OrchardCMS module development

So, you need a Content Management System on the .NET framework. While your business might spend wheelbarrows of money on a platform that is powerful and extensible, your personal site would abandon extensibility for a free, open-source solution. But what if we had an option that was free and powerful and extensible? We do: Orchard CMS. Since we already know that Orchard is free, in this session we will discuss the power of Orchard’s CMS engine. You will learn how to build new modules for the Orchard platform, allowing you to extend functionality as you see fit to meet the needs of your site, your business, and customers.

Author:
Jay Harris
Problem Solver | Arana Software
jay@aranasoft.com | www.aranasoft.com
www.twitter.com/jayharris

Transcript

1. Orchard
   MODULES
   GROWING YOUR


   View Slide

2. We wanted a modern CMS based on ASP.NET
   MVC. We also wanted an extremely extensible
   platform similar to what PHP has with Drupal.
   But most importantly we wanted to build
   better bridges between our team at Microsoft
   and the open-source community.
   “
   ”
   Betrand Le Roy, Creator of Orchard


   View Slide

3. Content
   FUNDAMENTALS


   View Slide

4. ContentFields


   View Slide

5. ContentFields
   contain Data
   “Get in my belly!”
   “Oh noes!”


   View Slide

6. ContentParts


   View Slide

7. ContentParts
   have Behavior
   scary eye
   big sharp
   teeth
   really mean!


   View Slide

8. ContentTypes


   View Slide

9. ContentTypes
   are Consumable by Users


   View Slide

10. Types Parts Fields
    Data


    View Slide

11. Types
    Fields
    Data


    View Slide

12. content item
    a
    is an
    each
    instance of
    content type


    View Slide

13. Module/Feature


    View Slide

14. Module/Feature
    features extend the CMS
    modules contain and distribute


    View Slide

15. View Slide

16. Module
    FUNDAMENTALS


    View Slide

17. RecordsAndParts
    records are Data Models
    parts are View Models


    View Slide

18. HandlersAndDrivers
    handlers give behavior to the code
    drivers are are specialized controllers


    View Slide

19. ShapeTemplates


    View Slide

20. DependencyInjection


    View Slide

21. Controllers


    View Slide

22. ModuleManifest


    View Slide

23. A manifest stores metadata that Orchard
    uses to describe modules and themes to the
    system, such as name, version, description,
    author, and tags.”
    Manifest [Module|Theme]
    “
    docs.orchardproject.net


    View Slide

24. Name: AntiSpam
    AntiForgery: enabled
    Author: The Orchard Team
    Website: http://orchardproject.net
    Version: 1.7.2
    OrchardVersion: 1.7.2
    Description: Provides anti-spam services to protect your
    Features:
    Orchard.AntiSpam:
    Name: Anti-Spam
    Description: Provides anti-spam services to prot
    Category: Security
    Dependencies: Orchard.Tokens, Orchard.jQuery
    Akismet.Filter:
    Name: Akismet Anti-Spam Filter
    Description: Provides an anti-spam filter based
    Category: Security
    Dependencies: Orchard.AntiSpam
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18


    View Slide

25. Orchard
    EXECUTABLE


    View Slide

26. WebSiteAndConsoleApp


    View Slide

27. The Orchard command interpreter supports
    running a few built-in commands as well as
    specific commands from enabled features of
    an Orchard installation.
    “
    ” Orchard.exe


    View Slide

28. C:\Orchard\src\Orchard.Web\bin> Orchard.exe_


    View Slide

29. C:\Orchard\src\Orchard.Web\bin> Orchard.exe
    Initializing Orchard session. (This might take a few
    seconds...)
    Type "?" for help, "exit" to exit, "cls" to clear screen
    orchard> _


    View Slide

30. orchard> call me "Rock God"
    Error executing command "call me Rock God"
    ----------------------------------------------------------
    No command found matching arguments "call me Rock God".
    Commands available: site setting set baseurl, autoroute
    create, theme list, theme activate, widget create, layer
    create, menuitem create, menu create, blog create, blog
    import, ...


    View Slide

31. Module
    DEVELOPMENT


    View Slide

32. Step #1
    Code Generation


    View Slide

33. CodeGeneration


    View Slide

34. orchard> feature enable Orchard.CodeGeneration_


    View Slide

35. orchard> feature enable Orchard.CodeGeneration
    Enabling features Orchard.CodeGeneration
    Code Generation was enabled
    orchard> _


    View Slide

36. orchard> feature enable Orchard.CodeGeneration
    Enabling features Orchard.CodeGeneration
    Code Generation was enabled
    orchard> codegen module SlideShare /IncludeInSolution:true_


    View Slide

37. orchard> feature enable Orchard.CodeGeneration
    Enabling features Orchard.CodeGeneration
    Code Generation was enabled
    orchard> codegen module SlideShare /IncludeInSolution:true
    Creating Module SlideShare
    Module SlideShare created successfully
    orchard> _


    View Slide

38. ReadyGo


    View Slide

39. UpdateManifest


    View Slide

40. Name: SlideShare
    AntiForgery: enabled
    Author: Jay Harris, Arana Software
    Website: http://www.aranasoft.com
    Version: 1.0
    OrchardVersion: 1.0
    Description: Provide SlideShare presentations as an atta
    Features:
    SlideShare:
    Description: Provide SlideShare presentations as an
    Category: Social
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18


    View Slide

41. Step #2
    Records & Parts


    View Slide

42. RecordsAndParts
    AddNewClass


    View Slide

43. namespace SlideShare.Models {
    public class SlideShareRecord {
    }
    }
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10


    View Slide

44. using Orchard.ContentManagement.Records;
    namespace SlideShare.Models {
    public class SlideShareRecord : ContentPartRecord {
    }
    }
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10


    View Slide

45. using Orchard.ContentManagement.Records;
    namespace SlideShare.Models {
    public class SlideShareRecord : ContentPartRecord {
    public virtual string SlideShareId { get; set; }
    public virtual int? StartFromSlide { get; set; }
    }
    }
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10


    View Slide

46. Use Namespace
    MODELS
    or
    RECORDS


    View Slide

47. Mark Properties
    VIRTUAL


    View Slide

48. Mind Your
    BASE CLASS


    View Slide

49. using Orchard.ContentManagement.Records;
    namespace SlideShare.Models {
    public class SlideShareRecord : ContentPartRecord {
    public virtual string SlideShareId { get; set; }
    public virtual int? StartFromSlide { get; set; }
    }
    }
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10


    View Slide

50. using Orchard.ContentManagement;
    using Orchard.ContentManagement.Records;
    namespace SlideShare.Models {
    public class SlideShareRecord : ContentPartRecord {
    public virtual string SlideShareId { get; set; }
    public virtual int? StartFromSlide { get; set; }
    }
    public class SlideSharePart :
    ContentPart {
    }
    }
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18


    View Slide

51. public class SlideSharePart :
    ContentPart {
    public string SlideShareId {
    get { return Record.SlideShareId; }
    set { Record.SlideShareId = value; }
    }
    [Range(1, 20)]
    public int? StartFromSlide {
    get { return Record.StartFromSlide; }
    set { Record.StartFromSlide = value; }
    }
    }
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    23
    24
    25
    26


    View Slide

52. Compile
    Before Proceeding


    View Slide

53. Step #3
    Data Migration


    View Slide

54. orchard> codegen datamigration SlideShare_


    View Slide

55. orchard> codegen datamigration SlideShare
    Creating Data Migration for SlideShare
    Data migration created successfully in Module SlideShare
    orchard> _


    View Slide

56. DataMigration


    View Slide

57. using System.Data;
    using Orchard.Data.Migration;
    namespace SlideShare {
    public class Migrations : DataMigrationImpl {
    public int Create() {
    // Creating table SlideShareRecord
    SchemaBuilder.CreateTable("SlideShareRecord",
    table => table
    !!!! .ContentPartRecord()
    !!!! .Column("SlideShareId", DbType.String)
    !!!! .Column("StartFromSlide", DbType.Int32)
    );
    return 1;
    }
    }
    }
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18


    View Slide

58. // column methods can use generic types...
    !!!! .Column("SlideShareId")
    !!!! .Column("StartFromSlide")
    // or they can use a DbType argument.
    !!!! .Column("SlideShareId", DbType.String)
    !!!! .Column("StartFromSlide", DbType.Int32)
    // either way. just not both.
    11
    12
    13
    11
    12
    13


    View Slide

59. public class Migrations : DataMigrationImpl {
    public int Create() {
    // The ‘return’ is for versioning
    return 1;
    }
    public int UpdateFrom1() {
    // Do some data migrations
    return 2;
    }
    public int UpdateFrom2() {
    // More data migrations
    return 3;
    }
    }
    5
    6
    14
    15
    16
    25
    26
    27
    33
    34
    35


    View Slide

60. Indicates if administrators can attach the
    Content Part to any Content Type, or if the
    Part is limited only to Types explicitly
    specified by the Module. ”
    Attachable [Content Part]
    “


    View Slide

61. using System.Data;
    using Orchard.ContentManagement.MetaData;
    using Orchard.Core.Contents.Extensions;
    using Orchard.Data.Migration;
    using SlideShare.Models;
    namespace SlideShare {
    public class Migrations : DataMigrationImpl {
    public int UpdateFrom1() {
    ContentDefinitionManager.AlterPartDefinition(
    "SlideSharePart", cfg => cfg.Attachable());
    return 2;
    }
    }
    }
    1
    2
    3
    4
    5
    6
    7
    8
    17
    18
    19
    20
    21
    22
    23
    24


    View Slide

62. using System.Data;
    using Orchard.ContentManagement.MetaData;
    using Orchard.Core.Contents.Extensions;
    using Orchard.Data.Migration;
    using SlideShare.Models;
    namespace SlideShare {
    public class Migrations : DataMigrationImpl {
    public int UpdateFrom1() {
    ContentDefinitionManager.AlterPartDefinition(
    typeof(SlideSharePart).Name, cfg => cfg.Attachable(
    return 2;
    }
    }
    }
    1
    2
    3
    4
    5
    6
    7
    8
    17
    18
    19
    20
    21
    22
    23
    24


    View Slide

63. Step #4
    Handlers & Drivers


    View Slide

64. CreateHandler


    View Slide

65. Most Handlers will be very simple behavior
    managers. Often, the only behavior they will
    have to specify is how data is to be stored.”
    Part Handlers
    “


    View Slide

66. using SlideShare.Models;
    using Orchard.ContentManagement.Handlers;
    using Orchard.Data;
    namespace SlideShare.Handlers {
    public class SlideShareHandler : ContentHandler {
    public SlideShareHandler(
    IRepository repository)
    {
    Filters.Add(StorageFilter.For(repository));
    }
    }
    }
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18


    View Slide

67. CreateDriver


    View Slide

68. using System;
    using Orchard.ContentManagement;
    using Orchard.ContentManagement.Drivers;
    using SlideShare.Models;
    namespace SlideShare.Drivers {
    public class SlideShareDriver :
    ContentPartDriver {
    }
    }
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13


    View Slide

69. protected override DriverResult Display(
    SlideSharePart part,
    string displayType,
    dynamic shapeHelper) {
    return ContentShape("Parts_SlideShare",
    () => shapeHelper.Parts_SlideShare(
    SlideShareId: part.SlideShareId,
    StartFromSlide: part.StartFromSlide
    )
    );
    }
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21


    View Slide

70. //GET
    protected override DriverResult Editor(
    SlideSharePart part,
    dynamic shapeHelper) {
    return ContentShape("Parts_SlideShare_Edit",
    () => shapeHelper.EditorTemplate(
    TemplateName: "Parts/SlideShare",
    Model: part,
    Prefix: Prefix
    )
    );
    }
    23
    24
    25
    26
    27
    28
    29
    30
    31
    32
    33
    34
    35


    View Slide

71. //POST
    protected override DriverResult Editor(
    SlideSharePart part,
    IUpdateModel updater,
    dynamic shapeHelper) {
    updater.TryUpdateModel(part, Prefix, null, null);
    return Editor(part, shapeHelper);
    }
    37
    38
    39
    40
    41
    42
    43
    44
    45


    View Slide

72. Step #5
    Shape Templates


    View Slide

73. DisplayTemplate


    View Slide

74. Mind Your
    VIEW PATHS


    View Slide

75. protected override DriverResult Display(
    SlideSharePart part,
    string displayType,
    dynamic shapeHelper)
    {
    return ContentShape("Parts_SlideShare",
    () => shapeHelper.Parts_SlideShare(
    SlideShareId: part.SlideShareId,
    StartFromSlide: part.StartFromSlide
    )
    );
    }
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21


    View Slide

76. “Parts_SlideShare”
    Views/Parts/SlideShare.cshtml
    translates to


    View Slide

77. width="427" height="356" frameborder="0"
    marginwidth="0" marginheight="0"
    scrolling="no" allowfullscreen
    style="border: 1px solid #CCC; border-width: 1px 1px
    0; margin-bottom: 5px">

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10


    View Slide

78. @if(!string.IsNullOrWhiteSpace(Model.SlideShareId as
    string))
    {
    width="427" height="356" frameborder="0"
    marginwidth="0" marginheight="0"
    scrolling="no" allowfullscreen
    style="border: 1px solid #CCC; border-width: 1px 1px
    0; margin-bottom: 5px">

    }
    1
    2
    3
    4
    5
    6
    7
    8
    9


    View Slide

79. @if(!string.IsNullOrWhiteSpace(Model.SlideShareId as
    string))
    {
    var startSlide = Model.StartFromSlide as int?;
    var startSlideQS = startSlide.HasValue
    ? string.Format("startSlide={0}", startSlide.Value)
    : string.Empty;
    var slideShareUrl = string.Format(
    "http://www.slideshare.net/slideshow/embed_code/
    {0}?{1}",
    Model.SlideShareId,
    startSlideQS);
    width="427" height="356" frameborder="0"
    marginwidth="0" marginheight="0"
    scrolling="no" allowfullscreen
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16


    View Slide

80. EditorTemplate


    View Slide

81. //GET
    protected override DriverResult Editor(
    SlideSharePart part,
    dynamic shapeHelper)
    {
    return ContentShape("Parts_SlideShare_Edit",
    () => shapeHelper.EditorTemplate(
    TemplateName: "Parts/SlideShare",
    Model: part,
    Prefix: Prefix
    )
    );
    }
    23
    24
    25
    26
    27
    28
    29
    30
    31
    32
    33
    34
    35


    View Slide

82. “Parts/SlideShare”
    Views/EditorTemplates/
    Parts/SlideShare.cshtml
    translates to


    View Slide

83. @model SlideShare.Models.SlideSharePart

    SlideShare Fields

    @Html.LabelFor(m => m.SlideShareId)


    @Html.TextBoxFor(m => m.SlideShareId)
    @Html.ValidationMessageFor(m => m.SlideShareId)


    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11


    View Slide

84. @model SlideShare.Models.SlideSharePart

    SlideShare Fields

    @Html.LabelFor(m => m.SlideShareId)


    @Html.TextBoxFor(m => m.SlideShareId)
    @Html.ValidationMessageFor(m => m.SlideShareId)


    @Html.LabelFor(m => m.StartFromSlide)


    @Html.TextBoxFor(m => m.StartFromSlide)
    @Html.ValidationMessageFor(m => m.StartFromSlide)


    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18


    View Slide

85. ShapePlacement


    View Slide

86. View Slide

87. Celebrate


    View Slide

88. EnableFeature


    View Slide

89. AddContentDone


    View Slide

90. Module
    DISTRIBUTION


    View Slide

91. OrchardPackaging


    View Slide

92. orchard> feature enable Orchard.Packaging
    Enabling features Orchard.Packaging
    Packaging was enabled
    orchard> _


    View Slide

93. orchard> feature enable Orchard.Packaging
    Enabling features Orchard.Packaging
    Packaging was enabled
    orchard> package create SlideShare C:\Code_


    View Slide

94. orchard> feature enable Orchard.Packaging
    Enabling features Orchard.Packaging
    Packaging was enabled
    orchard> package create SlideShare C:\Code
    Package "C:\Code\Orchard.Module.SlideShare.1.0.nupkg"
    successfully created
    orchard> _


    View Slide

95. ...you’ll be able to achieve all kinds of
    glory and fame.
    “ ” orchardproject.net


    View Slide

96. View Slide

97. View Slide

98. View Slide

99. View Slide

100. View Slide

101. View Slide

102. Profit


     View Slide

103. github.com/aranasoft


     View Slide

104. bit.ly/growingOrchard


     View Slide

105. ...you’ll be able to achieve all kinds of
     glory and fame.
     “ ” orchardproject.net


     View Slide

106. jay harris
     P R E S I D E N T
     jay@aranasoft.com
     #growingOrchard
     @jayharris


     View Slide

107. Thanks


     View Slide
