CSC305 Lecture 21

Individual Software Design and Development
Final Project
(202411)

Transcript

1. Dr. Javier Gonzalez-Sanchez javiergs@calpoly.edu www.javiergs.info o ffi ce: 14 -227 CSC 305 Individual Software Design and Development Lecture 21. Final Project
2. Previously on CSC 305
3. GoF Patterns 3
4. Observer 4
5. Singleton 5
6. Decorator/Composite/Chain of Responsibility 6
7. Strategy 7
8. Factory 8
9. Builder 9 https://refactoring.guru/design-patterns/builder
10. Hints 10 ✅ ✅ ✅ ❌ ❌ 🤔
11. To a draft of Standard Concepts (Patterns) 11 wrapper2 Main wrapper1 Factory decoration Envelope Box Gift wrapper3 ball Supervisor Is big > 10, box Is small < 5, envelop
12. Final Project
13. Step 1: Click and draw a square; it has a name 13 Name01
14. Step 2: Change name to the square 14 Name01 Student
15. Step 3: Allow Drag and Drop 15 Student
16. Step 4: Allow Drag and Drop 16 Student
17. Step 5: Right click to display a popup menu 17 Student
18. Step 5: Decorate the box acording with the selection 18 Student 👀
19. Create your own decorations Make them intituive. Text is Fine but Images or Draws are encouraged Several decorations can be applied to the same box To Do
20. Step 5: Decorate the box acording with the selection 20 Student Cat Store Food 👀 O P F 👀 O
21. Step 6: Allow me to connect decorations 21 Student Cat Store Food 👀 O P F 👀 O
22. Step 7: Allow me to connect boxes (classes) File Box Connector Agreg a tion Composition Associ a tion Inherit a nce Re a liz a tion
23. Step 7: Allow me to connect boxes (classes) 23 Student Cat Store Food 👀 O P F 👀 O Main Person
24. Tip: This code can help 24 https://github.com/CSC3100/Patterns/tree/main/ChallengeCities
25. The better the graphics the best BUT, Ok, make it functional and that is enough To Do
26. Step 8: JTabbedPane 26 File Box Connector
27. Step 8: JTabbedPane 27 File Box Connector Student Cat Store Food 👀 O P F 👀 O Main Person
28. Step 9: Generate Text (Code in Java) File Box Connector Agreg a tion Composition Associ a tion Inherit a nce Re a liz a tion Tools Run
29. Step 9: Generate Text (Code in Java) 8: JTabbedPane 29 File Box Connector
30. Step 9: Generate Text (Code in Java) 30 File Box Connector public class Cat C a t O 👀 } { implements PropertyChangeListener extends PropertyChangeSupport
31. Step 9: Generate Text (Code in Java) 31 File Box Connector public class Cat extends PropertyChangeSupport implements PropertyChangeListener { public Cat() super(new Object()); } @Override public void propertyChange (PropertyChangeEvent e) { } C a t O 👀 }
32. What code (classes, interfaces, methods, instructions) can be automatically generated for each pattern? To Do
33. Step 10: File Menu: New, Save, Load File Box Connector Agreg a tion Composition Associ a tion Inherit a nce Re a liz a tion Tools Run New… Open… S a ve As… S a ve Help About
34. What are you going to save to be able to reload both digram and code? To Do
35. Step <Bonus>: About dialog box File Box Connector Agreg a tion Composition Associ a tion Inherit a nce Re a liz a tion Tools Run New… Open… S a ve As… S a ve Help About
36. Questions 36
37. CSC 305 Individual Software Design and Development Javier Gonzalez-Sanchez, Ph.D. javiergs@calpoly.edu Summer 2024 Copyright. These slides can only be used as study material for the class CSC305 at Cal Poly. They cannot be distributed or used for another purpose.
