  1. jgs
    SER332
    Introduction to Graphics and Game
    Development
    Lecture 18: Mesh Data Structure II
    Javier Gonzalez-Sanchez
    [email protected]
    PERALTA 230U
    Office Hours: By appointment

    View Slide

  2. jgs
    Plane, Cylinder, and Box

    View Slide

  3. Javier Gonzalez-Sanchez | SER332 | Spring 2018 | 3
    jgs
    Creating a Triangulated Plane
    // Generate vertices in XZ-plane
    for i = 0 to n
    for j = 0 to n
    Create vertex at location (i*xsize, 0, j*ysize)
    // step 2. Generate indices
    for i = 0 to ?
    Create triangle with indices(i, i+1, i+n+1)
    Create triangle with indices( i+1, i+n+2, i+n+1)
    xsize
    ysize vn
    v0
    v1
    v
    n+1
    vn+2

    View Slide

  4. Javier Gonzalez-Sanchez | SER332 | Spring 2018 | 4
    jgs
    Creating a Triangulated Plane
    // creating a triangulated plane
    Mesh* createPlane(int arena_width, int arena_depth, int arena_cell) {
    Mesh *me = new Mesh;
    int n = arena_width / arena_cell;
    int m = arena_depth / arena_cell;
    // vertices
    for (int i = 0; ifor (int j = 0; j < m; j++) {
    me->dot_vertex.push_back(Vec3(i*arena_cell, 0.0, j*arena_cell));
    }
    }
    // faces
    for (int i = 0; i<(n*m) - m; i++) {
    if ((i + 1) % n == 0) continue;
    me->face_index_vertex.push_back(i);
    me->face_index_vertex.push_back(i + 1);
    me->face_index_vertex.push_back(i + n);
    me->face_index_vertex.push_back(i + 1);
    me->face_index_vertex.push_back(i+ n + 1);
    me->face_index_vertex.push_back(i + n);
    }
    return me;
    }

    View Slide

  5. Javier Gonzalez-Sanchez | SER332 | Spring 2018 | 5
    jgs
    Creating a Triangulated Plane
    § Use colors to verify right-hand rule.

    View Slide

  6. Javier Gonzalez-Sanchez | SER332 | Spring 2018 | 6
    jgs
    Creating a Triangulated Cylinder
    // Generate vertices on top
    for i = 0 to n
    angle = (i*360) / (n+1)
    create vertex at (cos( angle), height, sin(angle))
    // Generate vertices on the bottom
    // same process but height = 0
    // Generate vertex in the middle of the top
    // Generate vertex in the middle of the bottom
    // Generate triangles on top
    // Generate triangles on the bottom
    // Generate triangles on the side
    v1
    Vn+2
    v0
    Vn+1

    View Slide

  7. Javier Gonzalez-Sanchez | SER332 | Spring 2018 | 7
    jgs
    Creating a Triangulated Cylinder
    // create a triangulated cylinder
    Mesh* createCylinder(int h, int radio) {
    int n = 100;
    double angle;
    Mesh *m =new Mesh;
    // Generate vertices on top
    m->vertex.push_back(Vec3(0.0, h, 0.0));
    for (int i = 0; iangle = (M_PI/180)*(1.0*i*360)/n;
    m->vertex.push_back(Vec3
    (cos(angle)* radio, h, sin(angle)* radio));
    }
    // Generate vertices on bottom
    for (int i = 0; iangle = (M_PI/180)*(i*360)/n;
    m->vertex.push_back(Vec3
    (cos(angle)* radio, 0.0, sin(angle)* radio));
    }

    View Slide

  8. jgs
    Javier Gonzalez-Sanchez | SER332 | Spring 2018 | 8
    // Generate triangles on top
    for (int i = 1; i<=n; i++) {
    m->vertexIndex.push_back(0); m->vertexIndex.push_back(i);
    if (i==n) {
    m->vertexIndex.push_back(1);
    }else{
    m->vertexIndex.push_back(i+1);
    }
    }
    // There is no bottom. Use the floor.
    // Generate triangles on the side
    for (int i = 1; i<=n; i++) {
    m->vertexIndex.push_back(i); m->vertexIndex.push_back(n+i);
    if (i!=n) {
    m->vertexIndex.push_back(n+i+1);
    } else {
    m->vertexIndex.push_back(n+1);
    }
    m->vertexIndex.push_back(i);
    if (i!=n) {
    m->vertexIndex.push_back(i+1); m->vertexIndex.push_back(n+i+1);
    }else{
    m->vertexIndex.push_back(1); m->vertexIndex.push_back(n+1);
    }
    }
    return m;
    }

    View Slide

  9. Javier Gonzalez-Sanchez | SER332 | Spring 2018 | 9
    jgs
    Creating a Triangulated Cylinder

    View Slide

  10. Javier Gonzalez-Sanchez | SER332 | Spring 2018 | 10
    jgs
    Creating a Triangulated Cube
    // Generate vertices on top
    // Generate vertices on the bottom
    // Generate triangles on top
    // Generate triangles on the bottom
    // Generate triangles on the sides

    View Slide

  11. Javier Gonzalez-Sanchez | SER332 | Spring 2018 | 11
    jgs
    Creating a Triangulated Cube

    View Slide

  12. Javier Gonzalez-Sanchez | SER332 | Spring 2018 | 12
    jgs
    Source Code
    § https://github.com/javiergs/SER332/blob/master/Lecture18/main.cpp

    View Slide

  13. Javier Gonzalez-Sanchez | SER332 | Spring 2018 | 13
    jgs
    Test Yourselves
    § Include methods to create cubes, planes, and cylinders
    § Include methods to create spheres

    View Slide

  14. jgs
    SER332 Introduction to Graphics
    Javier Gonzalez-Sanchez
    [email protected]
    Spring 2018
    Disclaimer. These slides can only be used as study material for the class SER332 at ASU. They cannot be distributed or used for another purpose.
