1. jgs
   SER 594
   Software Engineering for
   Machine Learning
   Lecture 21: Classification
   Dr. Javier Gonzalez-Sanchez
   javiergs@asu.edu
   javiergs.engineering.asu.edu | javiergs.com
   PERALTA 230U
   Office Hours: By appointment


   View Slide

2. Javier Gonzalez-Sanchez | SER 594 | Spring 2022 | 2
   jgs
   Machine Learning


   View Slide

3. Javier Gonzalez-Sanchez | SER 594 | Spring 2022 | 3
   jgs
   Definition
   § Supervised learning is the machine learning task of learning a function that
   maps an input to an output based on example input-output pairs.
   § Classification – approximating a mapping function (f) from input variables (X)
   to discrete output variables (y).
   § Regression – approximating a mapping function (f) from input variables (X)
   to a continuous output variable (y).
   § Discretization – convert a regression problem to a classification problem


   View Slide

4. Javier Gonzalez-Sanchez | SER 594 | Spring 2022 | 4
   jgs
   But,
   How does a Classifier work?


   View Slide

5. Javier Gonzalez-Sanchez | SER 594 | Spring 2022 | 5
   jgs
   Previously
   /
   / yes, we are still using Mallet.
   /
   / Nothing else.


   View Slide

6. jgs
   Classification
   Naïve Bayes


   View Slide

7. Javier Gonzalez-Sanchez | SER 594 | Spring 2022 | 7
   jgs
   Naïve Bayes
   § It is one of the most popular and simple machine learning classification
   algorithms
   § based on the Bayes Theorem for calculating probabilities and conditional
   probabilities
   § It can be extremely fast relative to other classification algorithms
   § It is easy to build and particularly useful for very large data sets
   § The name naive is used because it assumes the features that go into the
   model is independent of each other. That is changing the value of one
   feature, does not directly influence or change the value of any of the other
   features used in the algorithm.


   View Slide

8. Javier Gonzalez-Sanchez | SER 594 | Spring 2022 | 8
   jgs
   Bayes
   X Y Frequency Table Likelihood Table
   Example:
   P (Yes | Sunny) = P( Sunny | Yes) * P(Yes) / P (Sunny)
   P (Yes | Sunny) = 3 / 9 * 9 / 14 / 5/14 = 0.60
   Bayes Rule:


   View Slide

9. Javier Gonzalez-Sanchez | SER 594 | Spring 2022 | 9
   jgs
   Outlook
   Temperat
   ure
   Humidity Windy
   Play
   Golf
   0 Rainy Hot High False No
   1 Rainy Hot High True No
   2 Overcast Hot High False Yes
   3 Sunny Mild High False Yes
   4 Sunny Cool Normal False Yes
   5 Sunny Cool Normal True No
   6 Overcast Cool Normal True Yes
   7 Rainy Mild High False No
   8 Rainy Cool Normal False Yes
   9 Sunny Mild Normal False Yes
   10 Rainy Mild Normal True Yes
   11 Overcast Mild High True Yes
   12 Overcast Hot Normal False Yes
   13 Sunny Mild High True No
   X1 X2 X3 X4 Y
   Frequency Table


   View Slide

10. Javier Gonzalez-Sanchez | SER 594 | Spring 2022 | 10
    jgs
    Naïve Bayes
    Bayes Rule:
    Naïve Bayes Rule:


    View Slide

11. Javier Gonzalez-Sanchez | SER 594 | Spring 2022 | 11
    jgs
    Naïve Bayes
    Example:
    P (Yes | Rainy, Hot, High, False) =
    P( Rainy | Yes) * P( Hot | Yes) * P( High | Yes) * P( False | Yes) *
    P(Yes) / P (Rainy) * P (Hot) * P (High) * P (False) =
    3/9 * 2/9* 3/9 * 6/9 *
    9/14 / 5/14* 4/14 * 7/14 * 8/14 =
    0.01646* 0.6428 / 0.0291 = 0.3629
    P (No | Rainy, Hot, High, False) =
    P( Rainy | No) * P( Hot | No) * P( High | No) * P( False | No) *
    P(No) / P (Rainy) * P (Hot) * P (High) * P (False) =
    2/5 * 2/5* 4/5 * 2/5 *
    5/14 / 5/14* 4/14 * 7/14 * 8/14 =
    0.0512* 0.3571 / 0.0291 = 0.6282


    View Slide

12. Javier Gonzalez-Sanchez | SER 594 | Spring 2022 | 12
    jgs
    Weka | NaiveBayes
    CSV file


    View Slide

13. Javier Gonzalez-Sanchez | SER 594 | Spring 2022 | 13
    jgs
    Note: ARFF Files
    String path = "data/weather.nominal.arff";
    BufferedReader bufferedReader = new BufferedReader(
    new FileReader(path)
    );
    Instances datasetInstances = new Instances(bufferedReader);


    View Slide

14. Javier Gonzalez-Sanchez | SER 594 | Spring 2022 | 14
    jgs
    Weka | NaiveBayes | Evaluation


    View Slide

15. jgs
    Classification
    Decision Tree


    View Slide

16. Javier Gonzalez-Sanchez | SER 594 | Spring 2022 | 16
    jgs
    Decision Tree
    § Also known as Classification And Regression Trees (CART)
    § Learning answers to a hierarchy of if/else questions leading to a decision


    View Slide

17. Javier Gonzalez-Sanchez | SER 594 | Spring 2022 | 17
    jgs
    Example


    View Slide

18. Javier Gonzalez-Sanchez | SER 594 | Spring 2022 | 18
    jgs
    Example
    Which Attribute Should be the ROOT?


    View Slide

19. Javier Gonzalez-Sanchez | SER 594 | Spring 2022 | 19
    jgs
    Data


    View Slide

20. Javier Gonzalez-Sanchez | SER 594 | Spring 2022 | 20
    jgs
    Entropy
    Entropy is a measurement of
    the degree of randomness or
    the increase in the disorganization within a system.


    View Slide

21. jgs
    To be continued…


    View Slide

22. Javier Gonzalez-Sanchez | SER 594 | Spring 2022 | 22
    jgs
    Questions


    View Slide

23. jgs
    SER 594 Software Engineering for Machine Learning
    Javier Gonzalez-Sanchez, Ph.D.
    javiergs@asu.edu
    Spring 2022
    Copyright. These slides can only be used as study material for the class CSE205 at Arizona State University.
