1. Building apps using Kotlin Native A pragmatic, introduction and overview Jeremy Rempel
2. Intro
3. R&D
6. What is this talk? • Why Multiplatform? • Introduction to Kotlin Native technology • Basic Android/iOS App • Comparison to other tech such as Flutter • Current state of Kotlin Native • Not a deep dive
8. The Status Quo • 2 code bases (Swift/ObjC) + (Java/Kotlin). DRY • 2 teams with no common language or architecture • Accidental differences resulting in tech debt • The more the codebases diverge the harder it is to maintain and update • We’re spending a lot of time on boilerplate and architecture • Cross platform code is the history of computing
9. Android Developers are from Mars iOS Developers are from Venus
10. • Code sharing is a solution; Figure out what problem you are attempting to solve • Evaluate your team, app and existing codebase • Code sharing doesn’t make sense for all projects • Avoid HDD and Whataboutisms. Do your own analysis Your App Multi Platform
11. Writing code once, running on multiple platforms… Is a Super Power
12. What now? • Finding common ground and shared problems is the first step • Android and iOS developers need to understand basics and tradeoffs of each platform • VIPER, Clean Architecture, MVVM, MVP, MVI are all solving similar problems • We can’t share code until we start breaking down barriers
13. My MPP Wish List • Avoid big decisions, incremental adoption, reduce risk • Integration with underlying platform should be default not exception • Choose the when and what to share. Empower not limit • Reuse one of the supported languages (Kotlin, Swift) Avoid introducing yet another language • Reuse existing skillsets, build tools, IDEs, libraries and tooling
14. People don’t want to use your software, Its about the users! They want to go shopping, lose weight, laugh, be entertained, get smarter, spend time with loved ones, go home on time, sleep better, eat good food and be happy Your product is only as good as the experiences it enables people to have
15. What is KN? • Compiler toolchain, backend LLVM • Compiles to different targets where virtual machines are not available such as iOS • One dependency: Kotlin stdlib • Memory management via reference counting and GC for cycles
16. Interop with iOS • Kotlin Native is provided as an Objective-C binary with header • CocoaPod integration • Common Kotlin code can access iOS platform APIs such as Foundation and UIKit • Ability to utilize all existing abstractions (classes, interfaces, lambdas, exceptions) • Kotlin Native is a library not a framework
17. fun main() = println("hello world”) ➜ kotlinc helloworld.kt Kotlin JVM ➜ java HelloworldKt hello world ➜ file HelloworldKt.class HelloworldKt.class: compiled Java class data, version 50.0 (Java 1.6)
18. fun main() = println("hello world”) ➜ kotlinc-native helloworld.kt Kotlin Native ➜ ./helloworld.kexe hello world ➜ file helloworld.kexe helloworld.kexe: Mach-O 64-bit executable x86_64
19. Compiling for iOS ➜ ./gradlew :lib:linkMainDebugFrameworkIos BUILD SUCCESSFUL in 9s fun main() = println("hello world”) • ➜ file main main: Mach-O 64-bit dynamically linked shared library x86_64 ➜ file Headers/main.h Headers/main.h: Objective-C source text, ASCII text, with very long lines
20. “So just some gradle magic and I can have iOS app for free?“
21. Shared Common Common Module (Kotlin) Android libs (Kotlin+Java) Android App (Kotlin+Java) iOS App (Swift+ObjC) iOS Framework (Kotlin) Android AAR (Kotlin) MPP Libs (Kotlin)
22. Project Structure
23. Kotlin Modules • Common: Kotlin code compiled to all platforms. Limited • iOS: Compiled to only iOS • Can use Objective C, Swift libs • Android: Compiled to only Android • Can use Android and Java libs
24. Bridging the Gap • Common code that can only use Kotlin stdlib is not useful enough on its own • Kotlin MPP introduces expect and actual • expect defined in the common module defines behavior such as fun log(message: String) • actual provides declaration of how to fulfill the request using the platform specific APIs
25. Example: Logger • Timber is not available on Kotlin Native (yet) • Lets take build our own logger • Accept a Log Level (Debug, Info, Error, Fatal), String and optional exception
26. Native Logger
27. IDE Context
28. iOS Actual import platform.Foundation.NSLog actual fun log(level: LogLevel, tag: String, message: String, error: Throwable) { NSLog("[$level]: ($tag), $message, $error") } actual fun log(level: LogLevel, tag: String, message: String) { NSLog("[$level]: ($tag)") }
29. Android Actual import android.util.Log actual fun log(level: LogLevel, tag: String, message: String, error: Throwable) { when (level) { is LogLevel.DEBUG -> Log.d(tag, message, error) is LogLevel.INFO -> Log.i(tag, message, error) is LogLevel.WARN -> Log.w(tag, message, error) is LogLevel.ERROR -> Log.e(tag, message, error) } } actual fun log(level: LogLevel, tag: String, message: String) { when (level) { is LogLevel.DEBUG -> Log.d(tag, message) is LogLevel.INFO -> Log.i(tag, message) is LogLevel.WARN -> Log.w(tag, message) is LogLevel.ERROR -> Log.e(tag, message) } }
31. App: Android View: Fragment Interactor: Business Logic Repository: Persistence (Sqlite, Shared Pref) Repository: Networking (Http, Serialization) Presenter DI: Dagger App: iOS View: UIViewController Common DI: Custom
32. Repository Serialization JSON • Jetbrains provides 1st party library support via kotlinx.serialization • JSON, CBOR and Protobuf out of box • Annotation based on Kotlin data classes
33. apply plugin: 'kotlinx-serialization'
34. data class Greeting(val name: String) @Serializable
35. val input = """ {"name": “Hello Droidcon”} """ data class Greeting(val name: String) @Serializable val result: Greeting = Json.parse(Greeting.serializer(), input)
36. Repository Http Ktor • Android engine provided by OkHttp+OkIO or HttpUrlConnection • iOS engine provided by async NSURLSession
37. implementation “io.ktor:ktor- client-core:$ktor_version" implementation "io.ktor:ktor- client-json:$ktor_version"
38. val client = HttpClient { }
39. val client = HttpClient { Json { serializer = KotlinxSerializer().apply { register(Greeting.serializer()) } } }
40. suspend fun getGreeting(): Greeting { }
41. suspend fun getGreeting(): Greeting { } return client.get { url { takeFrom(“http://myserver") encodedPath = “/greeting/" } }
42. Repository Http Ktor Tests val mockResponse = """{"name": “Droidcon”}""" val client = HttpClient(MockEngine) { }
43. val mockResponse = """{"name": “Droidcon”}""" val client = HttpClient(MockEngine) { } engine { addHandler { respond( mockResponse, HttpStatusCode.OK, headersOf( HttpHeaders.ContentType, “application/json" ) ) } } Json { serializer = KotlinxSerializer().apply { register(Greeting.serializer()) } }
44. runBlockingTest { val service = Service(client, “http://myapi”) val actualResponse = service.getGreeting() val expectedResponse = Greeting(“Hello Droidcon”) assertEquals( actualResponse, expectedResponse ) } @Test fun `run http mock test`() { }
45. Repository: Kotlin interface GreetingApi { suspend fun getGreeting(): Greeting }
46. Repository: Kotlin class GreetingService( private val client: HttpClient, private val serverEndPoint: String ) : GreetingApi { } override suspend fun getGreeting(): Greeting = client.get { url { takeFrom(serverEndPoint) encodedPath = "/greeting/" } }
47. Common Testing • Common unit tests are compiled and executed on each platform • Android tests execute on JVM, iOS tests use xrun • IDE support for unit testing is still incomplete • No mockk support yet, need to create your own Mocks, Stubs & Spys
48. // view implemented native interface GreetingView { var isUpdating: Boolean fun onUpdate(data: Greeting) } MVP Contract: Kotlin // actions, presenter common interface GreetingActions { fun onRequestData() }
49. Presenter: Kotlin } class GreetingPresenter( uiContext: CoroutineContext, private val useCase: GreetingUseCase, private val view: GreetingsView ) : CoroutinePresenter(uiContext),GreetingsActions {
50. Presenter: Kotlin } override fun onRequestData() { view.isUpdating = true launch(coroutineContext) { val result = useCase.getGreeting() view.onUpdate(result) }.invokeOnCompletion { view.isUpdating = false } } class GreetingPresenter( uiContext: CoroutineContext, private val useCase: GreetingUseCase, private val view: GreetingsView ) : CoroutinePresenter(uiContext),GreetingsActions {
51. Interactor: Kotlin class GreetingUseCase( private val api: GreetingApi private val db: GreetingQueries ) { } suspend fun getGreeting(): Greeting { // check cache first val cache = db.select() if (cache != null) return cache // get from remote val greeting = api.getGreeting() // transform val result = greeting.copy( name = greeting.name.trim().toUpperCase() ) // update cache db.insertOrReplace(result) return result }
52. Sqlite Persistence: SqlDelight CREATE TABLE greeting ( name TEXT NOT NULL ); insertOrReplace: INSERT OR REPLACE INTO greeting(name) VALUES ?; select: SELECT * FROM greeting;
53. iOS Integration Podfile myapp/iosApp on  master [$+] ➜ cat Podfile # Either use_frameworks! or use_modular_headers! must be specified. use_frameworks! platform :ios, '12.2' target 'ios-App' do pod 'lib', :path => '../lib' end
54. Xcode
55. ViewController: Swift import UIKit import lib class GreetingViewController: UIViewController { }
56. ViewController: Swift override func viewDidLoad() { super.viewDidLoad() // Greeting is a Kotlin data class let greeting = Greeting( name: “Hello Droidcon" ) } import UIKit import lib class GreetingViewController: UIViewController { }
57. Dependency Injection iOS let apiUrl:String = “https://myapi.com” let client:Ktor_client_coreHttpClient = DIKt.getHttpClient() let service: GreetingApi = DIKt.getService(client: client, apiUrl: apiUrl)
58. Presenter: Swift override func viewDidLoad() { super.viewDidLoad() // obtain dependencies let view: GreetingsView = self let presenter = GreetingsPresenter( uiContext: uiContext, view: view, api: service) ) } } class GreetingController: UIViewController, GreetingsView {
59. UI View Controller: Swift func loadData() { presenter.onRequestData() } override func onUpdate(response: Greeting) { updateUi(response) }
60. Coroutine Context: Swift public class UI: Kotlinx_coroutines_coreCoroutineDispatcher { } override public func dispatch(context: KotlinCoroutineContext, block: Kotlinx_coroutines_coreRunnable) { } DispatchQueue.main.async { block.run() }
61. Dependency Injection: Kotlin Dagger Module @Module class ServiceModule { } @Provides @Singleton fun providesHttp() = HttpClient() @Provides @Singleton fun providesGreetingApi(client: HttpClient, @Named("APIURL") apiUrl: String): GreetingApi { return GreetingService(client, apiUrl) } @Provides @Singleton fun providesActions(): GreetingActions = GreetingPresenter(…)
62. Dependency Injection: Dagger Component @Component(modules = [ServiceModule::class]) { } @Singleton interface ContentFragmentComponent { fun inject(frag: GreetingFragment)
63. class GreetingFragment() : Fragment(), GreetingView { } @Inject lateinit var actions: GreetingActions override var isUpdating: Boolean by Delegates.observable(false) { _, _, isLoading -> { loadingView.isGone = !isLoading content.isGone = isLoading } override fun onUpdate(response: Greeting) = updateUi(response) override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) DaggerContentFragmentComponent.builder() .contentsPresenterModule(GreetingPresenterModule(this)) .build() .inject(this) actions.onRequestData() }
64. Concurrency • The story is still evolving around concurrency • Simple in concept, difficult in practice • KN concurrency is not compatible with existing JVM based coroutines • Bridging the two worlds is challenging and can result in runtime errors • Ktor client has open defect where cannot be created on non-main thread (fixed in 1.3.0, Github #1183) • Coroutine Worker (Ben Asher), Reaktive (Badoo)
65. Meet Worker • Workers are primitive built on top of threads • 2 basic rules: • All mutable state is owned by one thread • All shared state is immutable (frozen) • Immutable data can be shared across threads safety • Only available in Native module
66. Freeze /** * Freezes object subgraph reachable from this object. Frozen objects can be freely * shared between threads/workers. * * @throws FreezingException if freezing is not possible * @return the object itself * @see ensureNeverFrozen */ public fun <T> T.freeze(): T
67. val worker = Worker.start() val future = worker.execute( 2019-08-24 17:55:02.014 test.kexe[16051:146036] isFrozen: true 2019-08-24 17:55:02.014 test.kexe[16051:146029] isFrozen: true , value: HELLO DROIDCON} TransferMode.SAFE, { "Hello Droidcon".freeze() }, // producer lambda { // bg thread NSLog("isFrozen: ${it.isFrozen}") it.toUpperCase() } ) future.consume { // main thread NSLog("isFrozen: ${it.isFrozen} , value: $it}") } worker.requestTermination(true)
68. val input = "Fail Whale" val worker = Worker.start() val future = worker.execute( TransferMode.SAFE, { "Hello Droidcon”.freeze() }, // producer { } ) kotlin/worker/WorkerTest.kt: (43, 29): kotlin.native.concurrent.Worker.execute must take an unbound, non- capturing function or lambda // bg thread. this will fail it + input
69. val hello1 = Greeting("Hello Droidcon").freeze() val future = worker.execute( TransferMode.SAFE, { ref }, { val hello2 = Greeting("Hello NYC").freeze() it.value = hello2 } ) future.consume { assertEquals("Hello NYC", ref.value.name) } val ref = AtomicReference(hello1) assertTrue(ref.isFrozen) assertEquals("Hello Droidcon", ref.value.name)
70. val ptr = DetachedObjectGraph { Greeting("Hello Droidcon") }.asCPointer() val future = worker.execute(TransferMode.SAFE, { ptr.freeze() }, { // assign ownership to bg thread and mutate val greeting = DetachedObjectGraph<Greeting>(it).attach() greeting.name = "${greeting.name} + Mutate" }) future.consume { // attach to main thread val greeting = DetachedObjectGraph<Greeting>(ptr).attach() assertEquals("Hello Droidcon + Mutate", greeting.name) }
71. Kotlin Native is not all rainbows and unicorns
72. MPP is (still) hard • Developing an app for multiple platforms will always be harder than a single platform. There is more surface area • Requires knowledge of Android, iOS and MPP tech • MPP solves some problems and introduces new problems • The community is still figuring out architecture and best practices • Just because things are hard doesn’t mean we shouldn’t do it
73. KN is the future, Is the future now? • Early adopter phase, its usable but it still has some rough edges • 1st party libs (ktor, serialization), compiler still in beta • Documentation is lacking • The IDE support is still a work in progress • Debugging native code is challenging • No multi threaded coroutines
74. KN vs Flutter • Kotlin Native is a compiler technology. It provides a library for business logic and backend logic • Kotlin Native compliments the Native SDKs • Flutter is an alternative framework and language (Dart) • Flutter provides an alternative to the Native SDKs • Flutter maximizes code sharing, KN maximizes native platform interop
75. Kotlin Native Less limits and will enable you to get more places
76. Flutter Can’t go as many places but *might get you there faster
77. My Limited Experience w/ Flutter • Shared UI, 3rd language (Dart) • Integration with brownfield apps is not great (crashes, memory leaks, integration boilerplate, lifecycle issues) • Flutter excels for simple greenfield apps with common UI, small teams • Uncanny valley. Its very hard to provide a seamless experience in a brownfield app
78. Road to Adoption • Start small, avoid making big decisions • Prototype and experiment • Discuss with both iOS and Android teams • Be aware of the limitations • Plan your use cases, architecture and team, pick a feature-layer
79. “Thanks for listening! I hope you learnt something. Feel free to contact me with any questions.” twitter @jeremyrempel http://jeremyrempel.com
