1. © JAMF Software, LLC
   If You Build it, They Will Come

   1:30 - 2:15 PM
   UP NEXT


   View Slide

2. View Slide

3. © JAMF Software, LLC
   Mark Lamont
   Professional Services Engineer

   Jigsaw24
   Jack Hollister
   Apple Enterprise Solutions Architect

   Jigsaw24


   View Slide

4. © JAMF Software, LLC
   If You Build it, They Will Come!
   Presentation agenda:
   Overview
   Automated Device Enrolment builds
   Automated NON Device Enrollment builds
   Policy driven reprovisioning


   View Slide

5. © JAMF Software, LLC
   Are you an organisation with…
   Devices of various OS levels
   Some assigned in ABM/ASM and Jamf
   Some, probably lots, not….
   Need a common build and rebuild method
   Then this talk is for you..


   View Slide

6. © JAMF Software, LLC
   First Up
   Out of the box DEP build….



   View Slide

7. © JAMF Software, LLC
   Automated Device Enrolment Build
   How to setup automated provisioning of a
   DEP ready Mac
   Ideal for use with Jamf Connect Login, NoMAD or AD
   Binding

   No end user account created during the build


   View Slide

8. © JAMF Software, LLC
   Automated Device Enrolment
   Firstly a custom package is needed….



   View Slide

9. © JAMF Software, LLC
   Automated DE Build - Package
   Required components
   NoMAD Login

   NoMAD settings profile

   Branding graphics


   View Slide

10. © JAMF Software, LLC
    Automated DE Build - Package
    Package Post Install Script


    View Slide

11. © JAMF Software, LLC
    Enrollment Prestage
    A prestage is needed….



    View Slide

12. © JAMF Software, LLC
    Max image dimensions
    Automated DE Build - Prestage
    Add the package to
    Enrollment packages


    View Slide

13. © JAMF Software, LLC
    Max image dimensions
    Automated DE Build - Prestage
    Set local User
    account creation
    to
    Skip Account Creation


    View Slide

14. © JAMF Software, LLC
    Post Enrollment Policy
    A build policy is needed….



    View Slide

15. © JAMF Software, LLC
    Automated DE Build - Policy
    One policy required to
    run the build
    run on Enrollment Complete
    ongoing frequency
    Runs the build script


    View Slide

16. © JAMF Software, LLC
    Automated DE Build - Script
    What does it do?
    waits until any required input is
    made
    Runs policies using custom
    triggers
    Displays status updates
    Sets login window type


    View Slide

17. © JAMF Software, LLC
    Automated DE Build - Master Script
    Let’s break it down


    View Slide

18. © JAMF Software, LLC
    Automated DE Build - Script
    Wait until user input completed


    View Slide

19. © JAMF Software, LLC
    Automated DE Build - Script
    Write to Notify screen


    View Slide

20. © JAMF Software, LLC
    Automated DE Build - Script
    Install an application


    View Slide

21. © JAMF Software, LLC
    Automated DE Build - Script
    Reset Login window


    View Slide

22. © JAMF Software, LLC
    Automated DE Build - Demo Time


    View Slide

23. © JAMF Software, LLC
    Part 2…. Non Device Enrollment Build
    Teaching (your) grandmother
    to suck eggs is an English
    language saying that refers to a
    person giving advice to another
    person in a subject with which the
    other person is already familiar
    (and probably more so than the
    first person)


    View Slide

24. © JAMF Software, LLC
    NON DE Build - Uses
    What’s this used for?
    For devices NOT DEP capable but you…

    Want a common OS level

    Want to erase with a common method

    Want to build with same build as the DEP devices


    View Slide

25. © JAMF Software, LLC
    NON DE Build - Overview
    Stages:
    1. Wipe and install clean macOS

    2. Install extra workflow packages

    3. Enroll in Jamf

    4. Apply build

    It’s OK, it’s mostly automated!


    View Slide

26. © JAMF Software, LLC
    Let’s get started
    Back to basics…..



    View Slide

27. © JAMF Software, LLC
    NON DE Build - Your starter for 10
    How do we get this process started?
    Mac Deploy Stick

    https://twocanoes.com/products/mac/mac-deploy-stick/


    View Slide

28. © JAMF Software, LLC
    The Extras
    A couple of packages…..



    View Slide

29. © JAMF Software, LLC
    NON DE Build - Package #1
    Components:
    NoMAD Login

    NoMAD settings profile

    QuickAdd.pkg

    Control script

    LaunchDaemon for script


    View Slide

30. © JAMF Software, LLC
    NON DE Build - Package #1
    Post install script
    LaunchDaemon has to be loaded during package install

    Post install script does this


    View Slide

31. © JAMF Software, LLC
    NON DE Build - Package #1
    QuickAdd Package
    Management user different to the DEP user

    Used in Smart Group later


    View Slide

32. © JAMF Software, LLC
    NON DE Build - Package #2
    Graphics
    Common graphics package


    View Slide

33. © JAMF Software, LLC
    The Extras
    The control script…..



    View Slide

34. © JAMF Software, LLC
    NON DE Build - Control Script
    Check _mbsetupuser is active


    View Slide

35. © JAMF Software, LLC
    NON DE Build - Control Script
    Setup NoMAD


    View Slide

36. © JAMF Software, LLC
    NON DE Build - Control Script
    Check Jamf contactable


    View Slide

37. © JAMF Software, LLC
    NON DE Build - Control Script
    Switch Login Window to NoMAD Login
    Create .AppleSetupDone

    Kill loginwindow


    View Slide

38. © JAMF Software, LLC
    NON DE Build - Control Script
    Install the QuickAdd package
    Enrolls device in Jamf

    Sends enrollment trigger

    Starts the build process


    View Slide

39. © JAMF Software, LLC
    User Logon post build
    It’s built, now what happens?
    User logs in using:
    Jamf Connect

    NoMAD

    AD Bound


    View Slide

40. © JAMF Software, LLC
    MDM Profile Approval
    MDM Profile needs approving
    Full MDM functionality not available without this


    View Slide

41. © JAMF Software, LLC
    MDM Profile Approval
    So how can we force approval?
    Can’t force approval but…

    Can guide

    Repeatedly until they give up…


    View Slide

42. © JAMF Software, LLC
    UAMDM Smart Group
    Smart Group to scope approve MDM policy
    User Approved MDM not Yes
    Managed by non-DEP management user


    View Slide

43. © JAMF Software, LLC
    UAMDM Policy
    Approve MDM Policy
    Scoped to the Smart Group

    Runs at login and checkin


    View Slide

44. © JAMF Software, LLC
    UAMDM Script
    What does the script do?
    Checks if the MDM profile is approved

    Runs the user facing approval screens


    View Slide

45. © JAMF Software, LLC
    UAMDM Script
    Check MDM Profile approved


    View Slide

46. © JAMF Software, LLC
    UAMDM Script
    Run the approval process
    If approved - do nothing

    If not - Start user process


    View Slide

47. © JAMF Software, LLC
    UAMDM Script
    The process
    Launch Jamf Helper

    Alternatively use DEP Notify

    Open Profiles pane

    Approve!


    View Slide

48. © JAMF Software, LLC
    Non DE Build - Finally its Demo time


    View Slide

49. © JAMF Software, LLC
    Part 3…… Rinse and Repeat


    View Slide

50. © JAMF Software, LLC
    That was amazing…What now?
    Now the devices are in Jamf
    Deploy policy driven erase and rebuild

    Self Service or remote execution policy

    Conditionally deploy the NON DEP workflow packages

    Automatically switch between Non DEP and DEP
    !50


    View Slide

51. © JAMF Software, LLC
    Policy Driven Device Reprovisioning
    What’s required?
    Graham Pugh’s Erase-install script

    https://github.com/grahampugh/erase-install

    A couple of Extension Attributes

    and of course smart groups and policies!


    View Slide

52. © JAMF Software, LLC
    Erase-Install script
    What does it do?
    Downloads the appropriate OS install package

    Can be locked to a specific version if required

    Will perform the erase and install

    Displays user messaging when starting

    It has other functionality but not talking about them today


    View Slide

53. © JAMF Software, LLC
    Required Extension Attributes
    Two extension attributes required….



    View Slide

54. © JAMF Software, LLC
    Extension Attribute #1
    Installer valid EA
    To record if OS installer is:

    1. Downloaded

    2. Valid version

    Equal to or higher than installed OS version


    View Slide

55. © JAMF Software, LLC
    Extension Attribute #2
    Is the device DEP capable?
    EA that records if device has DEP record in Apple

    Profiles show -type enrollment


    View Slide

56. © JAMF Software, LLC
    Required Package
    One package required….



    View Slide

57. © JAMF Software, LLC
    Package Required
    Deploy Extras package
    Need to deploy the non-DEP packages

    Deployed as a single package


    View Slide

58. © JAMF Software, LLC
    Required Smart Groups
    Four Smart Groups required….



    View Slide

59. © JAMF Software, LLC
    Smart Group #1
    Installer download required
    OS > 10.13.4

    Add APFS requirement if HFS devices in estate

    Installer not downloaded or not valid


    View Slide

60. © JAMF Software, LLC
    Smart Group #2
    Non DEP Extra packages required
    Have valid OS installer

    Not DEP capable


    View Slide

61. © JAMF Software, LLC
    Smart Group #3
    Erase Ready Groups
    Two separate groups for erase ready

    One for DEP devices

    One for Non DEP devices


    View Slide

62. © JAMF Software, LLC
    Smart Group #4
    One last group….
    Non-DEP to DEP


    View Slide

63. © JAMF Software, LLC
    Required Policies
    Four policies are required….



    View Slide

64. © JAMF Software, LLC
    Policy #1
    OS Installer download
    Downloads the OS installer

    Overwrites existing

    Scoped to download required

    Version options set

    Runs inventory when complete


    View Slide

65. © JAMF Software, LLC
    Policy #2
    Deploy Extras package
    Deploy the extras packages

    Scoped to extras required smart group


    View Slide

66. © JAMF Software, LLC
    Policy #3
    Remove Extras package

    When devices added to DEP

    Delete the extras package

    Build method will now be DEP


    View Slide

67. © JAMF Software, LLC
    Policy #3
    Remove Extras package
    Removes the packages

    Removes Jamf receipt


    View Slide

68. © JAMF Software, LLC
    Policy #4
    The big one!
    Erase and install

    Can be Self Service

    Can be force deployed

    Can be event trigger

    Scoped to the Erase ready groups


    View Slide

69. © JAMF Software, LLC
    Wrap up
    Nearly there ….



    View Slide

70. © JAMF Software, LLC
    Process Flow Diagram


    View Slide

71. © JAMF Software, LLC
    Before you ask..
    Does this work with 10.15?
    YES!


    View Slide

72. © JAMF Software, LLC
    Live uses
    Has this been deployed?

    Ark schools trust

    30 + school locations

    Few new DEP Macs

    Several hundred non DEP Macs

    Devices from 2012 and up


    View Slide

73. © JAMF Software, LLC
    And finally some links
    1. Neil Martin's MacADUK 2019 Presentation
    2. twocanoes.com mac-deploy-stick
    3. Graham Pugh's erase-install
    4. montysmacmusings blog


    View Slide

74. © JAMF Software, LLC
    Thank you for listening!
    Give us feedback by
    completing the 2-question
    session survey in the JNUC
    2019 app.
    UP NEXT
    Your Internal Beta Test Program
    2:45 PM


    View Slide
