Securing RESTful APIs using OAuth 2 and OpenID Connect

Constructing a successful and simple API is the lifeblood of your developer community, and REST is a simple standard through which this can be accomplished. As we construct our API and need to secure the system to authenticate and track applications making requests, the open standard of OAuth 2 provides us with a secure and open source method of doing just this. In this talk, we will explore REST and OAuth 2 as standards for building out a secure API infrastructure, exploring many of the architectural decisions that PayPal took in choosing variations in the REST standard and specific implementations of OAuth 2.

Transcript

1. Securing RESTful APIs Using OAuth 2 and OpenID Connect Jonathan LeBlanc (@jcleblanc) Head of Developer Evangelism (NA)
2. What We’re Covering Auth History and REST Concepts Adding in an Auth Mechanism Integration in Practice (server + client side integrations)
3. What We Want
4. The Ultimate Decision Security   Usability
5. Path to the Standard
6. The Insecure, Unmanageable Start
7. Very Secure, Long to Implement
8. Two Currently Widely Used Specs
9. REST Architecture
10. What a RESTful API isn’t Our API is RESTful, we support GET, PUT, POST, and DELETE requests   No…actually you just support HTTP…like the rest of the web.
11. What a RESTful API is Honor HTTP request verbs Use proper HTTP status codes No version numbering in URIs Return format via HTTP Accept header
12. Does Anyone Actually Do That? Very few APIs follow pragmatic REST principles
13. HATEOAS
14. "links": [{ "href": "https://api.sandbox.paypal.com/v1/payments/ payment/PAY-6RV75EKEYSZ6Y", "rel": "self", "method": "GET" },{ "href": "https://www.sandbox.paypal.com/webscr? cmd=_express-checkout&token=EC-6019609", "rel": "approval_url", "method": "REDIRECT" },{ "href": "https://api.sandbox.paypal.com/v1/payments/ payment/PAY-6RV75EKEYSZ6Y/execute", "rel": "execute", "method": "POST" } ]
15. Adding Auth Mechanisms
16. When You Need Access Security
17. A Few Different Flavors of Usage User login (authentication) Application only (bearer tokens) User Involvement (authorization)
18. Fetching a Code Prepare the Redirect URI Authorization Endpoint client_id response_type (code) scope redirect_uri nonce state Browser Redirect Redirect URI
19. Fetching the Access Token Fetch the Access Token Access Token Endpoint client_id code (query string) client_secret grant_type HTTP POST Access Token Endpoint
20. A few implementation differences Endpoints Scopes (dynamic / static) Using the Access Token in a request
21. Practical Implementation
22. Making Your Definitions <?php   define("CLIENT_ID",  "YOUR  CLIENT  ID");   define("CLIENT_SECRET",  "YOUR  CLIENT  SECRET");       define("URI_SANDBOX",  "h;ps://api.sandbox.paypal.com/v1/");   define("URI_LIVE",  "h;ps://api.paypal.com/v1/");   ?>
23. class  paypal{          private  $access_token;          private  $token_type;                    public  func1on  __construct(){                  $postvals  =  "grant_type=client_credenWals";                  $uri  =  URI_SANDBOX  .  "oauth2/token";                                    $auth_response  =  self::curl($uri,  'POST',  $postvals,  true);                  $this-­‐>access_token  =  $auth_response['body']-­‐>access_token;                  $this-­‐>token_type  =  $auth_response['body']-­‐>token_type;          }            …   }
24. private  func1on  curl($url,  $method  =  'GET',  $postvals  =  null,  $auth  =  false){        $ch  =  curl_init($url);                          if  ($auth){              $headers  =  array("Accept:  applicaWon/json",                                                                                "Accept-­‐Language:  en_US");              curl_setopt($ch,  CURLOPT_HTTPAUTH,  CURLAUTH_BASIC);              curl_setopt($ch,  CURLOPT_USERPWD,  CLIENT_ID  .  ":"  .CLIENT_SECRET);        }  else  {              $headers  =  array("Content-­‐Type:applicaWon/json",                      "AuthorizaWon:{$this-­‐>token_type}  {$this-­‐>access_token}");        }
25. $opWons  =  array(                  CURLOPT_HEADER  =>  true,                  CURLINFO_HEADER_OUT  =>  true,                  CURLOPT_HTTPHEADER  =>  $headers,                  CURLOPT_RETURNTRANSFER  =>  true,                  CURLOPT_VERBOSE  =>  true,                  CURLOPT_TIMEOUT  =>  10          );                                    if  ($method  ==  'POST'){                  $opWons[CURLOPT_POSTFIELDS]  =  $postvals;                  $opWons[CURLOPT_CUSTOMREQUEST]  =  $method;          }                            curl_setopt_array($ch,  $opWons);                                  $response  =  curl_exec($ch);          return  $response;   }
26. Making a Call with the Token public  func1on  process_payment($request){          $postvals  =  $request;          $uri  =  URI_SANDBOX  .  "payments/payment";          return  self::curl($uri,  'POST',  $postvals);   }
27. OAuth 2 & JavaScript?
28. A Little Use Background User login Application only User Involvement
29. User Agent Flow: Redirect Prepare the Redirect URI Authorization Endpoint client_id response_type (token) scope redirect_uri Browser Redirect Redirect URI
30. User Agent Flow: Redirect Building the redirect link var auth_uri = auth_endpoint + "?response_type=token" + "&client_id=" + client_id + "&scope=profile" + "&redirect_uri=" + window.location; $("#auth_btn").attr("href", auth_uri);
31. User Agent Flow: Hash Mod Fetch the Hash Mod access_token refresh_token expires_in Extract Access Token
32. User Agent Flow: Hash Mod http://site.com/callback#access_token=rBEGu1FQr5 4AzqE3Q&refresh_token=rEBt51FZr54HayqE3V4a& expires_in=3600 var hash = document.location.hash; var match = hash.match(/access_token=(\w+)/); Extracting the access token from the hash
33. User Agent Flow: Get Resources Set Request Headers + URI Resource Endpoint Header: token type + access token Header: accept data type HTTPS Request
34. User Agent Flow: Get Resources $.ajax({ url: resource_uri, beforeSend: function (xhr) { xhr.setRequestHeader('Authorization', 'OAuth ' + token); xhr.setRequestHeader('Accept', 'application/json'); }, success: function (response) { //use response object } }); Making an authorized request
35. Using the Skeleton Key
36. How it’s Normally Used Access user details Push data through user social streams
37. But why? Access token as a control structure Improve Existing Products Our showcase: Seamless Checkout
38. A Few Code Links OAuth2 & OpenID Connect Samples https://github.com/jcleblanc/oauth https://github.com/paypal/paypal-access Log in with PayPal http://bit.ly/loginwithpaypal
39. The Last Considerations REST and OAuth are specifications, not religions Don’t alienate your developers with security Open source is your friend
40. Thank You! Questions? http://slideshare.net/jcleblanc Jonathan LeBlanc (@jcleblanc) Head of Developer Evangelism (NA)
