Unifying Analytics Across Data Sources with Red Hat JBoss Data Virtualization

How can a business intelligence team evaluate and unify data that exists in many different types of data sources? For Red Hat IT, the answer is our own JBoss Data Virtualization product, which enables unifying access to these various sources behind a SQL interface, easily integrated with existing reporting software.

In this session you will learn:
* The problems data virtualization solves for Red Hat Business Intelligence, such as relating data between databases, web services, spreadsheets and flat files.
* How Red Hat IT enabled analytics across numerous data sources using JBoss Data Virtualization:
** Cloud friendly architecture
** Automated installation and configuration using Puppet on AWS
** Caching and materialized views
** Supporting multiple clients with different data needs

Transcript

1. #redhat #rhsummit
   UNIFYING ANALYTICS
   UNIFYING ANALYTICS
   ACROSS DATA SOURCES WITH
   ACROSS DATA SOURCES WITH
   RED HAT
   RED HAT JBOSS DATA
   JBOSS DATA
   VIRTUALIZATION
   VIRTUALIZATION
   Naveen Malik - Principal Software Engineer
   Burak Serdar - Principal Software Engineer
   Ian Firman - Business Intelligence Architect
   June 29, 2016
   1
   1


   View Slide

2. GET THIS DECK NOW...
   GET THIS DECK NOW...
   #redhat #rhsummit
   2
   2


   View Slide

3. RED HAT
   RED HAT IT JOURNEY
   IT JOURNEY
   #redhat #rhsummit
   Opportunity Research Test
   Plan Execute Maintain
   3
   3


   View Slide

4. OUR JOURNEY TODAY
   OUR JOURNEY TODAY
   #redhat #rhsummit
   Opportunity Research Test
   Plan Execute Maintain
   4
   4
   Ian Firman
   Burak Serdar
   Naveen Malik


   View Slide

5. WHAT IS JBOSS DATA
   WHAT IS JBOSS DATA
   VIRTUALIZATION?
   VIRTUALIZATION?
   #redhat #rhsummit
   JBoss Data Virtualization is a
   data abstraction solution that
   sits in front of multiple data
   sources, allows them to be
   treated as a single source and
   accessed by various data
   consumers and/or applications
   Heterogeneous Sources
   Heterogeneous Clients
   5
   5


   View Slide

6. OPPORTUNITY
   OPPORTUNITY
   BUSINESS CASE
   BUSINESS CASE
   #redhat #rhsummit
   Opportunity
   6
   6


   View Slide

7. Data is coming in fast
   #redhat #rhsummit
   OPPORTUNITY
   OPPORTUNITY
   7
   7


   View Slide

8. Data is coming in fast
   Diverse data consumers
   #redhat #rhsummit
   OPPORTUNITY
   OPPORTUNITY
   8
   8


   View Slide

9. Diverse data sources
   Data is coming in fast
   Diverse data consumers
   #redhat #rhsummit
   OPPORTUNITY
   OPPORTUNITY
   9
   9


   View Slide

10. OPPORTUNITY
    OPPORTUNITY
    Diverse data sources
    Data is coming in fast
    Diverse data consumers
    #redhat #rhsummit
    Combining real time and historical data
    10
    10


    View Slide

11. RED HAT
    RED HAT USE CASES
    USE CASES
    TRANSACTIONAL
    TRANSACTIONAL
    #redhat #rhsummit
    LOW COMPLEXITY (ONE END POINT)
    LOW COMPLEXITY (ONE END POINT)
    Report from Bugzilla
    Simplify queries
    Filter sensitive data
    Extract to Warehouse
    11
    11


    View Slide

12. RED HAT
    RED HAT USE CASES
    USE CASES
    OPERATIONAL
    OPERATIONAL
    #redhat #rhsummit
    MEDIUM COMPLEXITY (MANY END POINTS)
    MEDIUM COMPLEXITY (MANY END POINTS)
    "Where's my message?"
    Choice of reporting tools
    12
    12


    View Slide

13. RED HAT
    RED HAT USE CASES
    USE CASES
    ANALYTICAL
    ANALYTICAL
    #redhat #rhsummit
    HIGH COMPLEXITY (MANY END POINTS, DYNAMIC)
    HIGH COMPLEXITY (MANY END POINTS, DYNAMIC)
    Data Science - Discovery, Mining, Advanced Analytics
    Real-time and Historical
    13
    13


    View Slide

14. "All problems in computer science can be
    solved by another level of abstraction"
    paraphrased from David Wheeler
    #redhat #rhsummit
    14
    14


    View Slide

15. LOGICAL ARCHITECTURE
    LOGICAL ARCHITECTURE
    #redhat #rhsummit
    Data Sources
    Data Warehouse(s) Files
    Data Consumers
    BI Reports & Analytics Mobile ESB & ETL
    15
    15


    View Slide

16. LOGICAL ARCHITECTURE
    LOGICAL ARCHITECTURE
    #redhat #rhsummit
    Data Sources
    Data Warehouse(s) Files
    16
    16
    Data Consumers
    BI Reports & Analytics Mobile ESB & ETL


    View Slide

17. LOGICAL ARCHITECTURE
    LOGICAL ARCHITECTURE
    #redhat #rhsummit
    JBOSS Data Virtualization
    Integrated and abstracted sources
    Data Sources
    17
    17
    Data Warehouse(s) Files
    Data Consumers
    BI Reports & Analytics Mobile ESB & ETL
    Multiple protocol access


    View Slide

18. LOGICAL ARCHITECTURE
    LOGICAL ARCHITECTURE
    #redhat #rhsummit
    Business Logic
    and data formatting
    Central Security
    JBOSS Data Virtualization
    Integrated and abstracted sources
    18
    18
    Data Sources
    Data Warehouse(s) Files
    Data Consumers
    BI Reports & Analytics Mobile ESB & ETL
    Multiple protocol access


    View Slide

19. LOGICAL ARCHITECTURE
    LOGICAL ARCHITECTURE
    #redhat #rhsummit
    Business Logic
    and data formatting
    Central Security
    JBOSS Data Virtualization
    Integrated and abstracted sources
    19
    19
    Data Sources
    Data Warehouse(s) Files
    Data Consumers
    BI Reports & Analytics Mobile ESB & ETL
    Multiple protocol access


    View Slide

20. VIRTUAL DATABASES
    VIRTUAL DATABASES
    DEFINITION
    DEFINITION
    #redhat #rhsummit
    A virtual database (or VDB) is a container for
    components used to integrate data from multiple
    data sources, so that they can be accessed in
    an integrated manner through a single, uniform
    API.
    20
    20


    View Slide

21. VDB STRATEGY
    VDB STRATEGY
    SOURCES
    SOURCES
    #redhat #rhsummit
    21
    21


    View Slide

22. VDB STRATEGY
    VDB STRATEGY
    BASE VDB
    BASE VDB
    Abstracts the physical source
    #redhat #rhsummit
    22
    22


    View Slide

23. VDB STRATEGY
    VDB STRATEGY
    VIRTUAL DATA MART
    VIRTUAL DATA MART
    #redhat #rhsummit
    Combine Base VDBs for
    analysis/reporting
    Business logic/formatting applied
    Data security applied at this layer
    Abstracts the physical source
    23
    23


    View Slide

24. #redhat #rhsummit
    DEVELOP
    DEVELOP
    VDB LIFECYCLE
    VDB LIFECYCLE
    Virtual
    Database
    24
    24


    View Slide

25. #redhat #rhsummit
    DEPLOY
    DEPLOY
    VDB LIFECYCLE
    VDB LIFECYCLE
    Virtual
    Database
    25
    25


    View Slide

26. #redhat #rhsummit
    USE!
    USE!
    VDB LIFECYCLE
    VDB LIFECYCLE
    Virtual
    Database
    26
    26


    View Slide

27. PLAN
    PLAN
    ARCHITECTURE
    ARCHITECTURE
    #redhat #rhsummit
    Opportunity Plan
    27
    27


    View Slide

28. THINGS TO CONSIDER
    THINGS TO CONSIDER
    DESIGN OPPORTUNITIES
    DESIGN OPPORTUNITIES
    #redhat #rhsummit
    28
    28


    View Slide

29. THINGS TO CONSIDER
    THINGS TO CONSIDER
    FLEXIBILITY
    FLEXIBILITY
    #redhat #rhsummit
    WHERE TO DEPLOY?
    WHERE TO DEPLOY?
    Cloud and on premise
    Real-time data vs. materialized views
    Locality to clients
    29
    29


    View Slide

30. OPEN HYBRID CLOUD
    OPEN HYBRID CLOUD
    Heterogeneous Sources
    Heterogeneous Clients
    #redhat #rhsummit
    30
    30


    View Slide

31. THINGS TO CONSIDER
    THINGS TO CONSIDER
    SCALABILITY
    SCALABILITY
    #redhat #rhsummit
    HOW EASY TO SCALE
    HOW EASY TO SCALE
    Initial starting point
    Easily scale by adding and removing nodes
    Clients isolated from infrastructure changes
    31
    31


    View Slide

32. SIZING
    SIZING
    JDV SIZING TOOL
    JDV SIZING TOOL
    INPUT: REQUIREMENTS
    INPUT: REQUIREMENTS
    OUTPUT: RECOMMENDATION
    OUTPUT: RECOMMENDATION
    How much data?
    How is data being accessed?
    CPU
    Storage
    Memory
    JVM Architecture
    #redhat #rhsummit
    32
    32


    View Slide

33. THINGS TO CONSIDER
    THINGS TO CONSIDER
    SECURITY
    SECURITY
    #redhat #rhsummit
    IN TRANSIT, AT REST, AUTH?
    IN TRANSIT, AT REST, AUTH?
    Transport Layer Security (TLS)
    Disk encryption
    Authentication
    Authorization
    33
    33


    View Slide

34. JBOSS EAP ROLE MANAGEMENT
    JBOSS EAP ROLE MANAGEMENT
    SAML
    LDAP
    Basic Auth
    Custom
    more..
    SECURITY
    SECURITY
    ROLE BASED ACCESS CONTROL
    ROLE BASED ACCESS CONTROL
    #redhat #rhsummit
    34
    34


    View Slide

35. Object
    #redhat #rhsummit
    SECURITY
    SECURITY
    DEFINED AT...
    DEFINED AT...
    35
    35


    View Slide

36. Object
    Row
    SECURITY
    SECURITY
    DEFINED AT...
    DEFINED AT...
    #redhat #rhsummit
    36
    36


    View Slide

37. Object
    Row
    Field
    #redhat #rhsummit
    SECURITY
    SECURITY
    DEFINED AT...
    DEFINED AT...
    37
    37


    View Slide

38. PHYSICAL ARCHITECTURE
    PHYSICAL ARCHITECTURE
    Amazon Web Services and AWS are trademarks of Amazon.com, Inc. or
    its affiliates in the United States and/or other countries.
    #redhat #rhsummit
    38
    38


    View Slide

39. EXECUTE
    EXECUTE
    IMPLEMENTATION
    IMPLEMENTATION
    Opportunity Plan Execute
    #redhat #rhsummit
    39
    39


    View Slide

40. #redhat #rhsummit
    Virtual
    Database
    MAKING IT HAPPEN!
    MAKING IT HAPPEN!
    TOOLS
    TOOLS
    40
    40


    View Slide

41. #redhat #rhsummit
    Virtual
    Database
    MAKING IT HAPPEN!
    MAKING IT HAPPEN!
    TOOLS
    TOOLS
    jcliff
    41
    41


    View Slide

42. PUPPET & JCLIFF
    PUPPET & JCLIFF
    #redhat #rhsummit
    jcliff
    . . .
    Configuration
    Snippets
    42
    42


    View Slide

43. PUPPET & JCLIFF
    PUPPET & JCLIFF
    #redhat #rhsummit
    jcliff
    . . .
    Differences
    Configuration
    Snippets
    43
    43


    View Slide

44. PUPPET & JCLIFF
    PUPPET & JCLIFF
    #redhat #rhsummit
    Differences
    jcliff
    . . .
    Configuration
    Snippets
    44
    44


    View Slide

45. DATA SOURCES
    DATA SOURCES
    REDSHIFT RESOURCE
    REDSHIFT RESOURCE
    #redhat #rhsummit
    jcliff::datasource { 'redshift_ds': }
    jndi_name => 'java:/redshift',
    url => hiera('jdvbi::redshift::url'),
    driver_name => 'RedshiftJDBC4-1.1.1.0001.jar',
    username => hiera('jdvbi::redshift::username'),
    45
    45


    View Slide

46. DATA SOURCES
    DATA SOURCES
    REDSHIFT RESOURCE
    REDSHIFT RESOURCE
    #redhat #rhsummit
    { "datasource" => {
    "redshift_ds" => {
    "jndi-name" => "java:/redshift",
    "driver-name" => "RedshiftJDBC4-1.1.1.0001.jar",
    "enabled" => "true",
    " " " "
    jcliff::datasource { 'redshift_ds': }
    jndi_name => 'java:/redshift',
    url => hiera('jdvbi::redshift::url'),
    driver_name => 'RedshiftJDBC4-1.1.1.0001.jar',
    username => hiera('jdvbi::redshift::username'),
    46
    46


    View Slide

47. #redhat #rhsummit
    jcliff::teiid_salesforce_ra { 'sfcom':
    jndi_name =>'java:/sf_ds',
    url => hiera('jdvbi::salesforce::url'),
    username => hiera('jdvbi:salesforce:username'),
    SALESFORCE
    SALESFORCE
    DEFINE RESOURCE ADAPTER
    DEFINE RESOURCE ADAPTER
    47
    47


    View Slide

48. #redhat #rhsummit
    { "resource-adapter" => {
    "sf_ra" => {
    "module" => "org.jboss.teiid.resource-adapter.salesforce:main",
    "transaction-support" => "NoTransaction",
    "connection-definitions" => { "sf_ra" => {
    "enabled" => true,
    "jndi-name" => "java:/sf_ds",
    "config-properties" => {
    jcliff::teiid_salesforce_ra { 'sfcom':
    jndi_name =>'java:/sf_ds',
    url => hiera('jdvbi::salesforce::url'),
    username => hiera('jdvbi:salesforce:username'),
    SALESFORCE
    SALESFORCE
    DEFINE RESOURCE ADAPTER
    DEFINE RESOURCE ADAPTER
    48
    48


    View Slide

49. CONNECTIONS
    CONNECTIONS
    SECURE DATABASE
    SECURE DATABASE
    # Add a teiid JDBC transport with TLS
    jcliff::configfile { 'ssl-jdbc.conf':
    content > template('jbossdvbi/ssl jdbc conf erb')
    #redhat #rhsummit
    49
    49


    View Slide

50. CONNECTIONS
    CONNECTIONS
    SECURE DATABASE
    SECURE DATABASE
    {"teiid" => {
    "transport" => {
    "jdbc" => {
    "keystore-key-alias" => "<%=@keystore_alias%>",
    "keystore-key-password" => "<%=@keystore_password%>",
    "keystore-password" => "<%=@keystore_password%>",
    "keystore-type" => "JKS",
    "socket-binding" => "teiid-jdbc",
    "ssl-authentication-mode" => "1-way",
    # Add a teiid JDBC transport with TLS
    jcliff::configfile { 'ssl-jdbc.conf':
    content > template('jbossdvbi/ssl jdbc conf erb')
    #redhat #rhsummit
    50
    50


    View Slide

51. CONNECTIONS
    CONNECTIONS
    SECURE CLIENTS
    SECURE CLIENTS
    # Add a socket binding for TLS JDBC
    jcliff::socket_binding { 'teiid-jdbc':
    #redhat #rhsummit
    51
    51


    View Slide

52. CONNECTIONS
    CONNECTIONS
    SECURE CLIENTS
    SECURE CLIENTS
    { "standard-sockets" => {
    "socket-binding" => {
    " " "t iid jdb "
    # Add a socket binding for TLS JDBC
    jcliff::socket_binding { 'teiid-jdbc':
    #redhat #rhsummit
    52
    52


    View Slide

53. VIRTUAL DATABASES
    VIRTUAL DATABASES
    DEPLOY VDB
    DEPLOY VDB
    #redhat #rhsummit
    # Retrieve VDB from staging area
    exec { 'get-vdb':
    command => "wget ..."
    }
    # deploy VDB
    53
    53


    View Slide

54. VIRTUAL DATABASES
    VIRTUAL DATABASES
    DEPLOY VDB
    DEPLOY VDB
    #redhat #rhsummit
    { "deployments" => {
    "my.vdb" => {
    # Retrieve VDB from staging area
    exec { 'get-vdb':
    command => "wget ..."
    }
    # deploy VDB
    54
    54


    View Slide

55. CONCLUSION
    CONCLUSION
    #redhat #rhsummit
    55
    55


    View Slide

56. VALUE
    VALUE
    IS IT WORKING OUT?
    IS IT WORKING OUT?
    #redhat #rhsummit
    CURRENT DEPLOYMENTS
    CURRENT DEPLOYMENTS
    MORE IN THE FUTURE!
    MORE IN THE FUTURE!
    Marketing VDB
    Data Scientists VDB
    56
    56


    View Slide

57. USEFUL NEW FEATURES
    USEFUL NEW FEATURES
    NEW THINGS FROM THE PRODUCT!
    NEW THINGS FROM THE PRODUCT!
    #redhat #rhsummit
    NEW AND EXCITING
    NEW AND EXCITING
    Dynamic VDB
    Unified RBAC
    Redshift Translator
    57
    57


    View Slide

58. CONCLUSION
    CONCLUSION
    PARTING THOUGHTS
    PARTING THOUGHTS
    Opportunity Plan Execute
    #redhat #rhsummit
    58
    58


    View Slide

59. CONCLUSION
    CONCLUSION
    PARTING THOUGHTS
    PARTING THOUGHTS
    Fast integration.
    Heterogeneous sources.
    Decoupling.
    #redhat #rhsummit
    Plan Execute
    59
    59


    View Slide

60. CONCLUSION
    CONCLUSION
    PARTING THOUGHTS
    PARTING THOUGHTS
    Centralize business logic.
    Centralize security.
    Flexible architecture.
    Fast integration.
    Heterogeneous sources.
    Decoupling.
    #redhat #rhsummit
    Execute
    60
    60


    View Slide

61. Repeatable.
    Automated.
    Supported.
    CONCLUSION
    CONCLUSION
    PARTING THOUGHTS
    PARTING THOUGHTS
    Centralize business logic.
    Centralize security.
    Flexible architecture.
    Fast integration.
    Heterogeneous sources.
    Decoupling.
    #redhat #rhsummit
    61
    61


    View Slide

62. #redhat #rhsummit
    QUESTIONS?
    QUESTIONS?
    62
    62


    View Slide

63. LEARN. NETWORK.
    LEARN. NETWORK.
    EXPERIENCE OPEN SOURCE.
    EXPERIENCE OPEN SOURCE.
    #redhat #rhsummit
    63
    63


    View Slide

64. APPENDIX
    APPENDIX
    ADDITIONAL MATERIAL
    ADDITIONAL MATERIAL
    #redhat #rhsummit
    64
    64


    View Slide

65. RESOURCES
    RESOURCES
    PRODUCTS
    PRODUCTS
    #redhat #rhsummit
    Red Hat JBoss Data Virtualization
    https://www.redhat.com/en/technologies/jboss-middleware/data-virtualization
    Red Rat CloudForms
    https://www.redhat.com/en/technologies/cloud-computing/cloudforms
    Ansible
    https://www.ansible.com/
    65
    65


    View Slide

66. RESOURCES
    RESOURCES
    TOOLS
    TOOLS
    #redhat #rhsummit
    JBoss Data Virtualization Sizing Architecture Tool
    https://access.redhat.com/labs/jbossdvsat/
    jcliff
    https://github.com/bserdar/jcliff
    puppet-jcliff
    https://github.com/bserdar/puppet-jcliff
    66
    66


    View Slide
