Playing in the Treehouse with Redwood and Zipline (KotlinConf 2023)

Redwood is Cash App's multiplatform Compose library which targets the native UI toolkit of each platform while still sharing presentation logic. This means our app's existing Android views and iOS UIViews can be powered by common Compose and still offer a path to Compose UI and Swift UI.

Zipline is a multiplatform Javascript engine for Android, iOS, and the JVM which uses Kotlin interfaces for calls in and out of JS. This allows us to update the logic of our apps faster than going through the app store release process.

Treehouse is what we call the combination of Redwood and Zipline. By moving the Compose presentation logic into Zipline we can update the screens of our apps across Android, iOS, and web without waiting for the app store.

This talk will cover how Redwood and Zipline can work in isolation but how the combination as Treehouse is their most powerful form.

Video: https://jakewharton.com/playing-in-the-treehouse-with-redwood-and-zipline/

Transcript

1. @jw@jakewharton.com
   Playing in the Treehouse
   with Redwood and Zipline


   View Slide

2. Redwood Zipline


   View Slide

3. Redwood Zipline
   Treehouse


   View Slide

4. Figma Android Eng
   iOS Eng
   Web Eng
   Redwood


   View Slide

5. Figma Android Eng
   iOS Eng
   Web Eng
   View Impl
   UIKit Impl
   DOM Impl
   Redwood


   View Slide

6. Figma Android Eng
   iOS Eng
   Web Eng
   View Impl
   UIKit Impl
   DOM Impl
   Redwood
   Redwood


   View Slide

7. Figma Android Eng
   iOS Eng
   Web Eng
   View Impl
   UIKit Impl
   DOM Impl
   Redwood
   Redwood


   View Slide

8. Schema Widgets
   Redwood


   View Slide

9. Schema
   Widgets
   Compose
   Redwood


   View Slide

10. Redwood Schema
    data class Column(
    val children: () -> Unit,
    )
    data class TextInput(
    val hint: String,
    val text: String,
    val onTextChanged: (String) -> Unit,
    )


    View Slide

11. Redwood Schema
    data class Column(
    val children: () -> Unit,
    val birthday: LocalDate,
    )
    data class TextInput(
    val hint: String,
    val text: String,
    val onTextChanged: (String) -> Unit,
    )


    View Slide

12. Redwood Schema
    import kotlinx.datetime.LocalDate
    data class Column(
    val children: () -> Unit,
    val birthday: LocalDate,
    )
    data class TextInput(
    val hint: String,
    val text: String,
    val onTextChanged: (String) -> Unit,
    )


    View Slide

13. Redwood Schema
    data class Column(
    val children: () -> Unit,
    )
    data class TextInput(
    val hint: String,
    val text: String,
    val onTextChanged: (String) -> Unit,
    )


    View Slide

14. Redwood Schema
    data class Column(
    val children: () -> Unit,
    )
    data class TextInput(
    val hint: String,
    val text: String,
    val onTextChanged: (String) -> Unit,
    )


    View Slide

15. Redwood Schema
    data class Column(
    val children: () -> Unit,
    )
    data class TextInput(
    val hint: String,
    val text: String,
    val onTextChanged: (String) -> Unit,
    )


    View Slide

16. Redwood Schema
    data class Column(
    val children: () -> Unit,
    )
    data class TextInput(
    val hint: String,
    val text: String,
    val onTextChanged: (String) -> Unit,
    )


    View Slide

17. Redwood Schema
    data class Column(
    val children: () -> Unit,
    )
    data class TextInput(
    val hint: String,
    val text: String,
    val onTextChanged: (String) -> Unit,
    )


    View Slide

18. Redwood Schema


    View Slide

19. Redwood Schema
    data class Row(…)
    data class Column(…)
    data class Image(
    val url: HttpUrl,
    val size: ImageSize,
    val borderStyle: BorderStyle,
    )
    data class Text(
    val text: String,
    val font: FontFamily,
    val style: FontStyle,
    )


    View Slide

20. Redwood Schema
    data class ContactItem(
    val name: String,
    val image: HttpUrl,
    val content: () -> Unit,
    )
    data class Text(
    val text: String,
    val font: FontFamily,
    val style: FontStyle,
    )


    View Slide

21. Redwood Schema
    data class Row(…)
    data class Column(…)
    data class Image(
    val url: HttpUrl,
    val size: ImageSize,
    val borderStyle: BorderStyle,
    )
    data class Text(
    val text: String,
    val font: FontFamily,
    val style: FontStyle,
    )
    data class ContactItem(
    val name: String,
    val image: HttpUrl,
    val content: () -> Unit,
    )
    data class Text(
    val text: String,
    val font: FontFamily,
    val style: FontStyle,
    )


    View Slide

22. Redwood Compose
    data class Column(
    val children: () -> Unit,
    )
    data class TextInput(
    val hint: String,
    val text: String,
    val onTextChanged: (String) -> Unit,
    )


    View Slide

23. Redwood Compose
    data class Column(
    val children: () -> Unit,
    )
    data class TextInput(
    val hint: String,
    val text: String,
    val onTextChanged: (String) -> Unit,
    )
    @Composable fun Column(
    children: @Composable () -> Unit,
    ) { … }
    @Composable fun TextInput(
    hint: String,
    text: String,
    onTextChanged: (String) -> Unit,
    ) { … }


    View Slide

24. Redwood Compose
    @Composable fun Column(
    children: @Composable () -> Unit,
    ) { … }
    @Composable fun TextInput(
    hint: String,
    text: String,
    onTextChanged: (String) -> Unit,
    ) { … }


    View Slide

25. Redwood Compose
    Column {
    var query by remember { mutableStateOf("") }
    TextInput(
    hint = "Search",
    text = query,
    onTextChanged = { query = it },
    )
    val images = LoadImages(query)
    ScrollableColumn {
    for (image in images) {
    Image(url = image.url)
    }
    }
    }


    View Slide

26. Redwood Widgets
    data class Column(
    val children: () -> Unit,
    )
    data class TextInput(
    val hint: String,
    val text: String,
    val onTextChanged: (String) -> Unit,
    )


    View Slide

27. Redwood Widgets
    data class Column(
    val children: () -> Unit,
    )
    data class TextInput(
    val hint: String,
    val text: String,
    val onTextChanged: (String) -> Unit,
    )
    interface Column : Widget {
    val children: Widget.Children
    }
    interface TextInput : Widget {
    fun hint(hint: String)
    fun text(text: String)
    fun onTextChanged(onTextChanged: ((String) -> Unit)?)
    }


    View Slide

28. Redwood Widgets
    interface Column : Widget {
    val children: Widget.Children
    }
    interface TextInput : Widget {
    fun hint(hint: String)
    fun text(text: String)
    fun onTextChanged(onTextChanged: ((String) -> Unit)?)
    }


    View Slide

29. Redwood Widgets
    interface Widget {
    val value: T
    }
    interface Column : Widget {
    val children: Widget.Children
    }
    interface TextInput : Widget {
    fun hint(hint: String)
    fun text(text: String)
    fun onTextChanged(onTextChanged: ((String) -> Unit)?)
    }


    View Slide

30. Redwood Widgets
    interface Column : Widget {
    val children: Widget.Children
    }


    View Slide

31. Redwood Widgets
    class ViewColumn : Column
    interface Column : Widget {
    val children: Widget.Children
    }


    View Slide

32. Redwood Widgets
    class ViewColumn(
    override val value: LinearLayout,
    ) : Column
    interface Column : Widget {
    val children: Widget.Children
    }


    View Slide

33. Redwood Widgets
    class ViewColumn(
    override val value: LinearLayout,
    ) : Column {
    override val children = ViewGroupChildren(value)
    }
    interface Column : Widget {
    val children: Widget.Children
    }


    View Slide

34. Redwood Widgets
    interface EmojiWidgetFactory : Widget.Factory {
    fun Column(): Column
    fun ScrollableColumn(): ScrollableColumn
    fun TextInput(): TextInput
    fun Image(): Image
    }


    View Slide

35. Redwood Widgets
    interface EmojiWidgetFactory : Widget.Factory {
    fun Column(): Column
    …
    }


    View Slide

36. Redwood Widgets
    class EmojiViewWidgetFactory : EmojiWidgetFactory
    interface EmojiWidgetFactory : Widget.Factory {
    fun Column(): Column
    …
    }


    View Slide

37. Redwood Widgets
    class EmojiViewWidgetFactory(
    private val context: Context,
    ) : EmojiWidgetFactory
    interface EmojiWidgetFactory : Widget.Factory {
    fun Column(): Column
    …
    }


    View Slide

38. Redwood Widgets
    class EmojiViewWidgetFactory(
    private val context: Context,
    ) : EmojiWidgetFactory {
    override fun Column(): Column {
    }
    }
    interface EmojiWidgetFactory : Widget.Factory {
    fun Column(): Column
    …
    }


    View Slide

39. Redwood Widgets
    class EmojiViewWidgetFactory(
    private val context: Context,
    ) : EmojiWidgetFactory {
    override fun Column(): Column {
    return ViewColumn(LinearLayout(context))
    }
    }
    interface EmojiWidgetFactory : Widget.Factory {
    fun Column(): Column
    …
    }


    View Slide

40. Redwood Widgets
    class EmojiViewWidgetFactory(
    private val context: Context,
    ) : EmojiWidgetFactory {
    override fun Column(): Column {
    return ViewColumn(LinearLayout(context))
    }
    …
    }
    interface EmojiWidgetFactory : Widget.Factory {
    fun Column(): Column
    …
    }


    View Slide

41. @Composable
    fun MessageCard(msg: Message) {
    Row(modifier = Modifier.padding(all = 8.dp)) {
    Image(
    painter = painterResource(R.drawable.profile_picture),
    contentDescription = null,
    modifier = Modifier
    .size(40.dp)
    .clip(CircleShape)
    .border(1.5.dp, MaterialTheme.colors.secondary, CircleShape),
    )
    Spacer(modifier = Modifier.width(8.dp))
    Column {
    Text(
    text = msg.author,
    color = MaterialTheme.colors.secondaryVariant,
    style = MaterialTheme.typography.subtitle2,
    )
    Spacer(modifier = Modifier.height(4.dp))
    Surface(shape = MaterialTheme.shapes.medium, elevation = 1.dp) {
    Text(
    text = msg.body,
    modifier = Modifier.padding(all = 4.dp),
    style = MaterialTheme.typography.body2,
    )
    }
    }
    }
    }


    View Slide

42. @Composable
    fun MessageCard(…) {
    Row(…) {
    Image(…)
    Spacer(…)
    Column {
    Text(…)
    Spacer(…)
    Surface(…) {
    Text(…)
    }
    }
    }
    }


    View Slide

43. @Composable
    fun MessageCard(…) {
    Row(…) {
    Image(…)
    Spacer(…)
    Column {
    Text(…)
    Spacer(…)
    Surface(…) {
    Text(…)
    }
    }
    }
    }
    Root


    View Slide

44. @Composable
    fun MessageCard(…) {
    Row(…) {
    Image(…)
    Spacer(…)
    Column {
    Text(…)
    Spacer(…)
    Surface(…) {
    Text(…)
    }
    }
    }
    }
    Root


    View Slide

45. @Composable
    fun MessageCard(…) {
    Row(…) {
    Image(…)
    Spacer(…)
    Column {
    Text(…)
    Spacer(…)
    Surface(…) {
    Text(…)
    }
    }
    }
    }
    Root
    Row


    View Slide

46. @Composable
    fun MessageCard(…) {
    Row(…) {
    Image(…)
    Spacer(…)
    Column {
    Text(…)
    Spacer(…)
    Surface(…) {
    Text(…)
    }
    }
    }
    }
    Root
    Row


    View Slide

47. @Composable
    fun MessageCard(…) {
    Row(…) {
    Image(…)
    Spacer(…)
    Column {
    Text(…)
    Spacer(…)
    Surface(…) {
    Text(…)
    }
    }
    }
    }
    Root
    Row


    View Slide

48. @Composable
    fun MessageCard(…) {
    Row(…) {
    Image(…)
    Spacer(…)
    Column {
    Text(…)
    Spacer(…)
    Surface(…) {
    Text(…)
    }
    }
    }
    }
    Root
    Row
    Spacer


    View Slide

49. Spacer
    Image Column
    @Composable
    fun MessageCard(…) {
    Row(…) {
    Image(…)
    Spacer(…)
    Column {
    Text(…)
    Spacer(…)
    Surface(…) {
    Text(…)
    }
    }
    }
    }
    Root
    Row


    View Slide

50. Spacer
    Image Column
    @Composable
    fun MessageCard(…) {
    Row(…) {
    Image(…)
    Spacer(…)
    Column {
    Text(…)
    Spacer(…)
    Surface(…) {
    Text(…)
    }
    }
    }
    }
    Root
    Row


    View Slide

51. Spacer
    Image Column
    @Composable
    fun MessageCard(…) {
    Row(…) {
    Image(…)
    Spacer(…)
    Column {
    Text(…)
    Spacer(…)
    Surface(…) {
    Text(…)
    }
    }
    }
    }
    Root
    Row
    Text


    View Slide

52. Spacer
    Image Column
    @Composable
    fun MessageCard(…) {
    Row(…) {
    Image(…)
    Spacer(…)
    Column {
    Text(…)
    Spacer(…)
    Surface(…) {
    Text(…)
    }
    }
    }
    }
    Root
    Row
    Text Spacer


    View Slide

53. Text Spacer Surface
    Spacer
    Image Column
    @Composable
    fun MessageCard(…) {
    Row(…) {
    Image(…)
    Spacer(…)
    Column {
    Text(…)
    Spacer(…)
    Surface(…) {
    Text(…)
    }
    }
    }
    }
    Root
    Row


    View Slide

54. Text Spacer Surface
    Spacer
    Image Column
    @Composable
    fun MessageCard(…) {
    Row(…) {
    Image(…)
    Spacer(…)
    Column {
    Text(…)
    Spacer(…)
    Surface(…) {
    Text(…)
    }
    }
    }
    }
    Root
    Row


    View Slide

55. Text Spacer Surface
    Spacer
    Image Column
    @Composable
    fun MessageCard(…) {
    Row(…) {
    Image(…)
    Spacer(…)
    Column {
    Text(…)
    Spacer(…)
    Surface(…) {
    Text(…)
    }
    }
    }
    }
    Root
    Row
    Text


    View Slide

56. @Composable
    fun MessageCard(…) {
    Row(…) {
    Image(…)
    Spacer(…)
    Column {
    Text(…)
    Spacer(…)
    Surface(…) {
    Text(…)
    }
    }
    }
    }
    Root
    Row
    Spacer
    Image Column
    Text Spacer Surface
    Text


    View Slide

57. Root


    View Slide

58. Root FrameLayout


    View Slide

59. Root
    Row
    Spacer
    Image Column
    Text Spacer Surface
    Text
    FrameLayout
    LinearLayout
    View
    ImageView LinearLayout
    TextView View FrameLayout
    TextView


    View Slide

60. Root
    Row
    Spacer
    Image Column
    Text Spacer Surface
    Text
    UIStackView
    UIStackView
    UIView
    UIImageView UIStackView
    UITextView UIView UIView
    UITextView


    View Slide

61. Root
    Row
    Spacer
    Image Column
    Text Spacer Surface
    Text








    View Slide

62. Redwood Compose & Widgets
    @Composable fun TextInput(
    hint: String,
    text: String,
    onTextChanged: (String) -> Unit,
    ) { … }


    View Slide

63. Redwood Compose & Widgets
    @Composable fun TextInput(
    hint: String,
    text: String,
    onTextChanged: (String) -> Unit,
    ) {

    ComposeNode<…>(
    factory = …,
    update = { … },
    )
    }


    View Slide

64. Redwood Compose & Widgets
    @Composable fun TextInput(
    hint: String,
    text: String,
    onTextChanged: (String) -> Unit,
    ) {

    RedwoodComposeNode<…>(
    factory = …,
    update = { … },
    )
    }


    View Slide

65. Redwood Compose & Widgets
    @Composable fun TextInput(
    hint: String,
    text: String,
    onTextChanged: (String) -> Unit,
    ) {

    RedwoodComposeNode, …>(
    factory = …,
    update = { … },
    )
    }


    View Slide

66. Redwood Compose & Widgets
    @Composable fun TextInput(
    hint: String,
    text: String,
    onTextChanged: (String) -> Unit,
    ) {

    RedwoodComposeNode, TextInput<*>>(
    factory = …,
    update = { … },
    )
    }


    View Slide

67. Redwood Compose & Widgets
    @Composable fun TextInput(
    hint: String,
    text: String,
    onTextChanged: (String) -> Unit,
    ) {

    RedwoodComposeNode, TextInput<*>>(
    factory = EmojiWidgetFactory<*>::TextInput,
    update = { … },
    )
    }


    View Slide

68. Redwood Compose & Widgets
    @Composable fun TextInput(
    hint: String,
    text: String,
    onTextChanged: (String) -> Unit,
    ) {
    RedwoodComposeNode, TextInput<*>>(
    factory = EmojiWidgetFactory<*>::TextInput,
    update = {
    set(hint) { hint(hint) }
    set(text) { text(text) }
    set(onTextChanged) { onTextChanged(onTextChanged) }
    },
    )
    }


    View Slide

69. Redwood Compose & Widgets
    @Composable fun TextInput(
    hint: String,
    text: String,
    onTextChanged: (String) -> Unit,
    ) {
    RedwoodComposeNode, TextInput<*>>(
    factory = EmojiWidgetFactory<*>::TextInput,
    update = {
    set(hint) { hint(hint) }
    set(text) { text(text) }
    set(onTextChanged) { onTextChanged(onTextChanged) }
    },
    )
    }


    View Slide

70. Root
    Row
    Spacer
    Image Column
    Text Spacer Surface
    Text
    FrameLayout
    LinearLayout
    View
    ImageView LinearLayout
    TextView View FrameLayout
    TextView


    View Slide

71. Root
    Row
    Spacer
    Image Column
    Text Spacer Surface
    Text
    FrameLayout
    LinearLayout
    View
    ImageView LinearLayout
    TextView View FrameLayout
    TextView


    View Slide

72. Root
    Row
    Spacer
    Image Column
    Text Spacer Surface
    Text
    FrameLayout
    LinearLayout
    View
    ImageView LinearLayout
    TextView View FrameLayout
    TextView
    Text(msg.body, …)


    View Slide

73. Root
    Row
    Spacer
    Image Column
    Text Spacer Surface
    Text
    FrameLayout
    LinearLayout
    View
    ImageView LinearLayout
    View FrameLayout
    TextView
    TextView
    Text(msg.body, …)


    View Slide

74. Redwood Layout
    data class Row(
    val width: Constraint,
    val height: Constraint,
    val margin: Margin,
    val overflow: Overflow,
    val horizontalAlignment: MainAxisAlignment,
    val verticalAlignment: CrossAxisAlignment,
    val children: RowScope.() -> Unit,
    )
    data class Column(…)
    data class Spacer(…)


    View Slide

75. Redwood Counter Sample
    data class Text(
    val text: String?,
    )
    data class Button(
    val text: String?,
    val enabled: Boolean = true,
    val onClick: (() -> Unit)? = null,
    )


    View Slide

76. Redwood Counter Sample
    @Composable
    fun Counter(value: Int = 0) {
    var count by remember { mutableStateOf(value) }
    Column {
    Button("-1", onClick = { count-- })
    Text("Count: $count")
    Button("+1", onClick = { count++ })
    }
    }


    View Slide

77. Redwood Counter Sample
    @Composable
    fun Counter(value: Int = 0) {
    var count by remember { mutableStateOf(value) }
    Column {
    Button("-1", onClick = { count-- })
    Text("Count: $count")
    Button("+1", onClick = { count++ })
    }
    }


    View Slide

78. Redwood Counter Sample
    @Composable
    fun Counter(value: Int = 0) {
    var count by remember { mutableStateOf(value) }
    Column {
    Button("-1", onClick = { count-- })
    Text("Count: $count")
    Button("+1", onClick = { count++ })
    }
    }


    View Slide

79. Redwood Counter Sample
    @Composable
    fun Counter(value: Int = 0) {
    var count by remember { mutableStateOf(value) }
    Column {
    Button("-1", onClick = { count-- })
    Text("Count: $count")
    Button("+1", onClick = { count++ })
    }
    }


    View Slide

80. Redwood Counter Sample
    @Composable
    fun Counter(value: Int = 0) {
    var count by remember { mutableStateOf(value) }
    Column {
    Button("-1", onClick = { count-- })
    Text("Count: $count")
    Button("+1", onClick = { count++ })
    }
    }


    View Slide

81. Redwood Counter Sample
    class AndroidText(
    override val value: TextView,
    ) : Text {
    override fun text(text: String?) {
    value.text = text
    }
    }


    View Slide

82. Redwood Counter Sample
    val root = findViewById(android.R.id.content)!!
    val composition = RedwoodComposition(
    scope = mainScope,
    container = ViewGroupChildren(root),
    provider = SchemaWidgetFactories(
    Counter = AndroidCounterWidgetFactory(this),
    RedwoodLayout = ViewRedwoodLayoutWidgetFactory(this),
    ),
    )


    View Slide

83. Redwood Counter Sample
    val root = findViewById(android.R.id.content)!!
    val composition = RedwoodComposition(
    scope = mainScope,
    container = ViewGroupChildren(root),
    provider = SchemaWidgetFactories(
    Counter = AndroidCounterWidgetFactory(this),
    RedwoodLayout = ViewRedwoodLayoutWidgetFactory(this),
    ),
    )


    View Slide

84. Redwood Counter Sample
    val root = findViewById(android.R.id.content)!!
    val composition = RedwoodComposition(
    scope = mainScope,
    container = ViewGroupChildren(root),
    provider = SchemaWidgetFactories(
    Counter = AndroidCounterWidgetFactory(this),
    RedwoodLayout = ViewRedwoodLayoutWidgetFactory(this),
    ),
    )


    View Slide

85. Redwood Counter Sample
    val root = findViewById(android.R.id.content)!!
    val composition = RedwoodComposition(
    scope = mainScope,
    container = ViewGroupChildren(root),
    provider = SchemaWidgetFactories(
    Counter = AndroidCounterWidgetFactory(this),
    RedwoodLayout = ViewRedwoodLayoutWidgetFactory(this),
    ),
    )


    View Slide

86. Redwood Counter Sample
    val root = findViewById(android.R.id.content)!!
    val composition = RedwoodComposition(
    scope = mainScope,
    container = ViewGroupChildren(root),
    provider = SchemaWidgetFactories(
    Counter = AndroidCounterWidgetFactory(this),
    RedwoodLayout = ViewRedwoodLayoutWidgetFactory(this),
    ),
    )


    View Slide

87. Redwood Counter Sample
    val root = findViewById(android.R.id.content)!!
    val composition = RedwoodComposition(
    scope = mainScope,
    container = ViewGroupChildren(root),
    provider = SchemaWidgetFactories(
    Counter = AndroidCounterWidgetFactory(this),
    RedwoodLayout = ViewRedwoodLayoutWidgetFactory(this),
    ),
    )
    composition.setContent {
    Counter()
    }


    View Slide

88. Redwood Counter Sample


    View Slide

89. Redwood Counter Sample
    class ComposeUiText : Text<@Composable () -> Unit> {
    private var text by mutableStateOf("")
    override val value = @Composable {
    Text(text = text)
    }
    override fun text(text: String?) {
    this.text = text ?: ""
    }
    }


    View Slide

90. Redwood Counter Sample
    val factories = SchemaWidgetFactories(
    Counter = ComposeUiCounterWidgetFactory,
    RedwoodLayout = ComposeUiRedwoodLayoutWidgetFactory(),
    )
    setContent {
    CounterTheme {
    RedwoodContent(factories) {
    Counter()
    }
    }
    }


    View Slide

91. Redwood Counter Sample
    val factories = SchemaWidgetFactories(
    Counter = ComposeUiCounterWidgetFactory,
    RedwoodLayout = ComposeUiRedwoodLayoutWidgetFactory(),
    )
    setContent {
    CounterTheme {
    RedwoodContent(factories) {
    Counter()
    }
    }
    }


    View Slide

92. Redwood Counter Sample
    val factories = SchemaWidgetFactories(
    Counter = ComposeUiCounterWidgetFactory,
    RedwoodLayout = ComposeUiRedwoodLayoutWidgetFactory(),
    )
    setContent {
    CounterTheme {
    RedwoodContent(factories) {
    Counter()
    }
    }
    }


    View Slide

93. Redwood Counter Sample


    View Slide

94. Redwood Counter Sample
    application {
    Window(
    onCloseRequest = ::exitApplication,
    title = "Counter",
    state = rememberWindowState(300.dp, 300.dp),
    ) {
    CounterTheme {
    RedwoodContent(factories) {
    Counter()
    }
    }
    }
    }


    View Slide

95. Redwood Counter Sample


    View Slide

96. Redwood Counter Sample
    class HtmlText(
    override val value: HTMLSpanElement,
    ) : Text {
    override fun text(text: String?) {
    value.textContent = text
    }
    }


    View Slide

97. Redwood Counter Sample


    View Slide

98. Redwood Counter Sample
    class IosText : Text {
    override val value = UILabel().apply {
    textAlignment = NSTextAlignmentCenter
    }
    override fun text(text: String?) {
    value.text = text
    }
    }


    View Slide

99. Redwood Counter Sample


    View Slide

100. Redwood
     Treehouse
     Zipline


     View Slide

101. Zipline
     2016
     2019
     2022


     View Slide

102. View Slide

103. View Slide

104. View Slide

105. View Slide

106. American Red Cross
     Payment to $redcross


     View Slide

107. American Red Cross
     Payment to $redcross


     View Slide

108. American Red Cross
     Payment to $redcross
     Donation


     View Slide

109. American Red Cross
     Payment to $redcross
     Donation
     ~1 day


     View Slide

110. American Red Cross
     Payment to $redcross
     Donation
     ~1 day
     3 - 7 days


     View Slide

111. American Red Cross
     Payment to $redcross
     Donation
     ~1 day
     3 - 7 days
     4 - 10 days


     View Slide

112. View Slide

113. View Slide

114. {"id":"Lgh13IUG7f6","amount":137,"currency":"USD","sender":
     {"id":"2q3u9bUG8f6","username":"jake","display_name":"Jake
     Wharton","is_non_profit":false},"recipient":
     {"id":"h98FUH87gwe","username":"redcross","display_name":"America
     n Red Cross","is_non_profit":true},"date":"2018-10-29T15:22:21"}


     View Slide

115. {"id":"Lgh13IUG7f6","amount":137,"currency":"USD","sender":
     {"id":"2q3u9bUG8f6","username":"jake","display_name":"Jake
     Wharton","is_non_profit":false},"recipient":
     {"id":"h98FUH87gwe","username":"redcross","display_name":"America
     n Red Cross","is_non_profit":true},"date":"2018-10-29T15:22:21"}
     {"payment_line_1":"American Red Cross","payment_line_2":"Donation
     to $redcross","payment_line_3":"$1.37","payment_line_4":"Oct 29,
     2018 at 3:22PM"}


     View Slide

116. {"id":"Lgh13IUG7f6","amount":137,"currency":"USD","sender":
     {"id":"2q3u9bUG8f6","username":"jake","display_name":"Jake
     Wharton","is_non_profit":false},"recipient":
     {"id":"h98FUH87gwe","username":"redcross","display_name":"America
     n Red Cross","is_non_profit":true},"date":"2018-10-29T15:22:21"}
     {"payment_line_1":"American Red Cross","payment_line_2":"Donation
     to $redcross","payment_line_3":"$1.37","payment_line_4":"Oct 29,
     2018 at 3:22PM"}
     if (payment.recipient.is_non_profit
     && payment.sender.is_florida_man) {
     return "Donation to %s"
     }
     return "Payment to %s


     View Slide

117. View Slide

118. View Slide

119. View Slide

120. View Slide

121. class PaymentRenderer {
     fun render(payment: Payment): String {
     …
     }
     }
     PaymentRenderer {
     fun render(payment: Payment): String {
     }


     View Slide

122. class RealPaymentRenderer : PaymentRenderer {
     override fun render(payment: Payment): String {
     …
     }
     }
     interface PaymentRenderer {
     fun render(payment: Payment): String
     }


     View Slide

123. class RealPaymentRenderer : PaymentRenderer {
     override fun render(payment: Payment): String {
     …
     }
     }
     interface PaymentRenderer : ZiplineService {
     fun render(payment: Payment): String
     }


     View Slide

124. class RealPaymentRenderer : PaymentRenderer {
     override fun render(payment: Payment): String {
     …
     }
     }
     interface PaymentRenderer : ZiplineService {
     fun render(payment: Payment): String
     }


     View Slide

125. class RealPaymentRenderer : PaymentRenderer {
     override fun render(payment: Payment): String {
     …
     }
     }


     View Slide

126. class RealPaymentRenderer : PaymentRenderer {
     override fun render(payment: Payment): String {
     …
     }
     }
     zipline.bind(RealPaymentRenderer())


     View Slide

127. class RealPaymentRenderer : PaymentRenderer {
     override fun render(payment: Payment): String {
     …
     }
     }
     zipline.bind(RealPaymentRenderer())
     val renderer = zipline.take()
     println(renderer.render(Payment(…))


     View Slide

128. class RealPaymentRenderer : PaymentRenderer {
     override fun render(payment: Payment): String {
     /* Fancy new impl */
     }
     }
     zipline.bind(RealPaymentRenderer())
     val renderer = zipline.take()
     println(renderer.render(Payment(…))


     View Slide

129. zipline.bind(SystemLocationManager(…))
     // Load Kotlin/JS
     val renderer = zipline.take()
     println(renderer.render(Payment(…))
     class RealPaymentRenderer : PaymentRenderer {
     override fun render(payment: Payment): String {
     /* Fancy new impl */
     }
     }
     zipline.bind(RealPaymentRenderer())


     View Slide

130. zipline.bind(SystemLocationManager(…))
     // Load Kotlin/JS
     val renderer = zipline.take()
     println(renderer.render(Payment(…))
     class RealPaymentRenderer(
     private val location: LocationManager,
     ) : PaymentRenderer {
     override fun render(payment: Payment): String {
     /* Fancy new impl */
     }
     }
     val location = zipline.take()
     zipline.bind(RealPaymentRenderer(location))


     View Slide

131. interface SomeService : ZiplineService {
     fun sync(in: String): String
     }


     View Slide

132. interface SomeService : ZiplineService {
     fun sync(in: String): String
     suspend fun async(in: String): String
     }


     View Slide

133. interface SomeService : ZiplineService {
     fun sync(in: String): String
     suspend fun async(in: String): String
     fun stream(in: String): Flow
     }


     View Slide

134. interface SomeService : ZiplineService {
     fun sync(in: String): String
     suspend fun async(in: String): String
     fun stream(in: String): Flow
     fun stateStream(in: String): StateFlow
     }


     View Slide

135. interface SomeService : ZiplineService {
     fun sync(in: String): String
     suspend fun async(in: String): String
     fun stream(in: Flow): String
     fun stateStream(in: StateFlow): String
     }


     View Slide

136. interface SomeService : ZiplineService {
     fun sync(in: String): String
     suspend fun async(in: String): String
     fun stream(in: Flow): String
     fun stateStream(in: StateFlow): String
     fun userTypes(in: Payment): RenderedPayment
     }


     View Slide

137. interface SomeService : ZiplineService {
     …
     fun userTypes(in: Payment): RenderedPayment
     }
     f
     u
     n s
     y
     n
     c
     (
     i
     n
     : S
     t
     r
     i
     n
     g
     )
     : S
     t
     r
     i
     n
     g
     s
     u
     s
     p
     e
     n
     d f
     u
     n a
     s
     y
     n
     c
     (
     i
     n
     : S
     t
     r
     i
     n
     g
     )
     : S
     t
     r
     i
     n
     g
     f
     u
     n s
     t
     r
     e
     a
     m
     (
     i
     n
     : F
     l
     o
     w
     <
     S
     t
     r
     i
     n
     g
     >
     )
     : S
     t
     r
     i
     n
     g
     f
     u
     n s
     t
     a
     t
     e
     S
     t
     r
     e
     a
     m
     (
     i
     n
     : S
     t
     a
     t
     e
     F
     l
     o
     w
     <
     S
     t
     r
     i
     n
     g
     >
     )
     :S
     t
     r
     i
     n
     g


     View Slide

138. interface SomeService : ZiplineService {
     …
     fun userTypes(in: Payment): RenderedPayment
     internal object Adapter : ZiplineAdapter {
     }
     }


     View Slide

139. interface SomeService : ZiplineService {
     …
     fun userTypes(in: Payment): RenderedPayment
     internal object Adapter : ZiplineAdapter {
     override fun outboundService(handler: Handler)
     }
     }


     View Slide

140. interface SomeService : ZiplineService {
     …
     fun userTypes(in: Payment): RenderedPayment
     internal object Adapter : ZiplineAdapter {
     override fun outboundService(handler: Handler) =
     object : SomeService {
     override fun userTypes(in: Payment) =
     handler.call(this, in) as RenderedPayment
     }
     }
     }


     View Slide

141. interface SomeService : ZiplineService {
     …
     fun userTypes(in: Payment): RenderedPayment
     internal object Adapter : ZiplineAdapter {
     override fun outboundService(handler: Handler) =
     object : SomeService {
     override fun userTypes(in: Payment) =
     handler.call(this, in) as RenderedPayment
     }
     }
     }


     View Slide

142. interface SomeService : ZiplineService {
     …
     fun userTypes(in: Payment): RenderedPayment
     internal object Adapter : ZiplineAdapter {
     …
     }
     }
     @Serializable
     class RenderedPayment(…)
     @Serializable
     class Payment(…)


     View Slide

143. QuickJS
     function sayHello() {
     return ['Hello', 'JavaScript']
     .join(' ');
     }


     View Slide

144. QuickJS
     function sayHello() {
     return ['Hello', 'JavaScript']
     .join(' ');
     }
     hello.js:1: function: sayHello
     mode: strict
     stack_size: 3
     opcodes:
     push_atom_value "Hello"
     push_atom_value "JavaScript"
     array_from 2
     get_field2 join
     push_atom_value " "
     tail_call_method 1


     View Slide

145. QuickJS
     hello.js:1: function: sayHello
     mode: strict
     stack_size: 3
     opcodes:
     push_atom_value "Hello"
     push_atom_value "JavaScript"
     array_from 2
     get_field2 join
     push_atom_value " "
     tail_call_method 1
     "Hello, JavaScript"


     View Slide

146. QuickJS
     hello.js:1: function: sayHello
     mode: strict
     stack_size: 3
     opcodes:
     push_atom_value "Hello"
     push_atom_value "JavaScript"
     array_from 2
     get_field2 join
     push_atom_value " "
     tail_call_method 1
     function sayHello() {
     return ['Hello', 'JavaScript']
     .join(' ');
     }
     "Hello, JavaScript"
     hello.js:1: function: sayHello
     mode: strict
     stack_size: 3
     opcodes:
     push_atom_value "Hello"
     push_atom_value "JavaScript"
     array_from 2
     get_field2 join
     push_atom_value " "
     tail_call_method 1


     View Slide

147. hello.js:1: function: sayHello
     mode: strict
     stack_size: 3
     opcodes:
     push_atom_value "Hello"
     push_atom_value "JavaScript"
     array_from 2
     get_field2 join
     push_atom_value " "
     tail_call_method 1
     function sayHello() {
     return ['Hello', 'JavaScript']
     .join(' ');
     }
     "Hello, JavaScript"
     hello.js:1: function: sayHello
     mode: strict
     stack_size: 3
     opcodes:
     push_atom_value "Hello"
     push_atom_value "JavaScript"
     array_from 2
     get_field2 join
     push_atom_value " "
     tail_call_method 1
     Server:
     Client:


     View Slide

148. hello.js:1: function: sayHello
     mode: strict
     stack_size: 3
     opcodes:
     push_atom_value "Hello"
     push_atom_value "JavaScript"
     array_from 2
     get_field2 join
     push_atom_value " "
     tail_call_method 1
     function sayHello() {
     return ['Hello', 'JavaScript']
     .join(' ');
     }
     fun sayHello() {
     return arrayOf("Hello", "JavaScript")
     .asDynamic()
     .join(" ")
     }


     View Slide

149. hello.js:1: function: sayHello
     mode: strict
     stack_size: 3
     opcodes:
     push_atom_value "Hello"
     push_atom_value "JavaScript"
     array_from 2
     get_field2 join
     push_atom_value " "
     tail_call_method 1
     function sayHello() {
     return ['Hello', 'JavaScript']
     .join(' ');
     }
     fun sayHello() {
     return arrayOf("Hello", "JavaScript")
     .asDynamic()
     .join(" ")
     }


     View Slide

150. hello.js:1: function: sayHello
     mode: strict
     stack_size: 3
     opcodes:
     push_atom_value "Hello"
     push_atom_value "JavaScript"
     array_from 2
     get_field2 join
     push_atom_value " "
     tail_call_method 1
     function sayHello() {
     return ['Hello', 'JavaScript']
     .join(' ');
     }
     fun sayHello() {
     return arrayOf("Hello", "JavaScript")
     .asDynamic()
     .join(" ")
     }
     {"version":3,"sources":
     ["../../src/commonMain/
     kotlin/com/example/
     Hello.kt"],"sourcesCont
     ent":[null],,"names":
     [],"mappings":";IAsBE,g
     C;IAMA,wB;IAMA,4B;"}


     View Slide

151. hello.js:1: function: sayHello
     mode: strict
     stack_size: 3
     opcodes:
     push_atom_value "Hello"
     push_atom_value "JavaScript"
     array_from 2
     get_field2 join
     push_atom_value " "
     tail_call_method 1
     function sayHello() {
     return ['Hello', 'JavaScript']
     .join(' ');
     }
     fun sayHello() {
     return arrayOf("Hello", "JavaScript")
     .asDynamic()
     .join(" ")
     }
     {"version":3,"sources":
     ["../../src/commonMain/
     kotlin/com/example/
     Hello.kt"],"sourcesCont
     ent":[null],,"names":
     [],"mappings":";IAsBE,g
     C;IAMA,wB;IAMA,4B;"}


     View Slide

152. Hello.kt:1: function: sayHello
     mode: strict
     stack_size: 3
     opcodes:
     push_atom_value "Hello"
     push_atom_value "JavaScript"
     array_from 2
     get_field2 join
     push_atom_value " "
     tail_call_method 1
     function sayHello() {
     return ['Hello', 'JavaScript']
     .join(' ');
     }
     fun sayHello() {
     return arrayOf("Hello", "JavaScript")
     .asDynamic()
     .join(" ")
     }
     {"version":3,"sources":
     ["../../src/commonMain/
     kotlin/com/example/
     Hello.kt"],"sourcesCont
     ent":[null],,"names":
     [],"mappings":";IAsBE,g
     C;IAMA,wB;IAMA,4B;"}


     View Slide

153. Hello.kt:1: function: sayHello
     mode: strict
     stack_size: 3
     opcodes:
     push_atom_value "Hello"
     push_atom_value "JavaScript"
     array_from 2
     get_field2 join
     push_atom_value " "
     tail_call_method 1
     function sayHello() {
     return ['Hello', 'JavaScript']
     .join(' ');
     }
     fun sayHello() {
     return arrayOf("Hello", "JavaScript")
     .asDynamic()
     .join(" ")
     }
     {"version":3,"sources":
     ["../../src/commonMain/
     kotlin/com/example/
     Hello.kt"],"sourcesCont
     ent":[null],,"names":
     [],"mappings":";IAsBE,g
     C;IAMA,wB;IAMA,4B;"}


     View Slide

154. java.lang.Exception: unexpected timezone: America/Gotham
     at captureStack (runtime/coreRuntime.kt:86)
     at IllegalStateException_init (kotlin-kotlin-stdlib-js-ir.js)
     at (app.cash.worldclock/TimeFormatter.kt:98)
     at (app.cash.worldclock/WorldClockJs.kt:615)
     at (InboundService.kt:837)
     at (zipline-root-zipline.js)
     at app.cash.zipline.OutboundService.runJob(platform.kt:37)
     at app.cash.zipline.EventLoop.run(CoroutineEventLoop.kt:57)
     at j.u.concurrent.Executor.runWorker(ThreadPoolExecutor.java:1167)
     at j.u.concurrent.Executor$Worker.run(ThreadPoolExecutor.java:641)
     at java.lang.Thread.run(Thread.java:920)


     View Slide

155. java.lang.Exception: unexpected timezone: America/Gotham
     at captureStack (runtime/coreRuntime.kt:86)
     at IllegalStateException_init (kotlin-kotlin-stdlib-js-ir.js)
     at (app.cash.worldclock/TimeFormatter.kt:98)
     at (app.cash.worldclock/WorldClockJs.kt:615)
     at (InboundService.kt:837)
     at (zipline-root-zipline.js)
     at app.cash.zipline.OutboundService.runJob(platform.kt:37)
     at app.cash.zipline.EventLoop.run(CoroutineEventLoop.kt:57)
     at j.u.concurrent.Executor.runWorker(ThreadPoolExecutor.java:1167)
     at j.u.concurrent.Executor$Worker.run(ThreadPoolExecutor.java:641)
     at java.lang.Thread.run(Thread.java:920)


     View Slide

156. Zipline
     JavaScript VM


     View Slide

157. Zipline
     JavaScript VM
     2015 - 2023
     WASM VM
     Coming 2024


     View Slide

158. Redwood Zipline
     Treehouse


     View Slide

159. Treehouse
     val root = findViewById(android.R.id.content)!!
     val composition = RedwoodComposition(
     scope = mainScope,
     container = ViewGroupChildren(root),
     provider = SchemaWidgetFactories(
     Counter = AndroidCounterWidgetFactory(this),
     RedwoodLayout = ViewRedwoodLayoutWidgetFactory(this),
     ),
     )
     composition.setContent {
     Counter()
     }
     Treehouse Counter Sample


     View Slide

160. Treehouse Counter Sample
     val root = findViewById(android.R.id.content)!!
     val composition = RedwoodComposition(
     scope = mainScope,
     container = ViewGroupChildren(root),
     provider = SchemaWidgetFactories(
     Counter = AndroidCounterWidgetFactory(this),
     RedwoodLayout = ViewRedwoodLayoutWidgetFactory(this),
     ),
     )
     composition.setContent {
     Counter()
     }


     View Slide

161. Treehouse Counter Sample
     val root = findViewById(android.R.id.content)!!
     val composition = RedwoodComposition(
     scope = mainScope,
     container = ViewGroupChildren(root),
     provider = SchemaWidgetFactories(
     Counter = AndroidCounterWidgetFactory(this),
     RedwoodLayout = ViewRedwoodLayoutWidgetFactory(this),
     ),
     )
     composition.setContent {
     Counter()
     }


     View Slide

162. Treehouse Counter Sample
     )
     val root = findViewById(android.R.id.content)!!
     val composition = RedwoodComposition(
     scope = mainScope,
     container = ViewGroupChildren(root),
     provider = SchemaWidgetFactories(
     Counter = AndroidCounterWidgetFactory(this),
     RedwoodLayout = ViewRedwoodLayoutWidgetFactory(this),
     ),
     )
     composition.setContent {
     Counter()
     }
     val = Redwood (


     View Slide

163. val composition = RedwoodComposition(
     scope = mainScope,
     )
     composition.setContent {
     Counter()
     }
     val root = findViewById(android.R.id.content)!!
     val rendering = RedwoodRendering(
     container = ViewGroupChildren(root),
     provider = SchemaWidgetFactories(
     Counter = AndroidCounterWidgetFactory(this),
     RedwoodLayout = ViewRedwoodLayoutWidgetFactory(this),
     ),
     )
     Presenter
     Compose
     Widgets
     Platform UI
     Zipline


     View Slide

164. val composition = RedwoodComposition(
     scope = mainScope,
     )
     composition.setContent {
     Counter()
     }
     Widgets
     Zipline
     Presenter
     Platform UI
     Compose
     val root = findViewById(android.R.id.content)!!
     val container = ViewGroupChildren(root)
     val provider = SchemaWidgetFactories(
     Counter = AndroidCounterWidgetFactory(this),
     RedwoodLayout = ViewRedwoodLayoutWidgetFactory(this),
     )
     val rendering = RedwoodRendering(
     container = container,
     provider = provider,
     )


     View Slide

165. val composition = RedwoodComposition(
     scope = mainScope,
     )
     composition.setContent {
     Counter()
     }
     Widgets
     Zipline
     Presenter
     Platform UI
     Compose
     val root = findViewById(android.R.id.content)!!
     val container = ViewGroupChildren(root)
     val provider = SchemaWidgetFactories(
     Counter = AndroidCounterWidgetFactory(this),
     RedwoodLayout = ViewRedwoodLayoutWidgetFactory(this),
     )
     val rendering = RedwoodRendering(
     container = container,
     provider = provider,
     )


     View Slide

166. val composition = RedwoodComposition(
     scope = mainScope,
     )
     composition.setContent {
     Counter()
     }
     Widgets
     Zipline
     Presenter
     Platform UI
     Compose
     val root = findViewById(android.R.id.content)!!
     val container = ViewGroupChildren(root)
     val provider = SchemaWidgetFactories(
     Counter = AndroidCounterWidgetFactory(this),
     RedwoodLayout = ViewRedwoodLayoutWidgetFactory(this),
     )
     val rendering = RedwoodRendering(
     container = container,
     provider = provider,
     )


     View Slide

167. val composition = RedwoodComposition(
     scope = mainScope,
     )
     composition.setContent {
     Counter()
     }
     Widgets
     kotlinx
     serialization
     Zipline
     Presenter
     Platform UI
     Compose
     kotlinx
     serialization
     val root = findViewById(android.R.id.content)!!
     val container = ViewGroupChildren(root)
     val provider = SchemaWidgetFactories(
     Counter = AndroidCounterWidgetFactory(this),
     RedwoodLayout = ViewRedwoodLayoutWidgetFactory(this),
     )
     val rendering = RedwoodRendering(
     container = container,
     provider = provider,
     )


     View Slide

168. Schema
     Widgets
     Compose


     View Slide

169. Schema
     Widgets
     Compose
     Compose
     Protocol
     Widget
     Protocol


     View Slide

170. Widgets
     Widget
     Protocol
     Zipline
     Presenter
     Platform UI
     Compose
     Compose
     Protocol


     View Slide

171. Widgets
     Widget
     Protocol
     Zipline
     Platform UI


     View Slide

172. Widgets
     Widget
     Protocol
     Zipline
     Platform UI
     Presenter Compose
     Compose
     Protocol


     View Slide

173. Redwood Protocol
     data class Column(
     val children: () -> Unit,
     )
     data class TextInput(
     val hint: String,
     val text: String,
     val onTextChanged: (String) -> Unit,
     )


     View Slide

174. Redwood Protocol
     @Widget(1)
     data class Column(
     val children: () -> Unit,
     )
     @Widget(2)
     data class TextInput(
     val hint: String,
     val text: String,
     val onTextChanged: (String) -> Unit,
     )


     View Slide

175. Redwood Protocol
     @Widget(1)
     data class Column(
     val children: () -> Unit,
     )
     @Widget(2)
     data class TextInput(
     @Property(1) val hint: String,
     @Property(2) val text: String,
     @Property(3) val onTextChanged: (String) -> Unit,
     )


     View Slide

176. Redwood Protocol
     @Widget(1)
     data class Column(
     @Children(1) val children: () -> Unit,
     )
     @Widget(2)
     data class TextInput(
     @Property(1) val hint: String,
     @Property(2) val text: String,
     @Property(3) val onTextChanged: (String) -> Unit,
     )


     View Slide

177. Widgets
     Widget
     Protocol
     Zipline
     Platform UI
     Presenter Compose
     Compose
     Protocol


     View Slide

178. Treehouse
     Widgets
     Widget
     Protocol
     Zipline
     Platform UI
     Presenter Compose
     Compose
     Protocol


     View Slide

179. Treehouse Demo


     View Slide

180. View Slide

181. Treehouse Demo


     View Slide

182. Redwood Zipline
     Treehouse


     View Slide

183. deviceframes.com


     View Slide

184. .com/cashapp/zipline
     .com/cashapp/redwood


     View Slide

185. @jw@jakewharton.com
     Playing in the Treehouse
     with Redwood and Zipline


     View Slide
