.java))


    View Slide

52. class ProfilePresenter(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    class Factory @Inject constructor(
    val imageLoader: Provider,
    val profilePersistence: Provider,
    val avatarRenderer: Provider
    ) {
    fun create(userId: String) =
    ProfilePresenter(imageLoader.get(), profilePersistence.get(),
    avatarRenderer.get(), userId)
    }Z
    }Y


    View Slide

53. @AutoFactory class ProfilePresenter(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    class Factory @Inject constructor(
    val imageLoader: Provider,
    val profilePersistence: Provider,
    val avatarRenderer: Provider
    ) {
    fun create(userId: String) =
    ProfilePresenter(imageLoader.get(), profilePersistence.get(),
    avatarRenderer.get(), userId)
    }Z
    }Y


    View Slide

54. @AutoFactory class ProfilePresenter(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    }Y


    View Slide

55. @AutoFactory class ProfilePresenter(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    }Y
    @Generated
    final class ProfilePresenterFactory {
    @Inject
    ProfilePresenterFactory(Provider imageLoader,
    Provider profilePersistence,
    Provider avatarRenderer) { … }
    ProfilePresenter create(userId: String) { … }
    }Z


    View Slide

56. @AutoFactory class ProfilePresenter(
    @Provided val imageLoader: ImageLoader,
    @Provided val profilePersistence: ProfilePersistence,
    @Provided val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    }Y
    @Generated
    final class ProfilePresenterFactory {
    @Inject
    ProfilePresenterFactory(Provider imageLoader,
    Provider profilePersistence,
    Provider avatarRenderer) { … }
    ProfilePresenter create(userId: String) { … }
    }Z


    View Slide

57. @AutoFactory class ProfilePresenter(
    @Provided val imageLoader: ImageLoader,
    @Provided val profilePersistence: ProfilePersistence,
    @Provided val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    }Y
    @Generated
    final class ProfilePresenterFactory {
    @Inject
    ProfilePresenterFactory(Provider imageLoader,
    Provider profilePersistence,
    Provider avatarRenderer) { … }
    ProfilePresenter create(userId: String) { … }
    }Z


    View Slide

58. @AutoFactory class ProfilePresenter(
    @Provided val imageLoader: ImageLoader,
    @Provided val profilePersistence: ProfilePersistence,
    @Provided val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    }Y
    @Generated
    final class ProfilePresenterFactory {
    @Inject
    ProfilePresenterFactory(Provider imageLoader,
    Provider profilePersistence,
    Provider avatarRenderer) { … }
    ProfilePresenter create(userId: String) { … }
    }Z


    View Slide

59. @AutoFactory class ProfilePresenter(
    @Provided val imageLoader: ImageLoader,
    @Provided val profilePersistence: ProfilePersistence,
    @Provided val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    }Y
    @Generated
    final class ProfilePresenterFactory {
    @Inject
    ProfilePresenterFactory(Provider imageLoader,
    Provider profilePersistence,
    Provider avatarRenderer) { … }
    ProfilePresenter create(userId: String) { … }
    }Z


    View Slide

60. class ProfilePresenter(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    class Factory @Inject constructor(
    val imageLoader: Provider,
    val profilePersistence: Provider,
    val avatarRenderer: Provider
    )G{
    fun create(userId: String) =
    ProfilePresenter(imageLoader.get(), profilePersistence.get(),
    avatarRenderer.get(), userId)
    }Z
    }Y
    i
    n
    t
    e
    r
    f
    a
    c
    e


    View Slide

61. class ProfilePresenter(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    interface FactoryG{
    fun create(userId: String): ProfilePresenter
    }Z
    }Y


    View Slide

62. class ProfilePresenter @AssistedInject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    var userId: String
    ) {
    // …
    interface FactoryG{
    fun create(userId: String): ProfilePresenter
    }Z
    }Y


    View Slide

63. class ProfilePresenter @AssistedInject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    @Assisted var userId: String
    ) {
    // …
    interface FactoryG{
    fun create(userId: String): ProfilePresenter
    }Z
    }Y


    View Slide

64. class ProfilePresenter @AssistedInject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    @Assisted var userId: String
    ) {
    // …
    @AssistedInject.Factory
    interface FactoryG{
    fun create(userId: String): ProfilePresenter
    }Z
    }Y


    View Slide

65. @Generated
    class AssistedInject_ProfilePresenter implements ProfilePresenter.Factory {
    private final Provider imageLoader;
    private final Provider profilePersistence;
    private final Provider avatarRenderer;
    @Inject AssistedInject_ProfilePresenter(
    Provider imageLoader,
    Provider profilePersistence,
    Provider avatarRenderer) {
    this.imageLoader = imageLoader;
    this.profilePersistence = profilePersistence;
    this.avatarRenderer = avatarRenderer;
    }
    @Override public ProfilePresenter create(String userId) {
    return new ProfilePresenter(imageLoader.get(),
    profilePersistence.get(), avatarRenderer.get(), userId);
    }
    }


    View Slide

66. @Generated
    class AssistedInject_ProfilePresenter implements ProfilePresenter.Factory {
    private final Provider imageLoader;
    private final Provider profilePersistence;
    private final Provider avatarRenderer;
    @Inject AssistedInject_ProfilePresenter(
    Provider imageLoader,
    Provider profilePersistence,
    Provider avatarRenderer) {
    this.imageLoader = imageLoader;
    this.profilePersistence = profilePersistence;
    this.avatarRenderer = avatarRenderer;
    }
    @Override public ProfilePresenter create(String userId) {
    return new ProfilePresenter(imageLoader.get(),
    profilePersistence.get(), avatarRenderer.get(), userId);
    }
    }


    View Slide

67. @Generated
    class AssistedInject_ProfilePresenter implements ProfilePresenter.Factory {
    private final Provider imageLoader;
    private final Provider profilePersistence;
    private final Provider avatarRenderer;
    @Inject AssistedInject_ProfilePresenter(
    Provider imageLoader,
    Provider profilePersistence,
    Provider avatarRenderer) {
    this.imageLoader = imageLoader;
    this.profilePersistence = profilePersistence;
    this.avatarRenderer = avatarRenderer;
    }
    @Override public ProfilePresenter create(String userId) {
    return new ProfilePresenter(imageLoader.get(),
    profilePersistence.get(), avatarRenderer.get(), userId);
    }
    }


    View Slide

68. @Generated
    class AssistedInject_ProfilePresenter implements ProfilePresenter.Factory {
    private final Provider imageLoader;
    private final Provider profilePersistence;
    private final Provider avatarRenderer;
    @Inject AssistedInject_ProfilePresenter(
    Provider imageLoader,
    Provider profilePersistence,
    Provider avatarRenderer) {
    this.imageLoader = imageLoader;
    this.profilePersistence = profilePersistence;
    this.avatarRenderer = avatarRenderer;
    }
    @Override public ProfilePresenter create(String userId) {
    return new ProfilePresenter(imageLoader.get(),
    profilePersistence.get(), avatarRenderer.get(), userId);
    }
    }


    View Slide

69. class ProfilePresenter @AssistedInject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    @Assisted var userId: String
    ) {
    // …
    @AssistedInject.Factory
    interface Factory {
    fun create(userId: String): ProfilePresenter
    }Z
    }Y


    View Slide

70. class ProfilePresenter @AssistedInject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    @Assisted var userId: String
    ) {
    // …
    @AssistedInject.Factory
    interface Factory {
    fun create(userId: String): ProfilePresenter
    }Z
    }Y


    View Slide

71. class ProfilePresenter @AssistedInject constructor(
    val imageLoader: ImageLoader,
    val profilePersistence: ProfilePersistence,
    val avatarRenderer: AvatarRenderer,
    @Assisted var userId: String
    ) {
    // …
    @AssistedInject.Factory
    interface Factory {
    fun create(userId: String): ProfilePresenter
    }Z
    }Y
    class AssistedInject_ProfilePresenter implements ProfilePresenter.Factory {
    @Inject AssistedInject_ProfilePresenter(…)
    }


    View Slide

72. @Module
    abstract class AssistedModule {
    }S


    View Slide

73. @Module
    abstract class AssistedModule {
    @Binds
    abstract fun bindProfilePresenterFactory(
    factory: AssistedInject_ProfilePresenter): ProfilePresenter.Factory
    }S


    View Slide

74. @Module
    abstract class AssistedModule {
    @Binds
    abstract fun bindProfilePresenterFactory(
    factory: AssistedInject_ProfilePresenter): ProfilePresenter.Factory
    }S


    View Slide

75. @Module
    abstract class AssistedModule {
    @Binds
    abstract fun bindProfilePresenterFactory(
    factory: AssistedInject_ProfilePresenter): ProfilePresenter.Factory
    }S


    View Slide

76. @Module
    abstract class AssistedModule {
    @Binds
    abstract fun bindProfilePresenterFactory(
    factory: AssistedInject_ProfilePresenter): ProfilePresenter.Factory
    }S


    View Slide

77. @Module
    abstract class AssistedModule {
    @Binds
    abstract fun bindProfilePresenterFactory(
    factory: AssistedInject_ProfilePresenter): ProfilePresenter.Factory
    }S
    @Component(modules = [PresenterModule::class])
    interface PresenterComponent {
    // …
    }T


    View Slide

78. @Module
    abstract class AssistedModule {
    @Binds
    abstract fun bindProfilePresenterFactory(
    factory: AssistedInject_ProfilePresenter): ProfilePresenter.Factory
    }S
    @Component(modules = [PresenterModule::class, AssistedModule::class])
    interface PresenterComponent {
    // …
    }T


    View Slide

79. @Module
    object PresenterModule {
    @JvmStatic @Provides
    fun thing() = Thing("API key")
    }H


    View Slide

80. @AssistedModule
    @Module
    object PresenterModule {
    @JvmStatic @Provides
    fun thing() = Thing("API key")
    }H


    View Slide

81. @AssistedModule
    @Module
    object PresenterModule {
    @JvmStatic @Provides
    fun thing() = Thing("API key")
    }H
    @Module
    @Generated
    abstract class AssistedModule_PresenterModule {
    @Binds
    abstract ProfilePresenter.Factory bindProfilePresenterFactory(
    AssistedInject_ProfilePresenter factory)
    }S


    View Slide

82. @AssistedModule
    @Module(includes = [AssistedModule_PresenterModule::class])
    object PresenterModule {
    @JvmStatic @Provides
    fun thing() = Thing("API key")
    }H
    @Module
    @Generated
    abstract class AssistedModule_PresenterModule {
    @Binds
    abstract ProfilePresenter.Factory bindProfilePresenterFactory(
    AssistedInject_ProfilePresenter factory)
    }S


    View Slide

83. @AssistedModule
    @Module(includes = [AssistedModule_PresenterModule::class])
    object PresenterModule {
    @JvmStatic @Provides
    fun thing() = Thing("API key")
    }H
    @Module
    @Generated
    abstract class AssistedModule_PresenterModule {
    @Binds
    abstract ProfilePresenter.Factory bindProfilePresenterFactory(
    AssistedInject_ProfilePresenter factory)
    // …
    }S


    View Slide

84. class MainActivity : Activity() {
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    AndroidInjection.inject(this)
    }C
    }B


    View Slide

85. class MainActivity : Activity() {
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    AndroidInjection.inject(this)
    }C
    }B


    View Slide

86. class MainActivity : Activity() {
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    AndroidInjection.inject(this)
    }C
    }B


    View Slide

87. class MainActivity : Activity() {
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    AndroidInjection.inject(this)
    }C
    }B
    @Module
    abstract class MainActivityModule {
    }A


    View Slide

88. class MainActivity : Activity() {
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    AndroidInjection.inject(this)
    }C
    }B
    @Module
    abstract class MainActivityModule {
    @ContributesAndroidInjector
    abstract fun contributeMainActivity(): MainActivity
    }A


    View Slide

89. class MainActivity : Activity() {
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    AndroidInjection.inject(this)
    }C
    }B
    @Module
    abstract class MainActivityModule {
    @ContributesAndroidInjector
    abstract fun contributeMainActivity(): MainActivity
    }A
    @Component(modules = [MainActivityModule::class])
    interface AppComponent


    View Slide

90. class MainActivity : Activity() {
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    AndroidInjection.inject(this)
    }C
    }B
    @Module
    abstract class MainActivityModule {
    @ContributesAndroidInjector
    abstract fun contributeMainActivity(): MainActivity
    }A
    @Component(modules = [MainActivityModule::class])
    interface AppComponent
    @Module
    abstract class MainActivityModule_ContributeMainActivity { … }


    View Slide

91. class MainActivity : Activity() {
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    AndroidInjection.inject(this)
    }C
    }B
    @Module
    abstract class MainActivityModule {
    @ContributesAndroidInjector
    abstract fun contributeMainActivity(): MainActivity
    }A
    @Component(modules = [MainActivityModule::class])
    interface AppComponent
    @Module
    abstract class MainActivityModule_ContributeMainActivity { … }


    View Slide

92. View Slide

93. View Slide

94. dependencies {
    compileOnly 'com.squareup.inject:assisted-inject-annotations-dagger2:0.3.0'
    kapt 'com.squareup.inject:assisted-inject-processor-dagger2:0.3.0'
    }A


    View Slide

95. dependencies {
    compileOnly 'com.squareup.inject:assisted-inject-annotations-dagger2:0.3.0'
    kapt 'com.squareup.inject:assisted-inject-processor-dagger2:0.3.0'
    // or 'annotationProcessor'…
    }A


    View Slide

96. class ProfileView(context: Context, attrs: AttributeSet)
    : ConstraintLayout(context, attrs) {
    }Z


    View Slide

97. class ProfileView(context: Context, attrs: AttributeSet)
    : ConstraintLayout(context, attrs) {
    lateinit var imageLoader: ImageLoader
    lateinit var avatarRenderer: AvatarRenderer
    }Z


    View Slide

98. class ProfileView(context: Context, attrs: AttributeSet)
    : ConstraintLayout(context, attrs) {
    lateinit var imageLoader: ImageLoader
    lateinit var avatarRenderer: AvatarRenderer
    fun showProfile(profile: Profile) {
    // Use avatarRenderer…
    // Use imageLoader…
    }Y
    }Z


    View Slide

99. class ProfileView(context: Context, attrs: AttributeSet)
    : ConstraintLayout(context, attrs) {
    lateinit var imageLoader: ImageLoader
    lateinit var avatarRenderer: AvatarRenderer
    fun showProfile(profile: Profile) {
    // Use avatarRenderer…
    // Use imageLoader…
    }Y
    }Z
    class ProfilePresenter @AssistedInject constructor(
    val imageLoader: ImageLoader, val avatarRenderer: AvatarRenderer, /*…*/
    ) {
    }I


    View Slide

100. class ProfileView(context: Context, attrs: AttributeSet)
     : ConstraintLayout(context, attrs) {
     lateinit var imageLoader: ImageLoader
     lateinit var avatarRenderer: AvatarRenderer
     fun showProfile(profile: Profile) {
     // Use avatarRenderer…
     // Use imageLoader…
     }Y
     }Z
     class ProfilePresenter @AssistedInject constructor(
     val imageLoader: ImageLoader, val avatarRenderer: AvatarRenderer, /*…*/
     ) {
     fun attachView(view: ProfileView) {
     }W
     }I


     View Slide

101. l
     l
     class ProfileView(context: Context, attrs: AttributeSet)G
     : ConstraintLayout(context, attrs) {
     lateinit var imageLoader: ImageLoader
     lateinit var avatarRenderer: AvatarRenderer
     fun showProfile(profile: Profile) {
     // Use avatarRenderer…
     // Use imageLoader…
     }Y
     }Z
     class ProfilePresenter @AssistedInject constructor(
     val imageLoader: ImageLoader, val avatarRenderer: AvatarRenderer, /*…*/
     ) {
     fun attachView(view: ProfileView) {
     view.imageLoader = imageLoader
     view.avatarRenderer = avatarRenderer
     }W
     }I


     View Slide

102. r
     r
     class ProfileView(
     context: Context, attrs: AttributeSet,
     val imageLoader: ImageLoader,
     val avatarRenderer: AvatarRenderer
     )G: ConstraintLayout(context, attrs) {
     fun showProfile(profile: Profile) {
     // Use avatarRenderer…
     // Use imageLoader…
     }Y
     }Z
     class ProfilePresenter @AssistedInject constructor(
     val imageLoader: ImageLoader, val avatarRenderer: AvatarRenderer, /*…*/
     ) {
     fun attachView(view: ProfileView) {
     view.imageLoader = imageLoader
     view.avatarRenderer = avatarRenderer
     }W
     }I


     View Slide

103. class ProfileView(
     context: Context, attrs: AttributeSet,
     val imageLoader: ImageLoader,
     val avatarRenderer: AvatarRenderer
     )G: ConstraintLayout(context, attrs) {
     fun showProfile(profile: Profile) {
     // Use avatarRenderer…
     // Use imageLoader…
     }Y
     }Z
     class ProfilePresenter @AssistedInject constructor(
     val imageLoader: ImageLoader, val avatarRenderer: AvatarRenderer, /*…*/
     ) {
     fun attachView(view: ProfileView) {
     }W
     }I


     View Slide

104. class ProfileView(
     context: Context, attrs: AttributeSet,
     val imageLoader: ImageLoader,
     val avatarRenderer: AvatarRenderer
     )G: ConstraintLayout(context, attrs) {
     fun showProfile(profile: Profile) {
     // Use avatarRenderer…
     // Use imageLoader…
     }Y
     }Z
     class ProfilePresenter @AssistedInject constructor(/*…*/) {
     fun attachView(view: ProfileView) {
     }W
     }I


     View Slide

105. class ProfileView(
     context: Context, attrs: AttributeSet,
     val imageLoader: ImageLoader,
     val avatarRenderer: AvatarRenderer
     ) : ConstraintLayout(context, attrs) {
     fun showProfile(profile: Profile) {
     // Use avatarRenderer…
     // Use imageLoader…
     }Y
     }Z
     class ProfilePresenter @AssistedInject constructor(/*…*/) {
     fun attachView(view: ProfileView) {
     }W
     }I


     View Slide

106. class LayoutInflater {
     }A


     View Slide

107. class LayoutInflater {
     interface Factory {
     }B
     }A


     View Slide

108. class LayoutInflater {
     interface Factory {
     @Nullable
     View onCreateView(
     @NonNull String name,
     @NonNull Context context,
     @NonNull AttributeSet attrs);
     }B
     }A


     View Slide

109. class LayoutInflater {
     interface Factory {
     @Nullable
     View onCreateView(
     @NonNull String name,
     @NonNull Context context,
     @NonNull AttributeSet attrs);
     }B
     }A
     class MyAppFactory : LayoutInflater.Factory {
     }P


     View Slide

110. class LayoutInflater {
     interface Factory {
     @Nullable
     View onCreateView(
     @NonNull String name,
     @NonNull Context context,
     @NonNull AttributeSet attrs);
     }B
     }A
     class MyAppFactory : LayoutInflater.Factory {
     override fun onCreateView(name: String,
     context: Context, attrs: AttributeSet): View? {
     }O
     }P


     View Slide

111. class LayoutInflater {
     interface Factory {
     @Nullable
     View onCreateView(
     @NonNull String name,
     @NonNull Context context,
     @NonNull AttributeSet attrs);
     }B
     }A
     class MyAppFactory : LayoutInflater.Factory {
     override fun onCreateView(name: String,
     context: Context, attrs: AttributeSet): View? {
     if (name == ProfileView::class.java.name) {
     return TODO()
     }I
     }O
     }P


     View Slide

112. class LayoutInflater {
     interface Factory {
     @Nullable
     View onCreateView(
     @NonNull String name,
     @NonNull Context context,
     @NonNull AttributeSet attrs);
     }B
     }A
     class MyAppFactory : LayoutInflater.Factory {
     override fun onCreateView(name: String,
     context: Context, attrs: AttributeSet): View? {
     if (name == ProfileView::class.java.name) {
     return TODO()
     }I
     return null
     }O
     }P


     View Slide

113. class ProfileView(
     context: Context, attrs: AttributeSet,
     private val imageLoader: ImageLoader,
     private val avatarRenderer: AvatarRenderer
     ) : ConstraintLayout(context, attrs) {
     }Z


     View Slide

114. class ProfileView(G
     @Assisted context: Context, @Assisted attrs: AttributeSet,
     private val imageLoader: ImageLoader,
     private val avatarRenderer: AvatarRenderer
     ) : ConstraintLayout(context, attrs) {
     }Z


     View Slide

115. class ProfileView @AssistedInject constructor(G
     @Assisted context: Context, @Assisted attrs: AttributeSet,
     private val imageLoader: ImageLoader,
     private val avatarRenderer: AvatarRenderer
     ) : ConstraintLayout(context, attrs) {
     }Z


     View Slide

116. class ProfileView @AssistedInject constructor(G
     @Assisted context: Context, @Assisted attrs: AttributeSet,
     private val imageLoader: ImageLoader,
     private val avatarRenderer: AvatarRenderer
     ) : ConstraintLayout(context, attrs) {
     @AssistedInject.Factory
     interface Factory {
     fun create(context: Context, attrs: AttributeSet): ProfileView
     }G
     }Z


     View Slide

117. class MyAppFactory : LayoutInflater.Factory {
     override fun onCreateView(name: String,
     context: Context, attrs: AttributeSet): View? {
     if (name == ProfileView::class.java.name) {
     return TODO()
     }I
     return null
     }O
     }P


     View Slide

118. class MyAppFactory @Inject constructor() : LayoutInflater.Factory {
     override fun onCreateView(name: String,
     context: Context, attrs: AttributeSet): View? {
     if (name == ProfileView::class.java.name) {
     return TODO()
     }I
     return null
     }O
     }P


     View Slide

119. class MyAppFactory @Inject constructor(
     private val profileViewFactory: ProfileView.Factory
     ) : LayoutInflater.Factory {
     override fun onCreateView(name: String,
     context: Context, attrs: AttributeSet): View? {
     if (name == ProfileView::class.java.name) {
     return TODO()
     }I
     return null
     }O
     }P


     View Slide

120. class MyAppFactory @Inject constructor(
     private val profileViewFactory: ProfileView.Factory
     ) : LayoutInflater.Factory {
     override fun onCreateView(name: String,
     context: Context, attrs: AttributeSet): View? {
     if (name == ProfileView::class.java.name) {
     return profileViewFactory.create(context, attrs)
     }I
     return null
     }O
     }P


     View Slide

121. class MyAppFactory @Inject constructor(
     private val profileViewFactory: ProfileView.Factory,
     private val cartViewFactory: CartView.Factory
     ) : LayoutInflater.Factory {
     override fun onCreateView(name: String,
     context: Context, attrs: AttributeSet): View? {
     if (name == ProfileView::class.java.name) {
     return profileViewFactory.create(context, attrs)
     }I
     if (name == CartView::class.java.name) {
     return cartViewFactory.create(context, attrs)
     }I
     return null
     }O
     }P


     View Slide

122. class MyAppFactory @Inject constructor(
     private val profileViewFactory: ProfileView.Factory,
     private val cartViewFactory: CartView.Factory,
     private val checkoutViewFactory: CheckoutView.Factory
     ) : LayoutInflater.Factory {
     override fun onCreateView(name: String,
     context: Context, attrs: AttributeSet): View? {
     if (name == ProfileView::class.java.name) {
     return profileViewFactory.create(context, attrs)
     }I
     if (name == CartView::class.java.name) {
     return cartViewFactory.create(context, attrs)
     }I
     if (name == CheckoutView::class.java.name) {
     return checkoutViewFactory.create(context, attrs)
     }I
     return null
     }O
     }P


     View Slide

123. class MyAppFactory @Inject constructor(
     private val viewFactories: Map
     ) : LayoutInflater.Factory {
     override fun onCreateView(name: String,
     context: Context, attrs: AttributeSet): View? {
     if (name == ProfileView::class.java.name) {
     return profileViewFactory.create(context, attrs)
     }I
     if (name == CartView::class.java.name) {
     return cartViewFactory.create(context, attrs)
     }I
     if (name == CheckoutView::class.java.name) {
     return checkoutViewFactory.create(context, attrs)
     }I
     return null
     }O
     }P
     private val profileViewFactory: ProfileView.Factory,
     private val cartViewFactory: CartView.Factory,
     private val checkoutViewFactory: CheckoutView.Factory


     View Slide

124. class MyAppFactory @Inject constructor(
     private val viewFactories: Map
     ) : LayoutInflater.Factory {
     override fun onCreateView(name: String,
     context: Context, attrs: AttributeSet): View? {
     return viewFactories[name]?.create(context, attrs)
     }O
     }P
     if (name == ProfileView::class.java.name) {
     return profileViewFactory.create(context, attrs)
     }I
     if (name == CartView::class.java.name) {
     return cartViewFactory.create(context, attrs)
     }I
     if (name == CheckoutView::class.java.name) {
     return checkoutViewFactory.create(context, attrs)
     }I null


     View Slide

125. class MyAppFactory @Inject constructor(
     private val viewFactories: Map
     ) : LayoutInflater.Factory {
     override fun onCreateView(name: String,
     context: Context, attrs: AttributeSet): View? {
     return viewFactories[name]?.create(context, attrs)
     }O
     }P
     interface ViewFactory {
     fun create(context: Context, attrs: AttributeSet): View
     }


     View Slide

126. class ProfileView @AssistedInject constructor(
     @Assisted context: Context, @Assisted attrs: AttributeSet,
     private val imageLoader: ImageLoader,
     private val avatarRenderer: AvatarRenderer
     ) : ConstraintLayout(context, attrs) {
     @AssistedInject.Factory
     interface Factory {A
     fun create(context: Context, attrs: AttributeSet): ProfileView
     }G
     }Z


     View Slide

127. class ProfileView @AssistedInject constructor(
     @Assisted context: Context, @Assisted attrs: AttributeSet,
     private val imageLoader: ImageLoader,
     private val avatarRenderer: AvatarRenderer
     ) : ConstraintLayout(context, attrs) {
     @AssistedInject.Factory
     interface Factory : ViewFactory {A
     override fun create(context: Context, attrs: AttributeSet): ProfileView
     }G
     }Z


     View Slide

128. class ProfileView @AssistedInject constructor(
     @Assisted context: Context, @Assisted attrs: AttributeSet,
     private val imageLoader: ImageLoader,
     private val avatarRenderer: AvatarRenderer
     ) : ConstraintLayout(context, attrs) {
     @AssistedInject.Factory
     interface Factory : ViewFactory {
     override fun create(context: Context, attrs: AttributeSet): ProfileView
     }G
     }Z
     @Module
     abstract class ViewModule {
     }Q


     View Slide

129. class ProfileView @AssistedInject constructor(
     @Assisted context: Context, @Assisted attrs: AttributeSet,
     private val imageLoader: ImageLoader,
     private val avatarRenderer: AvatarRenderer
     ) : ConstraintLayout(context, attrs) {
     @AssistedInject.Factory
     interface Factory : ViewFactory {
     override fun create(context: Context, attrs: AttributeSet): ProfileView
     }G
     }Z
     @Module
     abstract class ViewModule {
     @Binds
     abstract fun profileView(factory: ProfileView.Factory): ViewFactory
     }Q


     View Slide

130. class ProfileView @AssistedInject constructor(
     @Assisted context: Context, @Assisted attrs: AttributeSet,
     private val imageLoader: ImageLoader,
     private val avatarRenderer: AvatarRenderer
     ) : ConstraintLayout(context, attrs) {
     @AssistedInject.Factory
     interface Factory : ViewFactory {
     override fun create(context: Context, attrs: AttributeSet): ProfileView
     }G
     }Z
     @Module
     abstract class ViewModule {
     @Binds
     @IntoMap
     abstract fun profileView(factory: ProfileView.Factory): ViewFactory
     }Q


     View Slide

131. class ProfileView @AssistedInject constructor(
     @Assisted context: Context, @Assisted attrs: AttributeSet,
     private val imageLoader: ImageLoader,
     private val avatarRenderer: AvatarRenderer
     ) : ConstraintLayout(context, attrs) {
     @AssistedInject.Factory
     interface Factory : ViewFactory {
     override fun create(context: Context, attrs: AttributeSet): ProfileView
     }G
     }Z
     @Module
     abstract class ViewModule {
     @Binds
     @IntoMap
     @StringKey("com.example.ProfileView")
     abstract fun profileView(factory: ProfileView.Factory): ViewFactory
     }Q


     View Slide

132. class ProfileView @AssistedInject constructor(
     @Assisted context: Context, @Assisted attrs: AttributeSet,
     private val imageLoader: ImageLoader,
     private val avatarRenderer: AvatarRenderer
     ) : ConstraintLayout(context, attrs) {
     @AssistedInject.Factory
     interface Factory : ViewFactory {
     override fun create(context: Context, attrs: AttributeSet): ProfileView
     }G
     }Z
     @Module
     abstract class ViewModule {
     @Binds
     @IntoMap
     @StringKey("com.example.ProfileView")
     abstract fun profileView(factory: ProfileView.Factory): ViewFactory
     }Q


     View Slide

133. class ProfileView @AssistedInject constructor(
     @Assisted context: Context, @Assisted attrs: AttributeSet,
     private val imageLoader: ImageLoader,
     private val avatarRenderer: AvatarRenderer
     ) : ConstraintLayout(context, attrs) {
     @AssistedInject.Factory
     interface Factory : ViewFactory {
     override fun create(context: Context, attrs: AttributeSet): ProfileView
     }G
     }Z
     @Module
     abstract class ViewModule {
     @Binds
     @IntoMap
     @StringKey("com.example.ProfileView")
     abstract fun profileView(factory: ProfileView.Factory): ViewFactory
     }Q


     View Slide

134. class ProfileView @AssistedInject constructor(
     @Assisted context: Context, @Assisted attrs: AttributeSet,
     private val imageLoader: ImageLoader,
     private val avatarRenderer: AvatarRenderer
     ) : ConstraintLayout(context, attrs) {
     // …
     }Z


     View Slide

135. class ProfileView @InflationInject constructor(
     @Assisted context: Context, @Assisted attrs: AttributeSet,
     private val imageLoader: ImageLoader,
     private val avatarRenderer: AvatarRenderer
     ) : ConstraintLayout(context, attrs) {
     // …
     }Z
     @Assisted


     View Slide

136. class ProfileView @InflationInject constructor(
     @Assisted context: Context, @Assisted attrs: AttributeSet,
     private val imageLoader: ImageLoader,
     private val avatarRenderer: AvatarRenderer
     ) : ConstraintLayout(context, attrs) {
     // …
     }Z


     View Slide

137. @Generated
     class InflationInject_ProfileView implements ViewFactory {
     private final Provider imageLoader;
     private final Provider avatarRenderer;
     @Inject InflationInject_ProfileView(
     Provider imageLoader,
     Provider avatarRenderer) {
     this.imageLoader = imageLoader;
     this.avatarRenderer = avatarRenderer;
     }
     @Override public View create(Context context, AttributeSet attrs) {
     return new ProfileView(
     context, attrs, imageLoader.get(), avatarRenderer.get());
     }
     }


     View Slide

138. @Generated
     class InflationInject_ProfileView implements ViewFactory {
     private final Provider imageLoader;
     private final Provider avatarRenderer;
     @Inject InflationInject_ProfileView(
     Provider imageLoader,
     Provider avatarRenderer) {
     this.imageLoader = imageLoader;
     this.avatarRenderer = avatarRenderer;
     }
     @Override public View create(Context context, AttributeSet attrs) {
     return new ProfileView(
     context, attrs, imageLoader.get(), avatarRenderer.get());
     }
     }


     View Slide

139. @Generated
     class InflationInject_ProfileView implements ViewFactory {
     private final Provider imageLoader;
     private final Provider avatarRenderer;
     @Inject InflationInject_ProfileView(
     Provider imageLoader,
     Provider avatarRenderer) {
     this.imageLoader = imageLoader;
     this.avatarRenderer = avatarRenderer;
     }
     @Override public View create(Context context, AttributeSet attrs) {
     return new ProfileView(
     context, attrs, imageLoader.get(), avatarRenderer.get());
     }
     }


     View Slide

140. @Module
     object ViewModule {
     }H


     View Slide

141. @InflationModule
     @Module
     object ViewModule {
     }H


     View Slide

142. @InflationModule
     @Module
     object ViewModule {
     }H
     @Module
     @Generated
     abstract class InflationModule_ViewModule {
     @Binds
     @IntoMap
     @StringKey("com.example.ProfileView")
     abstract ViewFactory bindProfileView(
     InflationInject_ProfileView factory)
     }S


     View Slide

143. @InflationModule
     @Module(includes = [InflationModule_ViewModule::class])
     object ViewModule {
     }H
     @Module
     @Generated
     abstract class InflationModule_ViewModule {
     @Binds
     @IntoMap
     @StringKey("com.example.ProfileView")
     abstract ViewFactory bindProfileView(
     InflationInject_ProfileView factory)
     }S


     View Slide

144. @InflationModule
     @Module(includes = [InflationModule_ViewModule::class])
     object ViewModule {
     }H
     @Module
     @Generated
     abstract class InflationModule_ViewModule {
     @Binds
     @IntoMap
     @StringKey("com.example.ProfileView")
     abstract ViewFactory bindProfileView(
     InflationInject_ProfileView factory)
     // …
     }S


     View Slide

145. class MyAppFactory @Inject constructor(
     private val viewFactories: Map
     ) : LayoutInflater.Factory {
     override fun onCreateView(name: String,
     context: Context, attrs: AttributeSet): View? {
     return viewFactories[name]?.create(context, attrs)
     }O
     }P


     View Slide

146. class InflationInjectFactory @Inject constructor(
     private val viewFactories: Map
     ) : LayoutInflater.Factory {
     override fun onCreateView(name: String,
     context: Context, attrs: AttributeSet): View? {
     return viewFactories[name]?.create(context, attrs)
     }O
     }P


     View Slide

147. class ProfileActivity : Activity() {
     }A


     View Slide

148. class ProfileActivity : Activity() {
     override fun onCreate(savedInstanceState: Bundle?) {
     super.onCreate(savedInstanceState)
     AndroidInjection.inject(this)
     }B
     }A


     View Slide

149. class ProfileActivity : Activity() {
     @Inject lateinit var presenterFactory: ProfilePresenter.Factory
     @Inject lateinit var inflationFactory: InflationInjectFactory
     override fun onCreate(savedInstanceState: Bundle?) {
     super.onCreate(savedInstanceState)
     AndroidInjection.inject(this)
     }B
     }A


     View Slide

150. class ProfileActivity : Activity() {
     @Inject lateinit var presenterFactory: ProfilePresenter.Factory
     @Inject lateinit var inflationFactory: InflationInjectFactory
     override fun onCreate(savedInstanceState: Bundle?) {
     super.onCreate(savedInstanceState)
     AndroidInjection.inject(this)
     layoutInflater.factory = inflationFactory
     }B
     }A


     View Slide

151. class ProfileActivity : Activity() {
     @Inject lateinit var presenterFactory: ProfilePresenter.Factory
     @Inject lateinit var inflationFactory: InflationInjectFactory
     override fun onCreate(savedInstanceState: Bundle?) {
     super.onCreate(savedInstanceState)
     AndroidInjection.inject(this)
     layoutInflater.factory = inflationFactory
     setContentView(R.layout.profile_view)
     }B
     }A


     View Slide

152. class ProfileActivity : Activity() {
     @Inject lateinit var presenterFactory: ProfilePresenter.Factory
     @Inject lateinit var inflationFactory: InflationInjectFactory
     override fun onCreate(savedInstanceState: Bundle?) {
     super.onCreate(savedInstanceState)
     AndroidInjection.inject(this)
     layoutInflater.factory = inflationFactory
     setContentView(R.layout.profile_view)
     val userId = intent.getStringExtra("userId")
     val presenter = presenterFactory.create(userId)
     presenter.attachView(findViewById(R.id.profile_view)
     }B
     }A


     View Slide

153. class ProfileActivity : Activity() {
     @Inject lateinit var presenterFactory: ProfilePresenter.Factory
     @Inject lateinit var inflationFactory: InflationInjectFactory
     override fun onCreate(savedInstanceState: Bundle?) {
     super.onCreate(savedInstanceState)
     AndroidInjection.inject(this)
     layoutInflater.factory = inflationFactory
     setContentView(R.layout.profile_view)
     val userId = intent.getStringExtra("userId")
     val presenter = presenterFactory.create(userId)
     presenter.attachView(findViewById(R.id.profile_view)
     }B
     }A
     l
     l


     View Slide

154. class ProfileActivity @Inject constructor(
     val presenterFactory: ProfilePresenter.Factory
     val inflationFactory: InflationInjectFactory
     : Activity() {
     override fun onCreate(savedInstanceState: Bundle?) {
     super.onCreate(savedInstanceState)
     AndroidInjection.inject(this)
     layoutInflater.factory = inflationFactory
     setContentView(R.layout.profile_view)
     val userId = intent.getStringExtra("userId")
     val presenter = presenterFactory.create(userId)
     presenter.attachView(findViewById(R.id.profile_view)
     }B
     }A
     @
     I
     n
     j
     e
     c
     t l
     a
     t
     e
     i
     n
     i
     t r
     @
     I
     n
     j
     e
     c
     t l
     a
     t
     e
     i
     n
     i
     t r


     View Slide

155. View Slide

156. View Slide

157. View Slide

158. dependencies {
     compileOnly 'com.squareup.inject:inflation-inject:0.3.0'
     kapt 'com.squareup.inject:inflation-inject-processor:0.3.0'
     }A


     View Slide

159. dependencies {
     compileOnly 'com.squareup.inject:inflation-inject:0.3.0'
     kapt 'com.squareup.inject:inflation-inject-processor:0.3.0'
     // or 'annotationProcessor'…
     }A


     View Slide

160. View Slide

161. View Slide

162. View Slide

163. View Slide

164. View Slide

165. View Slide

166. allprojects {
     }A


     View Slide

167. allprojects {
     tasks.withType(JavaCompile).all {
     }B
     }A


     View Slide

168. allprojects {
     tasks.withType(JavaCompile).all {
     options.compilerArgs += []C
     }B
     }A


     View Slide

169. allprojects {
     tasks.withType(JavaCompile).all {
     options.compilerArgs += [
     '-Adagger.formatGeneratedSource=disabled'
     ]C
     }B
     }A


     View Slide

170. allprojects {
     tasks.withType(JavaCompile).all {
     options.compilerArgs += [
     '-Adagger.formatGeneratedSource=disabled'
     ]C
     }B
     afterEvaluate {
     extensions.findByName('kapt')?.arguments {
     arg("dagger.formatGeneratedSource", "disabled")
     }D
     }C
     }A


     View Slide

171. View Slide

172. allprojects {
     tasks.withType(JavaCompile).all {
     options.compilerArgs += [
     '-Adagger.formatGeneratedSource=disabled'
     ]C
     }B
     afterEvaluate {
     extensions.findByName('kapt')?.arguments {
     arg("dagger.formatGeneratedSource", "disabled")
     }D
     }C
     }A


     View Slide

173. allprojects {
     tasks.withType(JavaCompile).all {
     options.compilerArgs += [
     '-Adagger.formatGeneratedSource=disabled',
     '-Adagger.gradle.incremental=enabled'
     ]C
     }B
     afterEvaluate {
     extensions.findByName('kapt')?.arguments {
     arg("dagger.formatGeneratedSource", "disabled")
     arg("dagger.gradle.incremental", "enabled")
     }D
     }C
     }A


     View Slide

174. View Slide

175. View Slide

176. View Slide

177. View Slide

178. View Slide

179. View Slide

180. View Slide

181. View Slide

182. View Slide

183. ButterKnife.bind(this)


     View Slide

184. ButterKnife.bind(this)
     class ButterKnife {
     static Unbinder bind(Activity target) {
     // Class.forName lookup…
     }
     }
     butterknife-runtime.aar


     View Slide

185. ButterKnife.bind(this)
     class ButterKnife {
     static Unbinder bind(Activity target) {
     // Reflection implementation…
     }
     }
     butterknife-reflect.aar
     class ButterKnife {
     static Unbinder bind(Activity target) {
     // Class.forName lookup…
     }
     }
     butterknife-runtime.aar


     View Slide

186. dependencies {
     if (properties.containsKey('android.injected.invoked.from.ide')) {
     implementation 'com.jakewharton:butterknife-reflect:9.0.0-rc1'
     } else {
     implementation 'com.jakewharton:butterknife:9.0.0-rc1'
     kapt 'com.jakewharton:butterknife-compiler:9.0.0-rc1'
     }B
     }A


     View Slide

187. dependencies {
     if (properties.containsKey('android.injected.invoked.from.ide')) {
     implementation 'com.jakewharton:butterknife-reflect:9.0.0-rc1'
     } else {
     implementation 'com.jakewharton:butterknife:9.0.0-rc1'
     kapt 'com.jakewharton:butterknife-compiler:9.0.0-rc1'
     // or 'annotationProcessor'…
     }B
     }A


     View Slide

188. @Component(modules = [AppModule::class])
     interface AppComponent {
     fun foo(): Foo
     fun bar(): Bar
     fun thermosiphon(): Thermosiphon
     @Component.Builder
     interface Builder {
     @BindsInstance fun apiKey(@ApiKey apiKey: String)
     fun build(): AppComponent
     }B
     }A


     View Slide

189. @Component(modules = [AppModule::class])
     interface AppComponent {
     fun foo(): Foo
     fun bar(): Bar
     fun thermosiphon(): Thermosiphon
     @Component.Builder
     interface Builder {
     @BindsInstance fun apiKey(@ApiKey apiKey: String)
     fun build(): AppComponent
     }B
     }A
     val component = DaggerAppComponent.builder()
     .apiKey("IDt0n5RoTAc0l3CiVR3sRn13d0kdNaN1oK")
     .build()


     View Slide

190. @Component(modules = [AppModule::class])
     interface AppComponent {
     fun foo(): Foo
     fun bar(): Bar
     fun thermosiphon(): Thermosiphon
     @Component.Builder
     interface Builder {
     @BindsInstance fun apiKey(@ApiKey apiKey: String)
     fun build(): AppComponent
     }B
     }A
     val component = DaggerAppComponent.builder()
     .apiKey("IDt0n5RoTAc0l3CiVR3sRn13d0kdNaN1oK")
     .build()


     View Slide

191. class DaggerReflect {
     }A


     View Slide

192. class DaggerReflect {
     static B builder(Class builderClass) {
     }B
     }A


     View Slide

193. class DaggerReflect {C
     static B builder(Class builderClass) {
     return (B) Proxy.newProxyInstance(
     builderClass.getClassLoader(),
     new Class[] { builderClass },
     ComponentBuilderInvocationHandler.create(builderClass));
     }B
     }A


     View Slide

194. class DaggerReflect {C
     static B builder(Class builderClass) {
     return (B) Proxy.newProxyInstance(
     builderClass.getClassLoader(),
     new Class[] { builderClass },
     ComponentBuilderInvocationHandler.create(builderClass));
     }B
     }A


     View Slide

195. class DaggerReflect {C
     static B builder(Class builderClass) {
     return (B) Proxy.newProxyInstance(
     builderClass.getClassLoader(),
     new Class[] { builderClass },
     ComponentBuilderInvocationHandler.create(builderClass));
     }B
     }A


     View Slide

196. class DaggerReflect {
     static C create(Class componentClass) {
     return (C) Proxy.newProxyInstance(
     componentClass.getClassLoader(),
     new Class[] { componentClass },
     ComponentInvocationHandler.create(componentClass));
     }C
     static B builder(Class builderClass) {
     return (B) Proxy.newProxyInstance(
     builderClass.getClassLoader(),
     new Class[] { builderClass },
     ComponentBuilderInvocationHandler.create(builderClass));
     }B
     }A


     View Slide

197. @Component(modules = [AppModule::class])
     interface AppComponent {
     fun foo(): Foo
     fun bar(): Bar
     fun thermosiphon(): Thermosiphon
     @Component.Builder
     interface Builder {
     @BindsInstance fun apiKey(@ApiKey apiKey: String)
     fun build(): AppComponent
     }B
     }A
     val component = DaggerAppComponent.builder()
     .apiKey("IDt0n5RoTAc0l3CiVR3sRn13d0kdNaN1oK")
     .build()


     View Slide

198. @Component(modules = [AppModule::class])
     interface AppComponent {
     fun foo(): Foo
     fun bar(): Bar
     fun thermosiphon(): Thermosiphon
     @Component.Builder
     interface Builder {
     @BindsInstance fun apiKey(@ApiKey apiKey: String)
     fun build(): AppComponent
     }B
     }A
     val component = DaggerAppComponent.builder()
     .apiKey("IDt0n5RoTAc0l3CiVR3sRn13d0kdNaN1oK")
     .build()


     View Slide

199. final class DaggerAppComponent {
     }A


     View Slide

200. final class DaggerAppComponent {
     static AppComponent.Builder builder() {
     return DaggerReflect.builder(AppComponent.Builder.class);
     }B
     }A


     View Slide

201. final class DaggerAppComponent {
     static AppComponent create() {
     return DaggerReflect.create(AppComponent.class);
     }C
     static AppComponent.Builder builder() {
     return DaggerReflect.builder(AppComponent.Builder.class);
     }B
     }A


     View Slide

202. DaggerAppComponent.builder()


     View Slide

203. DaggerAppComponent.builder()
     final class DaggerAppComponent {
     static AppComponent.Builder builder() {
     // real Dagger implementation…
     }B
     }A
     dagger-compiler.jar + dagger.jar


     View Slide

204. DaggerAppComponent.builder()
     final class DaggerAppComponent {
     static AppComponent.Builder builder() {
     return DaggerReflect.builder(
     AppComponent.Builder.class);
     }B
     }A
     dagger-reflect.jar
     final class DaggerAppComponent {
     static AppComponent.Builder builder() {
     // real Dagger implementation…
     }B
     }A
     dagger-compiler.jar + dagger.jar


     View Slide

205. dagger-compiler.jar
     dagger.jar
     dagger-reflect.jar


     View Slide

206. @Component(modules = [AppModule::class])
     interface AppComponent {
     fun foo(): Foo
     fun bar(): Bar
     fun thermosiphon(): Thermosiphon
     @Component.Builder
     interface Builder {
     @BindsInstance fun apiKey(@ApiKey apiKey: String)
     fun build(): AppComponent
     }B
     }A
     val component = DaggerAppComponent.builder()
     .apiKey("IDt0n5RoTAc0l3CiVR3sRn13d0kdNaN1oK")
     .build()


     View Slide

207. @Component(modules = [AppModule::class])
     interface AppComponent {
     fun foo(): Foo
     fun bar(): Bar
     fun thermosiphon(): Thermosiphon
     @Component.Builder
     interface Builder {
     @BindsInstance fun apiKey(@ApiKey apiKey: String)
     fun build(): AppComponent
     }B
     }A
     val component = DaggerReflect.builder(AppComponent.Builder::class)
     .apiKey("IDt0n5RoTAc0l3CiVR3sRn13d0kdNaN1oK")
     .build()


     View Slide

208. class Dagger {
     }A


     View Slide

209. class Dagger {
     static B builder(Class builderClass) {
     }B
     }A


     View Slide

210. class Dagger {
     static B builder(Class builderClass) {
     return DaggerReflect.builder(builderClass);
     }B
     }A


     View Slide

211. class Dagger {
     static B builder(Class builderClass) {
     return DaggerReflect.builder(builderClass);
     }B
     }A
     class Dagger {
     }A


     View Slide

212. class Dagger {
     static B builder(Class builderClass) {
     return DaggerReflect.builder(builderClass);
     }B
     }A
     class Dagger {
     static B builder(Class builderClass) {
     }B
     }A


     View Slide

213. class Dagger {
     static B builder(Class builderClass) {
     return DaggerReflect.builder(builderClass);
     }B
     }A
     class Dagger {
     static B builder(Class builderClass) {
     return builderClass.getMethod("builder").invoke(null);
     }B
     }A


     View Slide

214. class Dagger {
     static B builder(Class builderClass) {
     return DaggerReflect.builder(builderClass);
     }B
     }A
     class Dagger {
     static B builder(Class builderClass) {
     return builderClass.getMethod("builder").invoke(null);
     }B
     }A
     dagger-reflect.jar
     dagger-codegen.jar


     View Slide

215. @Component(modules = [AppModule::class])
     interface AppComponent {
     fun foo(): Foo
     fun bar(): Bar
     fun thermosiphon(): Thermosiphon
     @Component.Builder
     interface Builder {
     @BindsInstance fun apiKey(@ApiKey apiKey: String)
     fun build(): AppComponent
     }B
     }A
     val component = DaggerReflect.builder(AppComponent.Builder::class)
     .apiKey("IDt0n5RoTAc0l3CiVR3sRn13d0kdNaN1oK")
     .build()


     View Slide

216. @Component(modules = [AppModule::class])
     interface AppComponent {
     fun foo(): Foo
     fun bar(): Bar
     fun thermosiphon(): Thermosiphon
     @Component.Builder
     interface Builder {
     @BindsInstance fun apiKey(@ApiKey apiKey: String)
     fun build(): AppComponent
     }B
     }A
     val component = Dagger.builder(AppComponent.Builder::class)
     .apiKey("IDt0n5RoTAc0l3CiVR3sRn13d0kdNaN1oK")
     .build()


     View Slide

217. @Component(modules = [AppModule::class])
     interface AppComponent {
     fun foo(): Foo
     fun bar(): Bar
     fun thermosiphon(): Thermosiphon
     @Component.Builder
     interface Builder {
     @BindsInstance fun apiKey(@ApiKey apiKey: String)
     fun build(): AppComponent
     }B
     }A
     val component = Dagger.builder(AppComponent.Builder::class)
     .apiKey("IDt0n5RoTAc0l3CiVR3sRn13d0kdNaN1oK")
     .build()


     View Slide

218. val component = Dagger.builder(AppComponent.Builder::class)G
     .apiKey("IDt0n5RoTAc0l3CiVR3sRn13d0kdNaN1oK")
     .build()


     View Slide

219. val component = AppComponent.Builder::class.builder()G
     .apiKey("IDt0n5RoTAc0l3CiVR3sRn13d0kdNaN1oK")
     .build()


     View Slide

220. val component = AppComponent.Builder::class.builder()G
     .apiKey("IDt0n5RoTAc0l3CiVR3sRn13d0kdNaN1oK")
     .build()
     // dagger-reflect:
     inline fun KClass.builder(): B = DaggerReflect.builder(java)


     View Slide

221. val component = AppComponent.Builder::class.builder()G
     .apiKey("IDt0n5RoTAc0l3CiVR3sRn13d0kdNaN1oK")
     .build()
     // dagger-reflect:
     inline fun KClass.builder(): B = DaggerReflect.builder(java)
     // dagger-codegen:
     inline fun KClass.builder(): B =
     throw UnsupportedOperationException("…")


     View Slide

222. val component = AppComponent.Builder::class.builder()G
     .apiKey("IDt0n5RoTAc0l3CiVR3sRn13d0kdNaN1oK")
     .build()
     // dagger-reflect:
     inline fun KClass.builder(): B = DaggerReflect.builder(java)
     // dagger-codegen:
     inline fun KClass.builder(): B =
     throw UnsupportedOperationException("…")
     // Generated from dagger-codegen-compiler:
     @JvmName("builderAppComponent")
     inline fun KClass.builder() = AppComponent.builder()


     View Slide

223. val component = AppComponent.Builder::class.builder()G
     .apiKey("IDt0n5RoTAc0l3CiVR3sRn13d0kdNaN1oK")
     .build()
     // dagger-reflect:
     inline fun KClass.builder(): B = DaggerReflect.builder(java)
     // dagger-codegen:
     inline fun KClass.builder(): B =
     throw UnsupportedOperationException("…")
     // Generated from dagger-codegen-compiler:
     @JvmName("builderAppComponent")
     inline fun KClass.builder() = AppComponent.builder()


     View Slide

224. AppComponent.Builder::class.builder()G
     val component =
     .apiKey("IDt0n5RoTAc0l3CiVR3sRn13d0kdNaN1oK")
     .build()
     // dagger-reflect:
     inline fun KClass.builder(): B = DaggerReflect.builder(java)
     // dagger-codegen:
     inline fun KClass.builder(): B =
     throw UnsupportedOperationException("…")
     // Generated from dagger-codegen-compiler:
     @JvmName("builderAppComponent")
     inline fun KClass.builder() = AppComponent.builder()
     AppComponent.builder()


     View Slide

225. View Slide

226. View Slide

227. Helping
     Dagger
     Help
     You
     @JakeWharton


     View Slide
