1. The first 200 milliseconds of HTTPS
   1
   Joshua Thijssen
   jaytaph


   View Slide

2. ➡ What’s happening in the first 200+
   milliseconds on a HTTPS connection.
   ➡ Give tips and hints on hardening your setup.
   ➡ Give you insights in new and upcoming
   technologies.
   ➡ Show you things to you (probably) didn’t
   knew.
   2


   View Slide

3. This talk is inspired by
   a blogpost from Jeff Moser
   http://www.moserware.com/2009/06/first-few-milliseconds-of-https.html
   Unknown fact!
   3


   View Slide

4. HTTPwut?
   4


   View Slide

5. HTTP over TLS
   5
   Transport Layer Security


   View Slide

6. Secure Socket Layer
   (SSL)
   6
   A short and scary history


   View Slide

7. then
   now
   feb
   1995
   SSL 2.0
   Not-so-secure-socket-layer
   jun
   1996
   SSL 3.0
   Something stable!
   jan
   1999
   TLS 1.0
   SSL 3.1
   apr
   2006
   TLS 1.1
   TLS 1.2
   aug
   2008
   SSL 1.0
   Vaporware
   1994
   7


   View Slide

8. https://www.trustworthyinternet.org/ssl-pulse/
   Supported versions - november 2013
   25,7%
   99,6% 99,3%
   18,2% 20,7%
   SSL 2.0 SSL 3.0 TLS 1.0 TLS 1.1 TLS 1.2
   8
   borked
   meh
   ok


   View Slide

9. RFC 5246
   (TLS v1.2)
   9


   View Slide

10. ➡ Binary protocol - so no quick
    telnet-to-see-if-it-works*
    ➡ Difficult algorithms and handshakes
    ➡ (Easy) extendible
    10
    * We can with openssl


    View Slide

11. 11
    https://github.com/vincentbernat/rfc5077/blob/master/ssl-handshake.svg


    View Slide

12. Attention:
    (live)
    wiresharking
    up ahead
    12


    View Slide

13. View Slide

14. View Slide

15. Generating
    randomness is HARD
    15


    View Slide

16. entropy
    (uncertainty)
    16


    View Slide

17. TIME is NOT random
    thus not a very good
    entropy source
    17


    View Slide

18. PHP is bad
    when it comes to
    entropy
    18
    Unknown fact!


    View Slide

19. srand(microtime())
    19
    Unknown fact!


    View Slide

20. openssl_pseudo_random_bytes()
    read from /dev/(u)random
    Use a HRNG
    “A million random digits”
    https://github.com/ircmaxell/RandomLib
    20


    View Slide

21. View Slide

22. TLS_ECDHE_ECDSA_WITH_AES_128_GCM_SHA256
    22


    View Slide

23. TLS
    ECDHE_ECDSA
    WITH
    AES_128_GCM
    SHA256
    Used for exchanging
    key information
    Used for authenticating
    key information
    Used for message
    authenticating
    Actual cipher (and
    length) used for
    communication
    Block cipher mode
    23


    View Slide

24. TLS_RSA_WITH_AES_256_CBC_SHA256
    24


    View Slide

25. TLS_NULL_WITH_NULL_NULL
    25


    View Slide

26. Client gives cipher options,
    Server ultimately decides on cipher!
    26


    View Slide

27. THIS IS WHY YOU SHOULD ALWAYS
    CONFIGURE YOUR CIPHERS
    ON YOUR WEBSERVER!
    27
    Unknown fact!


    View Slide

28. SSLProtocol all -SSLv2 -SSLv3
    SSLHonorCipherOrder on
    SSLCipherSuite "EECDH+ECDSA+AESGCM EECDH+aRSA+AESGCM EECDH+ECDSA+SHA384 \
    EECDH+ECDSA+SHA256 EECDH+aRSA+SHA384 EECDH+aRSA+SHA256 EECDH+aRSA+RC4 \
    EECDH EDH+aRSA RC4 !aNULL !eNULL !LOW !3DES !MD5 !EXP !PSK !SRP !DSS"
    ssl_protocols TLSv1 TLSv1.1 TLSv1.2;
    ssl_prefer_server_ciphers on;
    ssl_ciphers "EECDH+ECDSA+AESGCM EECDH+aRSA+AESGCM EECDH+ECDSA+SHA384 \
    EECDH+ECDSA+SHA256 EECDH+aRSA+SHA384 EECDH+aRSA+SHA256 EECDH+aRSA+RC4 \
    EECDH EDH+aRSA RC4 !aNULL !eNULL !LOW !3DES !MD5 !EXP !PSK !SRP !DSS";
    Apache
    Nginx
    28
    https://community.qualys.com/blogs/securitylabs/2013/08/05/configuring-apache-nginx-and-openssl-for-forward-secrecy


    View Slide

29. https://www.ssllabs.com/ssltest/
    29


    View Slide

30. View Slide

31. View Slide

32. 32
    ➡ SNI (Server Name Indication)
    ➡ Extension 0x0000
    ➡ Pretty much every decent browser /
    server.
    ➡ Isn’t supported by: IE6, Win XP,
    Blackberry, Android 2.x
    ➡ So no worries!


    View Slide

33. View Slide

34. View Slide

35. View Slide

36. View Slide

37. What an SSL certificate is NOT:
    37
    ➡ SSL certificate (but a X.509 certificate)
    ➡ Automatically secure
    ➡ Automatically trustworthy
    ➡ In any way better self-signed certificates
    ➡ Cheap


    View Slide

38. What an SSL certificate is:
    38
    ➡ The best way (but not perfect) to prove authenticity
    ➡ A way to bootstrap encrypted communication
    ➡ Misleading
    ➡ (Too) Expensive


    View Slide

39. 39
    ➡ X.509 Certificate
    ➡ Owner info (who is this owner)
    ➡ Domain info (for which domain(s) is
    this certificate valid)
    ➡ Expiry info (from when to when is this
    certificate valid)


    View Slide

40. View Slide

41. 41
    yourdomain.com
    Root
    CA
    Intermediate
    CA


    View Slide

42. 42
    IMPLIED TRU$T


    View Slide

43. ➡ (Root) Certificate Authorities
    ➡ They are built into your browser / OS
    and you will automatically trust them.
    43


    View Slide

44. 44
    wget http://mxr.mozilla.org/mozilla-central/source/security/nss/lib/ckfw/builtins/certdata.txt\?raw\=1 -O - -q | grep Issuer | sort | uniq | wc -l
    174


    View Slide

45. View Slide

46. View Slide

47. 47
    pre master secret server rand
    client rand
    master secret
    client MAC client KEY client IV server MAC server KEY server IV
    master secret server rand client rand
    key buffer
    Generating secrets:
    + +
    +
    +


    View Slide

48. View Slide

49. View Slide

50. View Slide

51. View Slide

52. View Slide

53. 53
    Wireshark CAN decrypt your HTTPS traffic
    Unknown fact!
    SSLKEYLOGFILE
    https://isc.sans.edu/forums/diary/Psst+Your+Browser+Knows+All+Your+Secrets+/16415


    View Slide

54. 54
    launchctl setenv SSLKEYLOGFILE /tmp/keylog.secret
    on a mac:


    View Slide

55. View Slide

56. ➡ TLS has overhead in computation and
    transfers. But definitely worth it.
    ➡ Some ciphersuites are better, but slower
    ➡ Speed / Security compromise
    ➡ (try: “openssl speed”)
    56


    View Slide

57. Are we safe yet?
    57


    View Slide

58. euh,.. no :/
    58


    View Slide

59. 59
    PRE MASTER
    SECRET


    View Slide

60. What if somebody*
    got hold of the site
    private key?
    60


    View Slide

61. View Slide

62. View Slide

63. View Slide

64. 64
    Playing the waiting game...


    View Slide

65. View Slide

66. View Slide

67. (PERFECT)
    FORWARDING
    SECRECY
    67


    View Slide

68. Compromising the
    pre-master secret does
    not compromise our
    communication.
    68


    View Slide

69. PFS:
    Can’t compromise
    other keys with a
    compromised key.
    69


    View Slide

70. Unfortunately..
    70


    View Slide

71. 71
    PFS needs server
    AND browser support


    View Slide

72. 72
    http://news.netcraft.com/archives/2013/06/25/ssl-intercepted-today-decrypted-tomorrow.html


    View Slide

73. 73
    http://news.netcraft.com/archives/2013/06/25/ssl-intercepted-today-decrypted-tomorrow.html


    View Slide

74. All bets are of when
    using MS and Apple.
    74


    View Slide

75. Update your cipher
    suite list and place
    PFS ciphers at the top
    75


    View Slide

76. But beware:
    heavy computations
    76


    View Slide

77. 77
    SSL Test
    https://www.ssllabs.com/ssltest/


    View Slide

78. -ETOOMUCHINFO
    78


    View Slide

79. 79
    ➡ Unless you got good reasons not to, get
    the cheapest certificate possible.
    ➡ Add the HTTP Strict Transport Security
    header.
    ➡ Don’t support SSLv3 or older
    ➡ Support PFS
    ➡ Check through https://ssllabs.com/ssltest


    View Slide

80. 80
    https://www.ssllabs.com/projects/best-practices/index.html


    View Slide

81. http://farm1.static.flickr.com/73/163450213_18478d3aa6_d.jpg 81


    View Slide

82. 82
    Find me on twitter: @jaytaph
    Find me for development and training: www.noxlogic.nl
    Find me on email: jthijssen@noxlogic.nl
    Find me for blogs: www.adayinthelifeof.nl
    http://joind.in/10292
