  1. jgs
    CSE 564
    Software Design
    Lecture 04: Modularization
    Dr. Javier Gonzalez-Sanchez
    [email protected]
    javiergs.engineering.asu.edu | javiergs.com
    PERALTA 230U
    Office Hours: By appointment

    View Slide

  2. jgs
    Previously …

    View Slide

  3. jgs
    00000010
    [ - < < ( - ) > > ]
    [ ( < - > ) ]
    main () {
    home
    if(){
    if(){
    while() {
    whatever
    }
    }
    }
    }
    home () {
    while() {
    if() {
    something
    }
    }
    }
    Case Study

    View Slide

  4. jgs
    564 00000100
    Top-Down Stepwise Refinement (step 1)
    public class Main {
    public static void main(String[] args) throws Exception {
    String text = readTextFile (path);
    Vector tokens = splitWords (text);
    translate (tokens);
    }

    View Slide

  5. jgs
    564 00000100
    Top-Down Stepwise Refinement (step 2)
    public static String readTextFile (String path) {
    File file = new File (path);
    BufferedReader br = new BufferedReader(new FileReader(file));
    String str;
    while ((str = br.readLine()) != null) {
    text = text + str;
    }
    }
    public static String splitWords (String text) {
    // code here ...
    do {
    int eolAt = text.indexOf("\n");
    if (eolAt >= 0) {
    // code here ...
    } else {
    // code here ...
    }
    // a lot of code here !
    } while (!text.equals(""));
    }
    public static void translate (Vector tokens) {
    // more code ...
    }

    View Slide

  6. jgs
    564 00000100
    Top-Down Stepwise Refinement (step 3)
    public static void createToken (int row, String line) {
    if ( ... ) {
    } else if ( ... ) {
    } else if ( ... ) {
    // etc.
    }
    }

    View Slide

  7. jgs
    564 00000100
    What about translate?
    Input:

    View Slide

  8. jgs
    564 00000100
    Top-Down Stepwise Refinement (step 4)
    private static int currentToken=0;
    public static void translate (Vector tokens) {
    while (curentToken < tokens.size()) {
    checkMethod();
    }
    }
    // checkMethod()
    // checkIf()
    // checkWhile()
    // checkInstruction()
    main () {
    home
    if(){
    if(){
    while() {
    whatever
    }
    }
    }
    } [ - < < ( - ) > > ]
    Output:

    View Slide

  9. jgs
    564 00000100
    Assignment 01
    § Due Date: Thursday Sept 2, 6:00 PM (AZ time).
    § Submit Individually (or team of 2). Only 1 student submit BUT be sure both
    names are included using the JavaDoc @author label
    § Source Code in Java (SHOULD compile and run)
    § Show your skills for readability (make your code easy to read) – Clean Code
    § Use Javadoc (correctly)
    § If you are not familiar with Java Guidelines, review
    https://google.github.io/styleguide/javaguide.html
    § Input is a txt file (path is to be received as parameter to main).
    § Output is to be printed on screen
    § Do not make assumptions. If you have a question, Ask

    View Slide

  10. jgs
    Modularization

    View Slide

  11. jgs
    564 00000100
    Timeline
    1971 Wirth
    1972 Parnas

    View Slide

  12. jgs
    564 00000100
    Decomposing Systems into Modules (1972)
    On the Criteria To Be Used in Decomposing Systems into Modules
    April 1972
    D.L. Parnas
    Communications of the ACM
    Pioneer of software engineering
    ACM Fellow
    Developed the concept of information hiding

    View Slide

  13. jgs
    564 00000100
    • What criteria to use?
    • Niklaus Wirth.
    • Information Hiding :
    A data structure, its internal linking, accessing procedures and
    modifying procedures are part of a single module
    • What is a module?
    • What is the difference of Function vs Module?
    • What is the difference of Task vs Responsibility?

    View Slide

  14. jgs
    564 00000100
    Decomposing Systems into Modules (1972)
    • Modularization
    Design decisions / independent modules
    • It improves flexibility and comprehensibility
    • What criteria to use in dividing the system into modules?
    Rule A:
    Information Hiding – data, getters, and setters in one module
    Rule B:
    A set of related tasks must live in the same module

    View Slide

  15. jgs
    564 00000100
    Wirth + Parnas
    • Niklaus Wirth.
    • Each major step in the process a module.
    • Begins with a list of difficult design decisions or design decisions
    which are likely to change. Each module is then designed to hide
    such a decision from the others.
    • In some cases, modules will not correspond to stages in the
    processing.

    View Slide

  16. jgs
    564 00000100
    Concepts
    • Module is a responsibility assignment rather than a subprogram.
    • Module specification = its inputs, its outputs its interfaces
    • Small enough and simple enough to be thoroughly understood
    • Independent development of modules
    • Comprehensibility: they make easy to understand parts, connections, and the
    whole.

    View Slide

  17. jgs
    564 00000100
    Summary
    § Functions are tasks.
    § One function perform one task. If needed (size, complexity) split in subtasks
    § A module encapsulate a responsibility
    § Responsibility include one or more tasks
    § A module encapsulate data shared by a group of tasks
    § How many modules and Which ones?
    § How many functions and in Which Module?

    View Slide

  18. jgs
    564 00000100
    Questions

    View Slide

  19. jgs
    CSE 564 Software Design
    Javier Gonzalez-Sanchez, Ph.D.
    [email protected]
    Fall 2021
    Copyright. These slides can only be used as study material for the class CSE564 at ASU.
    They cannot be distributed or used for another purpose.
