1. TRANSPORT Joffrey Lauthier ALSTOM Transport Driverless Metro Systems: Operational Benefits and Design Considerations
2. Urban Mass Transit Forum - Shanghai 2009 - 12/06/09 - P 2 Grade of Automation and Alstom's experience in China Driverless metro: benefits and trends Driverless metro: design considerations URBALIS™ CBTC signalling solution Driverless Metro Systems
3. Urban Mass Transit Forum - Shanghai 2009 - 12/06/09 - P 3 Grade of Automation and Alstom's experience in China Driverless metro: benefits and trends Driverless metro: design considerations URBALIS™ CBTC signalling solution Driverless Metro Systems
4. Urban Mass Transit Forum - Shanghai 2009 - 12/06/09 - P 4 Metro Operations – Grade of Automation IEC Standard 62290-1 Train Operation Setting train in motion Driving and stopping train Door closure Operation in event of disruption Driver ATP: Automatic Train Protection ATO: Automatic Train Operation DTO: Driverless Train Operation UTO: Unattended Train Operation Driver Driver Driver Driver Driver Automatic Automatic Automatic Automatic Automatic Automatic Automatic Attendant Attendant Automatic Driver Automatic ATP with Driver ATP and ATO with Driver Driverless (DTO) Unattended (UTO) GoA 1 GoA 2 GoA 3 GoA 4 Grade of Automation
5. Urban Mass Transit Forum - Shanghai 2009 - 12/06/09 - P 5 Alstom’s Signalling Projects in China Train Operation ATP: Automatic Train Protection ATO: Automatic Train Operation DTO: Driverless Train Operation UTO: Unattended Train Operation ATP with Driver ATP and ATO with Driver Driverless (DTO) Unattended (UTO) GoA 1 GoA 2 GoA 3 GoA 4 Grade of Automation + Hong Kong East Rail + Shanghai Line 1 + Hong Kong Tsuen Wan Line Hong Kong Island Line Hong Kong Kwun Tong Line + Hong Kong Tung Chung Line Hong Kong Airport Express Hong Kong East Rail Beijing Airport Link + + Singapore North-East Line Singapore Circle Line Shanghai Line 10 1995 2000 2005 2010 Shanghai Line 3 Shanghai Line 4 Beijing Line 2 + GoA 4 Technology Shenzhen Line 2 Shenzhen Line 5 Guangzhou Line 6
6. Urban Mass Transit Forum - Shanghai 2009 - 12/06/09 - P 6 URBALIS™ Signalling Platform for China Train Operation ATP: Automatic Train Protection ATO: Automatic Train Operation DTO: Driverless Train Operation UTO: Unattended Train Operation ATP with Driver ATP and ATO with Driver Driverless (DTO) Unattended (UTO) GoA 1 GoA 2 GoA 3 GoA 4 Grade of Automation Shanghai Line 3 Shanghai Line 4 Beijing Airport Link Singapore North-East Line Shanghai Line 10 Beijing Line 2 URBALIS™ Signalling for China CBTC Communication-Based Train Control
7. Urban Mass Transit Forum - Shanghai 2009 - 12/06/09 - P 7 Presence in Chinese signalling for over 20 years Joint venture between CRSC and ALSTOM Established in 1986 Dedicated to signalling systems and control centres www.casco.com.cn
8. Urban Mass Transit Forum - Shanghai 2009 - 12/06/09 - P 8 Grade of Automation and Alstom's experience in China Driverless metro: benefits and trends Driverless metro: design considerations URBALIS™ CBTC signalling solution Driverless Metro Systems
9. Urban Mass Transit Forum - Shanghai 2009 - 12/06/09 - P 9 Driverless metro: Benefits Passengers • Higher speed, shorter journey time • Shorter waiting time • Improved safety and security • Better comfort in demand surge • More customer-oriented staff • Better “network effect” Operators and funding authorities • Flexible operation management • Reliability, shorter down time • Operating safety • Job profile change • Capital expenditure • Operation expenditure
10. Urban Mass Transit Forum - Shanghai 2009 - 12/06/09 - P 10 Driverless: High Quality of Service SBS Transit experience with the Singapore North-East Line NEL Performance: Leong Yim Sing from SBS Transit at AsiaRail2007, Singapore, November 2007
11. Urban Mass Transit Forum - Shanghai 2009 - 12/06/09 - P 11 0 10 20 30 40 Singapore Circle Line Alstom Trains + Urbalis CBTC Shanghai Line 10 Alstom Trains + Urbalis CBTC Beijing Airport Express Urbalis CBTC Singapore North-East Line Alstom Trains + Urbalis CBTC Paris Line 1 Alstom Trains Paris Line 14 Alstom Trains line length in km Trend in Asia: long driverless lines
12. Urban Mass Transit Forum - Shanghai 2009 - 12/06/09 - P 12 Line Head- Train way Length Paris Line 4 100s 90m Paris Line 7 100s 75m Sao Paulo Line 3 101s 135m + trains + CBTC in 2011 for 85s Santiago Line 1 103s 125m + trains + CBTC to be tendered Paris Line 14 105s 90m + more trains in 2010 for 85s Paris Line 1 110s 90m + trains + CBTC for 2011 Busy metros moving to driverless CBTC to improve capacity Alstom signalling systems are present in 14 of the world 20 busiest metro
13. Urban Mass Transit Forum - Shanghai 2009 - 12/06/09 - P 13 Grade of Automation and Alstom's experience in China Driverless metro: benefits and trends Driverless metro: design considerations URBALIS™ CBTC signalling solution Driverless Metro Systems
14. Urban Mass Transit Forum - Shanghai 2009 - 12/06/09 - P 14 Driverless Metro – Design Considerations Driverless metro differ from conventional metro • Operational Modes • Degraded modes management This leads to design constraints on • Rolling Stock • Communication systems • Signalling Driverless metros require purpose-built E&M systems
15. Urban Mass Transit Forum - Shanghai 2009 - 12/06/09 - P 15 Driverless Metro – Design Considerations Critical safety principles: • Prevent prolonged stop in tunnel • Maintain passenger’s confidence • Redundant data communication paths Driverless metros have their own safety principles
16. Urban Mass Transit Forum - Shanghai 2009 - 12/06/09 - P 16 Driverless Metro – Design Considerations Redundant components required: • On-board data processing systems • Public address system • Traction/braking equipment and command-control circuits • Train batteries • Air conditioning • Lighting system • Train-to-wayside communications Availability is a key success factor
17. Urban Mass Transit Forum - Shanghai 2009 - 12/06/09 - P 17 Driverless Metro – Design Considerations • Real-time communication of train status to Operation Control Centre and Maintenance Support System • Trains with failed equipment can be withdrawn from operations before the redundant component fails Train status monitoring is key to ensure system availability
18. Urban Mass Transit Forum - Shanghai 2009 - 12/06/09 - P 18 • Passenger Information Systems: broadcast text messages • Public Address: broadcast voice message • Passenger Emergency Communication: for passengers to communicate with the Operation Control Centre • CCTV: for OCC to monitor the situation onboard and on platform Driverless Metro – Design Considerations Train-to-wayside communication is critical to maintaining passenger safety
19. Urban Mass Transit Forum - Shanghai 2009 - 12/06/09 - P 19 Rare events are to immobilise a trains in tunnel: • Prolonged loss of primary power supply • Catastrophic damage to rolling stock, rail, or signalling Driverless Metro – Design Considerations Evacuation Detrainment door is the safety device of last resort
20. Urban Mass Transit Forum - Shanghai 2009 - 12/06/09 - P 20 Driverless Metro – Design Considerations More E&M components required: • Platform Screen Doors • Platform and trainborne CCTV • Remote wake-up and standby of trains • Redundant communication paths More complex components More interfaces Proper interface management critical to success
21. Urban Mass Transit Forum - Shanghai 2009 - 12/06/09 - P 21 Grade of Automation and Alstom's experience in China Driverless metro: benefits and trends Driverless metro: design considerations URBALIS™ CBTC signalling solution Driverless Metro Systems
22. Urban Mass Transit Forum - Shanghai 2009 - 12/06/09 - P 22 Scope of the URBALIS™ CBTC Platform
23. Urban Mass Transit Forum - Shanghai 2009 - 12/06/09 - P 23 URBALIS™ CBTC Solution
24. Urban Mass Transit Forum - Shanghai 2009 - 12/06/09 - P 24 Including Integrated Control & Security Centres SCADA ATS Security Passenger Information
25. Urban Mass Transit Forum - Shanghai 2009 - 12/06/09 - P 25 GoA2 CBTC Alstom’s Ongoing Urban Transit Projects GoA3 CBTC GoA1 GoA1 GoA1 GoA1 Tram GoA1 Tram GoA1 Tram San Francisco 2010 Buenos Aires 2009 Boston MDTA Oran 2010 Algiers 2010 Constantine 2010 GoA4 CBTC GoA2 GoA2 Tram GoA3 CBTC GoA2 CBTC GoA2 CBTC GoA2 GoA2 Tram GoA4 CBTC GoA2 CBTC GoA4 CBTC Sao Paulo 2009 Beijing Airport 2008 GoA2 CBTC GoA2 CBTC GoA2 CBTC Lausanne 2008 Singapore CCL 2009 Shanghai L10 2010 Delhi 2010 Malaga Marmaray 2011 Milano 2009 Cairo 2010 Dubai 2011 Beijing L2 2008 Toronto 2011 Mexico 2011 Guangzhou L6 2011 Shenzhen L2, L5 2011
26. TRANSPORT Thank You! Joffrey Lauthier Business Development Director | Signalling & Telecom | Asia-Pacific joffrey.lauthier@transport.alstom.com
