of FMC TDC board Testing, Virtual Hardware and WhiteRabbit Technical details and demo Testing and HW Virtualization Javier Muñoz Mellid & Samuel Iglesias Gonsalvez
around the globe Hacking in different areas kernel virtualization graphics/rendering compilers distros ... www.igalia.com Testing and HW Virtualization Javier Muñoz Mellid & Samuel Iglesias Gonsalvez
the possibility to test low level software, such as firmwares, HDL cores or kernel/drivers, without real HW. It is not about replacing real hardware at all. The idea is analysing every test case on real hardware in order to know if we can run it on virtual hardware. This approach saves resources and time. Testing and HW Virtualization Javier Muñoz Mellid & Samuel Iglesias Gonsalvez
the time of arrival of each incoming pulse in order to save the timestamp into the memory, ready to be read later CERN/Igalia effort to support FMC-TDC board in Linux drivers, user-space library and test cases developed Integration with ZIO framework, use FMC bus and SPEC drivers Testing and HW Virtualization Javier Muñoz Mellid & Samuel Iglesias Gonsalvez
issues when developing drivers for non mature hardware Hardware not available Buggy firmwares delaying development Is it a hardware or software bug? Where is it? Flashing firmware, running tests... are time-intensive tasks Hardware specification evolving along the project ... Testing and HW Virtualization Javier Muñoz Mellid & Samuel Iglesias Gonsalvez
the previous issues we explored the virtual way with the following results ... No real hardware bottle-neck, parallel development No buggy firmwares issues Got a virtual baseline in order to test old and new specifications/firmwares, bug identification really easy Saved time in real flashing and testing approaches Developed continuous integration and automatic testing tooling for software (kernel, libraries, etc) on top of virtual hardware Got good-enough virtual models (buses, I/O spaces, memory maps, etc) to cover goals. Further emulation (VHDL, firmware, etc) possible but it wasn’t required for this project Testing and HW Virtualization Javier Muñoz Mellid & Samuel Iglesias Gonsalvez
not possible catching all bugs in a complex system A complex system based on hardware/software require different, but integrated, testing approaches Pragmatic testing is a must. Keep all possible testing in the soft side. It is more affordable, fast and flexible It doesn’t matter where the bug is (software or hardware). If it appears in a critical system then it is a critical bug In the long, continuous integration and automatic testing is the way Flexible and robust testing approach is key to get great releases At the end, final testing should always run in the real system Testing and HW Virtualization Javier Muñoz Mellid & Samuel Iglesias Gonsalvez
Tools and compilers (ARM, LM32) Builroot Barebox (bootloader) IPL Linux kernel and drivers (versions, configurations, etc) User space applications (ptpd, hal, libs, etc) VHDL and LM32 binaries Testing and HW Virtualization Javier Muñoz Mellid & Samuel Iglesias Gonsalvez
be possible on the following components No virtual Hardware required Tools and compilers (ARM, LM32) Builroot Virtual Hardware required Linux kernel and drivers code (similar FMC TDC approach) LM32 binaries (real-time) VHDL (behaviour) Not explored Barebox (bootloader) IPL User space applications (ptpd, hal, libs, etc) Testing and HW Virtualization Javier Muñoz Mellid & Samuel Iglesias Gonsalvez
on the driver Generic stuff The virtual board in being detected by the driver as a genuine device. Normal mode: no error injection. DMA DMA error: TDC_DMA_STAT_ERR and TDC_DMA_STAT_ABORT. DMA timeout. Input pulses Filter events with pulse width lower than 100 ns (requirement). Test different input pulse arrival rate. Test timestamp threshold setup. Test time threshold setup. Testing and HW Virtualization Javier Muñoz Mellid & Samuel Iglesias Gonsalvez
MSI support. Memory Map: BAR addresses. FMC TDC Firmware Memory map: status and configuration registers, Event’s circular buffer. DMA core: memory map, registers. Input pulse generation Different parameters setup: input pulse arrival rate, pulse width, etc. Error injection As it was previously mentioned. Testing and HW Virtualization Javier Muñoz Mellid & Samuel Iglesias Gonsalvez
and virtualizer. Buildbot (http://trac.buildbot.net/) Continuous integration system designed to automate the build/test cycle. Python. Web interface to check the logs. Our own testing suite Based on Sam’s experience working with PTS in the past. Needed more flexibility: different setups for the same test. Developed in Python, as PTS. Testing and HW Virtualization Javier Muñoz Mellid & Samuel Iglesias Gonsalvez
size, virtual machine image, network, etc. Snapshot mode. Shared folders to interchange data. No screen. The kernel is pass as a parameter to QEMU -> Not using the one in the virtual machine. Timeout. If QEMU is still running after a given time, something wrong happened. Forward kernel logs to QEMU’s serial port. We can read dmesg info from host. Testing and HW Virtualization Javier Muñoz Mellid & Samuel Iglesias Gonsalvez
model of the device. Add VHDL virtualization. QEMU configuration: use config files? Buildbot: fix issues. Testing suite Add new features (hooks, etc). Choose Red Hat’s autotest framework? Testing and HW Virtualization Javier Muñoz Mellid & Samuel Iglesias Gonsalvez
