1. jgs Compilers Lecture 07: Fundamentals of Syntactic Analysis Dr. Javier Gonzalez-Sanchez jgonzalezs@up.edu.mx
2. Dr. Javier Gonzalez-Sanchez | Compilers | 2 jgs Next Step  Lexical Analysis ☐ Syntactic Analysis
3. Dr. Javier Gonzalez-Sanchez | Compilers | 3 jgs High-Level Languages X,E,G,O,O #e1,I,I,0,7 @ OPR 19, AX STO x, AX LIT 5, AX OPR 21, AX LOD #e1,AX CAL 1, AX OPR 0, AX 5 Virtual Machine (interpreter) // sorce code int x; int foo () { read (x); print (5); } main () { foo (); } Lexer Parser Semantic Analyzer Code Generation 01001010101000010 01010100101010010 10100100000011011 11010010110101111 00010010101010010 10101001010101011 Assembler compilation execution
4. Dr. Javier Gonzalez-Sanchez | Compilers | 4 jgs Big Picture 5 integer / operator 5 integer x ID = operator
5. Dr. Javier Gonzalez-Sanchez | Compilers | 5 jgs Why we need trees? After lexical analysis, we have a series of tokens. But we can not: I. define a DFA matching all expressions with properly balanced parentheses. II. i.e., define a DFA matching all functions with properly nested block structure. void a () { b (c); for (;;) {a=(-(1+2)+5); } }
6. Dr. Javier Gonzalez-Sanchez | Compilers | 6 jgs Goal Now, we want to: ▪ Review the structure defined by the given series of words (tokens), i.e., whether the order of words is correct. ▪ Report errors if the tokens do not correctly represent a valid structure.
7. Dr. Javier Gonzalez-Sanchez | Compilers | 7 jgs Goal ▪ The goal of syntax analysis is to construct a parse tree for a given input (a sequence of tokens).
8. Dr. Javier Gonzalez-Sanchez | Compilers | 8 jgs Outline Language Lexical Analysis (Lexer) Rules Symbols Token Tools Regular Expression DFA Syntactic Analysis (Parser) Grammar (Rules) Tree
9. jgs Definitions
10. Dr. Javier Gonzalez-Sanchez | Compilers | 10 jgs Back to Elementary School Parse Trees Grammar
11. Dr. Javier Gonzalez-Sanchez | Compilers | 11 jgs Grammar | Definition A Grammar is a collection of four elements: 1. Set of terminal symbols (lowercase). Terminals can be tokens or specific words. 2. Set of non-terminal symbols (uppercase) 3. Set of production rules saying how each nonterminal can be converted by a string of terminals and nonterminals, 4. A start symbol Terminal (leaf) Non-Terminal (node) Start (root)
12. Dr. Javier Gonzalez-Sanchez | Compilers | 12 jgs Parse Tree ▪ A parse tree is a tree encoding the steps in a derivation. ▪ Internal nodes represent nonterminal symbols used in the production. ▪ Leaves represent terminals ▪ In-order Traversal describes a well-formed input ▪ Encodes what rules are used, not the order in which those rules are applied. Terminal (leaf) Non-Terminal (node) Start (root)
13. jgs Example Grammar for a Simple Calculator
14. Dr. Javier Gonzalez-Sanchez | Compilers | 14 jgs A Simple Calculator | Grammar 5 integer / operator 5 integer Non-Terminals Terminals ::= 'integer' ( '+' | '-' | '*' | '/' ) 'integer' Expression Rules Start Symbol (root) Assignment ::= 'id' '=' Expression x ID = operator Assignment Expression Assignment
15. Dr. Javier Gonzalez-Sanchez | Compilers | 15 jgs A Simple Calculator | Parse Tree Assignment ⇒ id = Expression ⇒ x = Expression ⇒ x = integer / integer ⇒ x = 5 / integer ⇒ x = 5 / integer ⇒ x = 5 / 5 5 integer / operator 5 integer x ID = operator
16. Dr. Javier Gonzalez-Sanchez | Compilers | 16 jgs Grammar | Derivation 5 integer / operator 5 integer x ID = operator
17. Dr. Javier Gonzalez-Sanchez | Compilers | 17 jgs Grammar | Derivation 5 integer { delimiter 5 integer x ID = operator
18. Dr. Javier Gonzalez-Sanchez | Compilers | 18 jgs Grammar | Derivation - operator 5 integer - operator x ID = operator - operator 20 integer
19. Dr. Javier Gonzalez-Sanchez | Compilers | 19 jgs Grammar | Derivation - operator 5 integer - operator x ID = operator * operator 20 integer
20. Dr. Javier Gonzalez-Sanchez | Compilers | 20 jgs Grammar | Derivation * operator 5 integer ( delimiter x ID = operator ) delimiter 20 integer + operator 20 integer
21. Dr. Javier Gonzalez-Sanchez | Compilers | 21 jgs Grammar | Derivation * operator 5 integer ( delimiter x ID = operator ; delimiter 20 integer + operator 20 integer
22. Dr. Javier Gonzalez-Sanchez | Compilers | 22 jgs Language Lexical Analysis (Lexer) Rules Symbols Token Tools Regular Expression DFA Syntactic Analysis (Parser) Grammar (Rules) Terminal Non-terminal Tools BNF (Backus-Naur Form) Syntax Diagrams Outline
23. Dr. Javier Gonzalez-Sanchez | Compilers | 23 jgs Homework Review Recursion
24. Dr. Javier Gonzalez-Sanchez | Compilers | 24 jgs Homework Finish Your Lexer
25. Dr. Javier Gonzalez-Sanchez | Compilers | 25 jgs Questions
