CSC305 Summer Lecture 10

Individual Software Design and Development
Builder and Chain of Responsabilities
(202508)

Transcript

1. Dr. Javier Gonzalez-Sanchez javiergs@calpoly.edu www.javiergs.info o ffi ce: 14 -227 CSC 305 Individual Software Design and Development | Summer Version Lecture 10. Builder + Chain of Responsibility
2. GoF Patterns 2
3. Fluent-Builder
4. Builder 4 https://refactoring.guru/design-patterns/builder
5. Fluent-Builder • The Fluent Builder is a builder whose design relies on method chaining. In doing so, it a ims to promote code legibility. 5
6. UserPro f ile class UserProfile { private final String username; private final String email; private final String phoneNumber; private final String address; private final int age; public UserProfile(String username, String email, String phoneNumber, String address, int age) { this.username = username; this.email = email; this.phoneNumber = phoneNumber; this.address = address; this.age = age; } public String toString() { return String.format( "UserProfile: { Username: %s, Email: %s, Phone: %s, Address: %s, Age: %d }", username, email, phoneNumber, address, age ); } } 6
7. FluentBuilderExample public class FluentBuilderExample { public static void main(String[] args) { // Example 1: Creating a user in a single line UserProfile user1 = new UserProfileBuilder("alice123") .email("alice@example.com") .phoneNumber("555-1234") .address("123 Main St, NY") .age(25) .build(); // Example 2: Building the object step by step UserProfileBuilder builder = new UserProfileBuilder("bob456"); builder.email("bob@example.com").phoneNumber("555-5678"); UserProfile user2 = builder.address("456 Elm St, LA").age(30).build(); System.out.println(user1); System.out.println(user2); } } 7
8. UserPro f ile class UserProfileBuilder { private final String username; private String email = "Not provided"; private String phoneNumber = "Not provided"; private String address = "Not provided"; private int age = 18; public UserProfileBuilder(String username) { this.username = username; } public UserProfileBuilder email(String email) { this.email = email; return this; } 8
9. UserPro f ile public UserProfileBuilder phoneNumber(String phoneNumber) { this.phoneNumber = phoneNumber; return this; } public UserProfileBuilder address(String address) { this.address = address; return this; } public UserProfileBuilder age(int age) { if (age < 13) throw new IllegalArgumentException("Age must be 13 or older."); this.age = age; return this; } public UserProfile build() { return new UserProfile(username, email, phoneNumber, address, age); } } 9
10. Another Fluent-Builder
11. Fluent-Builder import java.awt.*; public class Client { public static void main(String[] args) { FluentBuilder builder = new BoxFluentBuilder() .setColor(Color.RED) .setSize(20) .setX(10) .setY(20); Product box = ((BoxFluentBuilder)builder).get(); } } 11
12. Fluent-Builder import java.awt.Color; public interface FluentBuilder { public FluentBuilder setColor(Color color); public FluentBuilder setSize(int size); public FluentBuilder setX(int x); public FluentBuilder setY(int y); } 12
13. Fluent-Builder import java.awt.*; public class BoxFluentBuilder implements FluentBuilder { private Color color; private int size, x, y; public Builder setColor (Color color) { this.color = color; return this; } public FluentBuilder setSize(int size) { this.size = size; return this; } public FluentBuilder setX(int x) { this.x = x; return this; } public FluentBuilder setY(int y) { this.y = y; return this; } public Box get() { return new Box (color, size, x, y); } } 13
14. Chain of Responsibility
15. Chain of Responsibility • Avoid coupling the sender of a request to its receiver by giving more th a n one object a ch a nce to h a ndle the request. 15
16. Chain of Responsibility 16
17. Chain of Responsibility // Setup Chain of Responsibility Handler h1 = new ConcreteHandler2(); Handler h2 = new ConcreteHandler2(); Handler h3 = new ConcreteHandler1(); h1.setSuccessor(h2); h2.setSuccessor(h3); // Generate and process request int[] requests = { 2, 5, 14, 22, 18, 3, 27, 20 }; foreach (int i=0; i<requests.lenght; i++) { h1.handleRequest(request[i]); } 17
18. Handler abstract class Handler { public abstract void handleRequest(int request); } class ConcreteHandler1 extends Handler { public void handleRequest(int request) { if (request >= 0 && request < 10) { // code here… } else { // nothing can be done :( } } } 18
19. Handler class ConcreteHandler2 extends Handler { protected Handler successor; public void setSuccessor(Handler successor) { this.successor = successor; } public override void handleRequest(int request) { if (request >= 10 && request < 20) { // code here } else if (successor != null) { successor.handleRequest(request); } } } 19
20. One More Thing
21. GUI 21
22. Next 22
23. Let’s Work 23 https:/ /plantuml.com/class-diagram/
24. PlantUML 24 @startuml !pragma layout smetana class Foo class Bar Foo -|> Bar @enduml Always the first lines. Always the last line class interface abstract class <|-- extends <|.. realization *— composition o-- aggregation --> association ..>. dependency
25. Maven 25
28. GUI 28
29. Questions 29
30. Lab
31. Lab 31 1.Retrieve all files. 3. For each file, create a “class” box (ignore the actual file contents for now). 5. Connect all “class” boxes to each other using ..> (dependency).
32. CSC 305 Individual Software Design and Development Javier Gonzalez-Sanchez, Ph.D. javiergs@calpoly.edu Summer 2025 Copyright. These slides can only be used as study material for the class CSC305 at Cal Poly. They cannot be distributed or used for another purpose.
