UP Lecture 17

Compilers
Full Parser
(202404)

Transcript

1. jgs Compilers Lecture 17: Our Parser Dr. Javier Gonzalez-Sanchez jgonzalezs@up.edu.mx
2. jgs Previously …
3. Dr. Javier Gonzalez-Sanchez | Compilers | 3 jgs Error Recovery PROGRAM BODY ASSIGNMENT VARIABLE WHILE IF RETURN PRINT C EXPRESSION X Y R E A B
4. Dr. Javier Gonzalez-Sanchez | Compilers | 4 jgs Parser | Error Recovery Rule FIRST set FOLLOW set PROGRAM { EOF BODY FIRST (PRINT) U FIRST (ASIGNMENT) U FIRST(VARIABLE) U FIRST (WHILE) U FIRST(IF) U FIRST (RETURN) } PRINT print ; ASSIGNMENT identifier ; VARIABLE int, float, boolean, void, char, string ; WHILE while } U FIRST(BODY) IF if } U FIRST(BODY) RETURN return ; EXPRESSION FIRST(X) ), ; X FIRST(Y) | U FOLLOW(EXPRESSION) Y ! U FIRST(R) & U FOLLOW(X) R FIRST(E) FOLLOW(Y) E FIRST (A) !=, ==, >, < U FOLLOW(R) A FIRST (B) -, + U FOLLOW(E) B - U FIRST (C) *, /, U FOLLOW(A) C integer, octal, hexadecimal, binary, true, false, string, char, float, identifier, ( FOLLOW(B)
5. jgs Prediction Rules
6. Dr. Javier Gonzalez-Sanchez | Compilers | 6 jgs Prediction Rule 1 It should always be possible to choose among several alternatives in a grammar rule, i.e., To implement a single-symbol look-ahead predictive parser, the FIRST sets of any two choices in one rule must not have tokens in common. i.e., FIRST(R1 ) FIRST(R2 ) FIRST(R3 )... FIRST(Rn ) = Ø
7. Dr. Javier Gonzalez-Sanchez | Compilers | 7 jgs Prediction Rule 1 :: Example BODY
8. Dr. Javier Gonzalez-Sanchez | Compilers | 8 jgs Prediction Rule 2 For any optional part, no token beginning the optional part can also come after the optional part. i.e., FIRST(RULE) != FOLLOW(RULE)
9. Dr. Javier Gonzalez-Sanchez | Compilers | 9 jgs Prediction Rule 2 :: Example BODY PROGRAM
10. jgs Let’s Finish Our Parser Stage 1
11. Dr. Javier Gonzalez-Sanchez | Compilers | 11 jgs Step 1 Complete your Grammar 1. variable declaration with initialization 2. Global/Local 3. do/while 4. for loop 5. switch-case 6. method declaration 7. with parameters 8. return values 9. read from the keyboard (we have print)
12. Dr. Javier Gonzalez-Sanchez | Compilers | 12 jgs Step 2 Calculate FIRST and FOLLOW for the New Rules
13. jgs Let’s Finish Our Parser Stage 2
14. Dr. Javier Gonzalez-Sanchez | Compilers | 14 jgs Step 3 Program the New Rules
15. Dr. Javier Gonzalez-Sanchez | Compilers | 15 jgs Step 3
16. Dr. Javier Gonzalez-Sanchez | Compilers | 16 jgs Bonus
17. Dr. Javier Gonzalez-Sanchez | Compilers | 17 jgs Step 4 Implement Full Error Recovery § It is time to complete that error() method and ”recover from errors.” § Recover from an error: make the current token point to an expected token. In summary, it will be as follows: § A token in the FIRST set of the rule to be called next § A token in the FOLLOW set on the rule called before Details are in the following slides.
18. jgs Error Recovery
19. Dr. Javier Gonzalez-Sanchez | Compilers | 19 jgs Error Recovery PROGRAM BODY ASSIGNMENT VARIABLE WHILE IF RETURN PRINT C EXPRESSION X Y R E A B
20. Dr. Javier Gonzalez-Sanchez | Compilers | 20 jgs Parser | Error Recovery Rule FIRST set FOLLOW set PROGRAM { EOF BODY FIRST (PRINT) U FIRST (ASIGNMENT) U FIRST(VARIABLE) U FIRST (WHILE) U FIRST(IF) U FIRST (RETURN) } PRINT print ; ASSIGNMENT identifier ; VARIABLE int, float, boolean, void, char, string ; WHILE while } U FIRST(BODY) IF if } U FIRST(BODY) RETURN return ; EXPRESSION FIRST(X) ), ; X FIRST(Y) | U FOLLOW(EXPRESSION) Y ! U FIRST(R) & U FOLLOW(X) R FIRST(E) FOLLOW(Y) E FIRST (A) !=, ==, >, < U FOLLOW(R) A FIRST (B) -, + U FOLLOW(E) B - U FIRST (C) *, /, U FOLLOW(A) C integer, octal, hexadecimal, binary, true, false, string, char, float, identifier, ( FOLLOW(B)
21. Dr. Javier Gonzalez-Sanchez | Compilers | 21 jgs Error Recovery { x = a; x = 1 + ( x = (y;) if (a < b + ) {} else {} if (a < b) { if (a < b) { } else { } Input: We will not allow multi- line expressions; lines 3 and 4 should not be considered as follows: x= 1 + ( x = ( y;)
22. Dr. Javier Gonzalez-Sanchez | Compilers | 22 jgs Error Recovery Line 3: expected value, identifier, ( Line 3: expected ) Line 3: expected ; // move to the next line Line 4: expected ) Line 4: expected identifier or keyword // infinite loop or end Line 5: expected value, identifier, ( // simple Line 12: expected } // reported by program Output:
23. Dr. Javier Gonzalez-Sanchez | Compilers | 23 jgs Error Recovery At this point: § Errors do not increment currentToken. § currentToken increase when the token is used (added to the tree). § Error recovery is about ignoring tokens § How do we know which tokens should be ignored?
24. Dr. Javier Gonzalez-Sanchez | Compilers | 24 jgs Parser | Error Recovery PROGRAM Line N: expected { Line N: expected } currentToken++; Searching for FIRST(BODY) or }
25. Dr. Javier Gonzalez-Sanchez | Compilers | 25 jgs Parser | Error Recovery Line N: expected ; Line N: expected identifier or keyword currentToken++; Searching for FIRST(BODY) or FOLLOW(BODY) BODY
26. Dr. Javier Gonzalez-Sanchez | Compilers | 26 jgs Parser | Error Recovery ASSIGNMENT Line N: expected = currentToken++; Searching for FIRST(EXPRESSION) or FOLLOW(EXPRESSION)
27. Dr. Javier Gonzalez-Sanchez | Compilers | 27 jgs Parser | Error Recovery VARIABLE Line N: expected identifier
28. Dr. Javier Gonzalez-Sanchez | Compilers | 28 jgs Parser | Error Recovery WHILE Line N: expected ( Line N: expected ) currentToken++; Searching for FIRST(EXPRESSION) or ) currentToken++; Searching for FIRST(PROGRAM) or FOLLOW(PROGRAM)
29. Dr. Javier Gonzalez-Sanchez | Compilers | 29 jgs Parser | Error Recovery IF Line N: expected ( Line N: expected ) currentToken++; Searching for FIRST(EXPRESSION) or ) currentToken++; Searching for FIRST(PROGRAM) or FOLLOW(PROGRAM)
30. Dr. Javier Gonzalez-Sanchez | Compilers | 30 jgs Parser | Error Recovery RETURN
31. Dr. Javier Gonzalez-Sanchez | Compilers | 31 jgs Parser | Error Recovery PRINT Line N: expected ( Line N: expected ) currentToken++; Searching for FIRST(EXPRESSION) or )
32. Dr. Javier Gonzalez-Sanchez | Compilers | 32 jgs Parser | Error Recovery EXPRESSION X Y R E A B
33. Dr. Javier Gonzalez-Sanchez | Compilers | 33 jgs Parser | Error Recovery C Line N: expected value, identifier or ( Line N: expected )
34. Dr. Javier Gonzalez-Sanchez | Compilers | 34 jgs Parser | Error Recovery If ( tokens.get(currentToken).getLine() < tokens.get(currentToken+1).getLine() ) { / / go back until reaching RULE_BODY() }
35. Dr. Javier Gonzalez-Sanchez | Compilers | 35 jgs Questions
36. Dr. Javier Gonzalez-Sanchez | Compilers | 36 jgs Homework Programming Final Version of Your Parser
37. jgs Compilers Javier Gonzalez-Sanchez, Ph.D. jgonzalezs@up.edu.mx Spring 2024 Copyright. These slides can only be used as study material for the Compilers course at Universidad Panamericana. They cannot be distributed or used for another purpose.
