CSC305 Lecture 06

Individual Software Design and Development
Code Metrics
(202409)

Transcript

1. Dr. Javier Gonzalez-Sanchez javiergs@calpoly.edu www.javiergs.info o ffi ce: 14 -227 CSC 305 Individual Software Design and Development Lecture 05. Software Metrics
2. Code Metrics
3. Example 3
4. Test Yourselves
12. Software Metrics Complexity
13. Function Metrics • Cyclomatic Complexity. It is a quantitative measure of the number of linearly independent paths. • P a ths occur when "while,” "for,” "if,” "c a se," a nd "goto" keywords a ppe a r within the function. • If the source code cont a ined no control f low st a tements (condition a ls or decision points), the complexity would be 1 • If the code h a d one single-condition IF st a tement, there would be two p a ths through the code: one where the IF st a tement ev a lu a tes to TRUE a nd a nother one where it considers to be FALSE. • Two nested single-condition IFs, or one block with two conditions, would produce a complexity of 3. 13
14. Cyclomatic Complexity 14 CC = Edge - Node + 2 Or CC = ConditionalNodes + 1
15. Cyclomatic Complexity i = 0; n=4; while (i<n-1) { j = i + 1; while (j<n) { if (A[i]<A[j]) swap(A[i], A[j]); } i=i+1; } // CC = 9 - 7 + 2 = 4 // CC = 3 + 1 = 4 (Condition nodes are 1,2 and 3 nodes) // A set of possible execution path of a program // 1, 7 // 1, 2, 6, 1, 7 // 1, 2, 3, 4, 5, 2, 6, 1, 7 // 1, 2, 3, 5, 2, 6, 1, 7 15
16. Complexity Number Meaning 1-10 Structured and well written code
 High Testability
 Cost and Effort is less 10-20 Complex Code
 Medium Testability
 Cost and effort is Medium 20-40 Very complex Code
 Low Testability
 Cost and Effort are high >40 Not at all testable
 Very high Cost and Effort Cyclomatic Complexity 16
17. Questions 17
18. Lab 05 Software Metrics
19. Reminder 19 Calculate metrics for 2 versions of my Paint App https://github.com/CSC3100/App-Paint/
20. Part 1: For each class: LOC eLOC lLOC For each class, For each method: CC Reminder 20
21. Let’s Work 21
